Leigh Country CHAR-LOG TX 93859 User manual

Take assembled SEAT PANEL (6) and one of the arm frames, keep the arm frame
standing and attached the SEAT PANEL (6) to the inside of the arm frame, secure
with the indicated nuts and bolts.
Insert the other arm frame
on the other side and
secure loosely with
nuts and bolts.
Take the Lower Support
Beam (5) and secure
under the seat between
the arm frame with
nuts and bolts.
Once the bottom half is finished,
take the BACK PANEL (7) and
place it gently on the VERTICAL
SUPPORT (4) of the arm frame.
Secure with indicated hardware
in the diagram.
Tighten all nuts, bolts,
and screws once
every part and
assembled pieces
are in place.
Congratulations
on your assembly!
STEP 1: STEP 2:
STEP 3: STEP 4:
Assembling the Rocker Arm Frame Assembling the Bottom Half
Assembling the Upper Half Finish
Take one piece of the following parts with a letter “R” behind
each number: 1 , 2 , 3 , 4 , 8 (”R” = Right)
1: Part 1 to part 4
2: Part 3 to part 2
3: Part 2 to part 1
4: Part 4 to part 3
5: Part 8 to Part 2 & 3
Use indicated hardware, directed
by diagram.
REPEAT steps 1 through 5 above using parts
labeled with a letter “L” (”L” = Left) after the part number.
C
A
A
4R
3R
1R
8R
2R
A
BB
7
6
5
A
A
A
A
A
Left
Right
ITEM # TX 93605 , TX 93859
A B C
Mallet
Socket & Wrench
Phillips
Screwdriver
Tools required for assembly
13mm
NUT & BOLT NUT & BOLT SCREW
N08-11 N08-8 S04-4
X 16PCS X 4PCS X 4PCS
Tools included
1. Do not tighten bolts until fully assembled.
2. Recessed holes to face outward.
3. Insert bolts with washer and secure with washer and nut.
4. Pre-checked side must always face downward or inward.
IMPORTANT: READ CAREFULLY BEFORE BEGINNING
Recessed Hole
Pre-Checked
PARTS AND HARDWARE LIST
1 2
6
3
7
4
85
ARM REST
LOWER SUPPORT BEAM
FRONT LEG
SEAT
DIAGONAL SUPPORT
BACK
VERTICAL SUPPORT
RUNNER
X 2PCS X 2PCS X 2PCS X 2PCS
X 1PC X 1PC X 1PC X 2PCS
CHAR-LOG®SINGLE ROCKER
The use of power tools during
assembly may void this warranty.

www.LeighCountry.com
Limited Warranty and Care Instructions
LIMITED ONE YEAR WARRANTY (NON-TRANSFERABLE)
Customer Service may be reached Monday through Friday from 9:00a.m. to 5:00p.m. CST.
[email protected] OR 1-877-87LEIGH (53444)
©2022 UGS Co., INC. All Rights Reserved The Char-logfinishis copyright protected
DISTRIBUTED BY:
UNITED GENERAL SUPPLY CO., INC.
HOUSTON, TX 77036
PROPER CARE INSTRUCTIONS
This product is covered under United General Supply’s (UGS) one (1) year limited warranty. To the original purchaserof this
piece offurniture, cooler or accessory; UGS warrants that itwill be free from defects in material and workmanship for up to
one year from the date ofpurchase under normal use and proper care.
Replacement of defective or missing parts will be sent at no charge to the customer for a period of 30 days from the date of
purchase.UGS will no longer be responsible for missing parts or hardware 30 days after date of purchase.Freight, packaging,
laboror material charges toand from our customer service center is not covered underthe warranty and is therefore the
customer’s responsibility.
The limited warranty does not cover this piece of furniture, cooleror accessory for commercial purposes, abusive use,
damage by modification, freeze damage, severe weather damage, rust, fading and issues caused by improper care.
For minordefects or missingparts/hardware, please contact customerservice immediatelyupon purchase. Please donot
return product to the store unless the productis irreparable.A customerservice agent mayhelp determine whetherthe
damage is reparable and will provide further instructions.
If left untreated, wood will naturally weather. During long periods of non-use, store furniture or cooler in covered and
dry place. For the least maintenance, place your furniture, cooler, or accessory under a covered area.
To preserve and maintain the original finish of Char-log/Aspen log furniture, we recommend that a light lacquer coating
be applied every 4 to 6 months depending on the seasons. Remove the furniture completelyfrom sunlight prior to applying
oil. Apply generously and remove any excess with a cloth. Frequency of the application of lacquer depends on exposure to
the extremities ofthe outdoors.
We recommended an exterior poly-urethane product that features a clear satin or semi-gloss finish and a fast drying
process.
For returns and refunds, please refer to your local store returnpolicy with proof ofpurchase.
Proof ofpurchase (dated register receipt) will be required for warrantyclaims.
Please register your product warranty with us at www.LeighCountry.com/register
DO NOT USE POWER TOOLS ON THE ASSEMBLY OF THIS ITEM AS THEY MAY DAMAGE THE HARDWARE OR SPLIT THE WOOD. USE OF POWER
TOOLS ALSO VOID THE WARRANTY.
