Lennox Hearth Products Elite Series User manual

Report No. 050-S-15c-5
INSTALLATION AND OPERATION MANUAL
Direct-Vent Gas
Fireplace Inserts
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
- Ne pas entreposer ni utilizer d’essence ni d’autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir
des téléphones se trouvant dans le bâtiment où vous
trouvez.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du fournis-
seur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindie.
- L’installation et l’entretien doivent être assurés par un
installateur ou un service d’entretien qualifié ou par
le fournisseur de gaz.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result causing property damage, personal injury
or death.
AVERTISSEMENT:Assurez-vousdebiensuivrelesinstruc-
tionsdonnéesdanscettenoticepourréduireauminimum
le risque d’incindie ou d’explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
• Suitable for installation into masonry or factory built fireplaces. These appliances may be installed in an after-
market permanently located, manufactured (mobile) home (USA only), where not prohibited by local codes. This
appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible
for use with other gases unless a certified kit is used.
• Lennox Hearth Products gas-burning appliances are designed for use as a supplemental heater. They are not
intended for continuous use as a primary heat source.
Ravenna™ 33/40 (RDV33/40)
P/N 775,218M Rev.C, 06/2009
In the Commonwealth of Massachusetts:
• Installation must be performed by a licensed plumber or gas tter
• See Table of Contents for location of additional Commonwealth
of Massachusetts requirements
US
Portland
The Ravenna™
fireplace insert is
factory equipped for
40,000 BTU input and can
be converted to 33,000 using the
smaller orice provided.
AFrenchmanualisavailableupon request. Order
P/N 775,218CF.
Cemanueld’installationestdisponibleenfrancais,
simplement en faire la demande. Numéro de la
pièce 775,218CF.
WARNINGS
• Hot! Do not touch! The glass and surfaces of this appliance will be hot during operation and will retain heat
for a while after shutting off the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance. If small children are present in the home, it is
recommended that this appliance be fitted with a barrier screen kit. See Page 21 for ordering information.
Shown with Cast Pillar face
Installer: Leave This Manual With The Appliance.
Consumer: Retain This Manual For Future Reference.

2
FOR YOUR SAFETY do not install or operate your Raven-
na™ gas insert without first reading and understanding
this manual. Any installation or operation of the appli-
ance deviating from that which is stated in this manual
WILL void the warranty and may be hazardous.
INSTALLATION AND REPAIR SHOULD ONLY BE DONE BY
A QUALIFIED SERVICE TECHNICIAN. DO NOT ATTEMPT
TO SERVICE THE APPLIANCE YOURSELF.
The insert should be inspected and cleaned before use
and at least annually by a qualified service technician.
More frequent cleaning may be required due to exces-
sive lint from bedding material, carpeting, etc.
It is imperative that control compartments, burners and
circulating air passageways of the room heater be kept
clean.
Adequate clearances around the combustion chamber
and accessibility clearances for servicing and proper
operation must be maintained.
Turn off the gas before servicing this appliance. It is
recommended that a qualified service technician per-
form an appliance check-up at the beginning of each
heating season.
All installations must conform with all local, state
and national codes. In the absence of local codes, the
installation must conform with National Fuel Gas Code
ANSI Z223.1-latest edition, also known as NFPA 54
(In Canada, the current CAN/CSA B149.1 installation
code). Refer to the National Fuel Gas Code and local
zoning and code authorities for details on installation
requirements. Your Ravenna gas insert must be vented
to the outside in accordance with the latest edition of
the National Fuel Gas Code.
This gas insert MUST be vented directly to the outside
and MUST NEVER be attached to a chimney serving a
separate solid fuel burning appliance. Each gas appli-
ance MUST USE a separate vent system. Common vent
systems are PROHIBITED.
Mobile homeinstallationsmustconformwiththeMobile
Home Construction and Safety Standard, Title 24 CFR,
Part 3280 (in Canada CAN/CSA Z240 MH), or, when such
a standard is not applicable, the Standard for Mobile
Home Installations, ANSI A225.1 - latest edition.
The appliance, when installed, must be electrically
grounded in accordance with local codes or in the ab-
sence of local codes, with the National Electrical Code,
ANSI/NFPA 70 - latest edition. In Canada, the current
CSA C22-1 Canadian Electrical Code - latest edition.
