SOSUL
SOSUL TOP 2-3 M

2
Congratulaon for having chosen an equipment LEMI produced by Brusaferri & C.
This table has been designed and built using state of the art technologies and processes to guarantee
the best reliability in the me and ensure maximum safety.
This table is suitable for cosmec face and body treatments, massages, SPA treatments, relax.
For a correct and safe operaon of the table is essenal to carefully read and observe what is indicated
in this manual. All documentaon accompanying the table – and in parcular this manual – must be
carefully preserved for future reference.
Complimen per aver scelto un’arezzatura LEMI prodoa da Brusaferri & C.
Questo leno è stato progeato e costruito ulizzando tecnologie e procedimen allo stato dell’arte
per garanrne la migliore adabilità nel tempo ed assicurarne la massima sicurezza.
Questo leno è adao per traamen esteci viso-corpo, massaggi, traamen SPA, relax.
Per un correo e sicuro funzionamento del leno è indispensabile leggere aentamente ed osservare
quanto indicato nel presente manuale. Tua la documentazione di corredo del leno - ed in parcolar
modo il presente manuale - deve essere accuratamente conservata per riferimen futuri.
Félicitaons d’avoir choisi un équipement fabriqué par Brusaferri & C.
Cee table a étée conçue et construite en ulisant des technologies et des procédés de qualité élevée
an de garanr la plus grande abilité à long terme et d’assurer la plus grande sécurité.
Cee table de massage a été conçue pour les traitements esthéques visage-corps, massages, relax.
Pour un bon fonconnement du fauteuil il est indispensable de lire aenvement et de respecter les
indicaons fournies par la présente noce. Toute la documentaon fournie avec la table doit être soi-
gneusement conservée pour ulisaon ultérieure.
Herzlichen Glückwunsch für eine Ausrüstung LEMI erzeugten von Brusaferri & C. gewählt zu haben.
Diese Liege wurde verwendend die modernster Technologien und Prozesse entwickelt und gebaut, um
die beste Zuverlässigkeit in der Zeit und die maximale Sicherheit zu versichern.
Diese Liege ist für ästhesche Gesichts- und Körperbehandlungen, Massagen, SPA- Behandlungen und
Entspannung geeignet. Für einen korrekten und sicheren Betrieb der Liege ist es wichg, was in diesem
Handbuch angegeben sorgfälg zu lesen und beachten,. Die ganze Unterlagen geliefert mit der Liege –
und insbesondere dieses Handbuch – es muss sorgfälg für die Zukun erhalten bleiben.
EN
IT
FR
DE

3
INTRODUCTION
TRANSPORT AND INSTALLATION
ENVIRONMENTAL WORKING CONDITIONS AND STORAGE
PRELIMINARY CHECKS
DESCRIPTION OF THE TABLE
OPTIONS ON DEMAND
INSTRUCTION FOR USE
USE OF THE TABLE
MAINTENANCE
NOTICE TO OPERATORS AND RESIDUAL RISKS
SPARE PARTS
DISMANTLE
DISPOSAL OF OBSOLETE EQUIPMENT
DIMENSION
pag. 4
pag. 5
pag. 7
pag. 7
pag. 8
pag. 9
pag. 10
pag. 13
pag. 13
pag. 15
pag. 15
pag. 15
pag. 15
pag. 16
EN- INSTRUCTION FOR USE
1.
9.
5.
13.
3.
11.
7.
2.
10.
6.
4.
12.
8.

