Gira X1 User manual

Gira X1
2096 00
Operating instructions
for the
Gira Smart Home App

CONTENTS
1 User interface ............................................................................... p. 3
1.1 Structure of the user interface ..................................................... p. 3
1.2 Status bar ..................................................................................... p. 4
1.3 Navigation bar .............................................................................. p. 4
1.4 Action area ................................................................................... p. 4
1.4.1 Tile view ....................................................................................... p. 5
1.4.2 Detail view .................................................................................... p. 6
1.5 Operating the Alarm Connect security system ............................ p. 15
1.5.1 Alarm-specific buttons and displays ............................................ p. 15
1.5.2 Activating security area externally ............................................... p. 16
1.5.3 Activating security area internally ................................................ p. 17
1.5.4 Deactivating the security area ...................................................... p. 18
1.5.5 Viewing and acknowledging alarms and messages .................... p. 19
1.6 Remote access ............................................................................. p. 20
1.6.1 Remote access in detail view ....................................................... p. 20
1.6.2 Remote access in tile view ........................................................... p. 21
2 Settings in the system menu ........................................................ p. 22
2.1 System ......................................................................................... p. 23
2.1.1 Connection to Gira device ............................................................ p. 24
2.1.2 Start demo mode ......................................................................... p. 25
2.1.3 Configuring remote access .......................................................... p. 25
2.1.4 Connecting to Gira X1 via OpenVPN ............................................ p. 26
2.1.5 Changing password ..................................................................... p. 27
2.2 PIN protection .............................................................................. p. 28
2.3 View configuration ....................................................................... p. 29
2.3.1 Selecting Home ............................................................................ p. 30
2.3.2 Favourites ..................................................................................... p. 30
2.3.3 Favourites in front ........................................................................ p. 33
2.3.4 Display trades ............................................................................... p. 33
2.4 Occupancy simulation .................................................................. p. 34
2.4.1 Recording simulation ................................................................... p. 34
2.4.2 Play simulation ............................................................................. p. 34
2.5 Manage rooms ............................................................................. p. 35
2.6 Manage functions ........................................................................ p. 35
2.6.1 Create new function ..................................................................... p. 36
2.6.2 Manage function .......................................................................... p. 36
2.7 Sort rooms/functions .................................................................... p. 37
2.8 Manage subsections .................................................................... p. 37
2.9 Manage users ............................................................................... p. 38
2.9.1 Select functions that you wish to authorise ................................. p. 39
2.9.2 Apply functions ............................................................................ p. 40
2.10 Sonos audio function ................................................................... p. 41
2.10.1 Set up Sonos audio ...................................................................... p. 42
2.10.2 Change Sonos loudspeaker ......................................................... p. 43
2.10.3 Configuring favourites .................................................................. p. 44
2.10.4 How favourites behave after the memory function has been
used .............................................................................................. p. 45
2.10.5 What errors might occur? ............................................................ p. 45

Gira smart home app 3
1
User interface
1.1
Structure of the user interface
Note
Differences in the views
The figures in the tile or detail views may differ from the views in your project,
as the texts, functions and symbols can all be individually configured as desired.
Accordingly, this document makes reference only to the basic functions.
The user interface is divided into four areas:
[1] Status bar [see 1.2]
[2] Navigation bar [see 1.3]
[3] Action area [see 1.4]
[4] Orientation guide
At the lower edge of the screen you will see a circle for every available func-
tion or page. The circle marked shows the current position. By swiping hori-
zontally, you can change the function or page. This also causes the marked
circle to shift.
Fig. 1
User interface
[1]
[2]
[3]
[4]

Gira smart home app 4
1.2
Status bar
The symbols in the status bar have the following meanings:
[1] The warning symbol in the status bar shows that the Gira X1 can no longer
be reached.
If you tap the warning symbol, the relevant error message is displayed.
[2] Date and time display (obtained from Gira X1).
1.3
Navigation bar
The buttons in the navigation bar have the following functions:
[1] [Back] opens the previously opened page.
[2] [Home] opens the home page of the action area.
[3] [System] opens the [Settings] view.
[4] [Change view] switches between tile and detail view.
1.4
Action area
The action area is the central working area through which you can operate and
adjust the settings of the Gira X1. You can use all of the applications, the func-
tion folder and the KNX functions here.
The action area has two view options:
- Tile view
- Detail view
The first page of the action area is the [Home] page.
Fig. 2
Status bar
[1] [2]
Fig. 3
Navigation bar
[1] [2] [3] [4]

