LENCO MC-148 DAB+ User manual

USER MANUAL
www.lenco.com
Please read this manual carefully before connecting or operating
the appliance. Save it for future reference.
CD Micro System with DAB+
MC-148 DAB+

TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTION…………….........................
PANELS AND CONTROL…………………………………………........
PREPARATION FOR USE ………….......……………………………...
GENERAL OPERATION………….......……………………….............
DAB+ OPERATION………….......…………………….……................
FM OPERATION………….......…………………....……………...........
EXTERNAL INPUT …….…………………………………………..........
SPECIFICATIONS .....................................................................
SERVICE AND SUPPORT ..........................................................
CD OPERATION ………….......……………….........….………….......
TROUBLESHOOTING………….…….……...…….…….…….............
2
4
5
6
7
9
13
15
15
16
17
ACCESSORIES
• 1 x The Unit
• 2 x Speakers
• 1 x Remote Control(with batteries)
• 1 x User Manual
NOTE: This unit is designed to enter STANDBY mode
automatically after 15 MINUTES(approximately) of inactivity.
Press the STANDBY button to wake the unit.
NOTE: When you power on the unit from standby the last used mode
will resume.
1

• When using electrical equipments basic safety precautions should
• This equipment is not intended for use by persons(including
reduced physical, sensory or mental capabilities or
knowledge. They should be given appropriate
to use the equipment by a person
• Ensure the equipment is not too close to heat emitting appliances
in direct sunlight.
• Check that the voltage indicated on the data plate corresponds with
local network before connecting the equipment to the
mains power supply.
• Do not leave the equipment unattended while connected to the
• Do not immerse the equipment in water or any other liquids. It is
to unplug the power cord after the equipment has been
cleaned and while being repaired.
• Close supervision is required when using this equipment near
• Never leave the equipment within reach of children.
• Repairs to electrical appliances should only be performed by
Improper repairs may place the user and/or
risk.
• This equipments intended for household use only and should not
industrial or commercial purposes.
• Do not operate this appliance with a damaged plug or cord, after a
or after being dropped or damaged in any way.
• Do not use this equipment for anything other than its intended use.
This equipment must be placed on a stable, heat resistant surface.
• Do not push objects into any openings as damage to the
electric shock may occur.
• Do not use this product in wet or bad weather conditions. This
not a toy.
• Do not play music at excessive levels especially near children.
• The normal function of the product may be disturbed by Strong
Interference. If so, simply reset the product to
operation by following the instruction manual.
always
be followed.
children)with
lack of experience or
supervision and instructions
responsible for their safety.
or placed
that of
the
power
supply.
imperative
used, before it is
children.
qualified
personnel. equipment at
serious
be used
for
malfunction
equipment and/or
product is
Electro
Magnetic resume normal
IMPORTANT SAFETY INSTRUCTION
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
2

• Refer all serving to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture.
personnel only.
any servicing other than
unless you are qualified to do so.
shall
It has
connection
non-
insulated
such as
liquids,
such
• Please keep the unit in a good ventilation environment.
• These servicing instructions are for use by qualified service
To reduce the risk of electric shock, do not perform
that contained in the operating instructions
• The main plug is used as disconnect device, the disconnect device
remain readily operable.
• This equipment is a class II or double insulated electrical appliance.
been designed in such a way that it does not require a safety
to electrical earth.
• The lighting with the triangle symbols shows that the unit contains
dangerous voltage.
• The batteries in remote shall not be exposed or excessive heat
sunshine and fire.
• The apparatus shall not be exposed to liquid or objects filled with
as vases, shall not be placed on the apparatus.
WARNING: DANGER OF RADIATION
These labels tell you that the unit contains a laser component. Openi
compartment lid and defeating the safety interlocks wil
radiation from the laser beam. Do not stare into the
ng the
CD expose the user to
laser while it is opening.
IMPORTANT SAFETY INSTRUCTION
3

PANELS AND CONTROL
FRONT PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13 14
15
REAR PANEL
1. Indicator
2. STANDBY button
3. Display
4. PLAY/PAUSE button
5. SOURCE button
6. STOP/MENU button
7. CD loading drawer
8. EJECT button
9. IR sensor
10. VOLUME knob
11. PREVIOUS/NEXT button
12. AUDIO input
13. FM antenna
14. Speaker connectors
15. Power supply
REMOTE CONTROL
17
16
18
20
22
19
21
23
25
24
26
27
29
34
28
30
31
32
33
35
36
37
PROGRAM
STANDBY
CD DAB/FM AUX IN
MENU
ENTER
12 3
45 6
7 8 9
LOUD
DSP
TONE MUTE
VOLUME
INFO REPEAT
EJECT
SHUFFLE
0
-+
16. STANDBY button
17. CD mode button
18. DAB/FM button
19. PLAY/PAUSE button
20. STOP/MENU button
21. NEXT button
22. FAST REWIND button
23. PREVIOUS button
24. NUMBER buttons
25. TONE button
26. VOLUME +/- buttons
27. EJECT button
28. AUX IN mode button
29. REPEAT button
30. INFORMATION button
31. ENTER button
32. FAST FORWARD button
33. PROGRAM button
34. SHUFFLE button
35. LOUD button
36. DSP button
37. MUTE button
4
AC 220-240V 50Hz
MC-148 DAB+
Input: AC 220-240V 50Hz
40W
CD Micro System with PLL FM and DAB+
8
Made in China
AUDIO IN
STO P/MENU

PREPARATION FOR USE
CONNECT WITH SPEAKERS
1. Unwarp the speaker wires.
2. Place a speaker on either side of the main unit, preferably at the
same height, and with at least 150mm between each speaker and
the main unit.
3. Connect the speaker plugs to rear of the unit. Take care to match the
speaker placed to the LEFT output on the rear of the unit. Repeat for
the RIGHT speaker.
4. When connecting ensure the RED wires connects to the RED
terminals and the BLACK wires to the BLACK terminals.
CONNECT THE POWER
1. Check the voltage marked on the rear rating plate is the same as the
voltage in your area.
2. Connect the main plug to the wall socket and power on.
FITTING THE REMOTE CONTROL BATTERIES
1 2 3
1. Remove the battery cover(as shown).
2. Insert 2 x AAA batteries, taking note that the polarities match up.
3. Replace the battery cover, in the same manner as you removed it.
DISPOSAL OF BATTERIES
Dispose of used batteries with regard to the recycling regulations in
your area. Do not short circuit batteries or throw them into water, the
general rubbish or in a fire. Weak batteries can leak and damage the
remote control. Replace them in good time!
5
REAR PANEL
RIGHT SPEAKER LEFT SPEAKER
AC 220-240V 50Hz

GENERAL OPERATION
6
STANDBY MODE
Press the STANDBY button on the unit or the remote control to turn on
the system. To resume normal operation, press either button again.
VOLUME CONTROLS
Rotate the VOLUME control clockwise or press the VOLUME+ button
to increase the volume level.
Rotate the VOLUME control anti-clockwise or press the VOLUME-
button to decrease the volume level.
MUTE FUNCTION
Press the MUTE button to silence the output. Press again to resume.
DSP EFFECTS
Press the DSP button repeatedly to alter the sound field: Jazz, Rock,
Classic, Pop, Live, Dance and off.
LOUDNESS FUNCTION
This function will add a rounder bass sound at low levels. Press the
LOUD button on the remote control to enable the effect. Press again
to disable the effect.
SWITCHING MODES
To switch between the mode: CD, FM, DAB+, and AUX IN.
Press SOURCE button on the unit to cycle through the modes or press
the relevant button on the remote control from CD, DAB/FM, and
AUX IN.
Press DAB/FM button repeatedly to switch between DAB+ and FM
mode.
TONE CONTROLS
Adjust the Bass and Treble tone controls.
1. Press the TONE button on the remote control.
2. The first adjustment is Bass. Use the VOL+/- buttons to adjust.
3. Press the TONE button again to edit Treble. Use VOL+/- buttons
to adjust.
4. Press the TONE button once more to edit Volume. Use the VOL+/-
buttons to adjust.

