LENCO SCD-30 User manual

1. MENU BUTTON
2. FUNCTION BUTTON
3. ON/ STANDBY BUTTON
4. USB PORT
5. SD PORT
6. VOLUME CONTROL +
7. VOLUME CONTROL -
8. BAND / FOLDER BUTTON
9. CD DISPLAY
10. REMOTE SENSOR INDICATOR
11. CARRYING HANDLE
12. ENTER / PLAY/PAUSE BUTTON
13. RANDOM / P - BUTTON
14. PLAY MODE/P+ BUTTON
15. SPEAKER
16. TUNE + / NEXT BUTTON
17. STOP BUTTON
18. TUNE - / BACK BUTTON
19. STEREO/MONO BUTTON
20. PROGRAM/MEMORY BUTTON
21. TELESCOPIC ANTENNA
22. OPEN / CLOSE CD AREA
23. CD DOOR
24. PHONES JACK
25. BATTERY COMPARTMENT
26. AC SOCKET
SCD-30
STEREO RADIO MP3/WMA/USB/SD/CD PLAYER
INSTRUCTION MANUAL
CONTROLS
REMOTE CONTROL UNIT
MENU BUTTON ON/ STANDBY BUTTON
ENTER /
PLAY/PAUSE BUTTON
TUNE + NEXT BUTTON
FUNCTION BUTTON
STEREO / MONO BUTTON
RANDOM / P - BUTTON
STOP BUTTON
PRESET EQ BUTTON
BAND / FOLDER BUTTON
INTRO BUTTON
PLAY MODE / P + BUTTON
BBS BUTTON
PROGRAM / MEMORY BUTTON
VOLUME + BUTTON
VOLUME - BUTTON
TUNE - BACK BUTTON
MUTE BUTTON

WARNING
CLASS 1 LASER PRODUCT
This product contains a low power laser device.
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
PRECAUTIONS
Follow the advice below for safe and appropriate operations.
ON PLACEMENT
• Do not use the unit in places which are extremely hot, cold, dusty, or humid.
• Placetheunitonaatandevensurface.
• Donotrestricttheairowoftheunitbyplacingitinaplacewithpoorairow,bycoveringitwithacloth, 
 orbyplacingitonacarpet.
ON SAFETY
• WhenconnectinganddisconnectingtheACcord,griptheplugandnotthecorditself.Pullingthecordmaydamage
it and create hazard.
• Whenyouarenotgoingtousetheunitforalongperiodoftime,disconnecttheACpowercord.
ON AC VOLTAGE
• Beforeuse,checkthattheratedvoltageofyourunitmatchesyourlocalvoltage.
ON CONDENSATION
• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the CD player.
• When there is condensation inside the unit, the unit may not function normally.
• Letitstandfor1to2hoursbeforeturningthepoweron,orgraduallyheattheroomupanddrytheunitbeforeuse.
* Ensureaminimumdistanceof5cmaroundtheapparatusforsufcientventilation.
* Ensurethattheventilationisnotimpededbycoveringtheventilationopeningswithitems,suchasnewspapers,
table-cloths, curtains, etc..
* Donotplacenakedamesources,suchaslightedcandlesontheapparatus.
* Take attention to the environmental aspects of battery disposal.
* Use the apparatus only in moderate climates (not in tropical climates).
* Donotexposetheapparatustodrippingorsplashing.
* Donotplaceobjectslledwithliquids,suchasvases,ontheapparatus.
• Mainsplugisusedasthedisconnectdevice.Itshallremainreadilyoperableandshouldnotbeobstructedduring
 intendeduse.Tobecompletelydisconnectedtheapparatusfromsupplymains,themainsplugoftheapparatusshall
be disconnected from the mains socket outlet completely.
Should any trouble occur, disconnect the AC power cord and refer servicing to qualied personnel.
Warning: Do not touch the lens.
DO NOT THROW BATTERIES IN FIRE !
ATTENTION : To reduce the risk
of electric shock, do not remove the
cover. There are no user serviceable
partsinsidetheunit.Referallservicing
toqualiedpersonnel.
The exclamation point within
thetriangleisawarningsign
alertingtheuserofimportant
instructions accompanying
the product.