4
The successful and safe operaon of the table is guaranteed only if it is used in ac-
cordance with the specicaons in this manual and, in general, in the accompanying
documentaon; therefore it is essenal to carefully read and keep all the relave docu-
mentaon.
Although the table is equipped with acve and passive safety features, not all risks can be avoided due to its
incorrect use.
You must always make sure that all users have fully understood the rules of use; the manufacturer declines
any responsibility for damage to persons or property resulng from improper use of the device.
Do not remove or damage the labels, noces and warnings placed on side of the table. In case you need to
restore them, please contact the manufacturer.
The manufacturer Brusaferri & C., declines any and every responsibility for failure to observe the rules of
safety and prevenon described in the various secons of this manual and for any damage caused by impro-
per use. All works on the table (maintenance, adjustments, repairs, cleaning) must be carried out by suitably
trained personnel and in accordance with what is indicated in this manual.
1.2. Preservaon of the manual
This operang manual should be kept for future reference. We recommend:
1.1. Use purpose
The table has been designed and built to perform cosmec face and body treatments, massages, SPA treatments,
physiotherapy, pressotherapy and diagnosc visits.
In the case of sale or transfer of the table to another person, this manual and its annexes should be delivered intact to
the new users.
Keep the manual in a place accessible and known to all operators, protected from moisture and heat and pro-
tected from the direct sun beams:
Use the manual in order not to damage any part of the content: do not remove, tear or modify any part of the
manual.
WARNING! It is forbidden any use of the table other than that described in this ma-
nual. Brusaferri & C. declines any responsibility for malfuncons or damages to per-
sons or property due to uses other than those specied in this manual. The table
should be used only by personnel who are informed about the use mode, operaon
and its safety equipment.
WARNING! Please read this operaon manual before using the table. Anyone who uses
the table should be properly informed on the parts of this manual relevant to the ope-
raons to be performed.
1. INTRODUCTION

5
2.1. Handling and removal from the packaging
The table can be raised and moved manually by two or four people, taking it exclusively from the 4 support feet.
The table is shipped packed in a carton box.
Open the box so you can freely raise the table; remove it from the packaging, taking it from the 4 feet and pull it
upwards.
2.2. Flooring
The oor on which the table will be placed must be solid, smooth, horizontal and adequate to support its
weight and ensure the stability.
2.3. Lighng
The user must ensure that the lighng of the work areas is sucient to allow a good view of the operaons
and all elements of the table; the level of lighng should be in accordance with the UNI EN 12464-1:2004; in
parcular should be avoided shadows and annoying glare.
2.4. Posioning
The posion of the table compared to xed obstacles must be such as to allow the easy passage for the
use and maintenance; in parcular, the minimum space to allow the passage of persons shall be equal to
650 mm (in accordance with EN 547-1:1996). To prevent crushing of the whole body the minimum distance
between the leg rest fully stretched and the back completely lowered and xed obstacles must be equal
to 500 mm.
The weight of the table is equal to 77 kg.
WARNING! It is strictly forbidden to remove the table by
liing it from the top (maress).
WARNING! Do not use knives or box cuers to open the box so as not to risk dama-
ging the table and in parcular the pudding.
2. TRANSPORT AND INSTALLATION

6
2.6. Connecons
Insert the plug into a suitable power outlet.
If there is incompability between the socket and the plug of the table, replace the socket with a suitable type by
professionally qualied personnel.
Pull the plug from the power outlet holding the plug, not the cable.
The power supply must be supplied to the unit by a line:
Protected against overcurrent by an automac circuit breaker (circuit breaker) or fuses, properly sized; the ope-
rang current of the protecons must be as low as possible taking into consideraon the maximum absorpon
of the device;
Equipped with a device sensive to insulaon failure (dierenal) with operang current low enough; this device
must be posioned downstream of the overcurrent protecve device (or be integrated with it); Having cables
with secon suitable for the power absorbed by the appliance.
The table must also be connected to an external unipotenal protecon circuit (grounding)
adequate.
WARNING! It is strongly recommended to insert the plug into a single outlet exclusively
reserved to the device. We do not recommend the use of mulple sockets (power strip),
adopters and patch cords. The cable must not be bent.
2.5. Power supply
The system of power supply must have voltage and frequency equal to the rated voltage and frequency of the power
supply of the device and be appropriate to the installed capacity, as indicated on the idencaon plate of the table.
Voltage
Frequency
Absorpon
Transformer
Duty cycle
230/100 V
50/60 Hz
30 W
Primary 230V - 110V
Secondary 25V 120VA
10%, Max 2 min ON/ 18 min OFF

