Lennox Hearth Products EBVI25 User manual

B-VENT GAS
FIREPLACE
HEATER INSERTS
RETAIN THIS MANUAL FOR
FUTURE REFERENCE
Suitable for installation
into masonry or factory
built fireplaces
P/N 775,155M Rev. D,12/2005
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow your gas supplier's
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installationandservicemustbeperformedbyaquali-
fied installer, service agency or the gas supplier.
Lennox Elite®Series Models: EBVI25 & EBVI30
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d’essencenid’autrevapeursouliquidesinflammablesdans
le voisinage de cet appareil ou de tout autre appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L’installation et service doit être exécuté par un qualifié
installeur, agence de service ou le fournisseur de gaz.
WARNING:IFTHEINFORMATION INTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SIONMAYRESULTCAUSINGPROPERTYDAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE
POUR RÉDUIRE AU MINIMUM LE RISQUE D’INCENDIE
OU POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
Report No. 116-F-15-5
WARNINGS
• Hot! Do not touch! The glass and surfaces of this appliance
will be hot during operation and will retain heat for a while
after shutting off the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance.
• If small children are present in the home, it is recommended
that this appliance be fitted with a screen door or screen panel
kit. See Page 12 for ordering information.
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
2
It is imperative that the control compart-
ment,burnersandcirculatingairpassage
ways of the appliance be kept clean.
S'assurerquelebrùleuret lecompartiment
des commandes sont propres. Voir les
instructions d'installation et d'utilisation
qui accompagnent l'appareil.
GENERAL INFORMATION
Installation, repair and annual service in-
spection should be performed by a qualified
service technician.
Provideadequateclearancesaroundairopenings
and adequate accessibility clearance for service
and proper operation.
Never obstruct the front openings of the
appliance.
Due to high temperatures of this appliance
adequateclearancesneedtobemaintainedfrom
furnitureanddraperiesandothercombustibles.
Locatefurnitureand windowcoveringsaccord-
ingly.Therecommendedclearancezonefrom
thefrontoftheappliancetocombustiblesis36
inches(914 mm). Maintainall other clearances
as outlined in the Installation Manual.
These fireplaces are designed as supplemen-
tal heaters. Therefore, it is advisable to have
an alternate heat source when installed in a
dwelling.
Input of millivolt model is variable. The rates
are shown in the following table:
This appliance complies with National
Safety Standards and is tested and listed
by OMNI-Test Laboratories Inc.; Beaverton,
Oregon (Report No. 116-F-15-5) to ANSI
Z21.88-2002 (in Canada, CSA-2.33-2002),
and CAN/CGA-2.17-M91 in both USA and
Canada, as vented gas heaters.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code, ANSI Z223.1. (In Canada, the current
CAN-1 B149 installation code.) Electrical
wiring must comply with the National Elec-
trical Code ANSI/ NFPA 70 - latest edition.
In Canada, the current CSA C22-1 Canadian
Electrical Code - latest edition.
TABLE OF CONTENTS
Introduction ......................................Page 2
General Information..........................Page 2
Burn-In Period ..................................Page 3
Lighting Millivolt Appliances.............Page 3
Gas Controls .....................................Page 3
Control Compartment Access ...........Page 4
Operation & Care of Your Appliance..Page 4
Maintenance Procedures...................Page 4
Maintenance Schedule......................Page 6
Front Glass Door Assembly,
Removal and Installation.................Page 7
Burner Adjustments..........................Page 7
Flame Appearance and Sooting.........Page 7
Log Placement Instructions ..............Page 8
Millivolt Appliance Checkout.............Page 11
Blower Operation ..............................Page 11
Fireplace Requirements.....................Page 11
Wiring Diagrams...............................Page 11
Warranty Information........................Page 12
Accessory Components ....................Page 12
Lighting Instructions – Millivolt ........Page 15
Replacement Parts List.....................Page 17
Troubleshooting Guide......................Page 19
INTRODUCTION
The Insert model covered in this manual is
a B-Vent gas heater designed for residential
application for installation into an existing
masonry or factory built solid-fuel fireplace
using 4" diameter, UL1777 listed aluminum
liner for the exhaust. The vent must be routed
through the existing fireplace flue system to the
vent termination.
Thismillavoltappliance is designed to operate
on either natural or propane gas. A millivolt
gas control valve with piezo ignition system
provides safe, efficient operation. External
electrical power is required to operate the air
circulation blower.
Millivolt Models with
MAnnually-Modulated Gas Valves
Nat. Gas Propane
Model No. Input Rate
(BTU/HR)
Input Rate
(BTU/HR)
EBVI25 17,000 to
25,000
19,500 to
25,000
EBVI30 21,500 to
30,000
22,000 to
28,000
Table 1
WARNING
Do not attempt to alter or modify
theconstructionoftheappliance
or its components. Any modi-
fication or alteration may void
the warranty, certification and
listings of this unit.
WARNING
Improper installation, adjust-
ment, alteration, service or
maintenance can cause injury
or property damage. Refer to
this manual. For assistance or
additional information consult
a qualified installer, service
agency or the gas supplier.
WARNING
These fireplace Inserts are
vented heaters. Do not burn
wood or other material in these
appliances.
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW GAS APPLIANCE MANU-
FACTURED BY LENNOX HEARTH PRODUCTS.
When you purchased your new gas-fired heater, you joined the ranks of thousands of
individuals whose answer to their home heating needs reflects their concern for efficiency
and our environment. We extend our continued support to help you achieve the maximum
benefit and enjoyment available from your new gas-fired heater. It is our goal at Lennox
Hearth Products to provide you, our valued customer, with an appliance that will ensure
years of trouble-free warmth and pleasure.
Thank you for selecting a Lennox Hearth Products gas-fired heater as the answer to
your home heating needs.
Sincerely,
All of us at Lennox Hearth Products