Gira smart home app 5
User interface
1.4.1
Tile view
Tile view is one of the two view options of the action area, along with detail view.
The two function folders [Building] and [Subsystems] are always shown. If you
tap the [Building] tile, you can navigate to the desired function through the struc-
ture of your building.
If you tap the [Subsystems] tile, all functions will be displayed by subsystem, e.g.
[Light], [Temperature], [Shading] etc.
Functions marked as favourites will be displayed directly in tile view.
In tile view you can display up to six small tiles per page.
Operation in tile viewCentral functions such as switching on and off, adjusting the temperature or
dimming in fixed steps can be operated directly in tile view. To do this, tap Plus/
Minus or the arrow buttons to dim the light, adjust the temperature or move
blinds/shutters.
When you tap a tile, the detail view of the function opens. There (depending on
the configuration) you can carry out additional operations in the function.
Fig. 4
Examples of tile view

Gira smart home app 6
User interface
1.4.2
Detail view
Detail view is one of the two view options of the action area, along with tile view.
Detail view is opened by tapping on a tile in tile view. All operating features of
the relevant function are then available on the entire display. Operation for most
functions is by tapping, with some functions, such as the blind control, distin-
guishing between a short and long press of the button. The following sections
deal with some special features of operation.
Horizontal swipingYou can switch from one function to the next with a horizontal swiping move-
ment of the finger.
Adjustable scaleThe adjustable scale can be used in the [Dimmer] and [Heating] functions. In or-
der to adjust the brightness or setpoint temperature, tap directly on the desired
value in the scale or move the adjustable scale to the desired position.
Fig. 5
Examples of detail
view

Gira smart home app 7
User interface
Blind/shutters
Operation using slide
control
Blinds or shutters can be controlled using the slide control in the detail view. To
move blinds or shutters up or down or adjust the slats, slide the controller to the
desired position.
Stop buttonWhen you tap the [STOP] button, you can directly stop active movement of the
hanging or a slat adjustment. The hanging then stops immediately at its current
position.
Fig. 6
Detail view
Operation using slide
control

Gira smart home app 8
User interface
1.4.2.1
Function timer
The timer is easy to operate and can be used to control many functions. It allows
certain functions to be triggered at a specified time every day or only on certain
days. For example, the blinds are automatically raised every morning and low-
ered again in the evening, or the heating automatically switches to night mode.
A timer can be set up in the following functions:
- Switch (rocker function) with 10 switching times,
- Dimmer with 10 switching times,
- Blind Step/Move with 10 switching times
- Blind positioning with 10 switching times,
- Shutter positioning with 10 switching times,
- Scene auxiliary unit with 10 switching times,
- Room temperature controller auxiliary unit with 28 switching times.
1.4.2.2
Creating a switching time
•
1 Tap the [Timer] button in the detail view of the relevant function.
The [Timer overview] page opens.
2 Tap the [+] button.
The [Timer] page opens.
3 You can use your finger tip to activate or deactivate days when the switching
time should be effected. Days when the switching time should be effected
are highlighted in green.
4 Select one of the three possible switching times when the action should be
performed:
Fig. 7
Timer overview

Gira smart home app 9
User interface
- Time
Configure a time when the action should be performed.
Fig. 8
Set time

Gira smart home app 10
User interface
- Sunrise
Activates the switching time at the point in time when sunrise is calculated
to take place.
You also have the option of activating a time limit under “Set earliest/latest”.
“Earliest” activates the switching time at sunrise but not before the time that
you entered.
“Latest” activates the switching time at sunrise or before the time that you
entered here at the latest.
“Change sunrise time” allows you to shift the switching time by up to 120
minutes before or after the point in time for the calculated sunrise.
Fig. 9
Activate sunrise

Gira smart home app 11
User interface
- Sunset
Activates the switching time at the point in time when sunset is calculated to
take place.
You also have the option of activating a time limit under “Set earliest/latest”.
“Earliest” activates the switching time at sunset but not before the time that
you entered.
“Latest” activates the switching time at sunset or before the time that you en-
tered here at the latest.
“Change sunset time” allows you to shift the switching time by up to 120
minutes before or after the point in time for the calculated sunrise.
Fig. 10
Activate sunset

Gira smart home app 12
User interface
5 You can increase or decrease the switching times by up to 15 minutes using
a random component. To do so, move the slider switch [Activate random +/-
15 min.] to the right.
6 Under "Select action", choose the function to be carried out. The type of val-
ue that can be selected here depends on the function to be set up.
7 Tap the [OK] button.
The timer is set.
1.4.2.3
Deleting a switching time
1 Open the [Timer overview] page.
2 Tap the [Edit] button.
3 Mark the switching time to be deleted.
You can also mark and delete several switching times here.
A red tick appears in front of the switching time. The red [Delete] button is
shown.
4 Tap the [Delete] button.
The [Timer overview] page opens. The marked switching time is deleted.
Fig. 11
Activate random
function

