Lennox Hearth Products MERIT CR-3835R User manual

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 1
36" Wood Burning Fireplaces
P/N 850,048M REV. N/C 01/2007
CR-3835R CR-3835L
MODELS
This installation manual will enable you to obtain a safe, efficient and
dependableinstallationofyourfireplacesystem.Pleasereadandunder-
stand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any
circumstances. Any modification or alteration of the fireplace system,
including but not limited to the fireplace, chimney components and
accessories,mayvoidthewarranty,listingsandapprovalsofthissystem
and could result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS:
INSTALL THIS FIREPLACE IN A SQUARE AND PLUMB CONDITION,
USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.
INSTALLATION
INSTRUCTIONS
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
OTL Report No. 116-F-20-4
MERIT®SERIES

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
2
TABLE OF CONTENTS
Safety Rules .................................... page 2
Tools and Building Supplies ............ page 2
Precautions ..................................... page 2
Introduction..................................... page 3
Chimney/Mantel Clearances And
Height Requirements....................... page 3
Chimney System ............................. page 3
Assembly Outline............................. page 4
Location of Fireplace ....................... page 4
Assembly Steps............................... page 5
Preinstallation Notes........................ page 5
Fireplace Clearances ........................ page 5
Installing the Fireplace..................... page 5
Fireplace Specifications .................. page 6
Framing Specifications.................... page 7
Installing the Chimney System ........ page 8
30°Offset through Floor/Ceiling ...... page 9
Ten Foot Rule Summary .................. page 11
Multiple Terminations...................... page 11
Chimney Component Calculations ... page 11
Special Offset Instructions............... page 11
Offset Calculations........................... page 12
Vertical Elevation Chart................... page 13
Offset Elevation Chart ..................... page 15
Installing Offsets.............................. page 17
Combustion Air Kits ........................ page 17
Gas Line Connection........................ page 17
Glass Doors..................................... page 18
Cold Climate Insulation.................... page 18
Fireplace Finishes ............................ page 18
Mantels and Trim............................. page 18
Hearth Extensions/Wall Shields ....... page 18
Finish Requirements........................ page 20
Installation Components.................. page 21
IMPORTANT: PLEASE READ AND
UNDERSTAND THESE RULES TO
FOLLOW FOR SAFETY.
1. Before starting your fireplace installation,
read these installation instructions carefully to
besureyouunderstandthemcompletelyandin
entirety. Failure to follow them could cause a
fireplacemalfunctionresultinginseriousinjury
and/or property damage.
2.Alwayscheckyourlocalbuildingcodes.The
installationmustcomplywithalllocal,regional,
state and national codes and regulations.
13. DO NOT use a fireplace insert or any
other products not specified herein by the
manufacturer for use with this fireplace. All
gas log sets must be operated with the
damper clamped open.
3.Thesefireplacesmustbeinstalledwitheither
Security Chimneys model FTF8 (8" [203mm]
insidediameter)orFTF10(10"[250mm]inside
diameter) Chimney System only. These sys-
tems are intended for use in any application
whereatraditionalmasonrytypefireplacewould
apply.Thechimneysystemmustalwaysventto
the outside of the building.
4.Toensureasafefireplacesystemandtoprevent
the build-up of soot and creosote, inspect and
clean the fireplace and chimney prior to use and
periodically during the heating season.
5. Use solid fuel only. DO NOT use artificial
waxbasedlogs,chemicalchimneycleanersor
flame colorants in your fireplace.
6. DO NOT use charcoal or coal under any
circumstances.
7. NEVER use gasoline, gasoline-type lantern
fuel,kerosene,charcoallighterfluid,orsimilar
liquids to start or “freshen up” a fire in this
fireplace. Keep any flammable liquids a safe
distance from the fireplace.
8. NEVER leave children unattended when
there is a fire burning in the fireplace.
9.Alwayskeepfluedamperopenwhenheatis
present in the fireplace.