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 3
Table 2 shows the main burner gas orifice
size for the elevations indicated.
Model
No.
Orifice Size Elevation
Feet
(meters)
Nat.
Gas
Prop.
Gas
EBVI25 #41
(.096")
#53
(.0595")
0-4500
(0-1372)
EBVI30 #37
(.104")
1/16"
(.0625")
0-4500
(0-1372)
Table 2
Tables 3 and 4 show the gas pressure
requirements for all models:
Inlet Gas Supply Pressure (all models)
Fuel # Minimum Maximum
Natural Gas 4.5" WC
(1.12 kPa)
10.5" WC
(2.61 kPa)
Propane 11.0" WC
(2.73 kPa)
13.0" WC
(3.23 kPa)
Table 3
Manifold Gas Supply Pressure (all models)
Fuel # Low High
Natural
Gas
(Lo) 1.6" WC
(.40 kPa)
(Hi) 3.5" WC
(.87 kPa)
Propane (Lo) 6.3" WC
(1.57 kPa)
(Hi) 10.0" WC
(2.49 kPa)
Table 4
Test gauge connections are provided on the
frontof the millivolt gas control valve (identi-
fied IN for the inlet and OUT for the manifold
side). See Figures 1 & 2.
This appliance must not be connected to a
chimney or flue serving a separate solid-fuel
appliance.
This appliance must be isolated from the gas
supplypipingsystem(byclosingitsindividual
manual shut-off valve) during any pressure
testing of the gas supply piping system at
test pressures equal to or less than 1/2
psig (3.5 kPa).
This appliance and its individual shut-off
valve must be disconnected from the gas
supply piping system during any pressure
testing of that system at pressures greater
than 1/2 psig (3.5 kPa).
WARNING
Carbon monoxide poisoning:
Early signs of carbon monoxide
poisoning are similar to the flu
withheadaches,dizzinessand/or
nausea. If you have these signs,
obtainfreshairimmediately.Turn
offthegassupplytotheappliance
and have it serviced by a quali-
fied professional, as it may not
be operating correctly.
WARNING
Failuretocomplywiththeinstal-
lationandoperatinginstructions
provided in this document will
result in an improperly installed
andoperatingappliance,voiding
its warranty. Any change to this
appliance and/or its operating
controlsisdangerous. Improper
installation or use of this appli-
ance can cause serious injury or
deathfromfire,burns,explosion
or carbon monoxide poisoning.
BURN-IN PERIOD
During the first few burns of these appliances
there will be some odor due to the curing of the
high temperature paint and burning off of lubri-
cants used in the manufacturing process.
Depending on your use, the burn-in period may
take a few hours or a few days. Do not turn on
blower during Burn-In period.
IMPORTANT
Keep your house well ventilated
during the curing process. The
odor and haze emitted by the
curing process can be quite
noticeable and may set off a
smoke detector.
O
N
O
F
F
P
I
L
O
T
L
O
H
I
Figure 1
GAS CONTROL
KNOB
CONVERTIBLE
HI/LO REGULATOR
(adjusts flame height
and heat output)
INLET
PRESSURE
TAP
PILOT
ADJUSTMENT
SCREW
WIRING
TERM-
INALS
OUTLET
PRESSURE
TAP
Model EBVI30
Honeywell Millivolt Gas Valve Controls
TP/TH
PIEZO
IGNITER
TH
TP
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
IN OUT
Figure 2
MODEL EBVI25
SIT Millivolt Gas Valve Controls
GAS CONTROL
KNOB
INLET
PRESSURE
TAP
OUTLET
PRESSURE
TAP
CONVERTIBLE
HI/LO REGULATOR
(adjusts flame height
and heat output)
PIEZO
IGNITER
GAS CONTROLS
Thesemillivoltappliancesarefittedwithaburner
Off/On Switch, located on the side surround
panelas shown in Figure 4 on Page 4. Once the
pilot is lit, and valve knob is in the ON position,
the Off/On switch will control the appliance
Off/On operation. To operate, toggle the switch
between its ON and OFF positions.
Variable Flame Height Adjustment
These millivolt appliances are equipped with
variable gas control valves. Flame height may
be adjusted through a range between fixed low
and high settings by rotating the HI/LO knob on
thevalve(seeFigures 1 & 2)whiletheappliance
is in operation.
LIGHTING MILLIVOLT APPLIANCES
To light millivolt appliances refer to the detailed
lighting instructions found on Page 15 (Eng-
lish) and Page 16 (French). Millivolt appliance
lighting instructions may also be found on the
pull-outlightinginstructionlabelslocatedin the
control compartment (below glass door).

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
4
MAINTENANCE
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service technician.
However, more frequent periodic inspections
and cleanings should be performed by the
homeowner. Homeowner must contact a quali-
fied service technician at once if any abnormal
condition is observed.
Refer to the maintenance schedule on Page
6for maintenance tasks, procedures, recom-
mended frequency and by whom they should
be performed. Always verify proper operation
of the appliance after servicing.
Always turn off the gas and unplug the power
cord to the appliance before cleaning. Before
re-lighting, refer to the lighting instructions in
this manual. Instructions are also found on
pull-out panels located below the glass door
in the control compartment.
Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
More frequent cleaning may be required due to
excessivelintfromcarpeting,beddingmaterials,
etc. It is important that control compartments,
burners and circulating air passageways of the
appliance be kept clean.
CONTROL COMPARTMENT ACCESS
Pull down hinged door to access control
compartment (see Figure 3).
Control Compartment Access
Pull down hinged door to access control compartment
Pull down lower
louver (hinged)
Side View of Insert
Figure 3
Ifyourmillivolt appliance is equipped with an
optionalwallthermostat kitorremotecontrol
kit and the pilot is lit (and valve is in the On
position), the appliance main burner may be
turned on and off with the wall thermostat
or remote control.
Always keep the appliance area clear and
free from combustible materials, gasoline
and other flammable liquids.
Remember, millivolt appliances have a
continuous burning pilot flame. Exercise
caution when using products with combus-
tible vapors.
WARNING
Children and adults should be
alerted to the hazards of high
surface temperatures. Use cau-
tion around the appliance to
avoid burns or clothing ignition.
Youngchildrenshouldbecarefully
supervised when they are in the
same room as the appliance.
Do not attempt to touch the front
enclosureglass with yourhands
while the fireplace is in use.
Note:AnOptionalScreenPanelfor
the glass is available (see Page
12 for ordering information).
WARNING
Do not place clothing or other
flammable materials on or near
this appliance.
AVERTISSEMENT
Surveiller les enfants. Garder les
vêtements,lesmeubles,l'essence
ouautresliquidesà vapeurinflam-
mables loin de l'appareil.
WARNING
Do not use these appliances if
any part has been under water.
Immediately call a qualified,
professional service technician
to inspect the appliances and to
replace any parts of the control
system and any gas controls
which have been under water.
AVERTISSEMENT
Ne pas se servir de cet appareil
s'il a été plongé dans l'eau,
complètement ou en partie.
Appeler un technicien qualifié
pourinspecterl'appareiletrem-
placertoutepartiedusystèmede
contrôle et toute commande qui
ont été plongés dans l'leau.
Figure 4
Burner Off/on Switch and Rheostat Location
If optional surround is installed
Burner Off/On
Switch
Rheostat
(blower
speed
control)
Left Front
surround
Panel
Units with Beveled Surround
Units with Flat Surround
Left Front
surround
Panel
Rheostat
(blower
speed
control)
Burner Off/on
Switch
CAUTION
Wear gloves and safety glasses
for protection while doing
required maintenance.
IMPORTANT
Always verify proper operation
after servicing.
WARNING
Turnoff gas andelectricalpower
before servicing the appliance.
OPERATION AND CARE OF YOUR
APPLIANCE
Appliance operation may be controlled
through a remotely located optional wall
thermostat or remote control.
Inlieu ofremote controlorremote wallthermo-
stat operation, the appliance must be operated
directlythroughtheoff/onswitchlocatedonthe
side surround panel (see Figure 4).
Check Burner Flame Appearance
Visually check the flame of the burner periodi-
cally making sure the flames are steady and not
lifting or floating (see Figure 13 on Page 7).

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 5
Small Area Paint Touch-up
The finish of the insert body and surround
(optional) is a high-quality powdercoat. Only
use factory supplied powdercoat paint kit for
touch-ups (cat. no. 90L74).
Do not attempt to repaint the insert until the
finish is completely cured (see Burn-In Period
onPage 3). Ifthesurfacelaterbecomesstained
ormarred,it maybelightly sandedandtouched
up with spray paint.
PaintisavailableatyourlocalauthorizedLennox
Hearth Products dealer. Never attempt to paint
a hot insert.
Inspect Wiring
Inspect and clean all wire connections. Ensure
that there is no melting or damage. Inspection
should include:
• Terminals at the valve
• Off/On switch
• Wall thermostat, remote control, or control
kit (optional parts)
• Spill switch
Refer to wiring diagrams on Pages 11 & 12.
WARNING
Do not attempt to touch the front
enclosure glass with your hands
while the fireplace is in use.
IMPORTANT
Do not use abrasive cleaners
on glass. Never clean the glass
when it is hot.
Glass Cleaning
Note: Clean glass after first two weeks of
operation (after Burn-In period is over).
The viewing glass should be cleaned periodi-
cally to remove any build-ups caused from the
following:
• During start-up, it is normal for condensa-
tion to form on the inside of the glass (this
condensation and fog will usually disappear
in a few minutes). This can cause lint, dust
and other airborne particles to cling to the
glass surface.
• Initial curing of the high temperature paint
and burning off of lubricants used in the
manufacturing process may result in a film
on the glass.
• A white coating may form on the glass as a
result of impurities and minerals in the fuel.
It is recommended that the glass be cleaned
two or three times during each heating season,
depending on the circumstances present.
Use one of the following to clean glass:
• Non-ammonia based household cleaner
• 50%-50% mix of white vinegar & water
• gas stove glass cleaner
CAUTION
Label all wires prior to discon-
nection when servicing con-
trols. Wiring errors can cause
improper and dangerous appli-
ance operation.
Check
Connections
Spill Switch
Draft Hood
Figure 10
Servicing Blower
To access the blower assembly for mainte-
nance, adjustment or replacement, see the
following procedure:
1. Unplug 120-volt A.C. power supply to
insert.
2. Shut off gas supply to insert.
3. Remove Glass Door (see Procedure
For Removing Standard Glass Door
Assembly on Page 7).
4. Remove log set, burner and grate.
5. Remove blower access panel and
gasket (see Figure 5 for model EBVI25
and Figure 6 for model EBVI30). Be
careful not to damage the gasket.
Access Panel
w/ Gasket
Figure 6
6. (Model EBVI25) Remove the two hex
head bolts shown in Figure 7.
(Model EBVI30) Remove the two
screws shown in Figure 8, then lift
out air duct channel.
Model EBVI30
Figure 5
Access Panel
w/ Gasket
Model EBVI25
Remove 10 Screws (use phillips screwdriver)
Remove 12 Screws (use phillips screwdriver)
Figure 8
Remove 2 Screws
7. Disconnect wires from the blower.
8. Lift blower up and pull it out from back
opening of firebox (see Figure 9).
9. To reinstall blower, reverse Steps 1
through 8.
Figure 7
Blower
Remove 2 Bolts
Model EBVI30
Model EBVI25
Lift Out Air
Duct Channel
Figure 9
Blower Assembly

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
6
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping
for leaks. Vacuum the control compartment, fireplace logs and
burner area.
Check Flame Patterns and Flame
Height
Qualified Service Technician Refer to Figure 13 on Page 7 and verify the flame pattern
and height displayed by the appliance conforms to the picture.
Flames must not impinge on the logs.
Inspecting/Cleaning Pilot and Burner Qualified Service Technician Refer to Figure 13 on Page 7 and Figure 25 on Page 11.
Remove any surface build-up on pilot and burner assembly.
Wipe the pilot nozzles, ignitor/flame rod and hood. Ensure the
pilot flame engulfs the flame sensor as shown.
Checking Vent System Qualified Service Technician Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation of the vent components.
Appliance Checkout Qualified Service Technician Perform the appropriate appliance checkout procedure detailed
in this manual.
Replacing Rockwool Ember Materials Homeowner/Qualified Services Techni-
cian
Remove old ember materials and vacuum the rockwool place-
ment area. Place new rockwool as described on Page 10 (see
Figure 23).
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior Homeowner Carefullyremovelogs,rockwoolandandvermiculite. Vacuumout
interiorof the firebox. Clean firebox walls and log grate. Replace
logs, Rockwool and vermiculite as detailed in this manual.
Check Flame Patterns and Flame
Height
Homeowner Refer to Figure 13 on Page 7 and verify the flame pattern and
heightdisplayedbytheapplianceconformstothepicture. Flames
must not impinge on the logs.
Checking Vent System Homeowner Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation of the vent components.
Cleaning Front Door Window Homeowner Clean as necessary following the directions provided in this
manual. DO NOT TOUCH OR ATTEMPT TO CLEAN GLASS WHILE
HOT.
Annually (Before the onset of the Burning Season)
MAINTENANCE

