LEICA 6376
QUICK START GUIDE
Download the full scope instruction manual here:
https://en.leica-camera.com/Service-Support/Support/Downloads
Please register via the following link if you would like to receive a printed
copy of the full scope instruction manual:
www.order-instructions.leica-camera.com

15
16
17
18
19
30
20
21
26
27
22
24
23
1
2
3
4a
4
5
5
12
8
7
14
13
11
10
3a
9
6
28

TOP VIEW
1Main switch
Switching the camera ON/OFF
2Shutter button
– Tap:
activates exposure metering and control
– Press down fully:
the picture is taken
– In standby mode:
The camera is reactivated
3Shutter speed setting wheel with stop
positions
–A: Automatic shutter speed control
–8s - 4000: Shutter speeds
(inc. intermediate values)
–B: Long-term exposure
(8s - 4min via menu control, in full
increments or Bulb)
–: Flash sync speed (1⁄180s)
aIndex
4ISO setting wheel
–A: Automatic ISO sensitivity control
–100 - 6400: Fixed ISO values
–M: Manual ISO sensitivity control
aIndex
1
2
2
5Strap lugs
66-bit encoding
sensor for lens detection
7Bayonet
8Lens release button
1
21
2
9Focus button
10 Rangefinder viewing window
11 Brightness sensor
12 Viewfinder viewing window
13 Self-timer LED
14 Image field selector
for the selection of bright-line frame pairs
35/135mm, 50/75mm and 28/90mm
15 LED for recording / data storage
16 MENU button
– for accessing the FAVORITES menu/
MAIN MENU
– for exiting the FAVORITES menu,
the MAIN MENU or any of the submenus
17 PLAY button
– for (continuous) playback mode
activation/deactivation
– for return to full-screen display
18 LV button
– for Live View mode activation/deactivation
19 Brightness sensor for LCD panel

20 Viewfinder eyepiece
21 LCD panel
22 Directional pad
– for menu navigation
– for menu item/function selection
– for scrolling through the picture memory
23 Center button
– to access the status display
– to apply menu settings
– to display settings/data during exposure
– for display of picture data during picture
review
24 Thumbwheel
– for menu navigation
– for menu item/function selection
– for exposure compensation value
selection
– for enlarging/reducing viewed pictures
– for scrolling through the picture memory
BOTTOM VIEW
25 Locking toggle for bottom cover
1
3
2
4
26 Tripod thread A ¼, DIN 4503 (¼”)
27 Memory card slot
28 Battery compartment
29 Battery locking latch
30 Bottom cover locking point
CHARGING THE BATTERY
A flashing green status LED indicates a correctly
functioning charging process. A fully charged
battery is indicated by a steady green light.

DISPLAYS IN THE VIEWFINDER
The bright-line frame rangefinder of this camera
is not just particularly bright viewfinder – it also
doubles as a lens-coupled rangefinder. All Leica
M lenses with focal lengths between 16 and
135mm are coupled automatically.
B A
C
35mm/135mm 28mm/90mm
ABright-line frame
BMetering field for focusing
CDigital display
50mm/75mm
FOCUSING
SUPERIMPOSED IMAGE METHOD
(DOUBLE IMAGE)
out of focus
in focus
SPLIT IMAGE METHOD
out of focus
in focus
DISPLAYS ON THE LCD PANEL
1
45
2
6
13
9 10 11 128
7
15 1614
3
1Battery capacity
2Exposure compensation scale
3Remaining memory card capacity
4ISO Sensitivity
5Light balance
6Shutter speed
7White Balance mode
8File format/compression level/resolution
9Exposure metering method
10 Shutter button/Drive Mode
11 WLAN status
12 GPS status
13 User profile
14 Exposure mode
15 Light intensity/focal length or lens type
16 Remaining number of pictures

REVIEW
SWITCHING BETWEEN PICTURE MODE/REVIEW
22:45PM 22.02.2012
999-9000
8234/999912MP
2.8F1/8000 12500ISO EV
INFO
SCROLL
MAGNIFY/REDUCE
DELETE/RATE
22:45PM 22.02.2012
999-9000
8234/999912MP
2.8F1/8000 12500ISO EV
INFO
All other operations are accessible by invoking the relevant
function from the menu list.
GESTURE CONTROL
Tap
briefly
Tap
twice
horizontal/vertical
swipe
Two-finger
pinch/spread
PICTURES
FOCUS AID IN LIVE VIEW
22:45PM 22.02.2012
999-9000
8234/999912MP
2.8F1/8000 12500ISO EV
INFO
SHIFT FOCUS POINT FOR FOCUS AID1AND
EXPOSURE METERING2
1Focus Aid is activated by turning the lens
2In combination with spot exposure metering