10. Before servicing, allow the fireplace to
cool. Always shut off any electricity or gas to
the fireplace while working on it. This will
preventanypossibleelectricalshockorburns.
11.Thisfireplaceisnotintendedtoheatanentire
home or be used as a primary heat source. It is
designedtoensurehomeownercomfortbypro-
viding supplemental heat to the room.
12. Always ensure an that adequate supply of
replacement combustion air from the outside
ofthehouseisaccessibletothefiretosupport
normalcombustion.Fireplacesconsumelarge
volumes of air during the normal combustion
process.Intheeventthehomeistightlysealed
withmodernenergy efficientfeatures,the op-
tional combustion air kit may not provide all
the air required to support combustion.
The manufacturer is not responsible for any
smoking or related problems that may result
fromthe lackof adequatecombustionair.Itis
the responsibility of the builder/contractor to
ensurethatadequatecombustionairhasbeen
provided for the fireplace.
WARNING: THIS FIREPLACE HAS NOT
BEEN TESTED WITH AN UNVENTED GAS
LOG SET. TO REDUCE RISK OF FIRE OR
INJURY,DONOTINSTALLANUNVENTED
GAS LOG SET INTO THIS FIREPLACE.
14."Smoke free"operation isnotwarranteed
norare weresponsibleforinadequatesystem
draft caused by mechanical systems, general
construction conditions, inadequate chimney
heights, adverse wind conditions and/or un-
usualenvironmentalfactorsorconditionsbe-
yond our control.
15. Never, under any circumstances, install a
fireplace, chimney component or any acces-
sories, that has visible or suspected physical
damage as a result of handling or transporta-
tion.Theseitemsshouldbeinspectedbyyour
distributor or qualified factory representative
toensuresafecondition.Whenindoubt,con-
sult your distributor.
16. For additional safety considerations and
complete operating instructions, refer to the
Care and Operation Manual provided with the
fireplace.
TOOLS AND BUILDING SUPPLIES
NORMALLY REQUIRED
Tools should Include:
Phillips screwdriver
Hammer
Saw and/or sabersaw
Level
Measuring tape
Plumb line
Electric drill and bits
Pliers
Square
Building supplies:
Framing materials
Wall finishing materials
Caulking materials (noncombustible)
Fireplace surround and hearth
extension materials (noncombustible)
PRECAUTIONS
Note: These fireplace systems are not difficult
toinstall.However,intheinterestofsafety,itis
recommended that the installer be a qualified
or certified “tradesman” familiar with com-
monlyacceptedfireplaceinstallationandsafety
techniques as well as prevailing local codes.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 3
Figure 1
TYPICAL INSTALLATION
*Construction Materials:
• framing materials • paneling
• particle board • flooring
• dry wall • etc.
• plywood
The most important areas of concern dealing
withtheinstallationoffactory-builtfireplacesare
clearancestocombustiblematerials,properas-
semblyofcomponentparts,heightofthechim-
ney system, the proper use of accessories sup-
plied by the manufacturer and the techniques
employedinusingfinishingmaterialsappliedto
thewallsurroundingthefireplace,hearthexten-
sions and wall shields. Each of these topics will
be covered in thorough detail throughout this
manual. Please give each your special attention
as you progress with your installation.
INTRODUCTION
General Information
These fireplaces are conventional radiant heat
fireplaces with standard bar grates, optional
outsidecombustionair kits andoptionaldeco-
rative glass doors.
Thesefireplaceshavebeentestedandlistedby
Omni Test Labs (Report No.116-F-20-4) to
U.L. standard 127. These units are intended
for installation in residential homes and other
buildingsofconventionalconstructioninclud-
ing commercial, not in mobile homes.
Note: Illustrations shown reflect “typical”
installations with nominal dimensions and
are for design and framing reference only.
Actual installations may vary due to indi-
vidual design preferences. However, always
maintain minimum clearances to combus-
tiblematerials anddonotviolateany specific
installation requirements.
These fireplace systems are designed for in-
stallation in accordance with the National Fire
Protection Standard for chimneys, fireplaces
and solid fuel burning appliances; NFPA 211
and in accordance with codes such as the
BOCABasic/NationalCodes,theStandardMe-
chanicalCodeandtheUniformBuildingCodes.
When complete these fireplace systems con-
sists of five basic “sub-systems”:
1. The Fireplace
2. The Chimney and Termination
3. The Optional Glass Doors
4. The Optional Combustion Air Kits
5. TheChimneyCollarEnclosureKit(Canada
Only) or Collar Duct Kit (U.S)
CHIMNEY CLEARANCES AND MANTEL
HEIGHT REQUIREMENTS
Thefireplacemaybeplacedonornearnormal
construction materials*. The combustion air
kit, firestop spacer and roof flashings (not
chase flashings) may be placed directly on or
against normal construction materials*. The
chimneyrequires aminimum 2"(51 mm)air
space to combustibles ( See **Note ).Acom-
bustiblemantlemaybeinstalled12"(305mm)
abovetheopeningofthefireplaceasperNFPA
211,Section7-3.3.3.InCanadathe minimum
is 18" (457 mm) above the opening.
The fireplace and chimney system must be
enclosed when installed in or passing through
alivingareawherecombustiblesorpeoplemay
come in contact with it. This is important to
preventpossible personalinjuryor firehazard.
For questions, please call your distributor or
themanufacturer.Specialrestrictionsapplyto
thefrontandfacingofthefireplaceandnearby
walls (See pages 16, 17 and 18 ).
CHIMNEY SYSTEM
These fireplaces are designed and code listed
for use with Security's FTF8 and FTF10 chim-
neySystemonly. AlwaysuseSecurity'sFTF8
and FTF10 chimney components with these
fireplaces. Do not modify or alter these com-
ponents as this may cause a potential serious
hazard and void the Warranty.
** Note: 1" (25 mm) when installed with
FTF10 in the U.S. only.
Outside
Combustion
Air Kit
(Optional)
Chimney
And
Termination
CCEK
W.H.I. Approved
(Required In
Canada)
WARNING:FAILURETOUSE MANUFAC-
TURE PROVIDED PARTS, VARIATIONS
IN TECHNIQUES AND CONSTRUCTION
MATERIALSORPRACTICESOTHERTHAN
THOSE DESCRIBED IN THIS MANUAL
MAYCREATEAFIREHAZARDANDVOID
THE LIMITED WARRANTY.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
4
Figure 2
Chimney Height
The total height of your completed fireplace sys-
temfromthe surfacethefireplace restsonto the
chimneytop must not exceed 50' (15.24 m) and
must also meet minimum height requirements.
Refer to the minimum system height chart.
Minimum System Height
FTF10 FTF8
Vertical 15'2" 16'8"
Installation (4.62 m) (5.08 m)
One 15'2" 16'8"
Offset (4.62 m) (5.08 m)
Two 25'0" 25'0"
Offsets (7.62 m) (7.62 m)
LOCATION OF FIREPLACE
Carefully select the proper location for heat
circulation, aesthetics, chimney obstructions
andclearancetosidewall(s).Withproperpre-
planning, a slight adjustment of a few inches
can save considerable time and expense later
during construction and assembly.
Figure 4
Carefullyconsiderthepositionofthefireplace
opening with respect to the location of adja-
cent or nearby stairwells, bath or kitchen ex-
haustfansand/orreturnairregistersforforced
air furnaces/air conditioners that could cause
a smoking fireplace condition if the house is
tightly insulated.
Whenlocatingthefireplace,considerationmust
be given to combustibles and final finishing.
See Figure 5 and confine the final location of
combustiblefinishmaterialstothe"SafeZone".
DO NOT permanently place furniture or other
items such as decorative pillows within 60" of
the fireplace front face.