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 7
PROCEDURE FOR REMOVING STANDARD
GLASS DOOR ASSEMBLY
Burner Flame Appearance
BURNER ADJUSTMENT
Flame Appearance and Sooting
Properflameappearanceisaflamewhichisblueatthe baseandbecomes
yellow/orange in the top of the flame. When the insert is first lit, the
entire flame may be blue and will graduallay turn yellow/orange during
the first 6-8 minutes of operation. If after 6-8 minutes the flame stays
blue, or if the flame is orange with evidence of sooting (black tip), the
air shutter may require adjustment.
An appliance operated with an air shutter opening that is too large will
exhibit flames that are blue and transparent. These weak, blue and
transparent flames are termed anemic. If the air shutter opening is too
small, sooting may develop.
Sooting is indicated by black puffs developing at the tips of very long
orange flames. Sooting results in black deposits forming on the logs,
appliance inside surfaces and on exterior surfaces adjacent to the
vent termination. Sooting is caused by incomplete combustion in the
flames and lack of combustion air entering the air shutter opening. To
achieve a warm yellow to orange flame that does not soot, the shutter
opening must be adjusted between these two extremes.
No smoke or soot should be present. Reposition the logs if flames
impinge on any of them. If the logs are properly positioned and
sooting conditions exist, the air shutter opening on the main burner
tube should be adjusted.
Figure 13 EBVI25 Shown
Release latch on
each side (below door)
Remove the front door assembly from insert as follows:
1) Open the two latches below the glass door as shown in Figures
11 & 12.
Figure 11
2) Swing the bottom of the door outward (see Figure 12)and lift it
off of firebox top. Set door aside in a safe place.
Figure 12
Latches
Glass Door
Top
Flange
Door
Frame
Firebox Floor
Bottom Vee-flange
Door Frame
Glass Door
WARNING
Handle glass door with extreme care! The glass
door assembly is susceptible to damage. Do not
scratch while handling or while reinstalling.
WARNING
Neveroperateunitwithoutthefrontglassdoorpanel
in place and secure.
IMPORTANT
Ensure that the front glass panel is in place and
sealed during adjustment.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
8
Iftheburner flameappearance differsgreatly
from what is shown in Figure 13 (see Burner
Flame Appearance), some adjustment from
thefactorysettingforthe air shutter gap may
be necessary (to compensate for variables
in the installation and fuel such as, BTU
value/composition, gas pressure, specific
gravity of gas, altitude, etc.).
See Table 5 on Page 8 for Burner Air Shutter
Adjustment Guidelines.
Initially, always position the air shutter to the
factorysettingasshowninFigure 14 (adjust-
mentrodis locatedin thelowercontrolarea).
This can be done by moving the adjustment
rodupordownaccordingly. Allowthe burner
to operate for at least 15 minutes. Observe
the flame continuously. If it appears weak
or sooty as previously described, adjust the
air shutter to a more open position until the
proper flame appearance is achieved.
Burner Adjustment Procedure
Burner Air Shutter Adjustment
Adjustment Rod Up
(1/8" Open Position)
Air Shutter
Burner Tube
Adjusting Set Screw
Adjustment Rod Down
(full open position)
Figure 14
MAIN BURNER FACTORY AIR
SHUTTER OPENING SETTING
Model Gas Type Air Shutter Gap
EBVI30 Natural Gas 5/16" (7.94mm)
Propane 1/2" (12.7mm)
EBVI25 Natural Gas 1/16" (1.59mm)
Propane 1/2" (12.7mm)
WARNING
Air shutter adjustment should
only be performed by a qualified
professional service technician.
CAUTION
The adjustment rod and nearby
appliance surfaces are hot. Exer-
cise caution to avoid injury while
adjusting flame appearance.
CAUTION
Carbon will be produced if the air shutter is closed too much. Any
damage due to carboning resulting from improperly setting the air
shutter is not covered under the warranty.
LOGS, VERMICULITE AND EMBERS
Carefully install the seven-piece log set into the firebox as shown in these instructions. All
logs should fit onto corresponding pins and/or log stoppers. This will ensure a proper flame
and safe combustion.
Note: Place some vermiculite around burner before installing logs (see Figure 24). The entire
bag of vermiculite will NOT be used.
The following chart is provided to aid you in achieving the correct air shutter adjustment
for your installation.
Table 5
Air Shutter Adjustment Guidelines
Amount of
Primary Air
Flame Color Air Shutter
Adjustment
If air shutter is
closed too far
Flame will be orange Air shuttergap should
be increased
If air shutter is open
too far
Flame will be blue Airshuttergap should
be decreased
WARNING
If logs are not installed according to the directions shown here, flame
impingement and improper combustion could occur and result in soot
and/or excessive production of carbon monoxide (CO) - a colorless,
odorless, toxic gas.
Top Left Log
Front Center Log
Top Right Log
Rear Log
Front Right Log
Front Left Log
Center Log
Figure 15
Installation Instructions

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 9
1. Place the rear log onto the two corresponding locating pins at the
back of the firebox as shown in Figure 16.
2. Place the Front Right Log onto the two corresponding locating pins
as shown in Figure 17.
3. Place the Center Log onto the two corresponding locating pins as
shown in Figure 18.
Figure 16 Rear Log
Figure 17 Front Right Log
Figure 18 Center Log
4. Place the Front Left Log onto the two corresponding locating pins
as shown in Figure 19.
5. Install the Top Left Log onto the corresponding locating pin and
indentation on Center Log as shown in Figure 20.
6. Install the Front Center Log over the Front Right Log. The front
of log will rest on the burner and the back of log will rest on rear
log as shown in Figure 21.
7. Install the Top Right Log into the corresponding indentations on
Front Center Log and front right twig as shown in Figure 22.
Figure 19 Front Left Log
Figure 20 Top Left Log
Figure 21 Front Center Log

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
10
8. Place the glowing embers on the burner as shown in Figure 23.
One package of ember material has been included with this log set
You will not need to use the entire bag.
IMPORTANT: The quantity and placement of the ember material can
affect insert performance therefore it is very important that it be placed
as shown in Figure 23.
a. Unpackage and divide the fine ember material (mineral wool) into
dime-sized fluffy pieces.
b. Distribute the pieces over the top of the front burner ports, filling the
area in front of the forward logs.
Figure 23 Embers
9. Place some vermiculite around the logs as shown in Figure 24
(the entire bag of vermiculite will NOT be used).
Figure 22 Top Right Log
Figure 24 Vermiculite

