LEM NORMA 4000 User manual

LEM NORMA GmbH
Liebermannstraße F01
CAMPUS 21
A-2345 Brunn am Gebirge
AUSTRIA
Tel.: [phone]
E-Mail: [e-mail]
Internet: www.lem.com
Power Analyze
r
NORMA 4000
NORMA 5000
Operating Instructions

Order no.: EO1111G
Version: Revision G
Date: 08 / 2005
The technical data contained in this document is subject to
changes without prior notice, due to continued product
development and improvements made by the manufacturer.
© LEM NORMA GmbH, All rights reserved.

Contents
Power Analyzer NORMA 4000, NORMA 5000 1
EO1111G REV G
Contents
1About this Document ......................................................................................... 3
1.1 Document structure ..................................................................................... 3
1.2 Signs and symbols ...................................................................................... 3
2General Safety Instructions ............................................................................... 4
2.1 Safety instructions on the device housing.................................................... 6
3Design and functions ......................................................................................... 7
3.1 Terminals (rear of housing).......................................................................... 7
3.2 Operating controls and display .................................................................... 8
3.3 Functions................................................................................................... 10
4Startup............................................................................................................... 11
4.1 Checking of delivery .................................................................................. 11
4.2 Installation and switching on...................................................................... 11
5Connection to Circuits ..................................................................................... 12
5.1 Connecting sequence................................................................................ 12
5.2 Overview ................................................................................................... 12
5.3 1-phase measurement............................................................................... 13
5.3.1 Direct connection.......................................................................... 13
5.3.2 With shunt..................................................................................... 14
5.3.3 With voltage and current transducer ............................................. 15
5.4 Aron circuit (triaxial/guard technique)......................................................... 16
5.4.1 Direct connection.......................................................................... 16
5.4.2 With shunt..................................................................................... 17
5.4.3 With voltage and current transducer ............................................. 18
5.5 3-phase measurement in 4-wire system .................................................... 19
5.5.1 Direct connection.......................................................................... 19
5.5.2 With shunt..................................................................................... 20
6Simple Measurement........................................................................................ 21
7Configuration .................................................................................................... 22
7.1 Call up General Setup / Call up system information screen ....................... 23
7.2 Load configuration..................................................................................... 23
7.3 Configure data transfer to printer and PC .................................................. 23
7.4 Configure average time and synchronisation............................................. 26
7.5 Adjust date and time.................................................................................. 29
7.6 Configure current and voltage channels .................................................... 30
7.7 Switch current input to external input (BNC) .............................................. 33
7.8 Integration function configuration............................................................... 34
7.9 Save configuration..................................................................................... 37
7.10 Delete configuration................................................................................... 37
7.11 Undersampling / Aliasing........................................................................... 37
8Measuring process........................................................................................... 39
8.1 Prior to measuring ..................................................................................... 39
8.2 Measure voltage, current and power ......................................................... 40
8.2.1 View the measured values for the individual channels .................. 40
8.2.2 View totals of all measured values................................................ 42
8.2.3 Compare measured values........................................................... 43
8.2.4 View fundamentals ....................................................................... 44
8.2.5 User defined screen view.............................................................. 45

