legate SMART CONTACT Assembly instructions

SMART CONTACT SENSOR
Legate Smart Appliances
Manual Guide

Let’s Get Started.
Install the app
Download the Legate Smart Home app
from Google Play or the App Store on a
compatible phone or tablet.
1
Register and login
Register on the app by using your contact
number or Email address.
2
Connect to wifi
Make sure that your mobile phone and
smart device are connected to 2.4 GHz
wifi network.
3
*note: The distance between the phone and smart device should not be greater
than 4meters while pairing both devices. If the signal is week you’ll need a wifi
booster. (Recommended Wifi Booster Version: TP LINK TL-WA855RE)

Legate Smart Contact Sensor
to Legate Smart Home App

Getting the Smart Device Ready
1
Press the Disassemble Button
to release the sensor’s cover.
2
Remove the White Battery Strip,
then a red light will blink rapidly.
Legate Smart Contact Sensor - Connecting the Smart Device to Legate Smart Home app

Add Smart Device
3
Open Legate Smart Home app,
Click “+” or Add Device.
4
Under “Security & Sensor” tab
Click “Contact Sensor”.
Legate Smart Contact Sensor - Connecting the Smart Device to Legate Smart Home app

Network Configuration
5
Click “Confirm indicator rapidly
blink”button.
6
Enter your Wifi Password. Then
click “Confirm” button.
(note: Only 2.4 GHz Wifi network are supported)
Legate Smart Contact Sensor - Connecting the Smart Device to Legate Smart Home app

Network Configuration
7
Wait for the Smart Device
connects to the app.
8
Click “Done” button when the Smart
Device is successfully added.
(note: You can change the device’s name)
Legate Smart Contact Sensor - Connecting the Smart Device to Legate Smart Home app

Legate Smart Contact Sensor
Features

Main Function
Working status, Open/Close the door or window. It takes 3-5 seconds to receive the
notification pushing when it is triggered.
1.
Legate Smart Contact Sensor - Features
Door/Window is Open Door/Window is Closed Push Notification

Main Function
Alarm recording (click “History”).
2.
Turn on and tur off the alarm (click “Notice”. No alarm pushing will be receiving
after alarm closed, only alarm record can received).
3.
Legate Smart Contact Sensor - Features
Alarm recording Turn on/off the alarm

Push Notification
Enable to turn off the notification.
Legate Smart Contact Sensor - Features
1
Click “Me” button on Legate
Smart Home app. Then click
“Settings”.
2
Click “Push Notification”
tab.
3
Can turn on or turn off the
“Enable notification”

Remove Device from Legate Smart Home app
Legate Smart Contact Sensor - Features
The device will restore to default settings.
1
Click “ ” button on upper
right corner of Smart Contact
Sensor’s main page.
2
Click “Remove Device”
tab.
3
Click “Confirm” button to
completely remove the device
from the Legate Smart Home app.

Legate Smart Contact Sensor
Configuration & Specifications

Product Configuration
Legate Smart Contact Sensor - Configurations & Specifications
Press and hold the Reset Button for 6 seconds until the LED Light blinks rapidly. Then
the device will be automatically be removed to the Legate Smart Home app.
Reset:
LED Light
Double Sided
Sticker
Smart Contact Sensor
deputy body
Disassemble button
Reset Button
LED Light
Battery
3M Electronics
3M Electronics
3M Electronics
3M Electronics
Screw
Wall Plug
Smart Contact Sensor
main body

Specifications
Legate Smart Contact Sensor - Configurations & Specifications
Battery
Standby current
Working current
Standby time
Working time
Wireless type
Wireless standard
Wireless range
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Size
CR2-3V x 1
13uA
115mA-120mA
5 years
1 year (15 times/day)
2 years (7 times/day)
2.4 GHz
IEEE 802.11b/g/n
45M
0°C ~ 40°C (32°F ~ 104°F)
20% ~ 85%
0°C ~ 60°C (32°F ~ 104°F)
0% ~ 90%
Main Body: 71mm x 21mm x 22mm
Small Body: 40mm x 11mm x 11mm
:
:
:
:
:
:
:
:
:
:
:
:
:
