Leica Zeno 5 User manual

Leica Zeno 5
User Manual
Version 1.0
English

2
Zeno 5, Introduction
Introduction
Purchase Congratulations on the purchase of a Leica Zeno 5.
This manual contains important safety directions as well as instructions for setting
up the product and operating it. Refer to "7 Safety Directions" for further informa-
tion.
Read carefully through the User Manual before you switch on the product.
Product identifica-
tion
The type and serial number of your product are indicated on the type plate.
Enter the type and serial number in your manual and always refer to this information
when you need to contact your agency or Leica Geosystems authorised service work-
shop.
Type: _______________
Serial No.: _______________

Zeno 5, Introduction 3
Symbols The symbols used in this manual have the following meanings:
Type Description
DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation or an unintended
use which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in minor or moderate
injury.
NOTICE Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in appreciable material,
financial and environmental damage.
)Important paragraphs which must be adhered to in practice as
they enable the product to be used in a technically correct and
efficient manner.

4
Zeno 5, Introduction
Trademarks • Windows is a registered trademark of Microsoft Corporation in the United States
and other countries
• Bluetooth is a registered trademark of Bluetooth SIG, Inc.
• SD is a trademark of the SD Card Association
All other trademarks are the property of their respective owners.
Validity of this
manual
This manual applies to the Zeno 5 handheld.
Available
documentation Name Description/Format
Zeno 5 User
Manual
All instructions required in order to operate the product
to a basic level are contained in the User Manual.
Provides an overview of the product together with tech-
nical data and safety directions.
99
Name Description/Format
Zeno GIS
Quick Start
Tutorial
Describes the general working of the product in
standard use. Intended as a quick reference field guide.
9

Zeno 5, Introduction 5
* only available as Online Help
Refer to the following resources for all Zeno 5 documentation/software:
• the Leica Zeno GIS DVD
• https://myworld.leica-geosystems.com
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a
wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services whenever
it is convenient for you, 24 hours a day, 7 days per week. This increases your effi-
ciency and keeps you and your equipment instantly updated with the latest informa-
tion from Leica Geosystems.
Zeno Field
Help *
Overall comprehensive help to the product and applica-
tion functions. Included are detailed descriptions of
special software settings and software functions.
Name Description/Format

6
Zeno 5, Introduction
Service Description
myProducts Simply add all Leica Geosystems products that you and your
company own. View detailed information on your products, buy
additional options or Customer Care Packages (CCPs), update your
products with the latest software and keep up-to-date with the
latest documentation.
myService View the service history of your products in Leica Geosystems
Service Centers and detailed information on the services performed
on your products. For your products that are currently in Leica
Geosystems Service Centers view the current service status and the
expected end date of service.
mySupport Create new support requests for your products that will be
answered by your local Leica Geosystems Support Team. View the
complete history of your Support and view detailed information on
each request in case you want to refer to previous support
requests.
myTraining Enhance your product knowledge with the Leica Geosystems
Campus - Information, Knowledge, Training. Study the latest online
training material or download training material on your products.
Keep up-to-date with the latest News on your products and
register for Seminars or Courses in your country.

Zeno 5, Table of Contents 7
Table of Contents
In this manual Chapter Page
1 Description of the System 12
1.1 Overview 12
1.2 Terminology 13
1.3 System Concept 14
1.3.1 Software Concept 14
1.3.2 Power Concept 16
1.3.3 Data Storage Concept 18
1.4 Zeno 5 Components 19
1.5 Docking Station Components 21
1.6 USB SnapOn Modul Components 22
2 User Interface 23
2.1 Keyboard 23
2.2 Today Screen 28
2.3 Operating Principles 31
3Operation 34
3.1 Power Functions 34

8
Zeno 5, Table of Contents
3.2 Batteries 35
3.2.1 Operating Principles 35
3.2.2 Changing the Battery 38
3.2.3 Charging the Battery 40
3.3 Inserting and Removing a microSD/SIM Card step-by-step 48
3.4 LED Indicators on Zeno 5 52
3.5 LED Indicators on Docking Station 55
3.6 Connecting to a Personal Computer 58
3.7 Connecting to a Wireless Network 61
3.8 Phones 62
3.8.1 Description of the Phone 62
3.8.2 Calls 63
3.8.3 Settings 64
3.9 Adjusting Speaker Volume 68
3.10 Resetting Zeno 5 69
4 Using Windows Embedded Handheld 6.5 or higher 71
4.1 Pictures & Videos 71
4.2 Time, Date and Alarms 76
4.3 Text Messages 80
4.4 Contacts 81
4.5 Internet Explorer 82

Zeno 5, Table of Contents 9
4.6 Windows Media 83
4.7 Task Notification 83
4.8 File Explorer 85
4.9 Internet Sharing 86
4.10 Task Manager 86
4.11 Search Phone 87
4.12 Office Mobile 88
4.13 Settings 90
4.13.1 Lock 90
4.13.2 Home 92
4.13.3 Power 93
4.13.4 Sounds & Notifications 98
4.13.5 Connections 100
4.13.6 System Folder 106
5 Wireless Wide Area Network (WWAN) 122
6 Care and Transport 127
6.1 Transport 127
6.2 Storage 128
6.3 Cleaning and Drying 129

10
Zeno 5, Table of Contents
7 Safety Directions 131
7.1 General Introduction 131
7.2 Definition of Use 132
7.3 Limits of Use 134
7.4 Responsibilities 135
7.5 Hazards of Use 136
7.6 Laser Classification 141
7.6.1 General 141
7.6.2 Imager 142
7.7 Electromagnetic Compatibility EMC 143
7.8 FCC Statement, Applicable in U.S. 146
7.9 ICES-003 Statement, Applicable in Canada 150
8 Technical Data 151
8.1 Zeno 5 Technical Data 151
8.2 Radios Technical Data 155
8.2.1 Murata 802.11 a/b/g/n Direct Sequence Spread Spec-
trum Radio 155
8.2.2 Murata Bluetooth Radio 156
8.2.3 Sierra Wireless MC5728V 157

Zeno 5, Table of Contents 11
8.2.4 Cinterion PH8 GSM/GPRS/EDGE Radio 158
8.3 Conformity to National Regulations 162
9 International Limited Warranty, Software Licence Agreement 164
Index 166

12
Zeno 5, Description of the System
1 Description of the System
1.1 Overview
System compo-
nents
)Do not use adhesives to secure screws on carrying accessories as these chemicals
may damage the plastic casing.
Y UI O P
L
K
J
H
G
F
D
S
A
Z X C V B N M
.
Q W E R T
ESC
,
SYM
TAB
<
<
<
<
2 3
1
5
46
8 9
7
0
F1 F2
F7 F8
F9 F10
F3 F4
F5 F6
CTRL
#
ALT
àü
?
DEL
OK
:
=+
_
@
/
Zeno 5
003896_001

Zeno 5, Description of the System 13
1.2 Terminology
Zeno 5 general
description
The Zeno 5 is a small and durable handheld PDA device. The Zeno 5 can withstand
challenging weather and environmental conditions.
Zeno 5 available
models
Model Touch screen Colour display Internal UMTS 3.8 G Internal CDMA GPS Internal battery microSD card Bluetooth Interactive sensors Wireless WAN Wi-Fi Windows Embedded Handheld 6.5 or higher
Zeno 5 UMTS 999-99999999
Zeno 5 CDMA 99-999999999
)Use the supplied stylus on the screens of the touch screen.