Insulate Joists
Same As Ceiling
Draft Stops
Firestop
CTDT
Termination
Note: Non-
Combustible
Chase
Flashing
Must Be
Used To
Cover
Chase
Opening
Optional
Insulation
In Outside
Walls Of
Chase
Solid
Continuous
Surface
Outside
Base
Insulation
(Thermal Barrier)
8'
Level
Note: Do not insulate the chase cavity with
blown or fill type insulation materials.
Note:Localcodesmaynotrequirefirestopping
at the ceiling levels for outside chase installa-
tions. However, it is recommended for safety
and the reduction of heat loss.
Figure 5
Chase Enclosure
A chase is a vertical box-like structure con-
structedtosurroundthefireplaceandchimney.
Referto
Figure2 foratypicalchaseconfigura-
tion. As with all chimney installations, avoid
overhead obstructions such as trees, power
lines, etc. A chase should be constructed and
insulated just like any outside wall. In a cold
climate, we recommend the base of the chase
should also be insulated between the solid
continuous floor beneath the fireplace and the
chase bottom. Chase insulation in a cold cli-
mate installation is not required for safety.
ASSEMBLY OUTLINE
Before You Start
Checkyourinventorylisttobesureyouhave all
the necessary parts supplied in good usable
condition.Checkalsoforanyconcealeddamage.
Checktheoperationofthedamper.Thedamper
iscontrolledthroughtheuseofacontrollever
located within the firebox opening at the top
centerjustbehindthefireboxlintel(
Figure3 ).
The control lever snaps into place at the ex-
treme range of motion, up and back in the
closed position. When pulled forward and
down, the damper is open.
Figure 3
Damper
Closed Damper
Open
Lintel
Combustion
Air Actuator
Inside
Corner
Installation
Hearth
Hearth
8" (203mm) Min.
To Protected Side
Wall
Outside
Corner
Installation
12" Min. Distance To
Unprotected Side Wall
8"
45°
Combustible
Materials
Allowed In
Shaded Area
“Safe Zone” 8"
Min. Distance To
Protected Side Wall
Fireplace
11 ⁷⁄₈”
15 ⁷⁄₈”
WARNING:IFINSULATIONISUSED,THE
FIREPLACE MUST NOT BE PLACED DI-
RECTLY AGAINST IT. INSULATION OR
VAPORBARRIERS,IFUSED,MUSTFIRST
BE COVERED WITH GYPSUM BOARD,
PLYWOOD,PARTICLEBOARDOROTHER
MATERIALTOASSUREINSULATIONAND
VAPOR BARRIERS REMAIN IN PLACE.
WARNING: DO NOT PACK OR FILL RE-
QUIRED AIR SPACES WITH INSULATION
OR OTHER MATERIAL. NO MATERIAL IS
ALLOWED IN THESE AREAS.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 5
Note:Installthehearthextension only as illus-
trated.
The safety strips should extend from front of
thefireplaceat least1¹⁄₂" andshouldextend to
be at least flush with the sides. In the event a
woodensupportisusedtoelevatethefireplace
abovethefloor,a“Z”typesafetystripshouldbe
fabricatedandusedtoprotectthefrontsurface
ofthewoodsupportaswellasthefloorbeneath
the hearth extension (
Figures 8 and 9 ). The
safetystrips shouldbetacked downtoprevent
possible movement.
Note: The “Z” type safety strip is not supplied.
2. Measure the square footage of the floor
spacetobeoccupiedbythesystem,surrounds
and hearth extensions.
3.Notethefloorconstruction,i.e.2x6’s,2x8’s
or 2 x 10’s, single or double joists, type and
thickness of floor boards.
4. Use this information and consult your local
building code to determine if you need addi-
tional support.
CAUTION: DO NOT BLOCK THE HEAT-CIRCU-
LATING AIR INLET AND OUTLET PORTS ON
CIRCULATINGMODELS. DOING SOMAY RE-
SULT IN A POTENTIAL FIRE HAZARD.
If you plan to raise the fireplace and hearth
extension, build the platform assembly then
positionfireplaceandhearth extension on top.
Secure the platform to the floor to prevent
possible shifting.