Do not make any make-shift compromises during in-
stallation. Any modification or alteration may result
in damage to the appliance or dwelling and will void
the warranty, certification and listings of this unit.
Failure to use manufacturer provided parts, variations
in techniques and construction materials or practices
other than those described in this manual may create
a fire hazard and void the limited warranty.
YourLennoxHearthProductsgasinsertmustbeequipped
for the proper fuel type and altitude at which it will be
operated.Anyoperationoutsidetheparametersoutlined
in this manual may result in a hazardous condition and
will void the warranty. Please carefully read the sec-
tions pertaining to these subjects and/or be sure your
appliance is properly equipped.
Do not use this insert if any part has been under water.
Immediatelycallaqualifiedservicetechniciantoinspect
the appliance and to replace any part of the control sys-
tem and any gas control which has been under water.
Due to high temperatures, the insert should be located
out of traffic areas and away from furniture and draper-
ies.
Children and adults should be alerted to the hazards of
high surface temperature and should stay away to avoid
burns or clothing ignition. Young children should be
carefully supervised when they are in the same room as
the Lennox gas insert. Clothing or any other flammable
material should not be placed on or near the insert.
Never use solid fuels such as wood, paper, cardboard,
coal, or any flammable liquids, etc., in this appli-
ance.
Any grill, panel, or glass removed for service MUST be
replaced prior to operating the insert. Do not operate
appliance with the glass front removed, cracked or
broken. Replacement of the glass should be done by a
qualified service technician.
DO NOT USE abrasive cleaner on the glass door assem-
bly. DO NOT ATTEMPT to clean the glass door when it
is hot.
Gold and nickel plated surfaces must be cleaned with
glass cleaner and a clean soft cloth before firing the first
timeorfingerprints willremainpermanently.NEVERuse
brass polish to clean gold or nickel, this will remove
the plating!!!
When opening the lower door on the face while the
insert is burning, pull at the far left or far right vent
openings, because the door is hot during operation.
Lennox Hearth Products, its employees, or any of its
representatives assume no responsibility for any dam-
ages caused by an inoperable, inadequate, or unsafe
condition as a result of any improper operation, service
or installation procedures, whether direct or indirect.
INSTALLER: THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOME OWNER!
IMPORTANT SAFETY AND WARNING
INFORMATION

3
CONGRATULATIONS!
When you purchased your new gas fireplace insert, you joined
theranksofthousandsof individualswhoseanswerto theirhome
heating needs reflects their concern for aesthetics, efficiency
and our environment. We extend our continued support to help
you achieve the maximum benefit and enjoyment available from
your new gas fireplace insert.
Thank you for selecting a Lennox Hearth Products gas fireplace
insert as the answer to your home heating needs.
TABLE OF CONTENTS
Cautions and Safety ........................................................ 2
Orifice Size / Altitude Adjustment ........................................ 4
Fireplace Requirements ................................................... 4
Codes and Approvals....................................................... 5
New York City, New York (MEA) .......................................... 5
Requirements For The Commonwealth of Massachusetts............ 5
Pre-Installation............................................................ 6-8
Features ............................................................ 6
Packaging List ..................................................... 6
Ratings.............................................................. 6
Insert and Fireplace Dimensions ............................... 7
Clearances to Combustibles..................................... 8
Insert Leveling..................................................... 8
Installation............................................................... 9-11
Venting Installation ............................................... 9
Zero Clearance Fireplace Installation ........................ 10
Brick Panel and Log Set Installation .......................... 10
Surround Panels Installation ................................... 11
Face Installation ................................................. 11
Gas Line Installation ...................................................... 12
Gas Pressure Requirements.................................... 12
LP and Natural Gas Supplies................................... 12
Air Shutter Adjustment................................................ 12-13
Operating Instructions ................................................ 13-16
Pre-Lighting Checklist........................................... 13
Lighting Instructions............................................. 13
Flame Color and Behavior ...................................... 15
Paint Curing....................................................... 15
Quiet Operation................................................... 15
Blower Operation................................................. 15
Optional Wall Thermostat....................................... 15
Operating Options................................................ 16
Millivolt Control System ........................................ 16
Maintenance and Servicing .......................................... 17-18
Maintenance Checklist .......................................... 17
Glass Maintenance .............................................. 17
Door Removal .................................................... 18
Fuel Conversion .................................................. 18
Blower Removal.................................................. 18
Troubleshooting ............................................................ 19
Replacement Parts ........................................................ 20
Accessories............................................................. 20-21
Insert Labels............................................................ 22-23
Product Reference Information .......................................... 24
USING THIS MANUAL
Please read and carefully follow all of the instructions found in this
manual. Please pay special attention to the safety instructions provided
in this manual.
