NEXT STEPS WITH

LEGO® MINDSTORMS® EDUCATION EV3

Next Steps with LEGO®MINDSTORMS®Education EV3

Develop your skills and integrate LEGO MINDSTORMS EV3 into your teaching.

Congratulations! You have completed the ﬁrst step in exploring this new teaching tool and now you are ready to take the next steps.

This document outlines what you should do next, and provides six lessons for you to try with your students. Below, you can see an overview of what you will ﬁnd in

the next pages.

1 Explore Curriculum Coverage

page ................................. 3

2 Use Tutorials to Build

Conﬁdence

page ................................. 7

3 Create a Learning Sequence

Using Tutorials

page ................................. 8

4 Provide Frequent Feedback

page ................................. 9

5 Provide Frequent Feedback

During a Lesson

page ................................ 10

6 Integrate Formal Assesment

page ................................ 12

7 Integrate Formal Assesment

during a lesson

page ................................ 14

8 Use STEM Lessons in Your

Classroom

page ................................ 16

9 Explore More Projects

page ................................ 21

10 Create a Playing Surface

page ................................ 21

11 Customize Your Lessons

page ................................22

12 Get More Support

page ................................23

1. Explore Curriculum Coverage

Using LEGO®MINDSTORMS®Education EV3 in your classroom opens up the possibility for a variety of successful learning outcomes.

Skills such as teamwork, creativity, and problem-solving are an inherent part of the experience, and students’ natural mastery of

digital technologies will help them to rapidly learn the language of programming.

Below is a selected overview of standards that are addressed or partially-addressed when using LEGO MINDSTORMS Education EV3.

This list will grow steadily as you expand the use of EV3 in your classroom.

NGSS CSTA

Practices

• Asking questions

• Developing and using models

• Planning and carrying out investigations

• Analyzing and interpreting data

• Using mathematics and computational thinking

• Constructing explanations and designing solutions

• Engaging in argument from evidence

• Obtaining, evaluating, and communicating information

Computational Thinking

• Recognize that software is created to control computer operations

• Understand and use the basic steps in algorithmic problem-solving

• Develop a simple understanding of an algorithm

Computing Practices and Programming

• Use technology resources for problem-solving and self-directed learning

• Construct a program as a set of step-by-step instructions to be acted out

• Implement solutions to problems using a block-based visual programming

language

Computers and Computing Devices

• Use standard input and output devices to successfully operate computers

and related technologies

• Apply strategies for identifying simple hardware and software problems

that may occur during use

• Identify factors that distinguish humans from machines

• Recognize that computers model intelligent behavior (as found in

robotics, speech and language recognition, and computer animation)