Contents
2Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
8.3 Change view mode.................................................................................... 47
8.3.1 Numerical display ......................................................................... 47
8.3.2 Vector graphs ............................................................................... 47
8.3.3 Oscilloscope curves...................................................................... 48
8.3.4 Recorder view............................................................................... 49
8.4 Fast Fourier analysis ................................................................................. 50
8.4.1 FFT mode ..................................................................................... 50
8.4.2 Harmonic Order mode .................................................................. 52
8.4.3 Harmonic Order mode related to fundamental in %....................... 53
8.5 Integration function / electrical work........................................................... 54
8.6 Save and print measurements................................................................... 56
8.6.1 Save measurements..................................................................... 56
8.6.2 Print measurements...................................................................... 56
9PI1 Process Interface (optional) ...................................................................... 57
9.1 Pin assignment.......................................................................................... 57
9.2 Measured values ....................................................................................... 57
9.3 Configuring PI1.......................................................................................... 58
9.4 Measuring with PI1 .................................................................................... 61
9.5 PI1 - technical data.................................................................................... 63
9.5.1 8 inputs (analog/digital)................................................................. 63
9.5.2 4 digital inputs for the detection of the sense of rotation................ 63
9.5.3 4 outputs (analog)......................................................................... 64
10 Formulas ........................................................................................................... 65
10.1 Direct current............................................................................................. 65
10.2 Alternating current ..................................................................................... 65
10.3 Fundamental and harmonics ..................................................................... 66
10.4 Frequency analysis.................................................................................... 66
10.5 Uncertainty of measurement...................................................................... 66
11 Transport and Storage ..................................................................................... 67
11.1 Transport................................................................................................... 67
11.2 Storage...................................................................................................... 67
12 Warranty............................................................................................................ 67
13 Recalibration..................................................................................................... 67
14 Maintenance...................................................................................................... 67
15 Decommissioning and Disposal...................................................................... 68
15.1 Shutting down............................................................................................ 68
15.2 Recycling and disposal.............................................................................. 68
15.3 Packaging.................................................................................................. 68
15.4 Housing ..................................................................................................... 68
15.5 Electronic components .............................................................................. 68
16 Technical Data .................................................................................................. 69
16.1 Technical data NORMA 4000 .................................................................... 69
16.2 Technical data NORMA 5000 .................................................................... 72
16.3 Block diagrams.......................................................................................... 75
17 Service and Accessories.................................................................................. 78
17.1 Instrument ................................................................................................. 78
17.2 Accessories............................................................................................... 79
17.3 Service ...................................................................................................... 79

About this Document
Power Analyzer NORMA 4000, NORMA 5000 3
EO1111G REV G
1 About this Document
1.1 Document structure
This document consists of several chapters. Within these chapters,
shoulder headings in the margin identify sections in the text
focussing on the respective topic or procedure. Example:
The text belonging to this shoulder heading informs you on how
the details of a measured value can be viewed, including
introductory notes, safety instructions, hints and tips, instructions
on procedures, figures and tables, if any.
1.2 Signs and symbols
The following signs and symbols are used in this document:
Symbol Description
 ... ... identifies a requirement.
This requirement must be met before you can
proceed with the task described in this section of
the text.
 ...
... identifies a mandatory action.
You are requested to carry out a specified task.
 ...
– or –
 ...
... identifies a mandatory action to which there is
an alternative procedure. The alternative
procedure is introduced with "– or –" or by a left
indent.
... identifies general information and hints.
In the related section of the text, you find
important information regarding a certain system
feature or procedure.
... identifies important information.
The related information and instructions must
always be strictly followed.
... identifies a warning relating to a risk to life and
limb from electric shock.
If the instructions are not strictly adhered to,
there is an inevitable risk to life and limb.
... identifies a warning relating to a potential risk
or dangerous situation.
If the instructions are not adhered to, there is a
risk of death, injury or damage to property.
Format Description
Detail Names of software and operating elements,
lettering on the device as well as numbers and
text shown on the display are printed in italics.
"View details"
Symbols
Text formats

General Safety Instructions
4Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
2 General Safety Instructions
The design and manufacture of this device conform to the latest
state of technology and the safety standards laid down in IEC
61010-1/ 2nd edition. If used improperly, there is a risk of damage
to persons and property.
The device is assigned to protection class I according to IEC
61010-1 and is equipped with a protective earth connector.
 The device may only be operated by suitably qualified
personnel.
For the purpose of these instructions, all persons who are familiar
with the installation, assembly, connection, inspection of
connections and operation of the analyzer and who have
completed training in at least one of the following areas:
- switching on/off, enabling, earthing and identification of
electrical circuits and devices/systems according to the
applicable safety standards;
- maintenance and operation of appropriate safety gear, in
accordance with the applicable safety standards;
- first aid.
 Ensure that all persons using the device have read and fully
understood the operating manual and safety instructions.
 The device may only be used under certain ambient
conditions. Ensure that the actual ambient conditions conform
to the admissible conditions laid down in chapter "Technical
data".
 During operation, ensure that the cooling vents are not
obstructed.
 Always comply with the instructions in chapter "Transport and
storage".
 Do not use the device for any other purpose than the
measuring of voltages and currents that are within the
measuring ranges and categories, including voltage to earth,
laid down in chapter "Technical Data".
Improper use shall void all warranty.
 The warranty period for fault free operation is limited to
2 years from the date of purchase.
 The warranty period for accuracy is 2 years.
 Ensure that the power and connecting cables used with the
device are in proper working order.
 Ensure that the protective earth connector of the power lead is
connected according to the instructions to the low-resistance
unit earth cable.
 Ensure that the power and connecting cables as well as all
accessories used in conjunction with the device are in proper
working order and clean.
Protection class
Qualified
personnel
Safe operation
Proper use
Warranty
Electrical
connections