7
WARNING! Do not expose the table to an excessively humid environment. If the
table gets wet, remove the plug from the outlet and have it checked by an Authori-
zed Service Centre.
WARNING! The table was not designed to work in environments with explosice at-
mospheres , in the presence of ne dust or corrosive gases, in the presence of acids,
corrisive agents, salt; it is also not suitable for operaon in the presence of ionizing
and non-ionzing radiaon (X-rays, laser, microwaves, ultraviolet rays).
STORAGE! For the correct funconing of the electrical equipment the storage of the
table must be at a temperature between -25° C and +55° C, and only for short periods
not exceeding 24 hours, to +70°C.
The table has no special requirements for storage, provided that it takes place in
a closed and dry rooms; this condion should also be ensured during all phases of
transport.
The table has been designed and built to operate in a closed and dry room. The ambient operang condion are:
If the environmental condions are parcularly crical it is advisable to provide the room with an adequate air condi-
oning system to bring the humidity and temperature values within acceptable limits.
Temperature: 5° ÷ 40° C
Humidity: 30% ÷ 95% without condensaon.
3. ENVIRONMENTAL WORKING
CONDITIONS AND STORAGE
4. PRELIMINARY CHECK
Before the seng at work of the table, make sure that:
There is no damage to the equipment due to the phases of transport and handling; eventually proceed
to solve these problems by contacng Brusaferri & C.;
All packaging components have been removed;
Check that the supply voltage is equal to the rated one as dened in § 2.5. Power Supply;
Check the eciency of the operaon of the control equipment.
Before using the table for the rst me, make sure qualied personnel carry out some tests in safety condi-
ons.

8
5. DESCRIPTION OF THE TABLE
SOSUL
SOSUL 2000
Seat
Seat
Legs
Legs
Foot pedal
control
Foot pedal
control
Lever for back
rest adjustment
Lever for back
rest adjustment
Zak headrest
Face hole head rest
Predisposion
for roll holder
Predisposion for
roll holder
Small adjustable
foot
Back
Back
Predisposion for
arm rests
Small adjustable
foot

9
6. OPTION ON DEMAND
6.1. Heang
OFF = heang o (led: ON)
ON = heang on (led: ON + LOW)
LOW = lower temperature (led: ON + LOW)
HIGH = higher temperature (led: ON + HIGH)
2H = heang is on for 2 hours (LOW or HIGH), then
turn o automacally.
When acvated, the led blinks ll the end of the
second hour.
You can stop heang in any me pressing OFF but-
ton.
Usually, heang stops automacally (LOW or HIGH
temperature) aer 1 hour from switch on.
SOSUL TOP
Seat
Legs
Foot pedal
control
Lever for back
rest adjustment
Face hole head rest
Predisposion for
roll holder
Small adjustable
foot
Back
Predisposion for
arm rests