Explore Curriculum Coverage

ISTE

Creativity and Innovation

• Demonstrate creative thinking, construct knowledge, and develop innovative

products and processes using technology

• Apply existing knowledge to generate new ideas, products, or processes

• Use models and simulations to explore complex systems and issues

Communication and Collaboration

• Use digital media and environments to communicate and work

collaboratively, including at a distance, to support individual learning and

contribute to the learning of others

• Contribute to project teams to produce original works or solve problems

Critical Thinking, Problem-Solving, and Decision Making

• Use critical thinking skills to plan and conduct research, manage projects,

solve problems, and make informed decisions using appropriate digital tools

and resources

• Plan and manage activities to develop a solution or complete a project

• Collect and analyze data to identify solutions and/or make informed

decisions

• Use multiple processes and diverse perspectives to explore alternative

solutions

Digital Citizenship

• Exhibit a positive attitude toward using technology that supports

collaboration, learning, and productivity

• Demonstrate personal responsibility for lifelong learning

Technology Operations and Concepts

• Demonstrate a sound understanding of technology concepts, systems, and

operations

• Understand and use technology systems

• Select and use applications eﬀectively and productively

• Troubleshoot systems and applications

• Transfer current knowledge to the learning of new technologies

Explore Curriculum Coverage

ITEEA Standards for Technological

Literacy Common Core Mathematics

Standards

The Nature of Technology

• Develop an understanding of the characteristics and scope of technology

• Develop an understanding of the core concepts of technology

Design

• Develop an understanding of the attributes of design

• Develop an understanding of engineering design

• Develop an understanding of the role of troubleshooting, research and

development, invention and innovation, and experimentation in problem-

solving

Abilities for a Technological World

• Develop the ability to apply the design process

• Develop the ability to use and maintain technological products and

systems

Practices

• Make sense of problems and persevere in solving them

• Reason abstractly and quantitatively

• Construct viable arguments and critique the reasoning of others

• Attend to precision

• Look for and make use of structure

• Look for and express regularity in repeated reasoning

• Model using mathematics

• Use appropriate tools strategically

Expressions and Equations

• Solve real-life and mathematical problems using numerical and algebraic

expressions and equations

Geometry

• Solve real-life and mathematical problems involving angle measure, area,

surface area, and volume

Explore Curriculum Coverage

LEGO, the LEGO logo and MINDSTORMS are trademarks of the/sont des marques de commerce de/son marcas registradas

Introduction

Next Generation

Science Standards

= addresses standard

ENERGY

Energy Transfer

Wind Energy

Solar Energy

Energy Eﬃciency

Electric Vehicles

FORCE AND MOTION

Gears

Inclined Plane

Friction

Velocity

Acceleration of Gravity

LIGHT

Light Intensity

HEAT AND TEMPERATURE

Freezing and Thermal Insulation

Heat Transfer

Convection

Practices

1Asking questions

2Developing and using models

3Planning and carrying out investigations

4Analyzing and interpreting data

5Using mathematics, Informational and Computer Technology, and computational

thinking

6Constructing explanations and designing solutions

7Engaging in argument from evidence

8Obtaining, evaluating, and communicating information

Cross-cutting Concepts

1Patterns

2Cause and eﬀect: Mechanism and explanation

3Scale, proportion, and quantity

4Systems and system models

5Energy and matter: Flows, cycles, and conservation

6Structure and function

7Stability and change

Core Ideas: Physical Science

PS1 Structure and Properties of Matter

PS2 Motion and stability: Forces and interactions

PS3 Energy

PS.4 Waves and their applications in technologies for information transfer

Curriculum Grid

For learning grids mapping each of our Curriculum Packs to current

curriculum standards, download the pack(s) or visit:

www.legoeducation.com

Common Core English

Language Arts

Reading Standards for Literacy in Science and Technical Subjects

• Precisely follow a multistep procedure when carrying out experiments,

taking measurements, or performing technical tasks

• Determine the meaning of symbols, key terms, and other domain-speciﬁc

words and phrases as they are used in a speciﬁc scientiﬁc or technical

context relevant to texts and topics in grades 6–8

Reading Standards for Informational Text

• Draw on information from multiple print or digital sources, demonstrating

the ability to locate an answer to a question quickly or to solve a problem

eﬃciently

Speaking and Listening Standards

• Engage eﬀectively in a range of collaborative discussions (one-on-one, in

groups, and teacher-led) with diverse partners on topics, texts, and issues,

building on others’ ideas and clearly expressing their own ideas

2. Use Tutorials to Build Conﬁdence

The tutorials provided in the software will help to build your conﬁdence and your

students’ conﬁdence. Take some time to browse through them and identify the

ones you might be interested in using.

Here is an overview of the tutorials that are available.

Basics (Driving Base)

Learn how to control the Driving Base and trigger events based on input from the

various sensors.

For EV3 Lab Only

Basics (Hardware)

Familiarize yourself with the Intelligent EV3 Brick and its assorted sensors and

motors.

Beyond Basics (Driving Base)

Grasp the fundamentals of more complex topics, such as program loops,

switches, multiple switches, arrays, and data wires.

Data Logging

Master various Data Logging concepts, such as live and Remote Data Logging,

Graph Programming, and Dataset Calculation.

Tools

Learn how to use the various tools that are available to your students, such as the

Sound Editor and the Display Image Editor.

3. Create a Learning Sequence Using

Tutorials

A good way to learn about about the functionailty of the EV3 Brick is to explore

the Robot Educator tutorials and to combine two or three of them to create a

learning sequence.