CD OPERATION
PLAYBACK
1. Make sure you are in CD mode, if not press the CD button on the
remote or press the SOURCE button until you reach CD.
2. Press the EJECT button, when the disc drawer pops out, insert a
disc, press the EJECT button again to close.
3. When the door is closed, “LOADING DISC” will appear on the
display as the unit detects compatible audio tracks.
4. Playback will begin automatically from Track 01.
5. To stop playback, press the STOP/MENU button once. Press
PLAY/PAUSE button to resume. If press the STOP/MENU button
twice, it will start from beginning.
6. To pause playback, press the PLAY/PAUSE button during playback.
To resume playback, press once more.
NOTE: The playback of CD Mp3 disc is the same as a standard CD.
SKIPPING TRACKS
1. To skip to the next track on a disc press .
2. To skip to the previous track press .
FAST SEARCHING TRACKS
To fast forward a track during playback, press the button. Each
press of the button increases the search speed e.g.: 2x & 4x, the next
press will resume normal playback. To fast rewind a track during
playback, press the button.
REPEAT OPERATION
1. During playback pressing the REPEAT button, you will see
'REPEAT: One' on the display.
2. Press the REPEAT button again will repeat all tracks on the disc.
You will see 'REPEAT: All' on the display.
3. To cancel the repeat function, press the REPEAT button for a third
time. You will see 'REPEAT: Off' on the display.
NUMERIC BUTTONS
While listening to a CD, a specific track number can be played by
pressing the relative digit on the number buttons, e.g.: track 6 would
be 06. To play track 12, you would press the 1 button then 2.
7

CD OPERATION
PROGRAM PLAYBACK
You may wish to play back tracks of a CD in a different order than the
original disc was recorded in.
1. Press the PROGRAM button to enter the program setup function.
2. Use the buttons to skip between the play order numbers.
3. Set the play order track numbers using the numeric keys.
4. When tracks 1-2 are set, use the buttons to access further play
order screens. Repeat steps 2-3 for the remainder of the program
play list.
5. When complete, use the / buttons to scroll across to the arrow
on the right of the display and press the ENTER or PLAY/PAUSE
button to begin playback.
6. To cancel the program sequence, press the STOP/MUNE button
twice.(The first press is to stop the playback, and the second is to
cancel.)
NOTE: The program function is not enable with Mp3 Cds.
RANDOM CD OPERATION
1. Press the SHUFFLE button on the remote control. The CD contents
will be played once in a random order. You will see 'SHUFFLE' on
the display.
2. To cancel the random operation, press the SHUFFLE button again.
You will see 'OFF' on the display.
NOTE: The SHUFFLE play is only available on standard music Cds,
not Mp3 Cds.
/
PROGRAM INPUT
01[02] 02[14]
PROGRAM INPUT
01[00] 02[00]
Play Order
Track Number
For example: the diagram on the right would play track 02 as the first
track and track 14 as the second track.
8

DAB+ OPERATION
9
AUTO SCAN MODE
1.To activate the full scan, press the STOP/MENU button.
2. When you see the <Autoscan> option, press the PLAY/ PAUSE or
ENTER button. The unit will search for all available DAB+ stations
that can be tuned.
MANUAL TUNING
As well as an auto tune function, you can manually tune the receiver.
1. Press the STOP/MENU button in DAB+ mode, and use either
on the unit, on the remote to find <Manual tune>. Press the
PLAY/PAUSE button on the main unit or ENTER button on the
remote to activate the manual tune options.
2. Now use the on the unit, on the remote to cycle through
the DAB+ ensembles/multiplexes, which are numbered from 5A to
13F.
3. Press the ENTER or PLAY/PAUSE button to view the ensemble/
multiplex details. Press the ENTER or PLAY/PAUSE button again
to enter the multiplex.
4. To see what stations are present in the found ensemble/multiplex,
just press either on the unit, on the remote. When you've
located a station that you would like to listen to, press the ENTER
or PLAY/PAUSE button.
5. Any stations found during the manual tune operation will be added
to your station list.
STORING STATION PRESETS
It is possible to store up to 10 of your favorite stations. This will enable
you to access your favorite stations quickly and easily.
1. To store a preset, you must first be listening to the station that you
would like to save.
2. Then press and hold one of the numeric buttons from 1-0 to store
the station under that number. You will see Preset X Stored appear
on the display with X being the number you stored the station under.
/
/
/
/
/
/
Switch to DAB+ mode by pressing SOURCE button on the unit or
DAB/FM button on the remote control.