10
6.2. Arm rests
To assemble the arm rests, place them in the predisposed support and screw the knobs in the clutches
situated on both sides near the backrest.
6.3. Arm support
To install/remove the arm support, unscrew the knob situated
under the backrest.
6.4. Wheels
You can install the braked wheels on the table by unscrewing the 4 small adjustable feet.
ATTENTION! Always block the brake of each wheel before the client sit on the table.
6.5. No hole head rest
Remove the face hole head rest cushion from the wooden support
(it is xed by Velcro®) and place the cushion without hole.
7.1. Operator
The table is controlled by an operator through the foot pedal control; the operator must posion themselves
so as to have complete view of the controlled parts and of the paent.
7. INSTRUCTION FOR USE
WARNING! During the funconing of the table the operator should always remain
in the vicinity of the controls; it is forbidden to leave the table unaended during its
operaon.
Operators should pay aenon to avoid creang potenally dangerous situaons for
their own or other’s safety.
All the people working on the table must be properly trained on the correct methods
of work and informed about its proper funconing. They also need to be aware of the
parts of this documentaon relevant to their work.
The heang works with the pressure of the body, so we do not feel any sensaon of heat if it is not stressed
by the weight of a body. It is recommended to always leave a weight laid (for example towels or magazines)
to maintain the minimum temperature.
ATTENTION! It is absolutely necessary TURN OFF THE HEATING (both led o) WHEN
THE TABLE IS NOT USED AND AT THE END OF EACH WORKING DAY.
Knob
Arm support
No hole
cushion
Wooden
support

11
7.2. Use of maress
In order to ensure hygiene and safety to your paents and ensure long life of the maress, we recommend
you always cover it with a towel/bed cover and disposable sheets of cartene before starng any treatment.
Both the operator and the paent should not wear rings, necklaces, bracelets, watches or other objects that
may damage the maress.
7.3. Controls
The table can be controlled by a foot pedal control. All controls are maintained acon, that is releasing the
control pedal the moon stops.
Pedal 1 = Base UP
Pedal 2 = Base DOWN
SOSUL / SOSUL 2000 PEDAL CONTROL
UP DOWN
1 2
Pedal 1 = Base up
Pedal 2 = Seat up (relax posion)
Pedal 3 = Base down
Pedal 4 = Seat down (at posion)
SOSUL TOP 2M PEDAL CONTROL
BASE
UP
SEAT
UP
BASE
DOWN
SEAT
DOWN
1 2 43

12
7.4. Adjustment of the head
To remove or extend the head cushion, remove the buery screw
under the back rest (2).
To adjust the inclinaon, open the black handle under the
wooden support (1).
7.5. Manual back adjustment (Sosul 2000 and Sosul Top 2M)
To raise the back rest, hold it with one hand and press the lever with the other hand .
To lower the back rest (horizontal posion), press the lever and push down the back.
7.6. Manual leg adjustment
To raise the leg (nal part of the maress), open the handle and pull
upwards the leg maress.
Fix into the required posion by closing the handle.
7.7. Manual seat/leg adjustment (relax posion – Sosul 2000)
4 dierent inclinaons may be obtained by seizing the ending part of legs
maress and pulling it gradually upwards.
To lower the legs, pull again the legs maress upwards to the limit and
follow the movement downwards.
Pedal 1 = Back up
Pedal 2 = Back down
Pedal 3 = Seat up (relax posion)
Pedal 4 = Seat down (at posion)
Pedal 1+2 = Base up
Pedale 3+4 = Base down
SOSUL TOP 3M PEDAL CONTROL
(2)
(1)
Handle
BASE
DOWN
BASE
UP
BACK
UP
BACK
DOWN
SEAT
UP
SEAT
DOWN
1 2 43

13
On the table, only one person can get up; the person must go up/down when the table is in the basic posion
going up on the seat.
150 kg (max. paent weight) 2000 N (Safety load)
The table has been designed and constructed so as to reduce as much as possible the necessary maintenance
and ensure proper funconing over the years without any problems.
During any intervenon on the table, it is recommended to follow the instrucons given in this secon.
8. USE OF THE TABLE
9. MAINTENANCE
WARNING! Stretch out on the table always sing properly
in the central part of the seat.
Do not sit or lean on the side of the feet or of the head.
WARNING! The limbs of the paent must always be on the table. The operator must
always inform the paent when he moves the table.
WARNING! Be careful to make sure that the table or its electrical parts are not wet
and that liquids become not stagnant on the table itself; immediately wipe up any li-
quids – including physiological liquids of the paent – which may end up on the table.
To avoid shock hazard, do not connect or disconnect the power plug with wet hands.
Do not use the table barefoot.
WARNING! All intervenons on the table must be carried out by competent and trai-
ned personnel on the methods to operate correctly and safety.
Do not make any acon on the table moving, and always check that the plug con-
necng to power supply is disconnected; bring the power plug next to you during the
execuon of the intervenon on the table so you can check at any me the actual
separaon.