The lightening flash
with arrowhead symbol
within the triangle is a
warning sign alerting
the user of "dangerous
voltage" inside the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Incaseofmisfunctionduetoelectrostaticdischargetheapparatushastoberesetbydisconnectingitfrommainssupply.
THE MARKING PLATE IS LOCATED AT THE BOTTOM OF ENCLOSURE OF THE APPARATUS.

POWER SUPPLY
USING HOUSE CURRENT
Beforeuse,checkthattheratedvoltage
ofyourunitmatchesyourlocalvoltage.
USING BATTERIES
Disconnect the AC power cord from the AC inlet of the
unit. Battery power is cut automatically by the cord while
it is connected.
Insert 8 UM-2 ( size C ) batteries.
battery door
When the volume decrease, or the sound distorts, replace
all of the batteries with new ones.
To AC socket
To AC outlet
GB 1
ADJUSTING THE SOUND
Press volume +/- to adjust volume level.
FOR PRIVATE LISTENING
Pluginheadphones(ø3.5mmstereomini-plug)tothePHONESjack.
Whenheadphonesarepluggedin,thespeakersareautomaticallydisconnected.
VOLUME
VOLUME
PresstheON/STANDBYbuttontoturntheaudioon.Tochangetheaudiomodebetween,
CD , U DISK and TUNER press FUNTION button while the power is on. the audio
mode is displayed.
Power will be cut off automatically when CD, MP3 and USB function in stop mode for 15 minutes.
TURN ON / OFF THE SYSTEM
FOR BETTER RECEPTION
FM AM
Tuning a RADIO Station
1. Press FUNCTION button repeatedly
until “TUNER” is shown.
2. Press the BAND/FOLDER button
 toselectthedesiredfrequencyband(FMorAM).
TUNER OPERATION
4. Press and hold the TUNE +/NEXT or
TUNE - /BACK button for more than 1 second,
 scanningstartsautomaticallyandtunerstopsatthe
 rstreceivablebroadcaststation.
5. Tostoptheautotuning,presstheTUNE+/NEXTor
 TUNE-/BACKbuttonagain.
3. Press the TUNE + /NEXT or
TUNE - /BACK button as many times
 asrequiredtotuneintothe
desired station.
2. “STEREO”iconwillbelitonwhenreceivingstationis
broadcasted in Stereo.
3. Toselectmonomode,pressST.MONObuttonagain.
4. “STEREO” icon will never turn on in FM MONO mode.
Selecting FM Stereo/Mono mode
1. To select FM stereo/mono mode, press ST/MONO
button on the remote control.

RADIO MEMORY FUNCTION
1. Tune to a desired radio station.
2. PressPROGRAM/MEMORYKeytoentertuningsavingmode.The“MEMORY”iconwillbeturnedon.
3. Programnumber“01”onthelefthandsidewillbeashing.
4. Within10seconds,pressP+orP-buttontoselectthedesiredprogramnumber.
5. PressProgramKeytocontironthememory.
6. Ifthereisnokeypressedwithin10seconds,itwillexittuningsave
mode and the “MEMORY” icon will be turned off.
7. Repeatsteps2to5tosetotherstations,orchangeapresetstation.
COMPACT DISC PLAYBACK
1. Press FUNCTION button repeatedly
until “CD” is shown on display.
2. Lift the CD door up.
3. Insert a disc with the label
 sidefacingup.
4. Close the CD door, the disc will rotate.
For CD :
The total tracks of the disc will show on the display.
For MP3/WMA/USB :
The total tracks of the disc and total number of the folder
will show on the display.
CD display
GB 2
5. Afterdiscreadnished,thediscwillplay
automatically.
In stop mode, press the Enter/Play/Pause
button to play the track.
For CD : Track number "001" & "CD" & "00:00" will be
shown,duringnormalcompactdiscplayback.
For MP3 : Track number "F01" & "MP3" & "00:00" will be
shown,duringMP3playback.
For WMA : Track number "F01" & "WMA" & "00:00" will
beshown,duringWMAplayback.
For USB : Track number "F01" & "USB" & "00:00" will
beshown,duringUSBplayback.
TO STOP PLAYBACK
Press the STOP button.