FIREPLACE CLEARANCES
Minimum clearance to combustibles for the
applianceisasfollows:sidesandback-¹⁄₂"(13
mm),floor-0"(0mm),adjacentwall-12"(305
mm), ceiling - 37 ¹⁄₂" (953 mm).
INSTALLING THE FIREPLACE
Step 1. Slide the fireplace into prepared fram-
ingorpositionfireplaceinitsfinalpositionand
frame later.
The fireplace may not be recessed into a com-
bustiblefloor. Maintainthefloortohearth clear-
anceestablishedbythefireplacelowerfrontface.
Step 2. Inserttheprovidedmetalsafetystrips,
beneaththefireplaceasillustrated(
Figures6,7
and8 ).Thesafetystripsshouldoverlap¹⁄₂"for
continual coverage of the floor.
Note: Safety strips are not required when fire-
place rests on a noncombustible surface.
ASSEMBLY STEPS
Note:Thefollowingstepsrepresentthenormal
sequence of installation. Each installation is
unique,however, and might require a different
sequence.
1. Position firebox prior to framing or into
prepared framing.
2. Install the chimney system.
3. Connect house wiring to the fireplace for
later attachment of optional blower.
4. Install optional outside combustion air kit.
5. Plumb gas line if a decorative gas appliance
will be used. (Gas connections should only be
performed by an experienced, licensed/certi-
fied tradesman.)
6. Complete the installation, finish wall mate-
rial, surround and hearth extension to your
individual taste.
7. Assemble and attach optional glass door
assembly.
Study the three dimensional illustration (
Fig-
ure1 ) togeta generalidea ofeachelement of
your fireplace system.
PRE-INSTALLATION NOTES
The fireplace may be installed directly on a
combustiblefloororraisedonaplatformofan
appropriate height. Do not place fireplace on
carpeting,vinylorothersoftfloorcoverings.It
may, however, be placed on flat wood, ply-
wood, particle board or other hard surfaces.
Be sure fireplace rests on a solid continuous
floor or platform with appropriate framing for
support and so that no cold air can enter the
room from under the fireplace.
The fireplace may be positioned and then the
framingbuiltaroundit,orthe framing may be
constructed and the fireplace positioned into
the opening.
Usually,nospecialfloorsupportisneededfor
the fireplace, however, to be certain:
1. Estimate the total weight of the fireplace
system including chimney and surround ma-
terials such as brick, stone, etc., to be in-
stalled. Shippingweightsforthefireplacemay
be found on page 18.
Figure 7
Figure 6
1/2" (13mm)
Clearance To
Back And Sides
Combustible
Wall
Metal
Safety Strip
Hearth
Extension Floor
Fireplace And
Hearth Extension
On Floor
1/2"
(13mm)
Figure 8
Metal
Safety Strip
2"
(51mm)
2"
(51mm)
Special “Z”
Metal Safety Strip
2"
(51mm)
2"
(51mm)
Blocking
Figure 9
Step 3. Refer to fireplace drawings and specifi-
cationsonpages6and7forframingdimensions
and details. Frame appliance enclosure as illus-
trated in Figures 11 through 14 on page 8.
1/2" (13mm)
Clearance To
Back And Sides
Combustible
Wall
Metal
Safety Strip Hearth
Extension
Floor
Platform
Fireplace And
Hearth Extension
On Raised Platform
1/2"
(13mm)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
6
FIREPLACE SPECIFICATIONS
Figure 11
17 1/2"
(445mm)
32 7/8"
(835mm)
21"
(533m)
6"
(152mm)
40 1/2"
(1029mm)37 3/8"
(949mm)
42 3/4"
(1086mm)
38 5/8"
(981mm)
17 1/2"
(445mm)
32 7/8"
(835mm) 21"
(533m)
6"
(152mm)
40 1/2"
(1029mm)
37 3/8"
(949mm)
42 3/4"
(1086mm)
38 5/8"
(981mm)
10"
(254mm)
40 1/4"
(1022mm)
10 1/2"
(267mm)
7 1/2
(191mm)
40 1/4"
(1022mm)
19 7/8"
(505mm)
10"
(254mm)
35"
(889mm)
15"
(381mm)
42 3/4"
(1086mm)
10"
(254mm) 24"
(610mm)
Right Corner Opening
Closed End
Left Corner Opening
Open End
Top View
For Canadian Installations
Proceed with Steps 4 through 7.
