Lemuria Technologies PEMF 4000 User manual

PEMF 4000
Users Manual
IMPORTANT: Read Me Before
Powering On Your Machine!

2013 Lemuria Technologies LLC
At the time of publishing the PEMF 000 is not approved by the FDA. It is for experimental use or use
as a supplemental treatment by a qualified health practitioner. The PEMF 000 device and information
contained herein are not intended to replace or delay medical diagnosis or treatment. We make no
claims that the device is capable of preventing, treating or curing any medical condition. And we will
not be liable for any claims stating otherwise. If you know or suspect that you may have a medical con-
dition, please seek medical attention from your doctor. We will not be held liable for injuries or per-
sonal harm resulting from use or misuse of the PEMF 000. This technology was created to support
and demonstrate clinical research obtained from both governmental and institutional publications. By
using the PEMF 000 the customer acknowledges his/her personal responsibility and risk. And there-
fore agrees to release us Lemuria Technologies, our affiliates, partners and other 3rd party associates
from liability resulting from use or misuse of the PEMF 000 technology and its accessories.

Opera ing Ins ruc ions
(1) How o Safely Power Your Machine On, Use I , and Turn I Off
•Select a treatment accessory. On the accessory, you will find two cables with connector plugs on
the end. Insert each plug into the matching adapters on the front panel of the PEMF 000
machine. Once inserted, twist gently to the right to lock the plug into place. You will feel a
gentle click when the plug enters the locked position. Do NOT power on the machine until your
treatment accessory is connected in this way.
•Plug the machine into an 110V 50/60 cycles outlet. Avoid plugging it into outlets that are
connected to a light dimmer.
•Flip the Power Switch on the bottom of the front panel. It will light up green. You will hear fans
turn on inside the machine. The Stop button on the front panel will light up red.
•Set how long the session should last. Turn the radial dial on the Timer anywhere from 1 to 30
minutes. When the timer reaches the time you set, the session will end.
•Press the Start button to start the session. The Start button is located directly above the red Stop
button. When the session starts, the Start button will light up green and the Stop button will go
dark. You will hear the machine make a rhythmic popping sound. As long as this popping
continues, the treatment is in session.
•To stop the treatment before the timer runs out, press the Stop button. It will light up red and the
popping sound will stop. Sometimes, one extra pop may go even after the button has been
pressed. This is normal and safe discharge of unused energy in the machine from the session. If
you press the Start button again, the timer will start over from the beginning for a fresh session.
•After the timer runs out or the Stop button is pressed, you may power down the machine. Flip
the green Power Switch to the off position to turn off the machine. Do NOT flip this switch
while a treatment is in session.
•When the Power Switch is in the off position and the machine is fully powered down, you may
remove the accessory plugs from the adapters in the front panel. To remove the plugs, pull back
on the silver locks with your thumb, twist the plug to the left, and gently pull back to remove
the plug from the adapter. Do NOT remove the treatment accessory while the machine is
powered on.

How o Trea Yourself and O hers
(1) How o Use he Trea men Rope (arranged from weakest to strongest treatment)
•No coil – Simply hold the treatment rope up to the area to be treated. This is best for sensitive
areas such as the eyes, mouth, neck and other areas near the head.
•Direct wrap – Wrap the rope around the body part to be treated. Increase the number of times
the rope wraps around this body part to increase the treatment strength.
•Loop coil – Arrange the rope into a coiled loop. The more loops you add to the coil, the stronger
the treatment will be proportionate to the amount of rope used. In other words, the more rope
you use to make your coil the stronger the treatment will feel. When creating a loop coil with
the rope, make each loop round in shape and at least 12 inches in diameter for a moderate
strength treatment. Hold the center of the coil up to the body part to be treated from multiple
angles for best results. Experiment by holding the loop at different distances from the body to
find the ideal comfort level.
(2) Basic Pro ocol for Trea ing Yourself, O hers and Animals
A. Identify the Source of Pain – Locate the source of pain in your or your patient's body. Touch it if
possible to get a sense of its size, shape and exact location. If the pain is all over, try to identify
where it is the strongest or the most swollen. This is where the treatment will begin.
B. Rate the Pain on a Scale of 0 (No Pain) to 10 (Extreme Pain) – This will give you a good gauge
from which to measure your results immediately after treatment and over the next week as you
monitor your progress. If you will be treating regularly it may prove useful to write this number
down before the Session and again after the Session for future reference.
C. Prepare the Rope – Take the treatment rope (or other accessory) and plug each end of the cable
into the top slots on the front panel of the unit. After inserting, secure each plug by gently
twisting it clockwise until it clicks into place. To remove the cables after powering down the
unit, pull the silver locks back with your thumb and twist the plug counter clockwise.
D. Power the Device On – Plug the power cord into the wall (or specific adapter). You will see a
Power Switch at the bottom of the front panel. When it is flipped into the ON position it will
light up green. Do not switch it on until the treatment accessory is attached.
E. Set the Timer – Each machine ships with the option to treat for up to 30 minutes. If you turn the
timer up all the way, it will pulse continuously without running out. The timer dial does not
move by itself. The end of the treatment will be marked by the green Start button dimming and
the red Stop button lighting up. Average treatment duration is 1 to 5 minutes.

