Leisure made CAMDEN BENCH 642003 User manual

ATTACH YOUR RECEIPT HERE
Order Number Purchase Date
www.leisuremade.com(888) 682-3012 1
Questions, problems, missing parts? Before returning to your retailer, email our customer service
department directly at [email protected] or call us at [phone]
8am-4pm EST, Monday-Friday.
Item # 642003
CAMDEN BENCH
ASSEMBLY INSTRUCTIONS

PACKAGE CONTENTS
www.leisuremade.com(888) 682-3012 2
A
PART DESCRIPTION QTY
A Bench Leg 2
B 1
C
Bench Seat
2
D
Cross Bar
1
F
E
E
F
Seat Cushion
2
1
B
CD
Middle Leg
Lumbar

www.leisuremade.com(888) 682-3012
HARDWARE CONTENTS
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
Before beginning assembly of product, make sure all parts are present. Compare parts with the
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
If you find a missing or damaged part, please look through all pieces to make sure nothing else is
missing or damaged. Compile a comprehensive list and give us a call. We will send out all parts
in a single shipment. Ensuring you have all missing parts identified at the time you call will ensure
a faster delivery to complete your beautiful patio furniture.
3
PREPARATION
Please call us directly, not your retailer. As the manufacturer we can walk you through any
issues you may have. We are here to help: [phone]
SAFETY INFORMATION
AA BB DD EE
CAUTION: Assemble on a soft, non-abrasive surface.
M6 Bolt x 20mm
Qty: 8
Washer Allen Key
Qty: 1
CC
Plastic Bolt Cap
Qty:14
Qty:14
M6 Bolt x 35mm
Qty: 6

ASSEMBLY INSTRUCTIONS
www.leisuremade.com(888) 682-3012 4
1.
2.
DD
Fasten the bench legs (A) and middle leg (D) to the bench seat (B) with bolts (AA) and
washers (CC) using allen key (EE).
BB
A
B
AA
CC
D
A
BB
Fasten the bench legs (A) & (B) to cross bar (D) with bolts (BB) and washers (CC) using
allen key (EE).
CC
DD
AA
B
A
B
D
C
DD
CC

ASSEMBLY INSTRUCTIONS
www.leisuremade.com(888) 682-3012 5
3.
BB
Turn the bench upside up and put seat cushion (F) and lumbars (E) on it.
A
B
Enjoy your beautiful furniture!
If you have any issues please call [phone] directly.