Step4.Attachthechimneycollarenclosurekit,
Model CCK1, around chimney collar with the
screws provided ( Figure 10 ).
Figure 10
Step 5. Connect the 4" (102 mm) Class 0 air
duct provided to the collar on the chimney
collarenclosurewiththescrewsprovidedinthe
hardware kit.
IMPORTANT: UNDER NO CIRCUMSTANCES
CANTHEFIREPLACETOPSPACERS( FIGURE
6 ) BE REMOVED OR MODIFIED, NOR MAY
YOU NOTCH THE HEADER TO FIT AROUND
OR BE INSTALLED LOWER THAN THE SPAC-
ERS. THE HEADER MAY BE IN DIRECT CON-
TACTWITHTHETOPSPACERSBUTMAYNOT
BE SUPPORTED BY THEM.
Note: The framed depth, 24 (610 mm) from a
framedwall,mustalwaysbemeasuredfroma
finished surface. If a wall covering such as
drywall is to be attached to the rear wall, then
the24"(610 mm)mustbemeasuredfrom the
drywall surface. It is important that this di-
mension be exact.
If the appliance is to be elevated above floor
level, a solid continuous platform must be
constructed.
The header may rest on the top metal spacers,
but must not be notched to fit around them.
Consult all local codes.
Enclosure
Box

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 7
FRAMING SPECIFICATIONS
Figure 15
Figure 14
Figure 12
Figure 13
Figure 16
Framing Dimensions for Ceiling
Flue Type A B
FTF8 Vertical 16 ¹⁄₂" 16 ¹⁄₂"
at 2" (419 mm) (419 mm)
FTF10 Vertical 17" 17"
at 1" (432 mm) (432 mm)
FTF10 Vertical 19" 19"
at 2" (483 mm) (483 mm)
FTF8 Offset 30°16 ¹⁄₂" 27"
at 2" (419 mm) (686 mm)
FTF10 Offset 30°17" 26"
at 1" (432 mm) (660 mm)
FTF10 Offset 30°19" 28"
At 2" (438 mm) (711 mm)
Framing Dimensions for Roof
Pitch FTF8 at 2" FTF10 at 1" FTF10 at 2"
CD*CD*CD*
0/12 16 ¹⁄₂" 16 ¹⁄₂" 17" 17" 19" 19"
(419 mm) (419mm) (432 mm) (432 mm) (483 mm) (483 mm)
6/12 16 ¹⁄₂" 19" 17" 19" 19" 21"
(419 mm) (483 mm) (432 mm) (483 mm) (483 mm) (533 mm)
12 /12 16 ¹⁄₂" 23 ¹⁄₂" 17" 24" 19" 26"
(419mm) (597mm) (432mm) (610 mm) (483mm) (660 mm)
*Perpendicular to roof ridge
A
B
Ceiling Framing
C
D
Roof Framing
Framing Without False Header
Header
B
AC
Outside Corner
C
A
Back Wall of Chase/Encloslure
Including Finishing
Materials if any
Rough Framing
Face (Unfinished
Shown)
Note: Allframingdimensionscalculatedfor 5/8"
nailing flange depth and 1/2" dry wall at the
fireplaceface. Ifsheathingthechaseorfinishing
with other thickness materials, calculations will
need to be made.
Framing Dimensions
CR-3835 Series
A42 ⁵₈"
(1082 mm)
B40 ⁵₈"
(1032 mm)
C24"
(610 mm)
D34 ⁷₈"
(886 mm)
11 ⁷⁄₈"
(302mm) 45°
8" Max.