F. Start and Stop Buttons – You will see two buttons next to the timer. When you turn on the unit,
the Stop button lights up red and the Start button stays dark. Press the Start button to begin the
session and it will light up green. Push the Start button again before the session times out to
start a new session of the same duration. Push the Stop button to end the session before the
timer runs out. Always stop the session before powering off the device.
G. Apply the Rope to the Treatment Area – Place the rope coiled with your chosen method on or
near the body so that it surrounds the source of pain identified in Step A. Start by holding the
rope far from the body. After you press the start button in Step H, you can slowly bring it closer
to the body until it touches or until each pulse is felt comfortably.
H. Start the Session – Press the Start button. You will hear a popping sound come through the
machine each pulse. Each pulse may produce a slight muscle contraction and tingling sensation.
The strength of the contraction depends on the number of wraps made on the treatment rope,
distance of the rope from your body, the size of the loop, the Intensity adjustment on the front
panel, and the muscle groups exposed. If you do not experience muscle contractions that is fine
because you are still receiving treatment.
I. Adjust the Intensity and Rep. Rate – There are two knobs on the front panel. One controls the
Intensity, which is the strength of each pulse. And the other controls the Repetition Rate, or
speed of each pulse. Turn the Rep Rate all the way up and focus on adjusting the Intensity.
Adjust the Intensity until the treatment is felt strongly but kept within the range of the user’s
comfort level. As the Intensity is turned up, the Rep Rate will automatically slow down. We
strongly recommend that you leave the Rep Rate dial set to maximum and only adjust the
Intensity dial.
J. On ‘Extra Pulses’ After the Session Ends – Sometimes after the timer runs out the machine will
make an additional pulse. The machine is discharging unused energy built up during the session.
This is normal and happens occasionally. After stopping a session, wait a moment to be sure
that any additional energy has safely discharged before powering the machine down and
removing the treatment accessory.

