Leica M11 User manual

L E I C A M11
QUICK START GUIDE
Download the full scope instruction manual here:
en.leica-camera.com/Service-Support/Support/Downloads
Please register via the following link if you would like to receive a printed copy of the
full scope instruction manual:
www.order-instructions.leica-camera.com

21
20
19
15
22
16
26
29
24
25
23
12
3
4a
4
5
6
510
11
12
14
9
8
7
3a
13
30
31
18
28
17
27
PART DESIGNATIONS

1Main switch
Switching the camera ON/OFF
2Shutter button
Tap:
– Activating exposure metering and exposure
control
Press down fully:
– Shutter release
in standby mode:
– The camera is reactivated
3Shutter speed setting dial with stop
positions
– A: Automatic shutter speed control
– 8s - 4000: Shutter speeds
(inc. intermediate values)
– B: Long-term exposure
(1⁄16000 s - 60 min, via menu control, in full
increments or Bulb)
– : Flash sync speed (1⁄180 s)
aIndex
4ISO dial
– A: Automatic ISO sensitivity control
– 64 - 6400: fixed ISO values
– M: Setting in the menu or status screen
aIndex
1
2
2
5Strap lugs
6Function button**
7Rangefinder window
8Brightness sensor
9Self-timer LED
10 Viewfinder window
11 Lens release button
1
21
2
12 Bayonet
13 6-bit encoding
Sensor for lens detection
14 Image field selector
Selection of bright-line frame pairs 35/135 mm,
50/75 mm and 28/90 mm
15 Viewfinder eyepiece
16 Brightness sensor for LCD panel
17 Accessory shoe
18 Thumbwheel
in the menu:
– Menu navigation
– Setting selected menu items/functions
in shooting mode:
– Exposure compensation value selection
in review mode:
– Enlarging/reducing viewed pictures
Press:
– Use as function button**
19 PLAY button
– Switchover between shooting and review/
playback mode
– Return to full-screen display
20 FN button**
21 MENU button
in the menu:
– Access to status screen and the menus
FavoritesFavorites/Main MenuMain Menu
– Exiting the currently displayed (sub) menu
22 LCD panel
23 Status LED
24 Directional pad
in the menu:
– Menu navigation
– Setting selected menu items/functions
in review mode:
– Scroll through the gallery
**Press & release: Access to the assigned function. Press & hold: Modify assignment (drop-down list).

25 Center button
in the menu:
– Applying menu settings
in shooting/playback mode:
– Accessing the information displays
26 Tripod thread
A ¼, DIN 4503 (¼”)
27 LED
28 Battery release lever
29 Memory card slot
▸ Ensure that the camera is switched OFF
▸ Removing the battery
30 Battery compartment
31 USB-C socket
CHARGING THE BATTERY
The camera is powered by a lithium-ion battery.
The status LED indicates a correct charging process.
PREPARING THE CHARGER
▸ Use the plug with the matching regional plug to
connect the charger to mains electricity
• The charger will automatically adapt to local
mains voltage.
CHANGING THE BATTERY
▸ Ensure that the camera is switched OFF
LIVE VIEW
▸ Press the FN button
• Only if the function Live ViewLive View is assigned to the
FN button (factory setting).

DISPLAYS IN THE VIEWFINDER
The bright-line rangefinder in this camera is more than
just a very bright viewfinder – it also is a lens-coupled
rangefinder. All Leica M lenses with focal lengths
between 16 and 135mm are coupled automatically.
B A
C
35 mm/135 mm 28 mm/90 mm
ABright-line frame 50 mm/75 mm
BMetering field for focusing
CDigital display
LEICA FOTOS APP
Experience the new Leica FOTOS app. The Leica
FOTOS app is a digital tool with plenty of exciting
options and allows the photographer to get more out
of his Leica camera than ever before. You can now link
all your WLAN-capable Leica cameras via a single app
to transfer images easily and instantly, capture the
essence of unforgettable moments, manage, optimize
and share your photos – anytime, anywhere.
DISPLAYS ON THE LCD PANEL
8
9
4
10
22
16
12
24
18
23
17
13 14
26
20
25
19
21
15
11
1 2 3
1Storage location
2Remaining number of recordings
3Remaining storage capacity
4Flash sync point
5Leica app connection
6GPS function via Leica FOTOS app
7Digital zoom
8Battery capacity
9Light balance
10 Exposure compensation scale
11 Exposure mode
12 Shutter speed
13 ISO Sensitivity
14 Exposure compensation value
15 Live View On/Off
16 Shooting mode (Drive ModeDrive Mode)
17 Exposure metering method
18 White balance mode
19 User profile
20 Light intensity/focal length or lens type
21 File format
22 DNG Resolution
23 JPG resolution
24 Formatting a memory card
25 Leica FOTOS
26 Main menu
5 6 7