(203mm)
8" (203mm) Min. To
Protected Side Wall
Inside Corner Using Outside Air
Note: Combustible Materials
May Be Placed In Shaded Area.
C
D
Note: No Wall Shield
Required On This Wall
Back Wall of Chase/Encloslure Including
Finishing Materials if any
Rough
Framing
Face
(Unfinished
Shown)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
8
Step 8. Fireplace should be secured to side
framing members using the full length nailing
tabsatthetopandbottomofthefireplacefront
face. Use 8d nails or equivalent (
Figure 17 ).
Figure 17
Note: The nailing tabs and the area directly
behind the nailing tabs are exempt from the
clearances described on page 5. Maintain at
least1/2"clearancefromthefireboxwrapperto
the framing at the closest point of contact,
directly adjacent to the flange. Figure 18
Step3.Positionappropriatefirestopspacerat
ceiling and fasten temporarily with two (2) 8d
nailsorequivalent.Ifchimneypenetratesceil-
ing vertically, use flat firestop spacer, Model
F8FS-2 for FTF8 system and Model F10FS-2
for the FTF10 system*. If chimney penetrates
ceiling at 30°angle (offset chimney), use 30°
firestopspacer, ModelF8FS30-2for FTF8and
ModelF10FS30-2forFTF10system*.Useone
nail on opposite sides to hold firestop spacer
inposition. Fastenpermanently,usingatleast
two (2) more 8d nails or equivalent, after
chimney sections have been assembled
throughthefirestop spacer andafteranynec-
essaryadjustmentshave been made.Firestop
spacermust besecuredby atleastfour (4)8d
nails or equivalent when completely installed.
Note: If there is a room above ceiling level,
firestopspacermustbeinstalledonthebottom
side of the ceiling. If an attic is above ceiling
level, firestop spacer must be installed on top
side of ceiling joist (Figures 19 and 20 ).
Figure 19
Figure 20
Firestop Spacer
Room Above
Firestop Spacer
Attic Above
INSTALLING THE CHIMNEY SYSTEM
Step1.Beforecontinuing,checktheoperation
of the damper, as described on page 4, ( refer
to Figure 3 ).
Step 2. Using standard construction framing
techniques, construct opening for chimney
route up through the ceiling(s) and roof or
through an outside chase.
Framingmustmaintainadequateminimumair
space clearance at all times.
CAUTION: ALLOW MINIMUM 2" (51 MM)
CHIMNEY AIR SPACE TO COMBUSTIBLE
FRAMING MEMBERS THROUGHOUT VERTI-
CAL OR OFFSET CHIMNEY INSTALLATION
( SEE **NOTE ).
A minimum 2" (51 mm) air space must be
reserved for all combustible materials ex-
tending for any continuous length surround-
ing the chimney ( See **Note ).
Reference Figures14 and 15 and charts Fram-
ing Dimensions for Ceiling and Roof, which
specifyminimumceiling and roofdimensions.
Todeterminechimneycenterlineinnewcon-
struction, use plumb line from roof or ceiling
above fireplace to center of flue collar on
fireplace.
For remodeling, plumb to center of flue collar
from ceiling above, drive nail through ceiling
from below to mark position, then mark and
cut to passage from above ceiling (around
nail) ( Figure 18 ). Then plumb from ceiling or
roof level directly above hole which has just
been completed.
Step 6. Route the Class0airductouttheback
wallorsidewall,upthroughtheceilingorfloor
joiststoanoutsidewall.Theairductshouldbe
located above snow level.
Note: If the fireplace is installed against an
inside wall, the Class 0 air duct may be ex-
tended into a ventilated attic space at least 18"
(457 mm)abovetheatticfloor.Securetheduct
hoodto averticalpost withtheinlet positioned
downward. Ensure nothing blocks the hood
opening. This air duct must never terminate
higher than the chimney.
Step 7. Cut or frame hole through the outside
wall for the installation of the duct inlet hood.