Channel Frequency
Programme Type
DLS (scrolling text)
Signal Error
Bitrate
Signal Strength
Ensemble Name
DAB+ OPERATION
RECALLING A STATION PRESET
To select a preset, just press the required numeric button while in
DAB+ mode to activate the station you stored.
DISPLAY MODES
Every time you press the INFO button on the remote control, the
display will cycle through the following display modes: The information
is displayed on the lower segment of the LCD display.
DLS (Dynamic Label Segment)
Dynamic label segment is a scrolling message that the broadcaster
may include with their transmissions. This message usually includes
information, such as program detail etc.
Signal strength
Displays how strong the current signal being received is.
Program type
This describes the “Style” or Genre” of music that is being broadcast
e .g . “Rock “or “Classical” .
Ensemble/Multiplex (Group name)
A multiplex/ensemble is a collection of radio stations that are bundled
and transmitted on one frequency. There are national and local
multiplexes. Local ones contain stations that are specific to that area
e .g . MXR West .
NOTE: DAB+ unlike normal radio, groups together several radio
stations and transmits them on one frequency.
10

DAB+ OPERATION
Channel Frequency
Displays the frequency information for the current station.
Signal Error
Displays information regarding the error rate in the signal.
Bit Rate
This displays the type of broadcast you are receiving e .g . mono or
stereo and what bit rate is being used .
SECONDARY SERVICES
On some occasions you will see a “>>” symbol directly after the name
of the station. This indicates that there are secondary services
available to that station .
These secondary services contain extra services that relate to the
primary station, e .g . a sports station may want to add extra
commentaries. The secondary services are inserted directly after the
primary station .
1. To activate a secondary service press the FFWD on the remote.
You will see that the >> has changed to a << to indicate you have
selected the secondary service .
2. Press the ENTER or PLAY/PAUSE button to begin playback of the
service .
3. To return to the original service, press the FRWD and then
ENTER or PLAY/PAUSE.
PRUNING
When the radio has performed a scan in several locations, you may
find there are stored stations that you can no longer receive.
This function automatically removes them from the stored station list.
1. Press the STOP/MENU button in DAB+ mode, and use either
on the unit, on the remote to find <Prune>. Press the
PLAY/PAUSE button on the main unit or ENTER button on the
remote.
2. Use the buttons on the remote to select <Yes> and press
ENTER or PLAY/PAUSE to select .
/
11
/
/

DAB+ OPERATION
DRC (DYNAMIC RANGE CONTROL)
This causes the radio to reduce the dynamic range of the audio signal.
The purpose of this is to adapt the dynamic range of the audio signal
to listening in a noisy environment.
NOTE: This is not available on some DAB+ stations.
1. Press the STOP/MENU button in DAB+ mode, and use either
on the unit, on the remote to find <DRC>. Press the PLAY/
PAUSE button on the main unit or ENTER button on the remote .
2. Choose between DRC off, DRC high and DRC low using either
on the unit, on the remote control.
3. Press the ENTER or PLAY/PAUSE button to save the setting.
FACTORY RESET
Follow the below steps to restore to factory settings.
1. Press the STOP/MENU button. Use buttons on the unit or
buttons on the remote control to find
2: When you see
< System > , press ENTER
button.
< Factory Reset >, press ENTER button.
3. Select <Yes> using buttons, then press ENTER to reset
process.
NOTE: Once the reset has been taken place, you will lose all the
stored presets both on DAB+ and FM mode, and the internal DAB+
registry.
SELECT LANGUAGE
Follow the below steps to select the language of the system.
1. Press the STOP/MENU button.
2. Use buttons on the remote control to find <System>, press
ENTER button.
3. When you see <Language>, press ENTER button.
4. Use buttons to select one of the system languages, press
ENTER button to confirm selection.
/
/
/
12
/
/
/
/
/
/