General Safety Instructions
Power Analyzer NORMA 4000, NORMA 5000 5
EO1111G REV G
 Install the device in such a way that its power cable is
accessible at all times and can easily be disconnected.
 For connection work, do not work on your own but in teams of
at least two persons.
 Do not use the device, if the housing or an operating element
is damaged.
 Ensure that the connected devices work properly.
 In the case of a direct connection to current circuits (without
transformer or shunt), ensure that the circuit is protected to
max. 16 A.
 Do not open the housing. Do not carry out any repairs and do
not replace any component parts of the device.
 Damaged connecting and power leads must be repaired or
replaced by an authorised service technician.
 Damaged or defective devices may only be repaired by
authorised, specialised technicians.
 Only use the accessories supplied with the device or
specifically available as optional equipment for your model.
 Ensure that any third-party accessories used in conjunction
with the device conform to the IEC 61010-2-031/-032 standard
and are suitable for the respective measuring voltage range.
 If you detect any damage to the housing, controls, power
cable, connecting leads or connected devices, immediately
disconnect the unit from the power supply.
 If you are in doubt as regards the safe operation of the device,
immediately shut down the unit and the respective
accessories, secure them against inadvertent switching on and
bring them to an authorised service agent.
Risks during
operation
Maintenance and
repairs
Accessories
Shutting down

General Safety Instructions
6Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
2.1 Safety instructions on the device housing
 The mains connection must conform to the following
ranges/values:
Mains:
85...264 VAC, 47...440 Hz/ 40 VA
120...370 VDC, 40 VA
The maximum input voltage for over-voltage category CAT II may
not exceed 1000 V to earth ( ).
 Do not remove the cover.
 Refer servicing to qualified personnel.
 The device may only be used indoors.
Conformity mark re. EC Low Voltage Directive 73/23/EEC and
EMC Directive 89/336/EEC.
Mains connection
Input voltage and
maintenance
Indoor use only

Design and functions
Power Analyzer NORMA 4000, NORMA 5000 7
EO1111G REV G
3 Design and functions
This chapter provides an overview of the terminals, ports and
interfaces of the power analyzer, as well as a list of display and
operating devices and a brief introduction to the basic functions of
the unit.
3.1 Terminals (rear of housing)
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
4 5 6 7
810
123
ALL INPUTS MAX 1000V CATII TO
11
12
1 Measuring inputs for current (channels 1 ... 6)
HI: Conductor, positive
LO: Conductor, negative
2 Measuring inputs for shunts (channels 1 ... 6)
3 Measuring inputs for voltage (channels 1 ... 6)
HI: Conductor, positive
LO: Conductor, negative
4 IEEE488 interface (optional)
5 Port for PI1 interface
6 Serial interface (RS 232)
7 Power switch
I: ON
0: OFF
8 Mains connection
9 Input for external synchronisation signal
10 IF2 network adapter (LAN) (optional)
11 Warning regarding max. voltage to earth
12 Warning symbol; danger, observe operating instructions

Design and functions
8Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
3.2 Operating controls and display
The display, operating controls and function keys are located at
the front of the device. The display consists of a menu bar, a
section in which the measured values and the channel settings are
shown and the assignment bar for the function keys.
1 Display of configuration;
menu item General Setup
2 Menu item Integration Setup / Motor-Generator Setup
3 Measurement status / display of average time
4 Display of synchronisation source frequency;
menu item Timing & Sync Setup
5 Display of time;
menu item Clock Setup
6 Navigation keys
7 Measuring keys
8 Display for measured values
9 Function keys
10 Assignment bar for function keys
11 Information row
12 Status display for channels 1 to 6 (including measuring
range, coupling and modulation bar);
menu items Current Channel Setup and Voltage
Channel Setup
13 Menu bar with menu items
Status Description
M Memory record active
T Wait for Trigger start condition(memory)
R Measurement active (Run mode)
H Measurement stopped (Hold mode)
∫Integration of selected values active