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 11
Tolighttheburner,rotatethegasvalvecontrol
knob counterclockwise to the “ON” position
then turn “ON” the off/on switch mounted
on the surround assembly (see Figures 1 &
2on Page 3)or operate the burner with the
optional remote control, wall thermostat or
control switch.
Withproper careand maintenance,your appli-
ance will provide many years of enjoyment. If
you should experience any problem, first refer
to the troubleshooting guide in this manual. If
problem persists, contact your Lennox Hearth
Products Dealer.
BLOWER OPERATION
When the insert heats up, the blower will auto-
matically be turned on by the fan disc located
under the firebox bottom on the front left side.
It will come on at the speed determined by the
rheostatlocatedonthesidesurroundpanel(see
Figure 4 onPage 4).To adjusttheblowerspeed,
dial the rheostat to the desired speed setting.
Rotate the dial down (clockwise), just past the
click(thefirstONposition)forthehighestspeed
setting. Turning the knob further clockwise will
provide slower blower speeds.
Note: If the rheostat is not turned “on,” the
blower will not operate.
Proper Pilot Flame Appearance
MILLIVOLT APPLIANCE CHECKOUT
Light the pilot by following the instructions on
Page 15 or 16 of this manual.
The pilot flame should be steady, not lifting
orfloating.Flame shouldbe blueincolorwith
tracesoforangeattheouteredge.Thetop3/8"
(10 mm) at the pilot generator (thermopile)
and the top 1/8" minimum (tip) of the quick
drop out thermocouple should be engulfed
inthe pilot flame. The flameshould project 1"
(25 mm) beyond the hood at all three ports
(Figure 25).
Replace logs if removed for pilot inspec-
tion.
Figure 25
Fireplace Warning Label
(Provided in Accessory Package)
FIREPLACE REQUIREMENTS
IMPORTANT: When installing this appliance
into a factory built fireplace or heatform, the air
flow within and around the fireplace shall not
be altered by the installation of the insert (i.e.
DO NOT BLOCK louvers or cooling air inlet or
outlet ports, circulating air chambers in a steel
fireplace liner or metal heat circulator).
CAUTION: The factory built firebox must
accept the insert without modification other
than removing bolted or screwed together
piecessuchassmokeshelf/deflectors,ashlips,
screenordoortracks,log grates,refractory and
damper assemblies. Any fireplace component,
which is removed, must be retained so they
can be reinstalled to restore the fireplace to
its original operating condition. The removal
of any part must not alter the integrity of the
outer shell of the pre-engineered fireplace
cabinet in any way.
Ifanycomponentsareremovedfrom(oraltered)
from the existing fireplace, a Warning Label
(see below) must be affixed inside the fireplace
firebox,sothatitshallbevisibleuponremovalof
thefireplaceinsert. Note:RTVhightemperature
silicone is an approved adhesive.
WARNING
THIS FIREPLACE HAS BEEN ALTERED TO
ACCOMMODATE A FIREPLACE INSERT
AND SHOULD BE INSPECTED BY A QUALI-
FIED PERSON PRIOR TO RE-USE AS A
CONVENTIONAL FIREPLACE.
Figure 26
1/8" Min.
(3 mm)
Thermocouple
Igniter Rod Hood
3/8" Min.
(9 mm)
Thermopile
Pilot
Nozzels
WIRING DIAGRAMS
Wiring diagrams are provided here for refer-
ence purposes only. This information is also
providedon schematics attached directly to the
appliance on a pullout panel located within the
control compartment.
WARNING:THEPOWERCORD MUST BE
PLUGGED DIRECTLY INTO A PROPERLY
GROUNDED THREE-PRONG 120 VOLT,
60 HZ WALL RECEPTACLE. DO NOT CUT
OR REMOVE THE GROUNDING PRONG
FROM THIS PLUG. DO NOT ROUTE
POWER CORD UNDER OR IN FRONT
OF APPLIANCE.
Room Air Circulation Blower
Figure 27
Fan Disc
Rheostat
Blower
Assembly
Power Cord
Black
Hot (Live)
RedBlackBlack
Black
120 V AC
Blower Wiring Diagram
IMPORTANT: BLOWER GROUND WIRE
WITH POWER CORD GREEN WIRE
SHOULDBEATTACHED TOTHEGROUND
SCREW. FAILURE TO DO SO WILL
RESULT IN A POTENTIAL SAFETY
HAZARD. THE APPLIANCE MUST BE
ELECTRICALLY GROUNDED IN ACCOR-
DANCE WITH LOCAL CODES OR, IN
THE ABSENCE OF LOCAL CODES, THE
NATIONAL ELECTRICAL CODE, ANSI/
NFPA70-LATESTEDITION.(INCANADA,
THE CURRENT CSA C22-1 CANADIAN
ELECTRICAL CODE - LATEST EDITION.
White
(Neutral)
Green
(Ground)
CAUTION
Label all wires prior to discon-
nection when servicing con-
trols. Wiring errors can cause
improper and dangerous appli-
ance operation.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
12
Figure 28
If original wire as supplied must be replaced, it must be
replaced with Type AWM 105°C, 18 gauge wire.
* Off/on Switch, Optional Thermostat or Remote
Control Receiver
Thermopile
* Switch
Spill
Switch
SIT & Honeywell
Millivolt Wiring Diagram
TH
TP TH
TP
ACCESSORY COMPONENTS
PRODUCT REFERENCE INFORMATION
Your Insert's Model Number __________________________________________
Your Insert's Serial Number___________________________________________
The Date On Which Your Insert Was Installed _____________________________
The Type of Gas Your Insert Uses ______________________________________
Your Dealer's Name ________________________________________________
Ifyouencounteranyproblemsorhaveanyques-
tions concerning the installation or application
of this system, please contact your distributor.
For the number of your nearest Lennox dealer,
please call 800-9-Lennox.
LENNOX HEARTH PRODUCTS
1110 West Taft Avenue
Orange, CA 92865
Visit us at www.LennoxHearthProducts.com
WARRANTY INFORMATION
Your gas appliance is covered by a limited
twenty-year warranty. You will find a copy
of the warranty accompanying this manual.
Please read the warranty to be familiar with
its coverage.
Retain this manual. File it with your other docu-
ments for future reference.
REPLACEMENT PARTS
A complete parts list is found at the end of
this manual. Use only parts supplied from the
manufacturer.
All parts should be ordered through your
Lennox Hearth Products Distributor or Dealer.
Parts will be shipped at prevailing prices at
time of order.
When ordering repair parts, always give the
following information:
1. The model and serial number of the appli-
ance (see rating plate in control compartment
of appliance).
2. The part number & description of part (see
Page 17).
3. The quantity required.
4. The installation date of the appliance.
Cat. No. Model Description
H0916 TPSDK-30BVI Twin-Pane Screen Door Kit, Md. BVI
H1501 TPSDK-25 Twin-Pane Screen Door Kit, Sm. BVI
Screen Door Kit
These decorative screen door panels fit over
the standard glass door panels.
Cat. No. Model Description
H1502 BFK-25I` Bay Front Kit, Small, EBVI25
H1581 BFK-30BVI Bay Front Kit, Medium, EBVI30
Bay Front Kits
These decorative bay front assemblies fit over
the standard flat glass doors.
CAT# MODEL# DESCRIPTION
H3595 TAPSDK25C 25” Charcoal, EBVI25
H3596 TAPSDK25TI 25” Textured Iron, EBVI25
H3597 TAPSDK25SP 25”Satin Pewter EBVI25
H3840 TAPSDK25PC 25” Pewt/Charc, EBVI25
H3598 TAPSDK30C 30” Charcoal, EBVI30
H3599 TAPSDK30TI 30” Textured Iron, EBVI30
H3600 TAPSDK30SP 30” Satin Pewter, EBVI30
H3841 TAPSDK30PC 30” Pewt/Charc, EBVI30
Tall Arch Pane Screen Door Kits
These decorative screen door panels fit on the
face of the appliance surround (eliminating the
need for the top and bottom louver panels).