INITIAL START/APP CONNECTION
FOCUSING
SUPERIMPOSED IMAGE METHOD
(DOUBLE IMAGE)
SPLIT IMAGE METHOD
VIA CABLE
Leica FOTOS
Cable*
USB-C
Automatic setting
Leica FOTOS Pairing
Date & Time
Shooting location
*Note
The Leica FOTOS cable allows direct data exchange between the Leica FOTOS app and the camera. It
cannot be used for the charging of Apple®devices.

TOUCH CONTROL
“tap” “double tap” “horizontal swipe”
“vertical swipe”
“two-finger pinch” “two-finger spread”
FN button Factory settings Available
20
Live ViewLive View
Activating/deactivating the
Live View mode
Lens DetectionLens Detection
Drive ModeDrive Mode
Self TimerSelf Timer
Interval ShootingInterval Shooting
Exposure BracketingExposure Bracketing
Capture AssistantsCapture Assistants
Exposure MeteringExposure Metering
M-ISOM-ISO
6
Focus AidFocus Aid Auto ISO SettingsAuto ISO Settings
Maximum ISOMaximum ISO
Shutter Speed LimitShutter Speed Limit
White BalanceWhite Balance
Gray cardGray card
File FormatFile Format
DNG ResolutionDNG Resolution
Max. JPG ResolutionMax. JPG Resolution
18
Exposure CompensationExposure Compensation Digital ZoomDigital Zoom
Film StyleFilm Style
Shutter TypeShutter Type
Flash SettingsFlash Settings
Flash Exp. CompensationFlash Exp. Compensation
User ProfileUser Profile
EVFEVF ⇄⇄LCDLCD
Format SD CardFormat SD Card
Leica FOTOSLeica FOTOS
FN BUTTON ASSIGNMENTS
• Press & release: Call-up of assigned function.
• Press & hold: Modify assignment (drop-down list).

TECHNICAL DATA
CAMERA
DesignationDesignation
Le i ca M11
Camera typeCamera type
Digital system camera with rangefinder
Type no.Type no.
2416
Order No.Order No.
Regional Variant
EU/US/C N JP ROW
Order No.
(Color)
20200
(black)
20201
(silver)
20202
(black)
20203
(silver)
20206
(black)
20207
(silver)
Wi-Fi
5 GHz
11a /n/a c:
channel 149–165
(5745–5825 MHz)
11a /n/a c:
channel 36–48
(5180–5240MHz)
-
Wi-Fi
2.4 GHz
11b/g /n :
channel 1–11 (2412–2462MHz)
Bluetooth 4.2 BR/EDR/LE:
BR/DR channel 1–79
LE channel 0–39 (2402–2480 MHz)
Storage mediumStorage medium
SD cards 1-2 GB / SDHC cards up to 32 GB / SDXC cards
up to 2 TB, internal memory 64 GB
MaterialMaterial
Top/bottom cover:
Silver: chromed brass, Black: coated aluminum
Front and rear housing panels: magnesium
Lens mountLens mount
Leica M bayonet
InterfacesInterfaces
ISO accessory shoe with additional control contacts for
Leica flash units and Leica Visoflex 2 viewfinder (optional
accessory)
USB-C cable for data transfer and battery charging
Compatible lensesCompatible lenses
Leica M-lenses, Leica R-lenses via adapter
Operating conditionsOperating conditions
0/+40°C
Rated input voltage / currentRated input voltage / current
DC 7.4V, 1.5A (continuous)
Dimensions (WxHxD)Dimensions (WxHxD)
139 x 38.5 x 80 mm
WeightWeight
Silver: approx. 640 g (with battery)
Black: approx. 530 g (with battery)
SENSOR
Sensor sizeSensor size
CMOS chip, active surface approx. 24 x 36 mm
Image resolutionImage resolution
DNG™ L- DNG 60.3 MP 9528 x 6328 pixels
M-DNG 36.5 MP 7416 x 4928 pixels
S-DNG 18.4 MP 5272 x 3498 pixels
JPG L-JPG 60.1 MP 9504 x 6320 pixels
M-JPG 36.2 MP 7392 x 4896 pixels
S-JPG 18.2 MP 5248 x 3472 pixels
LCD PANEL
LCD panelLCD panel
2.95” TFT LCD, 1080 x 720 pixels
EQUIPMENT
WLAN/BluetoothWLAN/Bluetooth
The Leica FOTOS app is required to use the WLAN
function. The Leica app is available from the Apple App
Store™ or the Google Play Store™. 2.4 GHz/5 GHz* dual
band IEEE802.11 a/b/g/n/ac Wave2 WLAN (standard
WLAN protocol), encryption method: WLAN-kompatible
WPA™/WPA2™, access method: infrastructure mode
POWER SUPPLY
Charger (Leica BC-SCL7)Charger (Leica BC-SCL7)
Input: USB-C DC 5 V, 2 A, output: DC 8.4 V, 1 A, operating
conditions: +10°C to +35°C, manufacturer: Dee Van
Enterprises Co., Ltd., made in China
AC-Adapter (Leica ACA-SCL7)AC-Adapter (Leica ACA-SCL7)
Input: AC 100 V - 240 V ~ 50/60 Hz, 0.3 A, output: DC 5 V,
2 A, operating conditions: +10°C to +35°C, manufacturer:
Dee Van Enterprises Co., Ltd.., made in China
Rechargeable battery (Leica BP-SCL7)Rechargeable battery (Leica BP-SCL7)
Li-Ion (Lithium-Polymer) rechargeable battery, rated
voltage: 7.4 V / capacity: 1800 mAh, Charging voltage /
current: DC 7.4 V, 1000 mA, operating conditions: +10°C
to +35°C (charging) / +0°C to +40°C (discharging),
manufacturer: Fuji Electronics (Shenzhen) Co., Ltd. made
in China
* Unavailable for regional variant "ROW".
The production date of your camera is printed on the packaging.
The date format is year/month/day. Subject to changes in design and
model type.
94 170 XI/21/D