14
9.1. General Checks
Constantly check the general condion of the table: the integrity of the protecons, the electrical equipment
and the condion of the pads.
9.2. Extraordinary Maintenance
Any extraordinary maintenance must be performed by qualied personnel of the technical service Brusaferri
& C. or Service Centre authorized by the manufacturer.
Informaon about the Authorized Service Centre to which you can turn, can be obtained directly from the
manufacturer Brusaferri & C srl – phone [phone] – mail: [email protected]
For a correct and quickly resoluon of the problem, it is necessary to communicate the model and the serial
number of the table and the descripon of the defect, or what are the visible problems, and under what
condion it occurs. The broken table, if under warranty, must be sent to the Service Centre together with the
cercate of guarantee, transport charges must be paid by the purchaser.
9.3. Authorized Personnel
Repairs and maintenance of the table can be carried out exclusively by competent personnel, that is of Bru-
saferri & C. or authorized by it. Informaon on the sta to contact for possible intervenons can be obtained
directly from Brusaferri & C.
9.4. Cleaning
Each me you make a treatment, always cover the maress with towels or disposable towels before to let lie
down the paent (See §7.2. Use of the maress).
Pay parcular aenon to the jeans that can stain the covering without any possibility of being
removed.
Clean the table before each use, paying parcular aenon to remove all traces of physiological
uids of the previous paent.
To clean the table use a cloth and lukewarm water (if necessary diluted neutral detergent). If
necessary, use a non-aggressive disinfectant, then wipe o with a clean dry cloth.
Do not use products such as alcohol, acetone, bleach, paint thinner, gasoline.
WARNING! Do not use the table if any component is found to be not perfectly intact
or in service.
In this case, put the table out of service by disconnecng the power plug immediately
and contact an Authorized Service Centre.
WARNING! Any form of warranty expires if intervenons are carried out on the table
by someone not authorized by Brusaferri & C.

15
All the spare parts must be requested to Brusaferri & C. that will supply them directly or will give you indicaons
on the place where they can be found. Please note that any extraordinary maintenance must be performed by
personnel of Brusaferri & C. or authorized by it.
If the table becomes inoperave or is not to be used for an extended period of me, it is recom-
mended to remove it from service and remove the plug from the socket. All materials used to ma-
nufacture the table are not toxic or hazardous to the health of operators, so they can be handled
without special precauons. In case of disable of the table you should perform a separaon of dierent
materials for subsequent reuse or dierenated eliminaon. All electrical and electronic products should be
separately disposed, using specic collecon facilies appointed by the Government or the Local Authories.
WARNING! Be careful not to spray liquids on the electrical equipments, pedal/pu-
sh-buon strip and on the protecons of the table.
You must follow the handling direcons given in the safety data sheets of the deter-
gents used.
WARNING! Do not bring the limbs near the elements in movements and in parcular
to the points described above.
WARNING! Any form of warranty expires if they are used spare parts other than those
originally ed.
10. NOTICE TO OPERATORS AND RESIDUAL RISKS
11. SPARE PARTS
12. DISMANTLE
The correct disposal of the obsolete equipment will help to prevent potenal negave eects on
human health and the environment. For informaon, contact your Local Council or the Waste Di-
sposal Service.
13. DISPOSAL OF OBSOLETE EQUIPMENT
During the movement of the table can create areas of potenal risk :
Crushing between moving parts of the maress and frame;
Entanglement between the moving parts of the frame;