Design and functions
Power Analyzer NORMA 4000, NORMA 5000 9
EO1111G REV G
26 27
25
24
23
22
14
27
15
16
17
18
19
21 20
14 Enter: confirm; call up menu
15 Numerical display
16 Recorder
17 Hold/Run: start/stop measurement
18 Oscilloscope diagrams
19 Print
20 Show power, current, voltage
21 Save
22 Select channel
23 Vector display
24 Show totals of all channels
25 Frequency analysis
26 Esc: cancel, up one menu level
27 Cursor keys: up/down; left/right
Use the navigation keys (6, page 8) and (27) to navigate through
the display and the menus.
The active menu item, display or entry field in which your cursor is
located is backlit.
Press Esc (26) to cancel an entry without saving or to go to the
next higher menu level.
Press Enter (14) to call up a menu or to confirm an entry made in a
menu.
Press the measuring keys (7, page 8) and (15) to (25) to select the
display mode and the saving/output functions for measured values.
The assignment of the function keys (9, page 8) varies, depending
on the current menu. The current key assignment is shown on the
assignment bar (10, page 8) located above the function keys.
Navigation and
measuring keys
Navigation
through display

Design and functions
10 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
The assignment of the function keys varies, depending on the
display or menu you have selected.
Name Function
Default Scale axes automatically
DELETE Delete configuration
Detail View details of a measured value
Freq Set frequency analysis filter
Info… View system information and version number of
unit firmware
LCD - Reduce brightness of display
LCD + Increase brightness of display
lin/log View linear/logarithmic scale
LOAD Load configuration
mode View table with harmonics
Offset Adjust zero (with cursor keys)
rms/h01 View rms values or H01 fundamental
SAVE Save configuration
Scale Adjust scales of axes (with cursor keys)
scroll Scroll through display
Set all Adopt configuration or set value for all channels
tab/gra View measured values in table/graph
U/I Switch between voltage channel configuration
and current channel configuration (in General
Setup)
zoom Adjust scales of axes (with cursor keys)
∫View electrical work reference power or
recuperated power
∫Clear Set electrical work integration to zero
∫Start Start electrical work integration
∫Stop Stop electrical work integration
3.3 Functions
The power analyzer allows for the analysis of currents from DC to
several MHz. Voltage values up to 1000 V and currents up to 20 A
are measured accurately, and the respective real, idle and
apparent power is calculated. The limit of error is between 0.1%
and 0.3%, depending on the model. For DC and AC up to a few
MHz, it is not affected by the wave shape, frequency or phase
position. The measuring range can be extended by connecting
shunts or clamps. When extending the range using third-party
shunts or clamp the extra errors due to these devices should be
considered. The device caters for simultaneous measuring in up to
6 channels.
Overview of
function keys

Startup
Power Analyzer NORMA 4000, NORMA 5000 11
EO1111G REV G
4 Startup
4.1 Checking of delivery
 Before commencing work with the analyzer, check the delivery
to ensure that it is compete, using the following list and the
delivery specifications:
- 1 power analyzer
- 1 operating manual
- 1 mains cable
- 1 calibration certificate
- 1 to 6 voltage and current channel modules, according to
the delivery specifications
4.2 Installation and switching on
 Follow the safety instructions regarding ambient conditions and
location of installation.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution
 Caution! The device is connected to the power mains, and a
number of internal components are live with dangerous voltage
levels. To remain safe during operation, the device must be
equipped with a low-resistance connection to the earth.
 Therefore check the mains socket and its wiring!
 Place the device onto a clean and stable surface.
 If necessary adjust the feet at the base of the unit to improve
the view onto the display.
 Connect the device to the mains socket, using the power lead.
 Set the power switch at the rear of the housing to position "I".
The device is now ready for operation. The start screen is
displayed.
 Set the power switch at the rear of the housing to position "0".
 If the device is not to be used for a prolonged period of time,
disconnect the plug from the mains socket.
Installation
Switching device
on
Switching device
off

Connection to Circuits
12 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
5 Connection to Circuits
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
 By connecting the unit to circuits, the terminals and certain
parts inside the device are live.
 In order to ensure safe operation, first connect the device to the
power supply.
 If possible, open the circuit before establishing a connection to
the analyzer.
 Prior to connecting the circuits, ensure that the maximum
measuring voltage and max. voltage to earth (1000V CATII and
600V CATIII respectively) are not exceeded.
 Do not use leads and accessories that do not fulfil the relevant
safety standards, as this could lead to serious injury or death
from electric shock!
5.1 Connecting sequence
When connecting a circuit to the power analyzer, for safety
reasons, proceed in the sequence outlined below:
1. Connect the power analyzer to the mains socket.
The analyzer is now connected to the protective earth wire.
2. Switch on the power analyzer.
3. Connect the measuring circuit as shown in the connection
diagram.
Ensure that the phase is connected to HI so that the energy
flow is from HI to LO; to ensure that the measured values are
indicated correctly.
4. Connect the circuit to the power supply.
5.2 Overview
The power analyzer offers the following options for connection:
Measurement direct with shunt with
transducer
1-phase
measurement
page 13 page 14 page 15
Aron connection page 16 page 17 page 18
3-phase
measurement in 4-
wire system
page 19 page 20 -
Note
When connecting a 4-channel device for electrical efficiency
analysis, the 3-phase power cables for this measurement should be
connected to the measuring channels 1 to 3, so that the efficiency
can be calculated and displayed directly on the device.