For CD : Total number of tracks and time will be shown.
For MP3 : Total number of tracks and folder will be shown.
For WMA : Total number of tracks and folder will be shown.
For USB : Total number of tracks and folder will be shown.
For CD : Track number "001" & "CD" will be shown, the
timeofthetrack"00:00"inash,duringnormalcompact
disc playback.
For MP3 : Track number "F01" & "MP3" will be shown,
thetimeofthetrack"001"inash,duringMP3playback.
For WMA : Track number "F01" & "WMA" will be shown,
thetimeofthetrack"001"inash,duringWMAplayback.
For USB : Track number "F01" & "USB" will be shown,
thetimeofthetrack"001"inash,duringUSBplayback.
TO INTERRUPT PLAYBACK
Press the Enter/Play/Pause button. Press the button
to resume playback.
CD display
MP3 display
WMA display
USB display
CD display
MP3 display
WMA display
USB display

FOR MP3 / WMA / USB PLAYBACK
ModesequenceREPEAT>>AREPEAT>>
A-BREPEAT>>REPEATALL>>FOLDER>>CLEAR.
FOR NORMAL COMPACT DISC PLAYBACK
ModesequenceREPEAT>>AREPEAT>>
A-BREPEAT>>REPEATALL>>CLEAR.
FOR MP3 / WMA / USB PLAYBACK
Mode sequence REPEAT >> REPEATALL >> FOLDER
>>CLEAR.
GB 3
FOR NORMAL COMPACT DISC PLAYBACK
ModesequenceREPEAT>>REPEATALL>>CLEAR.
REPEAT , REPEAT ALL , REPEAT AB AND REPEAT FOLDER PLAYBACK
MP3/WMA/USB display
CD display
Press PLAY MODE/P+ button during stop mode.
For CD: Total number of tracks & time will be shown.
For MP3/WMA/USB: Total number of tracks & folder will be shown.
Press PLAY MODE/P+ button during playback.
For CD: The folder tracks number &
time will be shown.
For MP3/WMA/USB: The folder tracks number
& folder will be shown.
CD display
PLAYING TRACKS IN RANDOM ORDERS
1. If the RANDOM/P- button is pressed, the tracks on the discs are
not played in consecutive order but in random order.
The word RAND appears on the display to provide a visual
reminder that the RANDOM function has been activated. .
2. Press the STOP button or
RANDOM button to switch
off the function RANDOM.
DuringRepeat4mode,
display shows
DuringRepeat1mode,
display shows
DuringRepeat2mode,
display shows
DuringRepeat3mode,
display shows
DuringRepeat1mode,
display shows
DuringRepeat2mode,
display shows
DuringRepeat3mode,
display shows
DuringRepeat4mode,
display shows
DuringRepeat1mode,
display shows
DuringRepeat2mode,
display shows
DuringRepeat3mode,
display shows
DuringRepeat1mode,
display shows
DuringRepeat2mode,
display shows
DuringRepeat3mode,
display shows
DuringRepeat4mode,
display shows
DuringRepeat5mode,
display shows
DuringRepeat5mode,
display shows
DuringRepeat6mode,
display shows
TO SKIP TO THE BEGINNING OF A TRACK
• Presseitheroneoftheskipbuttonsaccordingtothedesiredskipdirection.
• Play/back resumes from the selected track.
• Whenthebuttonispressedonceduringplay,theprevioustrackstartsagain.
• Whenthebuttonispressedonceduringplay,thenexttrackplays.
SEARCHING FOR A PASSAGE WITHIN A TRACK
• Keeptheorbuttonpressedduringplayback,andreleasethebuttonassoonasyou
 recognisethedesiredpassage.ThennormalCDplaybackwillresumefromthispoint.
MP3/WMA/USB display

GB 4
FOR MP3/WMA/USB PLAYBACK
Programmedplaybackenablestracksonadisctobeplayedinthedesiredorder.Upto20trackscanbeprogrammed.
1. ProgrammodeworksinSTOPmodeonly.
2. Press“PROGRAM/MEMORY”buttonfor2secondstoenterprogrammode.The“PROG”iconwillbeturnedon.
 “00000P01”willbeshownwith“00”ashing.“000”representstracknumberand“P:01”representsprogramlocation
number.