SAFETY REMARKS
GENERAL INFORMATION
• Do not use your camera in the immediate vicinity of devices that generate powerful magnetic, electrostatic or electromagnetic fields (e.g.
induction ovens, microwave ovens, television sets or computer screens, video game consoles, cell phones, broadcasting equipment). Their
electromagnetic fields can interfere with recordings.
• Strong magnetic fields, e.g. from speakers or large electric motors can damage the stored data or disrupt shooting.
• Switch off the camera, remove the battery briefly, replace it and switch the camera back on in case of a camera malfunction due to the effects of
electromagnetic fields.
• Do not use the camera in the immediate vicinity of radio transmitters or high-voltage power lines. Their electromagnetic fields may interfere with
recordings.
• Always store small parts e.g. the accessory shoe cover as follows:
• out of the reach of children
• in a safe location, where they will not get lost or stolen
• State-of-the-art electronic components are sensitive to static discharge. You can easily pick up charges of several 10,000 volts by simply walking
on synthetic floor coverings. A static discharge can occur when you touch the camera and especially if it is placed on a conductive surface. A
static discharge on the camera housing poses no risk for the electronics. Despite built-in safety circuits, you should avoid direct contact with
external camera contacts like those in the flash shoe.
• Take care not to soil or scratch the sensor for lens detection in the bayonet. You must similarly prevent direct contact of the bayonet with grains of
sand or similar particles, as these could cause irreparable damage. This component must only be cleaned with a dry cloth (in system cameras).
• Use a cotton or linen cloth instead of a microfiber cloth from an optician’s (synthetic) when cleaning the contacts. Make sure to discharge any
electrostatic charge by deliberately touching a heating or water pipe (conductive, grounded material). Dirt deposits and oxidation on the contacts
can be avoided by storing your camera in a dry location with the lens cap and the flash shoe/viewfinder cap (in system cameras) attached.
• Only use accessories specified for this model to prevent faults, short circuits or electric shock.
• Do not attempt to remove parts of the housing (covers) yourself. Repairs must be done at authorized service centers only.
• Protect the camera against contact with insect sprays and other aggressive chemicals. Petroleum spirit, thinner and alcohol must not be used for
cleaning. Some chemicals and liquids can damage the camera housing or the surface finish.
• Rubber and plastics are known to expel aggressive chemicals and should therefore not be kept in contact with the camera for extended periods of
time.
• Prevent any sand or dust or water penetration into the camera, e.g. during snowfall or rain or on the beach. Be extra careful when changing the
lens (in system cameras) and when inserting or removing the memory card and rechargeable battery. Sand and dust can damage the camera, the
lens, the memory card and the battery. Moisture can cause malfunctions and irreparable damage to the camera and memory card.
LENS
• A camera lens can have the effect of a magnifying glass when exposed to direct frontal sunlight. The camera must therefore be
protected against extended exposure to direct sunlight.
• Attaching the lens cap and keeping the camera in the shade or ideally in its camera case, will help prevent damage to the interior of the
camera.
BATTERY/CHARGER
• Use of the rechargeable battery type (BP-SCL7) named and described in this manual is mandatory.
• Improper use of the batteries or the use of unapproved battery types may result in an explosion!
• Do not expose the rechargeable battery to sunlight, heat, humidity or moisture for prolonged periods of time. Likewise, the batteries
must not be placed in a microwave oven or a high-pressure container as this would pose a fire or explosion hazard!
• Do not under any circumstances charge or insert a damp or wet battery into the camera!
• Keep the battery contacts clean and easily accessible. Although lithium-ion batteries are secured against short circuits, they should still be
protected against contact with metal objects like paper clips or jewelry. A short-circuited battery can get very hot and cause severe burns.
• When a battery is accidentally dropped, make sure to check the housing and the contacts immediately for any damage. A damaged
battery can damage the camera.
• The battery must be removed from the camera or charger and must be replaced immediately in case of a strange smell, discoloration,
deformation, overheating or leakage. Continued use of the battery may result in overheating, which can cause fire and/or explosion!
• Never throw batteries into a fire as they may explode.
• Keep the battery away from sources of heat in case of leakage or if you smell burning. Leaked fluid can catch fire!
• Use of the charger (BC-SCL7) named and described in this manual in combination with the stated AC-Adapter (ACA-SCL7) and its
interchangeable AC-Plugs is mandatory.
• The use of other chargers not approved by Leica Camera AG can cause damage to the batteries – and in extreme cases – cause serious or
life-threatening injuries.
• Make sure that the power socket is freely accessible at all times.
• Do not attempt to open the battery or the charger. Repairs must only be carried out by authorized service centers.
• Keep batteries out of the reach of children. Batteries can cause suffocation when swallowed.
• Always keep the charger contacts clean, and never short-circuit them.

