E7
Make sure all necessary connections are correctly
connected before turn on the power.
The power indicator turns red and the unit is in the standby
mode.
Turn on the power
Press [z] to turn on the main unit.
The power indicator turns blue.
Turn off the power
Press [z] again can turn off the main unit.
The unit is automatically set to the standby mode.
The power indicator turns red.
If not to use the main unit for a long time, press the
power switch to shut down the power, and unplug the
AC power cord from the AC outlet.
Using the Sleep Timer
The sleep timer automatically switches off the power after a
preset time has elapsed. There are 9 time periods available,
press [SLEEP] on the remote control repeatedly to
select the desired sleep time:
0 Min v 15 Min v 30 Min v 45 Min
v60 Min v 75 Min v 90 Min v 105 Min v 120 Min
(The sleep timer starts when the setting is finished.)
To check the remain sleep time
Press [SLEEP] on the remote control, the remain sleep time
appears on the screen for a few seconds.
Select the input source
Turn on the connected necessary external
device. Press [SOURCE] to select the
proper input source.
The input source menu appears.
Select the TV channel
After selected "ATV" or "DTV" as input source, you can do
either one of followings to select your channel.
Press [oCH] or [CH p] (or [-PROGRAM] or [PROGRAM+]
on the main unit).
•
Information display
Press [INFO] on the remote control, the related
information of current source appears on the screen
automatically.
NICAM Function
Press [I/II] on the remote control when input source is "TV".
This operation do no effect to the channels without NICAM
signal.
Once [I/II] is pressed, it alternates in the different
sound options such as mono, stereo, dual I, dual II.
Selecting the audio language
Press [AUDIO] on the remote control when input
source is "CVBS".
For some programs with audio language options, once
[AUDIO] is pressed, it alternates in the different audio
language options.
Adjusting the volume
Press [- VOL] to reduce the volume.
Press [VOL+] to increase the volume.
BASIC OPERATIONS
Press [0, 1~9],[10+] to input the
channel number directly.
Press [ ] to go back the previous
channel you've watched last time.
•
•
Mute function
Press [MUTE ] on the remote control to switch off
the sound temporarily.
Press this button again (or [VOL+], [VOL-]), the
sound comes back.
Selecting the picture mode
Press [P.STD ] repeatedly on the remote control to
select the picture mode as below:
Personal v Movie vSport vMild v
Game v Standard v...
Selecting the sound mode
Press [S.STD ] repeatedly on the remote control to
select the sound mode as below:
Personal v Voice v Music v Theatre v ...
TV
SCART
CVBS
S-VIDEO
VGA
HDMI
DVD
DTV
CH
FAV
VOL
AUDIO
1. Press [o/p] to move the high-lighted
bar to the desired source item.
2. Press [OK] ( or [p/o] )to confirm.
It exit the source menu automatically, and the information
of the selected source name appears on the TV for a few
seconds.