PRODUCT IS SUBJECT TO CHANGE WITHOUT NOTICE

4
For altitudes above 2,000 feet (In Canada 4,500 FT/1370 M), the orifice
should be de-rated by 4% for every 1,000 feet to maintain the proper
ratio of gas to air. Improper orifice sizing may result in damage and
unsafe conditions. Changing the orifice should only be done by a quali-
fied service technician. Contact your Lennox Hearth Products dealer for
proper orifice sizes.
ORIFICE SIZE/ALTITUDE ADJUSTMENT Fireplace Requirements
These heaters are designed to be installed into an existing masonry
fireplace (built to UBC 37 or ULC S628 standards) or factory built solid
fuel, wood burning fireplace (listed to UL 127 or ULC S610) only. All
exhaust gases must be vented outside the structure. Combustion air
is drawn from outside the structure. When installing in a factory built
fireplace, the fireplace grate must be removed and the damper must be
removed or secured open.
If the factory-built fireplace has no gas access hole(s) provided, an access
hole of 1-1/2 inches (38 mm) or less may be drilled through the lower
sides or bottom of the firebox in a proper workmanship like manner. This
access hole must be plugged with a non-combustible insulation after the
gas supply line has been installed. The installer must mechanically attach
themarkingsuppliedwiththegasfireplaceinsert to the insideof the firebox
of the fireplace into which the gas fireplace insert is installed.
IMPORTANT: When installing these appliances into a factory
built fireplace or heat-form, the air flow within and around the
fireplace shall not be altered by the installation of the insert
(i.e. DO NOT BLOCK louvers or cooling air inlet or outlet ports,
circulating air chambers in a steel fireplace liner or metal heat
circulator).
THE RAVENNA™ FIREPLACE
Since there are always several potential sources of fire in any home, we
recommend installing smoke detectors. If possible, install the smoke
detector in a hallway adjacent to the room (to reduce the possibility of
occasional false activation from the heat produced by the appliance). If
your local code requires a smoke detector be installed within the same
room, you must follow the requirements of your local code. Check with
your local building department for requirements in your area.
SMOKE DETECTORS
WARNING
THIS FIREPLACE HAS BEEN ALTERED TO
ACCOMMODATE A FIREPLACE INSERT AND
SHOULD BE INSPECTED BY A QUALIFIED
PERSON PRIOR TO RE-USE AS A
CONVENTIONAL FIREPLACE.
• Must conform with all local, state and national installation codes. In
the absence of local codes, the installation must conform with National
Fuel Gas Code ANSI Z223.1 - latest edition, also known as NFPA 54
(In Canada, the current CAN/CSA B149.1 installation code). Refer to
the National Fuel Gas Code and local zoning and code authorities for
details on installation requirements.
• Mobile home installations must conform with the Mobile Home Con-
struction and Safety Standard, Title 24 CFR, Part 3280 (in Canada
CAN/CSA Z240 MH), or, when such a standard is not applicable, the
Standard for Mobile Home Installations, ANSI A225.1 - latest edi-
tion.
• Must be vented directly to the outside in accordance with the latest
edition of the National Fuel Gas Code and must never be attached to
a chimney serving a separate solid fuel burning appliance.
• Has been certified for use with either natural gas or propane.
• Is not for use with solid fuels.
• Is approved for sitting rooms and/or bedrooms.

5
(Massachusetts Approval #G3-1104-102)
These fireplaces are approved for installation in the US state of Mas-
sachusetts if the following additional requirements are met:
• Install this appliance in accordance with Massachusetts Rules and
Regulations 248 C.M.R. Sec. 5.08 2(a) through 2(e).