Safe y Tips
(1) Precau ions - Do not use if you are using a pacemaker, insulin pump or other internally implanted
electronics whose function may be influenced by dynamic magnetic fields and induced electrical
current. Also, do not use this product on the brain. We do not recommend use of this machine on the
brain for any reason.
(2) Make Sure he Trea men Rope is In ac - Inspect the rope before use to make sure the insulation
(ie: white part of the rope) is not torn, damaged or severed such that the wire inside is exposed. If the
insulation is broken, STOP! Do not use that rope. Use a different accessory or visit our website to order
a replacement.
(3) Avoid Using Ou le s Con rolled by a Ligh Dimmer - The magnetic field generated by the PEMF
000 causes small electronics like those inside of light dimmers to malfunction. It will create a surge of
electricity that can damage either your PEMF unit or the light dimmer attached to the outlet. Make sure
the outlet you use is not controlled by a light dimmer before you power the unit on!
( ) Give he Fans Room o Brea he - If the fans are blocked or stopped this may cause internal
damage to your PEMF 000. Always make sure nothing can stop or slow the airflow from the fans
while the unit is powered on. Also ensure that no dust and debris can be sucked up by the fan.
(5) Power Down Before Changing Accessories - Stop the session and power the unit down before
swapping accessories. Make sure the cables snap securely into the connectors before powering on
again.
(6) Dealing wi h “Cleansing Crisis” - The PEMF 000 stimulates cell metabolism functions. These
functions include releasing toxins to be removed by your immune system. Cleansing crisis happens
when the immune system becomes overloaded by detoxifying the body too fast. To help the body flush
the toxins, drink a large glass of water after each treatment.
(7) Always Use he Handles on he Case o Move he Uni - The strain from pulling on the Treatment
Rope connectors or the power cord will damage your device. Tugging may also damage the wires.
Always use the suitcase handles or roll it on its wheels to move, adjust, swivel and transport your unit.
(8) Do No Drop or Toss he Uni - While the case is durable, remember it mainly lends external
protection to the sensitive electronics inside. Dropping and tossing the unit may cause internal damage.
Always put the unit down with care. And make sure the unit is fastened securely and padded for
minimal movement during travel.
(9) S oring Trea men Accessories - Avoid storing the rope or other accessories inside of the suitcase
of the machine where it can press down on the front panel and damage it. Store accessories separately.
(10) Do no expose o wa er - Do not allow the unit to get wet. If it does, dry it as best you can. If the
water gets inside of the machine, wait overnight for it to dry out. Do NOT power it on during this time.
If you receive your unit and find the front panel is wet with dew from changing temperatures during
shipping, make sure to dry it well especially around the accessory connectors and wait overnight for it
to dry internally before powering up.

Ge ing Suppor
Ques ions, Assis ance and Repairs
Please visit our website LemuriaTechnologies.com and click Contact to send a message to Support or
call our Customer Service line at 800-2 6-7608.
Warran y Informa ion
Every device includes a 3 Year Warranty. The warranty is the period of time during which we accept
units for repair or replacement without additional charge. This Warranty is subject to conditions.
Machines returned to us that we find to be damaged beyond repair, shows evidence of extreme usage,
intentionally damaged (ie: abused), serviced or opened by anyone other than a technician approved by
Lemuria Technologies, or revealing a security breach due to tampering, a fee may be applied or service
may be refused. We reserve the right to deny service for the above and for any reason.
Visit our website LemuriaTechnologies.com to read our full policy.

Like PEMF 4000? Help Us Spread he Word!
Did you know that thousands of people in every country of the world struggle with chronic pain and
permanent injury conditions but do not have access to therapy with PEMF 000?
If PEMF 000 made a positive difference in your life, you can help us to help others who are still
searching for a solution!
We understand that 80% of people who purchase the PEMF 000 only intend to use it for themselves,
their families, or at their own clinic. That's why this message is for the 10% of people who would go
out of their way to show others who are struggling like they were just what they are missing, and the
10% of doctors who would share with their peers the stunning results they learned were possible for
even their worst patients.
Our goal is to make PEMF 000 available to neighborhood doctors, chiropractors, and clinics around
the world because they are the first line of defense people turn to for chronic pain management.
We need your help to reach them! There are a couple things you can do to help us get the word out and
we've listed them below. If you take just one of these actions, you can feel good knowing that there is
a person somewhere in the world who is no longer living in unmanageable pain, thanks to your help!
•Tell Us Your S ory
If you experienced positive results using PEMF 000, share your experience with us! We love
to read the stories of people whose lives were changed for the better thanks to this therapy.
And we will share your story with those who are just learning about PEMF 000 and want to
hear from people like you! So please, send us your success stories! Visit the Contact page on
our website and fill out the form there to share your experience with us.
•Join Our Dis ribu or Program
This option is for doctors and store owners who know at least one doctor or clinic who would
be interested in adding the PEMF 000 to their selection of treatment modalities. Please call us
at 800-865-1527 to learn more about how to become a Distributor.
Although most people will read this call for help and do nothing, we believe that there are at least a
few of you reading this right now who can appreciate the value of a helping hand and are willing to
lend one to spread the word to someone who doesn't yet know their pain problem has been solved.
With your help we can make PEMF 000 the first line of defense against chronic pain and permanent
injury conditions for doctors and clinics the world over. Together, we can put chronic pain on ice.
Thanks from the whole team for reading and helping us heal the world!
Be Well,
Lemuria Technologies