When designing your own learning sequences, remember to allow time for:

• Building the robot, if it is not already built

• Programming the robot

• Tinkering

Example of a Learning Sequence Using Tutorials

Explore the functionality of the Color Sensor by making diﬀerent things happen

based on the color detected by the sensor:

• Color Sensor Color > Multiple Switch

Examples of other Learning Sequences for EV3 Lab Only

Explore the functionality of the Color Sensor, and practice logging ambient light

values:

• Color Sensor Light > Remote Data Logging

Explore math-related concepts:

• Stop at Object > Range

• Variables > Arrays

Straight Move

Tank Move

Stop at Object

The learning sequence used in the

LEGO®MINDSTORMS Education

EV3 “getting started” experience.

4. Provide Frequent Feedback

Encourage your students to tell their learning story. Give the opportunity to

share their thinking, ideas, and reﬂections. This will boost their conﬁdence and

engagement.

Student Documentation

Have your students document their work. By doing that, students will reﬂect on

and consolidate what they have just learned. They will also have to consider how

to use appropriate language to communicate their thoughts and ideas.

Using the Content Editor as a Documentation Tool

The Content Editor allows students to document their progress and ﬁndings as

they work through each tutorial.

They can use the Content Editor to:

• Write full descriptions of their working processes

• Insert their own pages

• Add images and videos of their robot in action

• Share their unique project with other students

You can also allow students to select the tool(s) they ﬁnd most

appropriate for capturing and sharing their ideas. Encourage them

to document their thoughts using text, videos, images, sketchnotes,

or another creative medium.

5. Provide Frequent Feedback During

a Lesson

Move an Object

(45 minutes)

Objective

After completing this lesson, students will be able to:

• Program their robots to move and release objects of diﬀerent shapes and sizes

• Optimize the performance of a design by prioritizing criteria, making trade-oﬀs,

testing, revising, and retesting

Setup

Deﬁne a starting position and and arrange various objects for the students to

collect using their robots. Use objects of various shapes and sizes like those

shown below.

Feedback

During the lesson, interact with each student to identify any diﬃculties they

are having in completing the task. Help them to improve by providing frequent

feedback.

A. Connect

Clean up your school by collecting objects of

diﬀerent shapes and sizes. Find ways to collect as

many objects as possible.

Provide Frequent Feedback During a Lesson

C. Contemplate

• Have students collect the Cuboid and return it to the robot’s initial position.

• Then have them collect a diﬀerent object, and observe how they adapt to the

change of task.

Discussion Questions

Robot Behavior

How did you overcome the challenge of moving diﬀerent objects?

Modiﬁed the medium motor module frame to ﬁt the bigger objects.

D. Continue

Use the project ideas provided in this document or refer to some of our

Curriculum Packs for additional ideas.

B. Construct

Build

1. Driving Base

2. Robot Arm

3. Cuboid

Program

Try to grab the Cuboid using the Robot Arm.

Move Object

If you need help, watch the “Move

Object” tutorial.

6. Integrate Formal Assesment

Teacher-Led Assessment

Developing students’ science, engineering, and computational

thinking skills requires time and feedback. Just as in the

design cycle, in which students should understand that failure

is part of the process, assessment should provide feedback

in terms of what the students did well and where they can

improve. Problem-oriented learning is not about success

or failure. It is about being an active learner and continually

building upon and testing ideas.

Giving feedback to students in order to help them develop

their skills can be done in various ways. We have provided

examples of rubrics that can be completed based on:

• Observation of students’ behavior, reactions, and strategies

• Asking the students questions about their thought processes

As students often work in groups, you can give feedback both

on a team level and on an individual level.

Observation Rubrics

Examples of rubrics have been provided on the next pages.

The intention of these rubrics is to help students reﬂect on

what they have done well in relation to the learning goals, and

what they could have done better. Students should mark an X

to indicate their level of achievement (Bronze, Silver, Gold, or

Platinum). You can also use the rubrics for your own evaluation

of the students’ work.

Integrate Formal Assesment

Sample Rubric - Assessing Design Skills

Bronze Silver Gold Platinum Notes

Deﬁning the problem:

Describe the problem in

your own words.

