Leica C-LUX 1 User manual

Elegant and robust metal
body available in black or
silver finish.
High resolution 2.5-inch display pro-
vides a clear view of critical details.
Exquisitely sharp photos even
in candlelight or of moving
objects thanks to the built-in
optical image stabilizer and the
high-sensitivity setting of up
to ISO 1600.
The extended focal length
range of the Leica wide-
angle lens is equivalent to
a 28-102 mm in the 35 mm
format.
Leica Camera AG / Oskar-Barnack-Straße 11 / D-35606 Solms
www.leica-camera.com / [e-mail]
Telephone [phone] / Fax + 49 (0)6442-208-333
Illustrations in original size
LEICA C-LUX 1
Camera
Image type/format
Resolution
Video sequences
Data recording
Storage media
Film speed setting
White balance
Lens
Optical image stabilizer
Focus range
Focusing
Exposure
Series exposures
Shutter speed range
Flash
Scene modes
Toning effects
LCD monitor
Self-timer
Power supply
Ports
Printer compatibility
Battery capacity (approx.)
Dimensions (Wx H xD)
Weight
Scope of delivery
Accessories
Case
Direct mains connector
Lithium-Ion-Battery
Digital Adapter
LEICA C-LUX 1
1/2.5" CCD sensor with 6.37 million pixels (6m pixels effective in 4:3 format).
In 4:3 format either 2816x 2112, 2048x1536, 1280 x 960 or 640x 480 pixels,
2816x 2112, 2048x1536,1600x1200 pixels. In Leica 3:2 format either 2816x1880
or 2048x1360 pixels. In16:9 format either 2816x1584 or1920x1080 pixels
(corresponds to HDTV standard).
In16:9 format with 848x 480 ; in 4:3 format with 640x 480 or in 4:3 format with
320x 240 pixels at either 30 fps or 10fps, duration of recording only limited by the
capacity of the memory card. Recordings with sound.
Data formats : Still pictures JPEG (Fine/Standard) ; Video QuickTime Motion JPEG.
SD Memory Card and MultiMedia card (a 64 MB-SD card is supplied with the camera).
Either automatic or manual ISO 80, ISO100, ISO 200 or ISO 400
(in high sensitivity mode 800 –1600).
Either automatic, for daylight, overcast sky, halogen light, two manual settings,
fine adjustment of white balance in a range of –1500 to +1500K in150K steps
(not available for automatic setting).
LEICA DC VARIO-ELMARIT f/2.8 – 5.6 / 4.6 –16.8 ASPH. (corresponds to 28 – 102 mm
in 35mm format), 3.6 x optical zoom. Change of focal length by conveniently located
zoom lever.
2 modes : either for exposure only or for exposure and monitor.
Normal : 50 cm – infinity ; Macro/Simple/Motion Picture : wide-angle 5 cm/
telephoto 30cm infinity.
Autofocus, either normal or macro ; Autofocus modes/measurement range either
5 fields (full image area), faster autofocus with 3 fields (across the center) or with
1 central field, 1 field, or spot.
Exposure modes either simple mode, normal image or macro.
Exposure metering Multi-field measurement.
Exposure bracketing ± 2 EV in 1
/3EV steps.
Either 3fps or 2 fps at full resolution, max. 8 pictures with JPEG standard, max. 6
pictures with JPEG fine.
In fully automatic mode : 8 –1/2000 sec. Starry sky mode : 15, 30, 60sec.
Flash modes either automatic flash on with or without pre-flash (to combat red-eye),
manual flash on (fill-in flash) with or without pre-flash, SLOW for slower shutter speeds
(with pre-flash), flash off. Flash range (ISO set at Auto) 0.6 – 4.0m (wide-angle),
0.3 – 2.0m (telephoto), in high-sensitivity mode : 0.8 – 5.7m (wide-angle), 0.8 - 2.8 m
(telephoto). Flash exposure bracketing ±2EV in
1
/3EV steps.
Portrait, soft skin, landscape, sport, night portrait, night landscape, self-portrait, food,
party, candlelight, fireworks, starry sky, snow, baby1, baby2, high sensitivity.
Blueish, reddish, black and white or sepia.
2.5" polycrystalline TFT color display with 207,000 pixels. Field of view : almost 100%
Power LCD mode, wide-angle viewing mode.
Either 2s or 10s countdown.
Lithium ion battery, 3.7 V,1150 mAH or optional mains unit.
USB 2.0 (Full speed), DC in (power supply) and AV out.
PictBridge
320 pictures (CIPA Standard)
approx. 3 11
/16 x 2 1 /8 x 15/16 in
approx.4.6 oz without battery and memory card ; approx. 5.6 oz with battery and
SD memory card.
Battery charger, battery, 64MB SD memory card AV cable, USB cable, AC cable, wrist
strap, CD ROM with software (Adobe Photoshop Elements 4.0, Quicktime Movieplayer).
real leather case with micro-velour lining. Cognac-brown Order No.18 651,
Black Order No.18 652, Red Order No.18 653
ACA-DC4 with mains cable (replacement)
LEICA BP-DC4 (replacement)
Digital Adapter 2 for all Leica Televid Order No. 42 303
Trademark of the Leica Camera Group / “Leica” and product names = ® Registered trademarks / © 2006 Leica Camera AG / All rights
to change construction, design and range reserved / Concept and Design : Heine/Lenz/Zizka, Frankfurt am Main / Image indication :
Product photography Tom Vack, Alexander Göhr / Photostory : Frank Rothe / Brochure order number :German 91249 / English 91250 /
US-English 91251 / French 91252 / Italian 91253 / Dutch 91254 / Japanese 91255 / Danish 91256 / Norwegian 91257/ Spanish 91258 /
Portuguese 91259 / 04/06/CGLW/B
Elegance that’s more than skin deep The LEICA C-LUX1 is an
engagingly attractive companion with a fashionably compact form factor.
Offered in smart black or lustrous silver and having a basic outline of
only 5x10 cm, it’s a camera you’ll want to take with you wherever you
go. And its elegant exterior is complemented by cutting-edge techno-
logy : 6-megapixel capture, ultra short shutter delay, precise autofocus
measurement, and a generous selection of scene modes make it ideal
for taking great pictures effortlessly. Whether you’re on the beach, on a
stroll through narrow streets, or in your favorite restaurant – the C-Lux 1
will capture all those precious moments you want to remember in stun-
ning, true-to-life color and detail.
F
ast stylish, compact,
fl
flexible, versatileflexible, versatile
e
, brilliant
apixel capture, ultra short shutter delay, precise autofocusapixel capture, ultra short shutter delay, precise autofocus
measurement, and a generous selection of scene modes make it idealmeasurement, and a generous selection of scene modes make it ideal
for taking great pictures effortlessly. Whether you’re on the beach, onfor taking great pictures effortlessly. Whether you’re on the beach, on
93253_LEI764_CLux_us_e.indd 193253_LEI764_CLux_us_e.indd 1 13.04.2006 12:18:43 Uhr13.04.2006 12:18:43 Uhr

LEICA C-LUX 1