FM OPERATION
Switch to the FM mode.
SCANNING FOR STATIONS
1. You can scan up or down the frequency range manually by pressing
the buttons on the remote or pressing buttons on the
unit to increase or decrease the frequency in 0 .05 MHz increments.
To scan through the frequency range quickly press and hold the
buttons on the unit or press the buttons on the remote control.
2. Once a station has been found, the scanning will stop automatically.
If no station is found, then the tuning will stop once it has cycled
through the entire FM band (87.5-108MHz).
SCAN MODES
When performing an scan, you can set the sensitivity level of the
stations to be found. E.g. : Strong stations only or All stations.
1. In FM mode, press the STOP/MENU button, when <Scan setting>
appears on the display press the ENTER or PLAY/PAUSE button to
view the submenu.
2. Use either on the unit, on the remote to select either
<All stations> (which will detect any stations, even with a weak
signal) or <Strong stations only> (which will only detect stations
with a good signal strength). Press the ENTER or PLAY/PAUSE
button to select the required option.
3. When you perform a scan as described above, only stations fitting
the applied setting will be detected.
STORING STATION PRESETS
It is possible to store up to 10 of your favorite stations.
This will enable you to access your favorite stations quickly and easily.
1. To store a preset, you must first be listening to the station that you
would like to save.
2. Then press and hold one of the numeric buttons from 1-0 to store
the station under that number. You will see Preset X Stored appear
on the display with X being the number you stored the station under.
/
13
/
/
/
/
/

FM OPERATION
RECALLING A STATION PRESET
To select a preset, just press the required numeric button while in FM
mode to activate the station you stored.
DISPLAY MODES
Every time you press the INFO button repeatedly on the remote control,
the display will cycle through the following display modes: The
information is displayed on the lower segment of the LCD display.
Audio Mode
This denotes whether the stations is in stereo or mono.
Radio Text
As with DAB+, the broadcaster can include a scrolling text that displays
information about the current program. If Radio text information is not
available, then the display will show <No Radio Text>.
PTY (Program type)
This describes the “Style” or “Genre” of music that is being broadcast
e .g .“Rock “or “Classical”. if no program type has been set, then <No
PTY> will be displayed.
Name(Program name)
This will display the frequency of the current station. If no program
name, <No Name> will be displayed.
AUDIO MODE
Press STOP/MENU button repeatedly on the remote control, the
display will cycle through the display modes. When shows <Audio
setting>, press ENTER button to select between <Stereo allowed>
and <Forced mono>.
14
Radio Text Name
PTY
Audio Mode(Stereo/Mono)

CONNECTING AN EXTERNAL AUDIO DEVICE
External audio sources such as iPod's & MP3 players can be
connected using a 3.5mm to 3.5mm audio cable (not supplied).
AUDIO IN
Mp3 player
1. Connect one end of the cable to the AUDIO devices headphone/Line
output and the other end to the AUDIO IN input on the front of the unit.
2. Press the SOURCE button until you reach the AUX IN option or press
the AUX IN button on the remote control.
3. Adjust the volume to your desired level.
NOTE: When connecting via the headphone output the volume of the
Micro system is affected by the volume control on the player. Ensure
that the player is set to about 70-80% to avoid distortion.
15
SPECIFICATIONS
Power Supply
Max. Power Consumption
Speaker Power
FM
Net Weight
DAB+
AC 220-240V 50Hz
40W
2 x 5W
87.5-108MHz
174.928-239.200MHz
3.0kg(Approximate)
Unit Size 170 x 220 x 140 mm
Speaker Size 130 x 186.5 x 125 mm