The student is unable to

describe the problem in

their own words.

With prompting, the student

is able to describe

the problem in their own

words.

The student is able to

describe the problem in

their own words.

The student is able to

describe the problem

in their own words and

can begin to decompose

the problem into smaller

parts.

Designing solutions:

Undertake a design project,

engaging in the design

cycle to construct and/

or implement a solution

that meets speciﬁc design

criteria and constraints.

Optimize performance of

a design by prioritizing

criteria, making trade-

oﬀs, testing, revising, and

retesting.

The student has diﬃculties

completing a design

project and engaging in the

design cycle to construct

and implement a solution.

The student has completed

a design project, engaging

in the design cycle to

construct and implement a

solution that met speciﬁc

design criteria and

constraints.

The student has completed

a design project, engaging

in the design cycle to

construct and implement

a solution that met

speciﬁc design criteria

and constraints. They have

optimized the performance

of a design using some

of the following methods:

prioritizing criteria, making

trade-oﬀs, testing, revising,

and retesting.

The student showed

creativity in using the

engineering design

process to implement a

solution that exceeded

speciﬁc design criteria and

constraints. They optimized

performance of their

design using the following

methods: prioritizing

criteria, making trade-

oﬀs, testing, revising, and

retesting.

7. Integrate Formal Assesment during a

lesson

Stop at Line

(45 minutes)

Objective

After completing this lesson, students will be able to use the Color Sensor to

stop the robot when a line is detected

Setup

Deﬁne a starting position, then place a sheet of white paper with a colored line

drawn on it a short distance away.

Assessment

During the lesson, encourage the students to interact with the rubrics. They

should record their progress by marking the box that best reﬂects their level of

achievement. Help your students to improve by providing frequent feedback.

A. Connect

Objects will need to be dragged to speciﬁc

locations identiﬁed by lines on the ﬂoor. Find ways

to use the Color Sensor to detect these lines.

Integrate Formal Assesment during a lesson

C. Contemplate

• Have students practice detecting lines of diﬀerent colors.

Discussion Questions

Robot Behavior

Which color or shade reﬂects the most light? The least?

White reﬂects the most and black reﬂects the least.

Discovery

What would you do if the robot were to detect a line of the color gray?

Use the Wait Block by setting it to read the Color Sensor in

ReﬂectedLightIntensity Mode.

D. Continue

Use the project ideas provided in this document or refer to some of our

Curriculum Packs for additional ideas.

B. Construct

Build

1. Driving Base

2. Color Sensor Down Module

Program

Try to have your robot stop at a black line.

Stop at Line

If you need help, look at the “Stop

at Line” tutorial.

8. Use STEM Lessons in Your Classroom

Develop STEM Skills with LEGO®MINDSTORMS®Education EV3

Using the Driving Base as the foundation, each of these four lessons oﬀers a diﬀerent STEM-related focus. Try one or try them all,

each will guide you as you explore one of our Curriculum Packs.

LESSON

Coding Focus

page .................... 17

LESSON PLAN

Science Focus

page .................... 18

LESSON

Engineering Focus

page .................... 19

LESSON

Math Focus

page ....................20

Following a Line

Autonomous cars will soon be driving

on our roads.

How do they follow their paths

without deviating from the road?

Measuring Speed

Biologists have long tried to calculate

the running speed of animals.

Use a robot to ﬁnd out how they do it!

Fixing a Car

You are stranded in the forest

because both front tires of your car

have gone ﬂat.

You have removed the wheels and

must now use anything other than

tires and rims to make your car move

forward again.

Moving in the XY Plane

To move an unmanned space vehicle

from point A to point B requires

precise calculations.

If the math is not right, you just might

end up in the next crater!

For more coding activities related to autonomous

cars, look online: www.legoeducation.com/lessons

Coding Focus: Following a Line

(45 minutes)

Curriculum Links

• Exploring the use of a loop

• Exploring ways of developing computational thinking skills, such as the ability to

develop algorithms

Connect

Autonomous cars will soon be driving on our roads. How do they follow their paths

without deviating from the road?