3. Press the TUNE +/NEXT or TUNE - /BACK button to select the desired folder.
4. PressTUNE+/NEXTorTUNE-/BACKtoselecttherequiredtracknumber.
5. PressPROGRAM/MEMORYbuttontoconrmthetracknumber.Thedisplaywillshowthenext
 programnumber“000P02”.Thetracknumberwillbeashingagainandwaitingfortracknumberinput.
6. Repeatsteps3and4untilallthedesiredtrackshasbeenprogrammedorallthe
 programmemorieshavebeenused.ItwillloopbacktoP01afteralltheprogram
 memorieshavebeenused.Sametracknumbercanbeprogrammedmorethanonce.
7. Press ENTER/PLAY/PAUSE button to playback.
8. Tocleartheprogrammedtracks,rstpressPROGRAM/MEMORYbutton
 for2secondstoenterprogrammode.
9. PressSTOPkeytoclearalltheprogrammedmemories.
MP3/WMA/USB display
USB OPERATION
1. Connect USB into the USB input of the system.
2. Press“FUNCTION”buttonrepeatedlyuntil“UDISK”isshownonthedisplay.Afterenteredthecorrespondingmode,
 thecorrespondingiconwillbelitup.
3. The unit will start to read the media and to start the playback automatically.
4. ID3 function can be enable/disable in the “MENU” function.
USB connector does not support connection with USB extension cable and it is not designed for communication
with computer directly.
PROGRAMMED CD OPERATION
FOR NORMAL COMPACT DISC PLAYBACK
Programmedplaybackenablestracksonadisctobeplayedinthedesiredorder.Upto20trackscanbeprogrammed.
1. ProgrammodeworksinSTOPmodeonly.
2. Holding“PROGRAM/MEMORY”button.The“PROG”iconwillbeturnedon.“000P01”willbeshownwith“000”
 ashing.“000”representstracknumberand“P01”representsprogramlocationnumber.
3. PressTUNE+/NEXTorTUNE-/BACKtoselecttherequiredtracknumber.
4. PressPROGRAM/MEMORYbuttontoconrmthetracknumber.Thedisplaywillshowthenext
 programnumber“000P02:”.Thetracknumberwillbeashingagainandwaitingfortracknumberinput.
5. Repeatsteps3and4untilallthedesiredtrackshasbeenprogrammedorallthe
 programmemorieshavebeenused.ItwillloopbacktoP01afteralltheprogram
 memorieshavebeenused.Sametracknumbercanbeprogrammedmorethanonce.
6. Press ENTER/PLAY/PAUSE button to playback.
7. Tocleartheprogrammedtracks,rstpressPROGRAM/MEMORYbutton
 for2secondstoenterprogrammode.
8. PressSTOPkeytoclearalltheprogrammedmemories.
CD display
Note on CD-R/RW discs
- Becauseofnon-standardizedformatdenition/productionofCD-R/RW,playbackqualityandperformancearenot
 guaranteed.
- ManufacturerisnotresponsiblefortheplayabilityofCD-R/RWduetorecordingconditions,suchasPCperformance,
 writingsoftware,mediaability,etc.
- Do not attach a seal or label to either side of the CD-R/RW disc. It may cause a malfunction.

BBS
1. Press MENU button repeatedly
unit BASS shown on the display.
2. Press ENTER to enter Bass
 Boostsettingmode.
3. Press ENTER to select " BASS
ON " or " BASS OFF ".
4. Pressentertoconrm. GB 5
Thebassbooston/offischangedcyclicallybypushing
BBS button on remote control.
INTRO
InCDmode,presstoplayonlytherst10secondsofeachtrack
on the disc.
MUTE
PRESET EQ
1. Press MENU button until EQ shown on the display.
2. PressENTERtoenterEQsettingmode.
3. Press MENU button to select of the EQ effect will be :
 -FLAT->ROCK->JAZZ->CLASSIC->POP->FLAT.
4. PressENTERbuttontoconrmthesetting.
5. PressSTOPbuttontocleartheEQsettingmode.
FOLDER SELECTION
1. In STOP mode, press BAND/FOLDER button will skip to the next folder.
2. This operation valid for all media of MP3,WMA and USB operation.
Themuteon/offischangedcyclicallybypushingMUTEbutton.