TROUBLESHOOTING
In the unlikely event of difficulties with your appliance please follow
the trouble shooting guide below.
Problem Reason(s) Solution(s)
No Power
No Sound CD/AUX/
RADIO.
No Sound from AUX
input.
Sound is distorted.
Sound is distorted
from AUX input.
Unable to Play
Static Sound
Desired station not
found.
Weak or no DAB+
signal
I can hear a
burbling noise on
some stations.
Unit switches off
after 20 minutes
of inactivity.
Power cable not conne-
cted to wall socket.
Power socket is not
switched on.
Volume is too low.
AUX source volume is
too low.
Volume is too high.
AUX source volume is
too high.
No disc in the tray.
Disc not loaded properly.
Disc is dirty.
Poor reception
Weak signal
Station not available in
your area.
DAB+ not available in
your area.
Weak signal.
Make sure the plug is
connected.
Switch the power on.
Increase the volume.
Increase the output volume
of the AUX source.
Reduce the volume.
Reduce the output volume
of the AUX source.
Insert a compatible disc.
Check the disc loaded.
Clean the disc.
Re-locate the antenna(FM).
Use the manual tune
function.
See DAB+ availablity
website:
Try re-positioning the aeria
(earphones).
This unit is designed to enter
STANDBY mode automati-
cally after 20 minutes of
inactivity. Press the
STANDBY button to wake
the unit.
Auto standby mode in
operation.
http://www.getdigital
radio.com/
16

SERVICE AND SUPPORT
For information: www.lenco.com
Lenco offers service and warranty in accordance to European law,
which means that in case of repairs (both during and after the warranty
period) you should contact your local dealer.
Important note: It is not possible to send products that need repairs to
Lenco directly.
Important note: If this unit is opened or accessed by a non-official
service center in any way, the warranty expires.
This device is not suitable for professional use. In case of professional
use, all warranty obligations of the manufacturer will be voided.
Products with the CE marking comply with the EMC
Directive (2004/108/EC) and the Low Voltage Directive
(2006/95/EC) issued by the Commission of the
European Community.
The declaration of conformity may be consulted at
https://lencosupport.zendesk.com/forums/22413161-CE-Documents
This symbol indicates that the relevant electrical product
or battery should not be disposed of as general
household waste in Europe. To ensure the correct waste
treatment of the product and battery, please dispose
them in accordance to any applicable local laws of
requirement for disposal of electrical equipment or
batteries. In so doing, you will help to conserve natural
resources and improve standards of environmental protection in
treatment and disposal of electrical waste (Waste Electrical and
Electronic Equipment Directive).
®All rights reserved
17

MODE D'EMPLOI
www.lenco.com
Veuillez lire attentivement ce mode d'emploi avant de brancher
utiliser l'appareil. conservez-le pour une consultation future.ou d'
Microchaîne avec lecteur
CD et DAB+
MC-148 DAB+

TABLE DES MATIÈRES
CONSIGNES DE SÉCURITÉ IMPORTANTES……………...............
PANNEAUX ET BOUTONS………………………………………….......
PRÉPARATION AVANT UTILISATION ………….......…………...…...
FONCTIONNEMENT GÉNÉRAL………….......…………………….....
UTILISATION D'UN CD ………….......……………….........….….......
UTILISATION EN DAB+………….......…………………….……..........
UTILISATION EN FM………….......…………………....………...........
ENTRÉE EXTERNE …….………………………………………….........
CARACTÉRISTIQUES TECHNIQUES .........................................
DÉPANNAGE………….…….……...…….…….…….........................
SERVICE ET SUPPORT .............................................................
2
4
5
6
7
9
13
15
15
16
17
ACCESSOIRES
•
•
•
•
1 appareil
2 haut-parleurs
1 télécommande (avec piles)
1 mode d'emploi
REMARQUE : Cet appareil est conçu pour passer en mode
VEILLE automatiquement au bout de 15 MINUTES (environ)
d'inactivité. Appuyez sur le bouton STANDBY/VEILLE pour
rallumer l'appareil.
REMARQUE : Lorsque vous mettez en marche l'appareil qui était en
veille, il reprend le dernier mode utilisé.
1