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 13
Cat. No. Model Description
89L36 WTK Wall Thermostat KiT
Wall Thermostat
The wall thermostat kit provides temperature
control for optimum comfort.
    

  

Cat. No. Model Description
H1511 BWTK-25G Bay Window Trim Kit, Gold,
EBVI25
H1512 BWTK-25BS Bay Window Trim Kit, Brushed
Stainless, EBVI25
H0898 BWTK-30G Bay Window Trim Kit, Gold,
EBVI30
H0899 BWTK-30BS Bay Window Trim Kit, Brushed
Stainless, EBVI30
Decorative Bay Window Trim Kits
These decorative trim accents, install along the
top and bottom front edges of the bay window.
They are available in two different finishes to
enhance the beauty of the insert and are sure
to fit into any decor.
Brick Liner Kit
Thebrickadelinerkitincludespanelsfor therear
and side walls of the firebox. The panels have
brick-likefeatures in relief. This kit can beretro-
fitted into a previously installed appliance.
Cat. No. Model Description
H0917 BLK-30BVI Brick Liner Kit, EBVI30
H1577 BLK-25BVI Brick Liner Kit, EBVI25
Cat. No. Model Description
H0249 RCL Remote Control System (Standard)
Standard Remote Control System
The Model RCL (Standard) Remote Control
System, features a simple Off/on control
function for the insert. This model includes a
hand-held transmitter, a remote receiver with
wall-mountcoverplateandallhardwarerequired
to install the unit. The remote receiver can be
wall or hearth mounted.
Deluxe Remote Control System
The Model RCL-T (Deluxe) Remote Control
System has all of the features of the standard
system along with an added easy to read LCD
screenwhichpresentsaccesstomanyenhance-
ments, including battery power level indicator,
timer, mode of operation, thermostatic display
including room temperature in either metric
or English units, flame indicator and clock.
Fully programmable, the Model RCL-T allows
for command over nearly all operational and
temperature variables, using the hand held
remote control transmitter.
Cat. No. Model Description
H0251 RCL-T Remote Control System (Deluxe)
ACCESSORY COMPONENTS
Touch-Up Powdercoat Paint Kit
Repair of minor scratches and discoloration of
theappliance'scharcoalpowdercoatedsurfaces
may be accomplished with the use of this touch-
up paint kit.
Cat. No. Model Description
90L74 TPK-C Touch-Up Powdercoat Paint Kit
P
A
I
N
T
Control Kit
If an optional surround kit is not purchased,
this kit is required to provide the off/on switch
and rheostat.
Cat. No. Model Description
H0919 CK-EI Control Kit, Elite Inserts

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Cat. No. Model Description
H1503 SKS-25 Beveled Surround, Small, EBVI25
H1504 SKM-25 Beveled Surround, Medium, EBVI25
H0881 SKS-30 Beveled Surround, Small, EBVI30
H0882 SKM-30 Beveled Surround, Medium, EBVI30
H0883 SKL-30 Beveled Surround, Large, EBVI30
Sizes
SKS-25 = 41 1/16" W X 26 1/16" H
SKM-25 = 44 1/8" W X 27 5/8" H
SKS-30 = 40 1/4" W x 27 1/2" H
SKM-30 = 45 3/4" W x 30 1/4" H
SKL-30 = 49 1/4"" W x 30" H
Height
14
Cat. No. Model Description
H1505 FLK-25 Flat Louver Kit, Charcoal, EBVI25
H1506 FLK-25G Flat Louver Kit, Gold, EBVI25
H1507 FLK-25BS Flat Louver Kit, Br. Stainless, EBVI25
H0846 FLK-30BVI Flat Louver Kit, Charcoal, EBVI30
H0847 FLK-30BVIG Flat Louver Kit, Gold, EBVI30
H0848 FLK-30BVIBS Flat Louver Kit, Br. Stainless, EBVI30
Decorative Flat Louver Kits
Thesedecorativetrimaccents,installabove and
belowtheglass door. They are available in three
different finishes to enhance the beauty of the
insert and are sure to fit into any decor.
Width
Beveled Surround Kits
These beveled surround panels install around
the insert body providing an attractive finished
look.
Decorative Bay Louver Kits
These decorative trim accents, install above
and below the optional Bay Front Assembly.
They are available in three different finishes to
enhance the beauty of the insert and are sure
to fit into any decor.
Cat. No. Model Description
EBVI25
H2042 HRKS1-25 Hearth Riser Kit, SM, E25I, 1”
H2043 HRKS3-25 Hearth Riser Kit, SM, E25I, 3”
H2044 HRKS6-25 Hearth Riser Kit, SM, E25I, 6”
H2045 HRKM1-25 Hearth Riser Kit, MED, E25I, 1”
H2046 HRKM3-25 Hearth Riser Kit, MED, E25I, 3”
H2047 HRKM6-25 Hearth Riser Kit, MED, E25I, 6”
EBVI30
H2098 HRKS1-30 Hearth Riser Kit, SM, E30I, 1”
H2099 HRKS3-30 Hearth Riser Kit, SM, E30I, 3”
H2100 HRKS6-30 Hearth Riser Kit, SM, E30I, 6”
H2101 HRKM1-30 Hearth Riser Kit, MED, E30I, 1”
H2102 HRKM3-30 Hearth Riser Kit, MED, E30I, 3”
H2103 HRKM6-30 Hearth Riser Kit, MED, E30I, 6”
H2104 HRKL1-30 Hearth Riser Kit, LG, E30I, 1”
H2105 HRKL3-30 Hearth Riser Kit, LG, E30I, 3”
H2106 HRKL6-30 Hearth Riser Kit, LG, E30I, 6”
Panels are available in 1”, 3” & 6” heights
Hearth Riser Trim Panel
Hearth Riser Kits
The hearth riser trim kits are designed to be
used with the optional surround kits (sold
separately). It provides a finished look below
the insert face when installed into fireplaces
with a elevated firebox.
SM = used with small surround
MED = used with medium surround
LG = used with large surround
Insert Surround
Cat. No Model Description
H3391 EFS-E25I Elite Insert Flat Surround Kit,
EBVI25
H3390 EFS-E30I Elite Insert Flat Surround Kit,
EBVI30
Flat Surround Kits
These flat surround kits are designed to have
the outside overall dimensions cut down
when custom shaped surround trim panels
are needed.
Cat. No. Model Description
H1508 BYLK-25 Bay Louver Kit, Charcoal, EBVI25
H1509 BYLK-25G Bay Louver Kit, Gold, EBVI25
H1510 BYLK-25BS Bay Louver Kit, Brushed
Stainless, EBVI25
H1582 BYLK-30BVI Bay Louver Kit, Charcoal, EBVI30
H1583 BYLK-30BVIG Bay Louver Kit, Gold, EBVI30
H1584 BYLK-30BVIBS Bay Louver Kit, Brushed
Stainless, EBVI30