MENU OVERVIEW Factory settings
FAVORITES
Available for
FAVORITES
Lens Detection 6
Drive Mode 6 6
Exp. Metering 6
Exp. Compensation 6 6
Flash Settings 6 6
ISO Setup
6
6
M-ISO
also available
White Balance 6 6
File Format 6 6
JPG Settings
6
6
JPG Resolution
also available
Auto Review 6
Capture Assistants 6
EVF/Display Control 6
User Profiles 6
Load Profile
also available
Customize Control 6
Display Brightness 6
EVF Brightness 6
Auto Power Saving 6
WLAN 6
GPS16
Date & Time 6
Language 6
Reset Camera 6
Format SD card 6
Image Numbering 6
Sensor Cleaning 6
Camera Information 6
1This menu item is only available if the Leica Visoflex viewfinder is attached (available as an accessory).
JOINING A WLAN
▸ Select WLAN in the main menu
▸ Select Connection in the same submenu
▸ Select Join WLAN
▸ Select Configuration in the same submenu
▸ Select the desired WLAN from the network list or enter
a hidden network via the Add network option
▸ Press the center button to confirm the selected
network
DIRECT CONNECTION WITHOUT WLAN
▸ Select WLAN in the main menu
▸ Activate (ON) Function in the submenu
▸ Select Connection in the same submenu
▸ Select Create WLAN

TECHNICAL DATA
Camera name
Leica6376
Camera type
Digital camera with rangefinder system
Type No.
6376
Order No.
20 002 (black), 20 003 (silver)
Lens mount
Leica M bayonet
Compatible lenses
Leica M lenses, Leica R lenses via adapter
Sensor
CMOS chip, active surface approx. 24 x 36mm
Storage media
SD cards 1-2GB / SDHC cards up to 32GB /
SDXC cards up to 2TB
Viewfinder
Large, bright-line frame rangefinder and
automatic parallax compensation
LCD panel
3” TFT LCD, 1.04MP, touch control available
WLAN
The Leica FOTOS app is required to use of the
WLAN function. The Leica app is available from
the Apple App Store™ or the Google Play
Store™. Complies with WiFi standard
IEEE802.11b/g/n, 2.4 GHz, channel 1-11,
frequency range 2412-2462 MHz, max. output
power <9 dBm.Standard WLAN protocol,
encryption method: WLAN-compatible WPA™/
WPA2™
Power supply (Leica BP-SCL5)
1 lithium-ion rechargeable battery, rated voltage
7.4V; capacity 1100mAh, max. charging
voltage/current: 1000mA DC, 7.4V; operating
conditions (in the camera): +0 to +40°C;
manufacturer:
PT. VARTA Microbattery, Made in Indonesia
Charger (Leica BC-SCL5)
Inputs: 100-240VAC, 50/60Hz, 300mA with
automatic switch-over or 12VDC, 1.3A, output:
DC, rated voltage 7.4V, 1000mA / max.
8.25V, 1100mA, operating conditions: +10 to
+35°C, manufacturer: Guangdong PISEN
Electronics Co. Ltd., Made in China
Housing
Full metal housing: Magnesium die-cast,
synthetic leather covering
Top cover and bottom cover: Brass, black or
silver chrome-plated finish
Dimensions (WxHxD)
139x38.5x80mm
Weight
approx. 675g (with battery)
You will find the manufacturing date of your camera on the stickers in the
Warranty Card and/or on the packaging. The format is year/month/day.
Subject to changes in design and production.
93 874 VI/19/D