The“mute”markisonduringmuteison.
The mute on is cancelled in case as shown below.
a. The power is off/on
b. The Volume is adjusted by the VOL +/- button.
MUTE ON/OFF
PROGRAMMED USB OPERATION
Program mode works in Stop mode
1. PressPROGRAM/MEMORYbutton.Then,the“00000P:01”willbeshownonthedisplayandtherst2digitswill
 beashing.
2. Press“TUNE+/NEXTorTUNE-/BACK”toselectthedesiredfolder.Afterpress“PROG”buttontoconrmthefolder,
 the3rdto5thdigitswillbeashing.
3. Press“TUNE+/NEXTorTUNE-/BACK”toselectthedesiredtrack.Then,press“PROG”buttontoconrmthetrack
number.
4. Press“PROGRAM/MEMORY”buttonagaintoconrmthesetting.Thedisplaywillshownextprogramnumber.
5. Repeatthesequenceasindicatedin2to4fornextprogram.
6. Afterallthedesiredprogramshavebeenselected,Press“PLAY/PAUSE”buttonforplayback.
USB display
ID3 Display
1. Press MENU button repeatedly unit ID3 shown on the display.
2. PressENTERtoenterID3settingmode.
3. Press MENU to select " ID3 ON " or " ID3 OFF ".
4. Pressentertoconrm.

GB 6
If at any time in the future you should need to dispose of this product please note that: Waste electrical products
should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local
Authorityorretailerforrecyclingadvice.(WasteElectricalandElectronicEquipmentDirective)
Where to place the item :
Today’sfurnitureiscoatedwithawidevarietyoflacquersandsynthetic-coatingsthataretreatedwithanextensiverange
ofcleaningproducts.Therefore,thepossibilitythatsomeofthesesubstancescontaincomponentsthatreactadverselyto
the rubber feet of the item and soften them, cannot be completely excluded. The rubber feet of the appliance can cause
discoloringtofurnituresurfaces.Ifnecessary,placetheapplianceonanon-slidesurface.
SPECIFICATIONS
CD SECTION
Channels: 2 channels
S / N ratio: 60 dB
Wow & Flutter: undetectable
Samplingfrequency: 44.1kHz8xoversampling
Quantization: 1 bit DA converter
Pickuplightsource: Semi-conductorlaser
Pickupwavelength
790 nm
RADIO SECTION
Tuningranges: FM87.5-108MHz
AM 522 - 1620 kHz
Antennas : AM Built - in ferrite bar
FM telescopic antenna
GENERAL
Output power: 1.2 W + 1.2 W (RMS)
Power consumption: 14 W
Speaker: 3" 8 OHM
Phones jack: 3.5MM
Power source: AC: 230V / 50Hz
(INDICATED ON THE REAR OF THE UNIT)
 DC:12V1.5x8UM2/R14/"C"SIZE
Dimensions: 350 (L) x 260 (D) x 134 (H) mm
Weight 1.95KGS
Duetocontinuingimprovement,thefeaturesandthedesignaresubjecttochangewithoutnotice.
CLEANING CD
IftheCDskipsorwillnotplay,thediscmayneedcleaning.
Beforeplaying,wipethediscfromthecentreoutwithacleaning
cloth.Afterplaying,storethediscinitscase.
CLEANING THE UNIT
Donotusevolatilechemicalsonthisunit.Cleanbylightlywiping
with a soft cloth.
IMPORTANT NOTE
Ifanabnormaldisplayindicationoranoperatingproblem
occurs, disconnect the AC power cord and remove the batteries.
Wait at least 5 seconds, then reconnect the AC power cord or
reinstall the batteries.
WARNING
Should the CD door be opened before the reading of the CD
completed, a jamming noise may occur. This is resolved by
closingtheCDdoor.
MAINTENANCE
CLEANING THE CD LENS
If the CD lens is dusty, clean it with a brush-blower. Blow several
timesonthelensandremovethedustwiththebrush.Fingerprints
may be removed with a cotton swab moistened with alcohol.