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 15
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
it
O
F
F
OUT
OUT
IN
IN
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B” in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark igniter (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1-1/2 minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released, stop
and immediately call your service technician
or gas supplier.
•If pilot will not stay lit after several tries,
turn the control knob to “OFF” and call
your service technician or gas supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
LIGHTING INSTRUCTIONS – MILLIVOLT GAS VALVE
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY, READ BEFORE LIGHTING
A. This appliance has a pilot which must be lighted with a piezo
igniter. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING, smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.” The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
4. Depress gas control knob slightly and turn clockwise
to “OFF.” Do not force.
5. Close lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician. Force
or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT” to “OFF”
unless the knob is pushed in slightly. Do not force.
Millivolt Pilot
Honeywell Millivolt
Gas Valve
O
N
O
F
F
P
I
L
O
T
L
O
H
I
GAS CONTROL
KNOB - LO/HI +
TP/TH
TH
PIEZO
IGNITER
TP
SIT Millivolt
Gas Valve
PIEZO
IGNITER
- LO/HI +
GAS CONTROL
KNOB
TP/TH
TH
TP

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
16
INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT
INSTRUCTIONS D'ALLUMAGE
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz
à étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à 8 inclusive-
ment.
• Si le bouton ne sort pas automatiquement après avoir été relâché,
arrêtez immédiatement et téléphonez à votre technicien de service
ou à votre fournisseur de gaz.
• Si la veilleuse refuse de rester allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à sa position d’arrêt “OFF” et
téléphonez à votre technicien de service ou à votre fournisseur de
gaz.
9. Tournez le bouton de réglage du gaz en sens inverse des aiguilles
d’une montre jusqu’à sa position de marche “ON”.
10. Fermez le compartiment de contrôle du bas.
11. Au besoin, rebrancher l’appareil au
courant électrique et remettre
l’interrupteur du brûleur principal
à la position “ON” ou régler le
0thermostat à la température désirée.
12. Si l’appareil ne fonctionne pas,
suivre les instructions intitulées
“Pour fermer le gaz qui alimente
l’appareil” et appeler un technicien
ou le fournisseur de gaz.
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANTL’ALLUMAGE:Assurez-vous que vous ne détectez aucune odeur
de gaz autour de l’apareil ainsi que près du sol; certains gaz, étant plus
lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez à aucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelez immédiatement votre compagnie de gaz en utilisant le télé-
phone du voisin.
•S’il vous est impossible de contacter votre compagnie de gaz, appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de bouger,
n’essayez pas de le réparer. Communiquez immédiatement avec un
technicien de service qualifié. Toute tentative pour le forcer ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergé dans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a été sous l’eau.
1. ARRÊTEZ! Lisez les consignes de sécurité au verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale est
ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”.
Remarque: Il est impossible de tourner le bouton de “PILOT” à “OFF” à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B” des consignes
de sécurité au verso de cette plaque. Si vous ne remarquez aucune
odeur de gaz, passez à l’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le en
sens inverse des aiguilles d’une montre jusqu’à la position de veil-
leuse “PILOT”.
1. Tournez l’interrupteur mural à la position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural à la posi-
tion d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
Millivolt Pilot
SIT Vanne
Gaz Millivolt
TP/TH
TH
TP
BOUTON DE RÉGLAGE DU GAZ
ALLUMEUR
- LO/HI + (COMMANDE
DE TAILLE DE FLAMME)
Honeywell Vanne
Gaz Millivolt
O
N
O
F
F
P
I
L
O
T
L
O
H
I
TP/TH
TH
TP
BOUTON DE RÉGLAGE DU GAZ
- LO/HI + (COMMANDE
DE TAILLE DE FLAMME)
ALLUMEUR
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
it
O
F
F
OUT
OUT
IN
IN

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 17
REPLACEMENT PARTS LIST
Gas Controls
Item # Part/Cat. No. Description Where Used
1 67L7001 Pilot Assembly, NG/LP EBVI25 & EBVI30
2 67L6801 Pilot Tube EBVI25 & EBVI30
3 67L6701 Thermocouple EBVI25 & EBVI30
4 60J79 Thermopile (pilot generator) EBVI25 & EBVI30
5a 111061 Piezo Igniter EBVI25
5b 24M8901 Piezo Igniter EBVI30
6 67L8701 Electrode Cable (piezo igniter wire w/ electrode) EBVI25 & EBVI30
7a H1657 Gas Valve, NG – SIT EBVI25
7b 24M1201 Gas Valve, NG – Honeywell EBVI30
Misc. Gas Components
8 H1161 Burner Assembly NG/LP EBVI25 & EBVI30
H1576 Conversion Kit, NG to LP (GCKNL-E25I) EBVI25
H0920 Conversion Kit, NG to LP (GCKNL-E30I) EBVI30
9 93L32 Connector-Flex Gas EBVI25 & EBVI30
10a 21L79 Orifice, Burner, NG (#41) EBVI25
10a 24M1001 Orifice, Burner, NG (#37) EBVI30
10b 69L45 Orifice, Burner, LP (#53) EBVI25
10b 21L01 Orifice, Burner, LP (.0625”) EBVI30
Miscellaneous Parts
12 H1585 Door Kit, Complete EBVI25
12 H0925 Door Kit, Complete EBVI30
13 H0928 Grate Assembly EBVI25 & EBVI30
69L2101 Latch, Door EBVI25 & EBVI30
14a H1138 Switch, Vent Spill Switch EBVI25 & EBVI30
15 27K30 Switch, Off/on EBVI25 & EBVI30
Log Set
16 88L53 FGE Glowing Embers EBVI25 & EBVI30
17 H1095 Log Set, 7 pc. EBVI25 & EBVI30
18 42363 Vermiculite, Bag EBVI25 & EBVI30
Room Air Blower System
19 H1391 Blower Assembly, 7” (H1128) EBVI25
19 H1141 Blower Assembly, 9” EBVI30
20 H1157 Power Cord EBVI25 & EBVI30
21a H1290 Rheostat (knob included) EBVI25 & EBVI30
21b 527 Knob, Rheostat EBVI25 & EBVI30
14b 13M2301 Switch, Temp. Control (TOD) EBVI25 & EBVI30