SAFETY REMARKS
GENERAL INFORMATION
• Do not use your camera in the immediate vicinity of devices with powerful magnetic, electrostatic or
electromagnetic fields (e.g. induction ovens, microwave ovens, television sets or computer monitors, video
game consoles, cell phones, broadcasting equipment). Their electromagnetic fields can interfere with
recordings.
• Image recording may be affected if you place the camera on a television set or operate the camera in its
vicinity or near a cell phone.
• Strong magnetic fields, e.g. from speakers or large electric motors, can damage the stored picture data or
disrupt recording.
• Switch off the camera, remove the battery and switch the camera back on if the camera malfunctions due
to the effects of electromagnetic fields.
• Do not use the camera in the immediate vicinity of radio transmitters or high-voltage power lines. Their
electromagnetic fields can also interfere with recordings.
• Always store small parts e.g. the accessory shoe cover as follows:
– out of the reach of children
– in a safe location, where they will not get lost or stolen
• State-of-the-art electronic components are sensitive to static discharge. You can easily pick up charges of
several 10,000 volts by simply walking on synthetic floor coverings. A static discharge can occur when you
touch the camera, and especially if it is placed on a conductive surface. A static discharge on the camera
housing poses no risk for the electronics. Despite built-in safety circuits, you should avoid direct contact
with external camera contacts like those in the flash shoe.
• Take care not to soil or scratch the sensor for lens detection (6-bit encoding) in the bayonet. You must
similarly prevent direct contact of the bayonet with grains of sand or similar particles, as these could cause
irreparable damage. This camera component must only be cleaned with a dry cloth.
• Use a cotton or linen cloth instead of an optical micro-fiber cloth (synthetic). Before touching the contacts,
you can make sure you discharge any electrostatic charge by deliberately touching a heating or water pipe
(conductive, grounded material). Dirt deposits and oxidation on the contacts can be avoided by storing your
camera in a dry location with the lens cap and flash shoe cap attached.
• Use only accessories specified for this model to prevent faults, short circuits or electric shock.
• Do not attempt to remove parts of the housing (covers) yourself. Repairs must be done at authorized
service centers only.
• Protect the camera against contact with insect sprays and other aggressive chemicals. Petroleum spirit,
thinner and alcohol must not be used for cleaning. Some chemicals and liquids can damage the camera
housing or the surface finish.
• Rubber and plastics are known to expel aggressive chemicals and should therefore not be kept in contact
with the camera for extended periods of time.
• Prevent any sand or dust or water penetration into the camera, e.g. during snowfall or rain or on the beach.
Be extra careful when changing the lens and inserting or removing the memory card and battery. Sand and
dust can damage the camera, the lens, the memory card and the battery. Moisture can cause malfunctions
and irreparable damage to the camera and memory card.
LENS
• A camera lens can have the effect of a magnifying glass when exposed to direct frontal sunlight. The
camera must therefore be protected against extended exposure to direct sunlight. Using the lens cap and
keeping the camera in the shade or ideally in its camera case will help prevent damage to the interior of the
camera.

BATTERY
• Improper use of the batteries or the use of unapproved battery types may result in an explosion!
• Do not expose the rechargeable battery to sunlight, heat, humidity or moisture for prolonged periods of
time. Likewise, the batteries must not be placed in a microwave oven or a high-pressure container as this
would pose a fire or explosion hazard.
• Do not under any circumstances charge or insert a damp or wet battery!
• A safety valve in the battery ensures that any excess pressure caused by improper handling is discharged
safely. It is nevertheless important to dispose of a bloated battery immediately. This battery will pose an
explosion hazard!
• Keep the battery contacts clean and easily accessible. Although lithium-ion batteries are secured against
short circuits, they should still be protected against contact with metal objects like paper clips or jewelry. A
short-circuited battery can get very hot and cause severe burns.
• When a battery is accidentally dropped, make sure to check the housing and the contacts immediately for
any damage. A damaged battery can damage the camera.
• In case of noise, discoloration, deformation, overheating or leaking fluid, the battery must be removed from
the camera or charger immediately and replaced. Continued use of the battery may result in overheating,
which can cause fire and/or explosion!
• Never throw batteries into a fire as they might explode!
• Keep the battery away from sources of heat in case of a leak or a smell of burning. Leaked fluid can catch
fire!
• The use of other chargers not approved by Leica Camera AG can cause damage to the batteries and, in
extreme cases, may cause serious or life-threatening injuries.
• Connect the charger to a freely accessible power socket.
• The car charging cable supplied must never be connected while the charger is connected to the mains.
• Battery and charger must not be opened. Repairs must only be carried out by authorized service centers.
• Keep batteries out of the reach of children. Batteries can cause suffocation when swallowed.
CHARGER
• Using the charger in the vicinity of broadcasting receivers may interfere with the reception of the device.
Ensure a distance of at least 1 m (3 ft) between the charger and the receiver.
• When the charger is in use, it may emit a buzzing sound – this is normal and not a malfunction.
• Disconnect the charger from the mains when it is not in use, because it consumes some (a very small
amount) electricity, even when no battery is inserted.
• Always keep the charger contacts clean, and never short circuit them.
• The car charging cable supplied must only be operated in 12V in-car grids and must never be connected
while the charger is connected to mains electricity.
MEMORY CARDS
• Never remove the memory card during a datasave or card reading process. The camera must not be
switched off or be subjected to impact or vibrations while working.
• Do not open the cover/remove the memory card or the battery while the status LED is lit, which indicates
memory access. Data on the card may otherwise be destroyed and camera malfunctions may occur.
• Do not drop or bend memory cards as this will cause damage and result in the loss of the stored data.
• Do not touch the connections on the reverse of the memory card and keep them clean and dry.
• Keep memory cards out of the reach of children. Swallowing a memory card may cause suffocation.
SENSOR
• Cosmic radiation (e.g. during flights) may cause pixel defects.