Connection to Circuits
Power Analyzer NORMA 4000, NORMA 5000 13
EO1111G REV G
5.3 1-phase measurement
5.3.1 Direct connection
 Ensure that there is no overload at the current input of the
power analyzer.
 If necessary, install appropriate fuses.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO
N
L1
max. 10 m
UI

Connection to Circuits
14 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
5.3.2 With shunt
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution! Do not touch sense terminals!
The sense terminals at the shunts are powered with the same
voltage as the power connections.
Shunts are not isolated.
 Never touch the sense terminals at the shunts.
 The connecting leads to the shunts should be as short as
possible in order to prevent noise voltages.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
UI
N
L1
max. 10 m
LOHI
Guard
*1
Last
ALL INPUTS MAX 1000V CATII TO
UI
N
L1
max. 10 m
LO HI
Guard
*1
Last
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO
*1 We recommend using MCS measuring leads for triaxial shunts and MCP leads
for planar shunts. Triaxial shunts are equipped with guard connectors in the
plugs, while planar shuts are equipped with guard sockets.

Connection to Circuits
Power Analyzer NORMA 4000, NORMA 5000 15
EO1111G REV G
5.3.3 With voltage and current transducer
Fehler!AutoText-Eintragnichtdefiniert.
Risk of damage to transducer, due to overload!
 Check rating of transducer.
Note
When using transducers, please note that transducer errors limit
the measuring bandwidth and reduce the intrinsic uncertainty.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
S
1
S
2
an
AN
P
1
P
2
U I
N
L1
max. 10 m
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO

Connection to Circuits
16 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
5.4 Aron circuit (triaxial/guard technique)
5.4.1 Direct connection
the Aron circuit is only available for 3-wire networks.
It is only required to measure two phases (currents I1 and I2 in the
connection diagram), as I1+I2+I3 must be 0.
Important
In most cases, the Aron circuit is not acceptable for measurements
on inverters, as there are capacitive leakage currents from the
windings to the housing!
 Ensure that there is no overload at the current input of the
power analyzer.
 If necessary, install appropriate fuses.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO
L2
max. 10 m
L1
L3
I
1
I
2
U
13
U
23

Connection to Circuits
Power Analyzer NORMA 4000, NORMA 5000 17
EO1111G REV G
5.4.2 With shunt
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution! Do not touch sense terminals!
The sense terminals at the shunts are powered with the same
voltage as the power connections.
Shunts are not isolated.
 Never touch the sense terminals at the shunts.
 The connecting leads to the shunts should be as short as
possible in order to prevent noise voltages.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
L3
L2
max. 10 m
LO
HI Last
LO
HI
U
13
I
1
Guard
*1
Guard
*1
L1
U
23
I
2
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO

Connection to Circuits
18 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
5.4.3 With voltage and current transducer
Fehler!AutoText-Eintragnichtdefiniert.
Risk of damage to transducer due to overload!
 Check rating of transducer.
Note
When using transducers, please note that transducer errors limit
the measuring bandwidth and reduce the intrinsic uncertainty.
Fehler!AutoText-Eintragnichtdefiniert.
Danger! Risk of electrocution!
Risk of injury when touching connections, internal circuits and
measuring devices that are not earthed.
 Always adhere to the instructions regarding the sequence of
connection (see page 12).
1
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
2
HI
CURRENT
LO
10 A max
PROBE
EXT.SHUNT
10 V max
HI
VOLTAGE
LO
1000 V max
3
ALL INPUTS MAX 1000V CATII TO
max. 10 m
L2
L1
L3
CBA
abc
P1
L1
S1
L1
P2
L1
S2
L1
P1
L3
S1
L3
P2
L3
S2
L3
I
3
I
1