• Installation and repair must be done by a plumber or gas fitter licensed
in the Commonwealth of Massachusetts.
• The flexible gas line connector used shall not exceed 36 inches (92
centimeters) in length.
• The individual manual shut-off must be a T-handle type valve.
Massachusetts Horizontal Vent Requirements
In the Commonwealth of Massachusetts, horizontal terminations installed
less than seven (7) feet above the finished grade must comply with the
following additional requirements:
• A hard wired carbon monoxide detector with an alarm and battery
back-up must be installed on the floor level where the gas fireplace
is installed. The carbon monoxide detector must comply with NFPA
720, be ANSI/UL 2034 listed and be ISA certified.
• A metal or plastic identification plate must be permanently mounted to
the exterior of the building at a minimum height of eight (8) feet above
grade and be directly in line with the horizontal termination. The sign
must read, in print size no less than one-half (1/2) inch in size, GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS.
Certification
Gas appliances must be tested and certified by a nationally recognized
testing and certification laboratory to ANSI (American National Standard
Institute) gas appliance safety standards.
This insert has been tested and certified by OMNI -Test Laboratories to
ANSI Z21.88/CSA 2.33 Standard for Vented Gas Fireplace Heater and CGA
2.17-M91 and UL 307B Gas Burning Heating Appliances for Manufactured
(Mobile) Homes in both USA and Canada.
It has met all necessary ANSI Standards and is fully certified for installa-
tion in any community. If there are any questions or if you need further
substantiation either write to or call your Lennox Hearth Products dealer.
If you have further questions, please contact Lennox Hearth Products.
Check all local building and safety codes before installation. The instal-
lation instructions and appropriate code requirements must be followed
exactly and without compromise. In the absence of local codes the fol-
lowing standards and codes must be followed.
Installation of these fireplaces are approved for installation in New York
City in the US state of New York (MEA#: 138-07-E).
CODES AND APPROVALS
NEW YORK CITY, NEW YORK (MEA)
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS

6
Features
Installation Options
.25Manufactured (Mobile) Home
Natural Gas Or Propane (LP)
Bedrooms
Optional Wall-mounted Or Remote Thermostat
Electrical
The standard blower motor requires 120 Volts AC for operation. The
fireplace is not dependent on the blower or an outside electrical supply to
operate. WARNING - Electrical Grounding Instructions - This appliance
is equipped with a three-prong (grounding) plug for your protection
against shock hazard and should be plugged directly into a properly
grounded three-prong receptacle. Do not cut or remove the grounding
prong from this plug.
Millivolt Valve
This insert is operated with a millivolt valve and therefore burns even
during a power outage.
Fuel
This insert comes from the factory equipped to burn natural gas at a speci-
fied elevation. The insert can be converted to burn LP (liquid propane) by
installing a conversion kit. Only Lennox Hearth Products conversion kits
can be used to convert from NG to LP or LP to NG. Contact your Lennox
Hearth Products dealer for details.
Packaging List
To install a Ravenna™ insert, an insert body, face, surround (flange) kit
and brick panel are required.
Insert Body Packaging List
1 Insert Body with Burner Cassette
1 Set of Refractory Brick Panels
1 Log Set
1 Ravenna 40
1 #36 Burner Ori fice (to convert to Ravenna 33)
1 Bag of Embers
1 Fasteners: 6 slotted 1/4" truss screws
6 speed nuts
9 spring clips
3 plastic adhesive wire restraints
1 Installation and Operation Manual
Decorative Faces - One Required
Traditional Arch inset
Foundry™ Screen
Cast pillar
Surround Kits - One Required
Traditional 1-pc. (41"W x 29"H)
Traditional 3-pc.(41"W x 29"H, 48"W x 29"H, 41"W x
33"H or 48"W x 33"H)
Cast Iron (45-1/2"W x 30"H-Cast Pillar face only) *
* See detailed dimensions on Page 21.