Gira smart home app 13
User interface
1.4.2.4
Activating and deactivating all switching times for a function
1 Set the switch [all active] to [I] to activate or to [O] to deactivate.
2 Tap the [OK] button.
The function from which you switched to the [Timer overview] page opens.
All switching times for this function are activated or deactivated.
Tip
Temporarily deactivating switching times
If you want to temporarily deactivate individual switching times for a function,
you can simply deactivate all days (set to grey).
Fig. 12
Activating/deactivat-
ing all switching
times

Gira smart home app 14
User interface
1.4.2.5
Heating mode
In the detail view for the [Heating] function, you can use the [Mode] button to
switch between various operating modes ("Comfort", "Night" etc.) to which dif-
ferent setpoint temperatures are assigned in the controller.
1 To switch operating mode, tap [Mode].
The operating mode page opens.
2 Select the desired mode and confirm with [OK].
The various modes have the following meanings:
- Comfort
Comfort mode is activated if people are in a room and the room temperature
is to be set to a comfortable value.
- Standby
Activate standby if a room is not used during the day. This adjusts the room
temperature to a standby value, enabling heating or cooling energy to be
saved.
- Night
Activate night mode during night hours or during a long absence. This adjusts
the room temperature to cooler temperatures in heating systems (e.g. in bed-
rooms). In this case, cooling systems can be set to higher temperature values
when air conditioning is not necessary (e.g. in offices).
- Frost/heat protection
Frost protection is required when, for example, the room temperature is not
to fall below critical values when a window is open. Heat protection may be
necessary when the temperature becomes too high due to external influenc-
es. In these cases, freezing or overheating of the room can be prevented by
specifying an individual temperature setpoint by activation of the frost/heat
protection, depending on the "Heating" or "Cooling" operating mode.
Fig. 13
Switching operating
mode

Gira smart home app 15
User interface
1.5
Operating the Alarm Connect security system
1.5.1
Alarm-specific buttons and displays
[1] [Information] opens the list of active messages.
[2] [Important] shows that messages are active.
[3] [Status] shows that the security area is not ready for activation.
[1] Internal activation not possible
[2] External activation not possible
Fig. 14
Alarm-specific but-
tons
[1] [2] [3]
Fig. 15
Alarm-specific dis-
plays
Internal active External active
[1] [2]

Gira smart home app 16
User interface
1.5.2
Activating security area externally
Proceed as follows to activate a security area externally:
1 Press the operating unit tile for the security area that you wish to activate.
The security area view opens and displays the switching condition.
2 Tap on the [Activate externally] button.
3 Enter your user PIN in the window which opens up.
The exit delay time starts and is displayed in the app.
The radio operating unit also signals the remaining exit delay time.
4 Now leave the security area and close the door if necessary.
Once the exit delay time has expired, the security area is activated externally
provided that no incidents which prevent activation have occurred in the
meantime.
Fig. 16
External active state
Operating unit
Apartment Kleve
Building functions
External active
Disarm
Gira Smart Home

Gira smart home app 17
User interface
1.5.3
Activating security area internally
Proceed as follows to activate a security area internally:
1 Press the operating unit tile for the security area that you wish to activate in-
ternally.
The security area view opens and displays the switching condition.
2 Tap on the [Activate internally] button.
3 Enter your user PIN in the window which opens up.
The security area is activated internally.
Fig. 17
Internal active state
Operating unit
Apartment Kleve
Building functions
Internal active
Disarm
Gira Smart Home

Gira smart home app 18
User interface
1.5.4
Deactivating the security area
Proceed as follows to deactivate a security area internally:
1 Tap on the [Deactivate] button on the security area view.
2 Enter your user PIN in the window which opens up.
The security area is deactivated.
Fig. 18
Deactivated state
Operating unit
Apartment Kleve
Building functions
Internal active External active
Deactivatet
Gira Smart Home

Gira smart home app 19
User interface
1.5.5
Viewing and acknowledging alarms and messages
Proceed as follows to acknowledge active alarms and security area messages:
1 Tap on the [Information] button on the security area view.
A list will open containing active alarms and messages.
2 Tap on the [Confirm] button.
3 Enter your user PIN in the window which opens up.
The message will be deleted if the correct PIN is entered.
Fig. 19
Alarms and
messages
Operating unit
Apartment Kleve
Building functions
Messages
confirm cancel
PIN confirmation required for the following
event: Sabotage alarm to alarm control unit
Gira Smart Home
This manual suits for next models
1
Table of contents
Other Gira Home Automation manuals