• Using the charger in the vicinity of broadcasting receivers may interfere with reception. Ensure a distance of at least 1m between the
charger and the receiver.
• When the charger is in use, it may emit a buzzing sound – that is normal and not a malfunction.
• Disconnect the charger from the mains when it is not in use, as it consumes electricity (a very small amount), even if no battery is inserted.
• The battery must have a temperature between +10°C and +35°C for charging (otherwise the charger will not switch on or will switch off again immediately).
• Lithium-ion batteries can be charged at any time, regardless of their current charge level. A partially charged battery will charge to full
capacity faster than a fully discharged one.
• The rechargeable batteries come only partly charged ex works and should therefore be charged fully before their first use.
• A new battery only reaches its full capacity after it has been fully charged and – by using it in the camera – depleted 2 to 3 times. This
depletion process should be repeated roughly every 25 cycles.
• Battery and charger heat up during the charging process. That is normal and not a malfunction.
• A flashing charge status indicator when charging commences indicates a fault (e.g. max. charging time is surpassed, voltage or temperature
outside permitted parameters or a short-circuit). Disconnect the charger from the mains and remove the battery. Ensure that the above
temperature conditions are met and then restart the charging process. Please contact your dealer, the Leica representative in your region or
Leica Camera AG if the problem persists.
• Rechargeable lithium-ion batteries generate power by way of internal chemical reactions. These reactions are influenced by ambient
temperature and humidity. Do not expose the battery to extreme temperatures (high or low) for extended periods of time (e.g. in a parked car
in the summer or winter) to ensure a maximum service life.
FIRST AID
• Battery fluid may cause blindness if it comes into contact with the eyes. Rinse the eyes thoroughly with clean water immediately.
Avoid rubbing. Seek medical attention immediately.
• Leaked battery fluid poses an injury hazard when it comes in contact with clothing or skin. Rinse the affected areas thoroughly with
clean water.
MEMORY CARD
• Never remove the memory card during a datasave or card reading process. The camera must not be switched off or be subjected to
impact or vibrations while working.
• Do not drop or bend memory cards as this will cause damage and result in the loss of stored data.
• Do not touch the connections on the reverse of the memory card and keep them clean and dry.
• Keep memory cards out of the reach of children. Swallowing a memory card may cause suffocation.
SENSOR
• Cosmic radiation (e.g. during flights) may cause pixel defects.
CARRY STRAP
• Once you have attached the carry strap, please make sure that the clips are mounted correctly to prevent the camera from falling.
• Carry straps are usually made of very robust material. You should therefore keep it out of the reach of children. A carry strap is not a toy
and poses a strangulation risk.
• Use the carry strap only for its intended purpose on a camera or on binoculars. Any other use poses the risk of injury and may possibly
result in damage to the carry strap and is therefore not permitted.
• Carry straps should also not be used for cameras/binoculars during sports activities that pose a risk of entanglement (e.g. when
mountain climbing and similar outdoor activities).
TRIPOD
• When using a tripod, make sure it is standing securely and turn the camera only by turning the tripod, not the actual camera.
• Ensure that the tripod screw is hand-tightened only.
• Avoid transporting the camera while the tripod is attached. You might injure yourself or others and the camera could get damaged.
FLASH
• The use of incompatible flash units with your LeicaM11 may result in irreparable damage to the camera and/or the flash unit.
REGULATORY INFORMATION
Specific regional approvals for this device can be found in the camera menu.
▸ Select Camera InformationCamera Information in the main menu
▸ Select Regulatory InformationRegulatory Information in the submenu