Surround Kit Contents
1 Top Surround
2 Side Surrounds
3 Black Extruded Trim Pieces
2 Elbowed Trim Fasteners
RATINGS Ravenna 40 (RDV40) Ravenna 33 (RDV33)
NATURAL GAS LP GAS NATURAL GAS LP GAS
Max/Min Input BTUh 0-2,000 Feet
(0-610 M)u40,000/28,000 37,500/26,000 33,000/24,000 33,000/24,000
Manifold Pressure (IN. WC) 3.5 10.0 3.5 10.0
Min. Inlet Pressure (IN. WC) 5.0 10.5 5.0 10.5
Maximum heat output BTUs/hour-
steady state (depending on vent
configuration)v
83% 83% 83% 83%
P4 Efficiency w
67.17% 69.07% 65.55% 67.80%
Orifice (DMS) 0-2,000 Feet (0-610
M)u1/8” #49 #36 #51
uUnit factory equipped for 0-2000 FT/0-610 M, In Canada 0-4500 FT/0-1370 M
vThe Steady State Efficiency numbers based on maximum vent configuration.
wTested to CSA P.4.1-02 “Testing Method for Measuring Annual Fireplace Efficiency.
Electrical Rating: 120 VAC, 60 HZ, Less Than 2 Amps
PRE-INSTALLATION

7
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Insert Dimensions
Minimum Fireplace Opening Required
A = 31-1/4” (794mm) Front Opening
B = 19-1/2” (495mm) Height
C = 19” (483mm) Rear Width
D = 16” (406mm) Fireplace Depth
* Top air duct will need to be removed for short ZC applications. Replace
tap tights when removed.
Minimum Fireplace Cavity
31-1/4”
(794mm)
13-3/4”
(349mm)
15-3/4"
(400mm)
19-3/4
(502mm)
15-3/4"
(400mm)
19-1/2"
(495mm)
Top View
Side View
Insert Dimensions
Width of insert behind Surround Panels 31-1/4" (794mm)
Rear height 19-3/4" (502mm)
Insert depth into fireplace 16" (406mm)
Flue collar diameter (OD) 2-15/16" 2-15/16" (75mm)
A
B
C
D
CAUTIONS
•Trim panels or surrounds must not seal ventila-
tion openings in the existing fireplace that the
appliance is installed in.
•The fireplace in which this gas insert is to be
installed must be thoroughly cleaned if it has
been used to burn wood or synthetic logs. Have
the chimney and all inside surfaces of the fire-
place brushed and vacuumed so that no soot,
embers, or loose combustion deposits can be
drawn into the heat circulation blower and blown
into the living area.
•If any portion of the chimney system shows signs
of structural or mechanical weaknesses, such
as: cracks, leaky joints, corroded or warped
surfaces, the faulty portion must be repaired
or replaced prior to installing this appliance.
•The factory built firebox must accept the insert
without modification other than removing bolted
or screwed together pieces such as baffles /
smoke shelf / deflectors, ash lips, glass door,
screen or door tracks, log grates, refractory or
masonry lining and damper assemblies. Any
fireplace component, which is removed, must be
retained so they can be reinstalled to restore the
fireplace to its original operating condition. The
removal of any part must not alter the integrity
of the outer shell of the pre-engineered fireplace
cabinet in any way. Any parts removed must be
replaceable. If any components are removed
from (or altered) from the existing fireplace,
a Warning Label (see Page 4) must be affixed
inside the fireplace firebox, so that it shall be
visibleuponremoval ofthefireplace insert. Note:
RTV high temperature silicone is an approved
adhesive to affix the label.
Figure 1
Figure 2
Figure 3

8NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Note: Hearth protection to be min. 3/8” (10mm) thick non-combustible
or equivalent, with a k factor of .84.
Insert Leveling
At each front and rear corner of the insert is an adjustable leg provided
to level the insert should the hearth of the fireplace be uneven. To adjust
the legs, loosen the two 5/32" allen head screws, move the leg to the
desired height and then tighten the screws. Repeat these steps for each
adjusting leg.
RDV40
G 14”(356mm) 10”(254mm) 0”(0mm)
H 0”(0mm) 2”(21mm) 4”(102mm)
IMPORTANT: If unit is converted to an RDV33 from an RDV40,
the clearances to combustibles can be reduced as shown on
this page.
WARNING: If this unit is ever converted back to an RDV40,
ensure that the clearances are correct for this model.