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
REPLACEMENT PARTS DIAGRAMS
9
15
16
17
3
4
2
12
7b
O
N
O
F
F
P
I
L
O
T
L
O
H
I
5b
1
8
19 18
13
20 14b
21a
21b 14a
10b
10a
7a
5a
6
18

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 19
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in the
“ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION
1) Spark igniter will not light
pilot after repeated triggering of
igniter button.
WARNING: IF THE PILOT WILL
NOTLIGHTAFTERONEMINUTE
OFATTEMPTING, WAITFORAT
LEASTFIVEMINUTESFORGAS
TO CLEAR BEFORE ATTEMPT-
ING AGAIN.
A. Electrode wire (at piezo igniter) not pushed completely
on. • Check connection
B. Piezo igniter is defective • Replace piezo igniter
C. Defective or misaligned electrode at pilot (spark at
electrode) • Using a match, light pilot. If pilot lights, turn off pilot and trigger the igniter
button again. If pilot lights, an improper gas mixture caused the bad lighting
and a longer purge period is recommended. If pilot will not light – check gap at
electrode and pilot – It should be between 1/8” and 3/16.” If the gap is out of this
range, adjust the gap or replace the pilot assembly. See Page 11, Figure 25.
D. Incorrect lighting procedure • Carefully follow the lighting instructions on Pages 15 &16 or as found in the
insert control compartment.
E. Gas supply problem • Check for multiple gas shut-offs. Check gas supply lines. Check inlet gas
pressure. It should be within the limits as marked on the rating plate.
F. Pilot orifice plugged • Clean or replace pilot orifice
2) Pilot will not stay lit after
carefully following the lighting
instructions.
A. Thermocouple is not firmly connected to control valve • Check connection at valve
B. Pilot flame is not directed to top of thermocouple • Ensure thermocouple is fully inserted into pilot assembly. Clean and/or adjust
pilot for maximum flame impingement on thermocouple if necessary.
C. Thermocouple is defective. The millivolt production
should be a minimum of 14 MV with pilot only. • Replace thermocouple
3) Pilot flame stays lit, but
main burner will not light
(valve pilot/off/on knob is in
ON position, off/on switch, wall
thermostat or remote control is
set to ON).
Read important note below.
IMPORTANT NOTE: If an
optional Remote Switch*
is used for burner opera-
tion and if the standard
burner OFF/ON switch is
still installed on appli-
ance, it must be in the
"OFF" position.
A. Burner control switch (off/on switch, wall thermostat
or remote control) is in “OFF” position; or thermostat (if
installed) is set to a temperature setting that is too low.
• Turnburner off/on switchonand/orreferto instructions provided with optional
thermostat or remote control, if applicable.
B. Electrical wiring is damaged or poorly connected or
remote switch is defective. • Check wall switch and wires for proper connections. Refer to Millivolt Wiring
Diagram(Page12,Figure 28). Jumpthewireacrossterminalsatthewallswitch,
if the burner comes on, replace the defective wall switch. If okay, jumper the
wires across the wall switch wires at the valve. If the burner comes on, wires
are faulty or connections are bad.
C. One of the following components may be defective:
burner control switch, thermostat, vent spill switch, or
thermopile. Thermopile: Millivolt production should be a
minimum of 325 MV with pilot only.
• Refer to Millivolt Wiring Diagram (Page 12, Figure 28). Electrically bypass
components one at a time and replace defective item.
D. Thermopile may not be generating sufficient mil-
livolts • Checkthermopilewithmillivoltmeter.Takereading atthermopileterminals
ofgasvalve.It should read 325 millivolts minimumwithoptionalwall switch
“OFF.” Replace faulty thermopile if reading is below specified minimum.
E. Plugged burner orifice • Check burner orifice for blockage and remove.
F. OFF/ON Switch & Remote Switch* are in the "ON"
position resulting in excessive resistance • When turning on the burner using a Remote Switch,* ensure that the
standard OFF/ON Switch is in the "OFF" position. If both switches are in
the ON position, it may result in excessive resistance (& millivolt drainage)
and the burner may not come on.
4) Frequentpilot/burneroutage
problem A. Pilot flame may be too low or blowing (high) causing the pilot/valve safety to drop out. • Clean and/or adjust pilot flame for maximum flame impingement on thermo-
couple. See Page 11, Figure 25.
5) Main burner stays lit for up
to 10 minutes and then shuts off,
pilot flame remains lit.
A. Vent is blocked; flue gas is “spilling,” which activates
the spill switch and shuts down the burner. • Examine venting system for blockage. Remove any blockage.
B. The house is negatively pressurized resulting in spill
switch activation. • Open a window to see if the problem is corrected.
6) Smell of gas A. Pilot, gas supply system, or pilot & burner adjustment
screwsonvalvemay beleaking. FOLLOW INSTRUCTIONS
ON THE COVER OF THIS MANUAL
• WARNING: NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS.
After the gas company or fire department has given clearance to re-enter the
dwelling, have a qualified technician test all gas joints from the gas meter to
the gas heater regulator for leaks using a gas leak test solution (also referred
to as bubble leak solution).
7) A thin coating of black soot
forms on the window.
Note: See Page 5, Glass Clean-
ing.
A. Burner primary air inlet is restricted or blocked • Ensure all openings (fresh air inlets) in the insert are free from dust and debris.
Recheck these areas periodically.
B. Flames make contact with logs or other surfaces • Ensure ceramic logs are in their correct positions.
C. Improper venting • Check for flue blockage, disconnected flue, improper installation. Make
appropriate corrections.
8) A white coating forms on
windows,logs,and/orinsidewalls
of firebox.
A. Residues/impurities being burned off or impurities in
the fuel • Follow cleaning guidelines outlined in the MAINTENANCE section of this
manual.
*Optional Remote Switch kits: wall switch, wall thermostat or remote control.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Printed in U.S.A. © LENNOX HEARTH PRODUCTS 2003
P/N 775,155M Rev. D 12/2005
LENNOX reserves the right to make changes at any time, without notice, in design, materials,
specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for insert code information.
1110 West Taft Avenue • Orange, CA 92865