Construct

Build Program

In the software, start with the “Switch”

tutorial.

Contemplate

Have the students create a driverless vehicle that can follow a line.

Ask them explore diﬀerent types of lines, such as:

• Thick lines

• Thin lines

• Colored lines

• Right angles

• Broken/interrupted lines

Continue

Create a racetrack in your classroom and ﬁnd out whose car is the fastest.

Science Focus: Measuring Speed

(45 minutes)

Curriculum Links

• Exploring the concept of speed

• Exploring ways of developing science-related skills, such as the ability to collect

and analyze data

Connect

Biologists have long tried to calculate the running speed of animals. Use a robot

to ﬁnd out how they do it!

Construct

Build Program

In the software, start with the “Math

Data” tutorial.

Contemplate

Use your Driving Base to model an animal “running” and calculate the speed

at which it is moving. Change the speed of the motors to check that your

calculations are correct.

Continue

Create a racetrack in your classroom and ﬁnd out whose car is the fastest.

For more science-related activities, download our

science activity pack for EV3 Lab:

www.legoeducation.com/download

Engineering Focus: Fixing a Car

(45 minutes)

Curriculum Links

• Exploring the concept of mechanisms

• Exploring ways of developing engineering-related skills, such as the ability to

develop various functional prototypes

Connect

You are stranded in the forest because both front tires of your car have gone ﬂat.

You have removed the wheels and must now use anything other than tires and

rims to make your car move forward again.

Construct

Build Program

In the software, start with the “Straight

Move” tutorial.

Contemplate

Design a solution to make your Driving Base, now without its wheels, move as

quickly as possible over a distance of one meter.

Continue

Create a racetrack in your classroom and ﬁnd out whose Driving Base is the

fastest.

For more engineering-related projects, download

our Design Engineering Projects Curriculum pack

for EV3 Lab: www.legoeducation.com/download

Math Focus: Moving in the XY Plane

(45 minutes)

Curriculum Links

• Exploring the concept of position in the XY plane

• Exploring ways of developing math-related skills, such as the abiliy to make

predictions and calculate results

Connect

To move an unmanned space vehicle from point A to point B requires precise

calculations. If the math is not right, you just might end up in the next crater!

Construct

Build Program

In the software, start with the

“Variables” tutorial.

Contemplate

Have students calculate the number wheel rotations necessary to move the robot

forward 88 cm (35 inch) or a distance of your choice.

Continue

Challenge the students by giving them one try to move their robots a speciﬁed

distance. Whoever comes the closest wins!

For more space-themed activities, download our

Space Mission Curriculum pack for EV3 Lab:

www.legoeducation.com/download

Other manuals for MINDSTORMS Education EV3

Table of contents

Other LEGO Toy manuals

Popular Toy manuals by other brands

Eduard

Eduard Su-25K exterior Assembly instructions

Bladez Toyz

Bladez Toyz BTSW002 operating instructions

Dancing Wings Hobby

Dancing Wings Hobby Wright Flyer I instruction manual

Mattel

Mattel Matchbox HDL62 instructions

Hasbro

Hasbro Scrabble Crossword Game Specification sheet

marklin

marklin 24194 user manual

Mega Bloks

Mega Bloks HALO 97214 manual

Rail King

Rail King 2-8-0 Steam Freight/ Passenger Set Operation manual

Century Helicopter Products

Century Helicopter Products Swift NX instruction manual

OYO Sports

OYO Sports FOOTBALL HELMET CART manual

Tiger Electronics

Tiger Electronics Harry Potter E-Pals Hedwig 36292 instructions

goliath

goliath ICE CREAM meltdown instructions

Hangar 9

Hangar 9 HAN5190 Assembly manual

RLC

RLC Jato Sportsman Nitro Funny Car Kit instruction manual

Extreme Flight

Extreme Flight Legacy Aviation Muscle Bipe Assembly manual

LGB

LGB IVk 145 Operating instruction

Mattel

Mattel Kiko of WINX CLUB Bunny instructions

REVELL

REVELL KIT 1188 Assembly manual

LEGO MINDSTORMS Education EV3 User manual

Popular Toy manuals by other brands