RDV33
G 13”(330mm) 10”(254mm) 0”(0mm)
H0”(0mm) 2”(21mm) 4”(102mm)
E
H
F
G
J
C
L
MANTEL
TRIM
Mantel
Trim
Hearth / Floor Protection
Minimum clearances include any projections such as shelves, window
sills,mantels,spacers/standoffsorsurfacestocombustibleconstruction
etc. above the appliance. Paint or lacquer used to finish the mantel
must be heat resistant in order to avoid discoloration.
The letters below, E through J, correspond to Figure 5 showing minimum
clearances required from the appliance to combustibles and the minimum
projection of the hearth extension.
E = From Top Facing or Mantel to Bottom of Insert -
.25 RDV40 = 35-1/2”(902mm) and RDV33 = 31-1/2”(800mm)
F = 25-1/2" From Center of Glass Door to Side Facing or Wall - RDV40
= 25.5”(648mm) and RDV33 = 25.5” (648mm)
J = 10.5” (267mm) Mantel to Bottom of Insert -
.25 RDV40 = 43”(1092mm) and RDV33 = 39”(991mm)
Hearth Protection
G = Minimum Hearth Protection from Front of Insert*
H = Vertical Distance from Insert Bottom to Combustible Material.
Clearances to Combustibles
Minimum Clearances to Combustibles
Figure 4A
Figure 5 - Clearances
RDV40
Facing and
Mantel - Side
View
Facing and Mantel Clearances
Please note that the RDV33 mantel clearances are 4" less than the RDV40
mantel clearances as shown in Figures 4A (RDV40) and 4B (RDV33).
3"/76mm
3"/76mm
3"/76mm
1-1/2”
38mm
35-1/2”
902mm
37-1/2”
953mm
40-1/2”
1029mm
43-1/2”
1105mm
3"/76mm
3"/76mm
3"/76mm
1-1/2”
38mm
31-1/2”
800mm
33-1/2”
851mm
36-1/2”
927mm
39-1/2”
1003mm
RDV33
Facing and
Mantel - Side
View
Figure 4B

9
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Vertical Venting
The vent pipes must be connected to the proper collars on the unit and
the exhaust vent pipe must be connected to the termination cap or the
unit will not operate. The combustion air vent pipe can be connected to
the termination cap or it can terminate inside the chimney.
The bottom opening of the chimney must be sealed around the vent pipes
if the combustion air vent is not connected to the termination cap. Use
unfaced fiberglass insulation to seal around the vent pipes. The insulation
may give off an odor during the first hour of operation.
Note: The minimum vertical rise (exhaust vent) is 10 feet (3.1 M) and the
maximumverticalrise is 35 feet (10.7 M). Thesedimensionsare measured
from the starting collars of the unit to the end of the vent pipe.
The fireplace and fireplace chimney must be clean and in good working
order and constructed of non-combustible materials. Inspect chimney
cleanouts for proper fit and seal.
* Other approved vent components include; Standard Simpson Dura-vent Co-linear
Chimney Liner Kit, Direct Vent Termination #991, Liner Termination Kit (includes
termination connector and flashing) #923GK and 3" x 35' Alum Flex #2280
Vertical Cap
Termination
Connector
Exhaust
Intake
Combustion Air Intake
The existing fireplace chimneys may take
various contours which the flexible liners will
accommodate.However,keeptheflexible liner
as STRAIGHT as possible, avoid unnecessary
bending.
Liner Requirements:
Vertical Height Min. = 10 ft. (3.1 M)
Vertical height Max. = 35 ft. (10.7 M)
Note: Measured from flue collar on
unit to the end of the vent pipe or liner
Use 3" (76 mm) diameter listed gas
vent liner (UL1777 ONLY) for the
EXHAUST
Use 3" (76 mm) diameter listed
liner (UL 181 or UL1777) for the
AIR INTAKE.
The flexible vent pipe
must NOT be allowed to
sag behind insert or in
fireplace flue.
The standard cap
inTerminationKit,
TKDVI, is a high
wind cap
Makesurethatbothlinerswillpassthroughexistingdamperarea.Remove
or lock damper to allow the passage of the flexible liners. If the damper
will not allow the passage of both liners, DO NOT PROCEED FURTHER.
