LENCO DVT-229 User manual

1
Contents
zIntroduction
zWarning
zCaution
zMain Unit Description
zRemote Control
zOSD basic adjustment
zDTV Features
zUSB Features
zDVD manual
zSpecifications
zTrouble Shooting

2
Introduction
Thank you very much for your purchase of our product of LCD TV. It serves as a normal
colour TV and PC monitor. To enjoy your TV to the full from the very beginning, read this manual
carefully and keep it handy for ready reference.
INSTALLATION
①Locate the TV in a room where direct light does not strike the screen. Total darkness or a
reflection on the picture screen can cause eyestrain. Soft and indirect lighting is recommended for
comfortable viewing.
② Allow enough space between the receiver and the wall to permit ventilation.
③Avoid excessively warm locations to prevent possible damage to the cabinet or premature
component failure.
④ This TV can be connected to AC100-240V 50/60HZ.
⑤ Do not install the TV in a location near heat sources such as radiator, air ducts, direct sunlight,
or in a place somewhere like close compartment and close area. Do not cover the ventilation
openings when using the TV.
⑥The indicator light will last about 30 seconds to go out after cutting off the electricity, during
this period, you cannot repower it on until the indicator light goes out, thanks a lot for your
attention!

3
Warning
This symbol is intended to alert the user to avoid the risk
of electric shock, do not disassemble this equipment by anyone
except a qualified service personnel.
This symbol is intended to alert the user to the presence
of important operation and maintenance instructions in
the literature accompanying the equipment.
CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER- SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

4
Caution
Caution
Highvoltagesare used in the operation of this product.
- Donot
open the product's casing. Refer servicing
to qualified service personnel .
Caution
To prevent fire or electrical shock hazard, Do not expose
the main unit to moisture.
Caution
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Caution
Avoid exposing the main unit to direct sunlight and other
sources of heat. Do not stand the television receiver
directly on other products which give off heat. E. g. video
cassette players, Audio amplifiers. Do not block the
ventilation holes in the back cover. Ventilation is essential
to prevent failure of electrical component. Do not squash
powersupplycordunderthemain
unit or other heavy objects.

5
Caution
Caution
Never stand on, lean on, push suddenly the product
or its stand. You should Pay special attention to
children.
Caution
Do not place the main unit on an unstable cart stand,
shelf or table. Serious injury to an individual, and
damage to the television, may result if it should fall.
Caution
Whentheproductis not used for an extended period
of time, it is advisable to disconnect the AC power
cord from the AC outlet.
Caution
The LCD panel used in this product is made of glass.
Therefore,itcan break when the product is dropped
or applied with impact. Be careful not to be injured
by broken glass pieces in case the LCD panel breaks.

6
Main unit description
Control Panel Button Function
TV Terminal Connections
1. USB input terminal (Only used for upgrading software).
2. HDMI input terminal.
3. VGA input terminal.
4. PC AUDIO input terminal.
5. SCART input terminal.
6. Video input terminal .
7. AUDIO input terminal.
8. ATV antenna/close circuit TV network port or DTV antenna port.
9. HEADPHONE output terminal.
10. CI input terminal. (optional)
Power Input Configuration
AC POWER
VOL+ : Volume up.
VOL- : Volume down.
CH+ : TV channel up.
CH- : TV channel down.
MENU : Press to select the main menu.
TV/AV : Select the input signal.
POWER : Switch on when in standby mode or enter the standby mode.

7
Remote control
POWER: Press this button to switch on the TV when at
standby mode or enter standby mode.
MUTE: Press this button to mute or restore sound.
DVD SETUP: Press this button to enter the DVD main menu
and press again to exit the main menu.
(Used for models with DVD function only)
TITLE: Press this button to return the title menu.
(Used for models with DVD function only)
MENU(BLUE): Press this button to return the root menu or
exit the DVD main menu.
(Used for models with DVD function only)
USB/CR: This button is not available.
NICAM/A2: In the TV condition, press this button to select
the sound effects.
SLEEP: Set the sleep timer.
ASPECT: Press to select the different picture size.
EJECT : press to eject the DVD-disc in DVD mode.
(Used for models with DVD function only)
DISPLAY: Display TV information.
AUTO: Press to adjust the picture automatically in PC mode.
PMODE: Select picture mode.
SMODE: Select sound mode.
DTV: Press to enter the DTV channel.
(Used for models with DTV function only)
SOURCE: Press to change signal source.
ENTER: Enter the selected option or perform the selected
operation.
MENU: Press this button to enter the main menu for various
optional adjustable setting.
EXIT: Exit the OSD (On-screen display).
0-9: Select and switch to a channel using 0 - 9.
-/--:Channel list.
:Switch back and front between the current and previous
channels.

8
CH+/CH-: Change the channel up and down.
VOL+/VOL-: Adjust the volume.
INFO: Display some information of current program in DTV
mode.
(Used for models with DTV function only)
AUDIO: Press to select the DTV audio or DVD audio.
(Used for models with DTV or DVD function only)
FAV: Switch between custom set “Favourite List”.
(Used for models with DTV function only)
TV/RADIO: Switch between DTV program and radio
program (only audio but not image).
(Used for models with DTV function only)
EPG: Enter electronic program guide.
(Used for models with DTV function only)
：Stop playing the disc.
(Used for models with DVD function only)
SUBTITLE(GREEN): Open or close subtitle.
(Used for models with DTV function only)
TEXT: Press to enter the Teletext mode.
(Used for European region only)
：Press to start playing the disc to pause playing.
(Used for models with DVD function only)
HOLD: Freeze a multi-page passage on screen in Teletext
mode. (Used for European region only).
INDEX: Press this button to go to the index page in Teletext.
(Used for European region only)
：Press to play backward.
(Used for models with DVD function only)
SIZE: Display the top, bottom or all of page to read easily in
Teletext mode.
(Used for European region only)
：Press to play forward.
(Used for models with DVD function only)

9
REVEAL: Press this button to reveal the hidden information
in Teletext page. Press again to hide the information.
(Used for European region only)
：Skip to previous chapter
(Used for models with DVD function only)
SUBPAGE: Carry out the function of SUBCODE in the text
while enter the text display mode.
(Used for European region only)
：Skip to next chapter
(Used for models with DVD function only)
ZOOM：Select the zoom picture.
(Used for models with DVD function only)
GOTO：Jump to the appointed chapter or title.
(Used for models with DVD function only)
SUBTITLE(BLUE)：Select the disc caption.
(Used for models with DVD function only)
ANGLE：Select the angle.
(Used for models with DVD function only)
PROGRAM：Select the disc program.
(Used for models with DVD function only)
INTRO：Press the button to display the time of chapter
remain or elapsed.
(Used for models with DVD function only)
REPEAT：Select the repeat mode.
(Used for models with DVD function only)
AB：Select the segment to repeat.
(Used for models with DVD function only)
RED,GREEN,YELLOW, BLUE: Correpond to
the different colored subjects.
(Used for european region function only)