16
DIMENSIONS
Dimensions in cm and inches
Minimum and maximum height in cenmeters, intermediate version of the 12 cm thick maress
SOSUL
SOSUL 2000 - SOSUL TOP
216 cm/85”
33cm/13” 171 cm/67” 68 cm/27”
H min. 48 cm/19”
53°
16°
H max. 86 cm/34”
205 cm/81”
175 cm/69”
H min. 54 cm/21”
H max. 94 cm/37”
74 cm/29”
25°
53°
30 cm/12”

17
IT- INDICE
INTRODUZIONE
TRASPORTO E INSTALLAZIONE
CONDIZIONI DI FUNZIONAMENTO E IMMAGAZZINAMENTO
VERIFICHE PRELIMINARI
DESCRIZIONE DEL LETTO
ACCESSORI A RICHIESTA
MODALITA’ D’USO
UTILIZZO DEL LETTINO
MANUTENZIONE
AVVERTENZE AGLI OPERATORI E RISCHI RESIDUI
PEZZI DI RICAMBIO
MESSA FUORI SERVIZIO
SMALTIMENTO APPARECCHIATURE OBSOLETE
DIMENSIONE
pag. 18
pag. 19
pag. 21
pag. 22
pag. 22
pag. 23
pag. 25
pag. 27
pag. 27
pag. 29
pag. 29
pag. 29
pag. 29
pag. 30
1.
9.
5.
13.
3.
11.
7.
2.
10.
6.
4.
12.
8.

18
Il correo e sicuro funzionamento del leno è assicurato solo se viene ulizzato in
accordo con quanto indicato nel presente manuale e, in generale, nella documentazione
di accompagnamento; pertanto è indispensabile leggere e conservare accuratamente
tua la relava documentazione.
Pur essendo il leno dotato di sicurezze ave e passive, non possono essere evita tu i rischi dovu
ad un suo ulizzo non correo.È necessario accertarsi sempre che tu gli operatori abbiano compreso
completamente le norme d’uso; si declina ogni responsabilità per danni a persone o cose derivan da un
uso improprio dell’apparecchio. Non rimuovere o deteriorare echee, scrie e avvertenze poste su par
del leno. In caso sia necessario riprisnarle, contaare il costruore. Il costruore, Brusaferri & C., declina
ogni e qualsiasi responsabilità per la mancata osservanza delle norme di sicurezza e di prevenzione descrie
nelle varie sezioni del presente manuale e per danni causa da un ulizzo improprio.
Tu gli interven sul leno (manutenzioni, regolazioni, riparazioni, pulizia) devono essere eeua da
personale opportunamente addestrato e secondo quanto indicato nel presente manuale.
1.2. Conservazione del manuale
Il presente manuale operavo deve essere conservato per qualsiasi futura consultazione. Si consiglia di:
1.1. Desnazione d’uso
Il leno è stato progeato e costruito per l’esecuzione di traamen esteci viso-corpo, massaggi, traa-
men SPA.
Nel caso di vendita o trasferimento del leno ad altro soggeo, il presente manuale e i relavi allega devo-
no essere consegna, integri, al nuovo ulizzatore
Conservare il manuale in un luogo accessibile e noto a tu gli operatori, proteo da umidità e calore
e al riparo dai raggi dire del sole;
Impiegare il manuale in modo da non danneggiarne tuo o in parte il contenuto: non asportare,
strappare o modicare alcuna parte del manuale.
ATTENZIONE! È vietato ogni ulizzo del leno diverso da quello descrio nel presen-
te manuale. Brusaferri & C. declina ogni responsabilità per malfunzionamen o dan-
neggiamen a persone o cose dovute ad ulizzi diversi da quelli indica nel presente
manuale. Il leno deve essere ulizzato solo da personale informato delle modalità
di ulizzo, del funzionamento e delle sue dotazioni di sicurezza.
ATTENZIONE! Leggere aentamente il presente manuale operavo prima di ulizzare il
leno. Chiunque ulizzi il leno deve essere adeguatamente informato sulle par del
presente manuale operavo rilevan per le operazioni che dovrà svolgere.
1. INTRODUZIONE