CARRY STRAP
• Once you have attached the carry strap, please make sure that the clips are mounted correctly to prevent
the camera from falling.
• Carry straps are usually made of very robust material. You should therefore keep it out of the reach of
children. A carry strap is not a toy and poses a strangulation risk.
• Use the carry straps only for their intended purpose on a camera or on binoculars. Any other use poses the
risk of injury and may possibly result in damage to the carry strap and is therefore not permitted.
• Carry straps should also not be used for cameras/binoculars during sports activities with a high risk of
getting entangled in the carry strap (e.g. mountain climbing and similar outdoor activities).
Alternating current (AC)
Direct current (DC)
Class II devices (the product has a double-insulated design)
REGULATORY INFORMATION
Specific regional approvals for this device can be found in the camera menu.
▸ Select Camera Information in the main menu
▸ Select Regulatory Information from the submenu
DISPOSAL OF ELECTRIC AND ELECTRONIC EQUIPMENT
(Applies within the EU and for other European countries with active waste separation policies)
This device contains electric and/or electronic components which must not be disposed of in
general household waste. Instead, it should be disposed of at a recycling collection point provided by
your local authority. This service is free of charge. Any standard or rechargeable batteries used in this
device must be removed and disposed of separately in accordance with local regulations.
Please contact your local authorities, waste disposal collection point or the retailer, from whom you
purchased the device for more information on correct waste disposal.
Product dependent (see technical data)
Type Frequency band (central frequency) Maximum power (dBm e.i.r.p.)
WLAN 2412–2462/5180–5240 MHz/
5260–5320/5500–5700 MHz
20
Bluetooth®Wireless
Technology
2402–2480 MHz 20
The CE mark on our products documents
compliance with the fundamental require-
ments of applicable EU directives.
FOR UNITED ARAB EMIRATES ONLY:
UAE-TRA
REGISTERED No.:
ERXXXXX/XX
DEALER No.:
DA0112968/13
FOR SINGAPORE ONLY:
Complies with
IMDA Standards
DA106734

FOR US ONLY:
FCC NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION:
To assure continued compliance, follow the attached installation instructions and use only shielded interface cables with ferrite core
when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
Declaration of Conformity
Trade Name: Leica
Type No.: 6376
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
Model No.: 6376
Responsible party/Support contact:
Leica Camera Inc.
1 Pearl Court, Unit A
Allendale, New Jersey 07401
Tel.: [phone]
Fax: [phone]
[email protected]
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC ID: N5A6376
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This equipment complies
with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines. This equipment is tested for specific absorption ratio (SAR) and complies with FCC/IC radiation exposure limits set forth
for an uncontrolled environment. This device complies with FCC/IC SAR limit of 1.6 W/kg. For body worn operation, this equipment
has been tested and meets the FCC/IC RF exposure guidelines when used with the Leica Camera AG accessories supplied or
designated for this product that have no metallic component in the assembly. Use of other accessories may not ensure compliance
with FCC/IC RF exposure guidelines.
FOR CANADA ONLY:
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received, including interference that may cause undesired operation of the device. This
equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio
frequency (RF) Exposure rules.
This equipment is tested for specific absorption ratio (SAR) and complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment. This device complies with FCC/IC SAR limit of 1.6 W/kg. For body worn operation, this equipment has
been tested and meets the FCC/IC RF exposure guidelines when used with the Leica Camera AG accessories supplied or
designated for this product that have no metallic component in the assembly. Use of other accessories may not ensure compliance
with FCC/IC RF exposure guidelines.