Alternating current (AC)
Direct current (DC)
Class II devices (the product has a double-insulated design)
DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT
(Applies within the EU and for other European countries with active waste separation policies.)
This device contains electric and/or electronic components which must not be disposed of in
general household waste. Instead, it should be disposed of at a recycling collection point provided
by your local authority. This service is free of charge. Any standard or rechargeable batteries used
in this device must be removed and disposed of separately in accordance with local regulations.
Please contact your local authorities, waste disposal collection point or the retailer, from whom you
purchased the device for more information on correct waste disposal.
CE MARK
English
Declaration of Conformity (DoC)
Hereby, “Leica Camera AG” declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 2014/53/EU.
Customers can download a copy of the original DoC to our Radio Equipment
products from our DoC server:
www.cert.leica-camera.com
Please contact Leica Camera AG, Am Leitz-Park 5, 35578 Wetzlar, Germany in
case of any further questions
Depending on product (see technical data)
Typ e Frequency band (center frequency) Maximum output
(dBm E.I.R.P.)
WLAN 2412–2462/5180–5240 MHz/
5260–5320/5500–5700 MHz
5735–5825 MHz
20
Bluetooth®Wireless
Technology
2402–2480 MHz 20
The CE mark on our products documents
compliance with the fundamental requirements
of applicable EU guidelines.
WARRANTY
In addition to your statutory warranty rights regarding your dealer, you will receive an additional Leica Camera
AG product warranty valid from the date of purchase at an authorized Leica retailer. Previously, the product
warranty was included with the product in the packaging. From now on, the product warranty will only be
available online as a new service. You will be able to review the warranty conditions for your product at any time,
without having to search fr the document. Please note that this new policy applies only for products that are no
longer delivered with a hardcopy product warranty included in the packaging. Any products still delivered with
the warranty document in the packaging remain governed exclusively by that document. For more information
regarding the warranty scope, services and limitations, please visit: warranty.leica-camera.com
FOR US ONLY:
FCC Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:
To assure continued compliance, follow the attached installation instructions and use only shielded interface cables with ferrite core
when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
Trade Name: LEICA Type No.: 2416
Type No. 2416
Responsible party/Support
contact:
Leica Camera Inc.
1 Pearl Count, Unit A, Allendale, New Jersey 07401
Tel.: [phone]/ Fax: [phone]
[email protected]
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
A recyclable lithium ion/polymer battery
powers this camera.
Please call 1-800-8-BATTERY for information
on how to recycle this battery.
FCC ID: N5A2416
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This equipment
complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF)
Exposure Guidelines.
FOR CANADA ONLY:
CAN ICES-3 (B)/NMB-3(B) IC: 11245A-2416
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure
limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules.
FOR US AND CANADA ONLY:
This equipment is tested for specific absorption ratio (SAR) and complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment. This device complies with FCC/IC SAR limit of 1.6 W/kg. For body worn operation, this equipment has
been tested and meets the FCC/IC RF exposure guidelines when used with the Leica Camera AG accessories supplied or
designated for this product that have no metallic component in the assembly. Use of other accessories may not ensure
compliance with FCC/IC RF exposure guidelines.
FOR UK ONLY FOR SINGAPORE ONLY
Complies with
IMDA Standards DA106734
FOR UNITED ARAB EMIRATES ONLY
REGISTERED No: ER98767/21
DEALER No: DA0112968/13
Use of the Made for Apple badge means that an accessory has been
designed to connect specifically to the Apple product(s) identified in the
badge and has been certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards.Please note that the use
of this accessory with an Apple product may affect wireless performance.
Apple®, Apple TV®, Apple Watch®, iPad®, iPad Air®, iPad Pro®, iPhone®, and
Lightning®are trademarks of Apple Inc., registered in the U.S. and other
countries. tvOS®is a trademark of Apple Inc.