19
2.1. Movimentazione e rimozione dall’imballo
Il leno può essere sollevato e movimentato manualmente da due o quaro persone, prendendolo esclusi-
vamente per i 4 piedini d’appoggio.
Il leno viene spedito imballato in uno scatolone di cartone.
Aprire lo scatolone in modo da poter sollevare liberamente il leno; rimuoverlo dall’imballo prendendolo
per i 4 piedini e slarlo verso l’alto
2.2. Pavimentazione
La pavimentazione sulla quale il leno verrà appoggiato deve essere compaa, liscia, orizzontale ed adegua-
ta a sostenerne il peso e a garanrne la stabilità. Regolare eventualmente avvitando o svitando i 4 piedini.
2.3. Illuminazione
L’ulizzatore deve garanre che l’illuminazione delle zone di lavoro sia suciente a consenre una buona
visuale delle operazioni e di tu gli elemen del leno; il livello di illuminamento dovrebbe essere confor-
me alla norma UNI EN 12464-1:2004; in parcolare devono essere evitate zone d’ombra ed abbagliamen
fasdiosi.
2.4. Posizionamento
La posizione del leno rispeo ad ostacoli ssi deve essere tale da consenre l’agevole passaggio per l’uliz-
zo e la manutenzione; in parcolare lo spazio minimo per consenre il passaggio delle persone deve essere
pari a 650 mm (in conformità alla norma EN 547-1:1996).
Per evitare schiacciamento di tuo il corpo la distanza minima tra l’appoggia gambe completamente allunga-
to e lo schienale completamente abbassato ed ostacoli ssi deve essere pari a 500 mm.
Il peso del leno è pari a 77 kg.
ATTENZIONE! È severamente vietato rimuovere il leno
sollevandolo dalla parte superiore (materasso).
ATTENZIONE! Non ulizzare coltelli o taglierini per aprire la scatola in modo da non
rischiare di danneggiare il leno ed in parcolare l’imbotura.
2. TRASPORTO E INSTALLAZIONE

20
Voltaggio
Frequenza
Assorbimento
Trasfromatore
230/110 V
50/60 Hz
1A max
Primary 230V - 110V
Secondary 25V 120VA
2.6. Collegamen
Inserire la spina in una presa elerica idonea.
Se c’è incompabilità tra la presa e la spina del leno, fare sostuire la presa con un po adao da personale profes-
sionalmente qualicato.
Estrarre la spina dalla presa aerrando la spina e non il cavo.
L’alimentazione elerica deve essere fornita all’apparecchio da una linea:
Protea contro le sovracorren mediante interruore automaco (magnetotermico) o fusibili, adeguatamente
dimensiona; la corrente di intervento delle protezioni deve essere la più bassa possibile tenendo in considera-
zione il massimo assorbimento dell’apparecchio;
Dotata di un disposivo sensibile ai guas dell’isolamento (dierenziale) con corrente di intervento suciente-
mente bassa; tale disposivo deve essere posto a valle del disposivo di protezione contro le sovracorren (o
essere integrato con esso;
Il leno deve essere inoltre collegato ad un circuito di protezione equipotenziale esterno (mes-
sa a terra) adeguato.
ATTENZIONE! È vivamente raccomandato di inserire la spina di alimentazione ad una
presa singola riservata esclusivamente all’apparecchio. Si sconsiglia l’uso di prese mul-
ple (ciabae), adaatori e prolunghe. Il cavo elerico non deve essere piegato.
2.5. Alimentazione elerica
L’impianto di alimentazione elerica deve avere tensione e frequenza pari alla tensione e frequenza nominale di ali-
mentazione dell’apparecchio ed essere adeguato alla potenza installata, come indicato sulla targa di idencazione del
leno.