(If fireplace is masonry) Consult a local mason for removal of the damper
without risk of structural damage or leakage (if the fireplace is factory
built) The appliance may NOT be installed into the fireplace.
WARNING
Direct-VentFireplaceInsertVentRequirements-Useliner
listed to UL181 (Factory-made Air Ducts And Air Connec-
tors) or UL1777 (Chimney Liners) for the AIR INTAKE. Use
liner listed to UL1777 ONLY for the EXHAUST.
Do not substitute the heat-rated flex liner (UL1777) for the
exhaust with any other type liner or a fire may result caus-
ing property damage, personal injury or loss of life.
Venting Installation
Your Lennox Hearth Products gas insert must be vented to the outside in
accordance with the current edition of the National Fuel Gas Code ANSI-
Z223.1 (In Canada, the current CAN/CSA B149.1 installation code). The
insert must not be connected to a chimney flue serving a separate solid
fuel burning appliance.
This gas insert requires a 3” diameter listed flex liner. The vent should
terminate with a listed direct vent termination cap. The chimney should be
sealed around the cap to prevent air and rain from entering the chimney.
Adhere to the vent manufacturer's instructions for installation and vent
termination. These appliances are approved for use with the following
vent kits.
Figure 6
Vent Kits
Cat. No. Model Description
H0909 FKDVI Flex Liner Kit, DVI 3” X 35’ (requires 2, one for
exhaust and one for intake)
TKDVI TKDVI Termination Kit, DVI (termination cap and
flashing)
DV3FK35 DV3FK35 Flex Liner and Termination Kit, 3" X 35'
(includes two flex liners, termination and four
gear clamps)
INSTALLATION

10 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Zero Clearance Fireplace Installation
This insert may be installed in a masonry or factory built/zero clearance
(ZC) fireplace. When installing in a ZC fireplace, the ZC grate must be
removed and the ZC damper must be removed or secured open. The ZC
doors, screen, refractory or masonry lining, baffles and smoke shelf may
be removed if necessary to install the gas insert. However, do not cut
or alter the fireplace components. The removal of any parts to facilitate
installation must not alter the integrity of the inner or outer shells of the
fireplace cabinet. Any parts removed must be replaceable if the insert is
taken out of the fireplace or the fireplace clearly marked with a paint stick
that "This fireplace has been altered and is no longer safe to operate."
The insert is designed to fit into a ZC fireplace with a minimum firebox
height of 19-1/2" (495mm). To facilitate this the hood will need to be
removed and discarded (Note: The screws should be replaced in the
insert body).
If the factory-built fireplace has no gas access hole(s) provided, an ac-
cess hole of 1-1/2" (37.5 mm) or less may be drilled through the lower
sides or bottom of the firebox in a proper workmanship like manner. This
access hole must be plugged with a non-combustible insulation after the
gas supply line has been installed.
The installer must mechanically attach the marking supplied with the gas
fireplace insert to the inside of the firebox of the fireplace into which the
gas fireplace insert is installed.
Ravenna™ 40 Conversion To Ravenna 33
To convert to a Ravenna 33 gas insert, after step 1 remove and replace
the stock burner orifice with the #36 NG orifice supplied in the installation
manual bag. Pipe dope or other approved gas line sealant will need to be
applied before inserting into bulkhead. The foil sticker supplied, stating
RDV33, will need to be affixed over the model name RDV40 on the serial
number label (located in the control compartment).
Brick Panel and Log Set Installation
If logs are not installed according to the log installation instructions,
flame impingement and improper combustion could occur and result in
soot and/or excessive production of carbon monoxide (CO), a colorless,
odorless, toxic gas.
The size and position of the log set is critical to achieve a safe, reliable
and attractive flame pattern. Any attempt to use a different log set in the
fireplace will void the warranty and will result in incomplete combustion,
sooting and poor flame quality.
1. Remove the log rack (2 screws) and install the rear log on the re-
tainer.
Retainer
Rear log
2. Place the rear brick panel on the brackets and reinstall the log rack
with the rear log. IMPORTANT!!! SCREWS PASS THROUGH THE LOG
RACK AND THE BURNER PAN.
3. Install the side brick panels by sliding them into place.
Side Brick Panels
Figure 7
Figure 8
Figure 9
2 Screws