14
Zeno 5, Description of the System
1.3 System Concept
1.3.1 Software Concept
Software for
Zeno 5 Software type Description
Microsoft Windows
Embedded Handheld
6.5 or higher
This software includes:
- The language-specific version of Windows
- The basic functionality of the Zeno 5
- Programming environment (HTML, XML, Mobile Devices
SDK, JavaTM, Visual Studio®2008, Standard protocol APIs -
Windows® sockets
- Application Software (Internet Explorer®, Mobile included
with Windows®Mobile®6, WordPad, ActiveSync, Mobile
Control Center (MCC) device management

Zeno 5, Description of the System 15
Software upload )Uploading firmware can take some time. Ensure that the battery is at least
75% full before beginning the upload, and do not remove the battery during
the upload process.
Software for Description
GG02 plus The software is stored in the flash RAM of the GG02 plus.
GG firmware update instructions
• Download the most recent GG firmware file from
https://myworld.leica-geosystems.com. Refer to "Intro-
duction".
• Copy GG firmware file onto a PC with Leica Zeno Field
installed.
• Connect the GG02 plus with the GEV234 cable to the PC.
Refer to "3.6 Connecting to a Personal Computer".
• Click on Start > All Programs > Leica Geosystems > Leica
Zeno Tools > Firmware Loader GG0X, to run the
Firmware loader application.
• Browse to the directory into which you copied GG
firmware file, select it and start the upload.

16
Zeno 5, Description of the System
1.3.2 Power Concept
General Use the Leica Geosystems batteries, chargers and accessories or accessories recom-
mended by Leica Geosystems to ensure the correct functionality of the instrument.
Power options Battery packs shipped from the factory are charged to approximately 40% and must
be fully charged prior to use. Batteries can be charged using a variety of chargers and
docking stations along with a Zeno 5 internal charger. When using the internal
charger, a suitable power source is required. All chargers and docking stations are
described in Chapter: “Peripheral Devices & Accessories”.
Model Power supply
Zeno 5 Internally by a high capacity 3600 mAh Lithium Ion battery pack,
OR
Externally by docking station RV4000, OR
Externally by RV4001 charger USB SnapOn module with DC, OR
Externally by RV3050 vehicle power outlet adaptor, OR
Externally by PS1050 - G1 AC wall adaptor to power both snap
module variants, OR
Externally by RV3055 AC vehicle power outlet adaptor to power
the docking station, quad docking station and quad charger.

Zeno 5, Description of the System 17
If an external power supply is connected and the internal battery
is inserted, then the external power is used.
Model Power supply

18
Zeno 5, Description of the System
1.3.3 Data Storage Concept
Description Data is stored on a data storage device. The data storage device can be a microSD
card or internal memory.
An USB stick can be used with the SnapOn module and the microUSB to USB adaptor.
Data storage
device
)Removing the microSD card or USB stick while the Zeno 5 is turned on can cause loss
of data. Only remove the microSD card or USB stick or unplug connecting cables when
the Zeno 5 CS field controller is switched off.
Transfer data Data can be transferred in various ways. Refer to "3.6 Connecting to a Personal
Computer".
microSD card: The Zeno 5 has an microSD card slot fitted as standard. A
microSD card can be inserted and removed.
USB stick: The Zeno 5 has a USB SnapOn module and adaptor cable
as standard.
Internal memory: The Zeno 5 has an internal memory fitted as standard.
Available capacity: 2 GB.

Zeno 5, Description of the System 19
1.4 Zeno 5 Components
Upside of Zeno 5 a) Light Emitting Diode (LED)
b) Receiver
c) Light sensor
d) Volume key
e) Scan key
f) Vertical scroll button
g) Screen
h) Keyboard
i) Microphone
j) Docking station contacts / USB-
On-The-Go
Y UI O P
L
K
J
H
G
F
D
S
A
Z X C V B N M
.
Q W E R T
ESC
,
SYM
TAB
<
<
<
<
2 3
1
5
46
8 9
7
0
F1 F2
F7 F8
F9 F10
F3 F4
F5 F6
CTRL
#
ALT
àü
?
DEL
OK
:
=+
_
@
/
003897_001
a
b
c
d
e
e
f
g
h
i
j

20
Zeno 5, Description of the System
Underside of
Zeno 5
a) Hand strap
b) Hand strap clip
c) Battery and SIM/microSD card
compartments
d) Camera
e) Flash
f) Scan key
g) Volume key
h) Stylus
i) Vertical scroll button
j) Battery latch
k) Speaker
l) EA11 Imager, optional
003898_001
a
b
b
c
d
e
f
f
g
h
ij
k
l