A 4 ¹⁄₄" (114 mm) diameter hole is sufficient.
Feed the loose end of the flexible air duct
through the hole cut for the inlet hood and
attach to collar on inlet hood using two (2)
screws. Insert hood into opening. Secure in
place with nails driven through holes in hood
flange. Seal with noncombustible waterproof
silicon type caulking. If additional air duct is
needed, use Class 0 metallic air duct.
*Note: Use Models F10FS or F10FS30 when
installing FTF10 chimney in the U.S. only.
**Note:1" (25mm)wheninstalledwithFTF10
in the U.S. only.
Plumb Line
Note: If installing the optional collar duct kit, it
shouldbe installed after the chimneyhasbeen
attached to the flue collar.
8d Nail Or
Equivalent

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 9
CHIMNEY30°OFFSETTHROUGH FLOOR
OR CEILING
Itmaybenecessarytoassemblethechimneyat
30°when passing through the floor or ceiling
area.UsetheF8FS30-2firestopspacerasshown
in
Figures 21 and 22 . Support the chimney at
floor or ceiling penetration with a FTF8 stabi-
lizerifdistanceofchimneybelowceilingis10'
or more. Maintain 2" minimum air space to
combustibles from chimney sections.
Figure 21
Figure 22
Step4. Note:Chimneysectionsareconstructed
with a unique locking tab design, which en-
sures an immediate, tight assembly between
sections.Planyourchimneyrequirementscare-
fullybeforeassemblyaschimneyisdifficultto
disassembleafterinstallation.Ifdisassembled,
the tabs might become damaged. Be certain
tabs are properly formed to ensure locking
tabs engage properly.
Security's FTF8 and FTF10 chimney systems
are two piece chimneys, which snap together
from the fireplace up. Start with the inner flue
section.Withthelancedendup,snaplockitinto
the matching collar on top of the fireplace.
At all subsequent joints, the upper flue section
fits into the preceding flue section. Each piece
snaps together by means of locking tabs (9
locking tabs per joint). Check each piece by
pullingupslightlyfromthetoptoensureproper
engagement before installing the next section.
Ifthefluehasbeeninstalledcorrectly,itwillnot
separate when you test it. Also, the inner flue
joint where each section is joined should be
tight and flat without gaps (
Figure 23 ).
F8FS30-2
Firestop Spacer
FTF8-S4 Stabilizer
2" Min.
Air Space
30°Firestop
And Attic Above
10'
Max.
Attic Space
2" Min.
Air Space
F8FS30-2
Firestop Spacer
FTF8-S4 Stabilizer
30°Firestop
And Room Above
10'
Max.
Room Above
2" Min.
Air Space
2" Min.
Air Space
Figure 23
Outer pipe section installs in just the opposite
way; the lanced end goes down and each new
sectiongoesOVERthe outside of the previous
section installed ( Figure 24 ).
Locking
Tabs
(Lances)
Alwaysmaintain2"(51mm)minimumairspace
to combustible materials and always check
eachchimney joint (inner and outer) to ensure
properengagement(
See **Note ).Checkverti-
cal alignment of chimney so that it projects
from the roof in true vertical position.
Note: Assembleone component of chimney at
a time (inner section first, then outer section
last)beforeproceedingwiththenext complete
section.
Continue to assemble the chimney up through
framedopening.Assemblejustenoughtopene-
trate the roof flashing openings ( Figure 25 ).
Figure 25
Figure 24
Security'schimneysectionsdonotneedtobe
screwedtogether.Additionalreinforcementis
not necessary except in certain offset condi-
tions (refer to page 14, Figure 36 ).
Step 5. The height of vertical chimney pipe
supported only by the fireplace must not ex-
ceed 30' (9.1 m). Chimney heights above 30'
(9.1m)mustbesupportedbyaModelF8-S4or
ModelF10-S4stabilizerinstalledat30'(9.1m)
intervals.
Note:TheModelF8-S4andModelF10-S4add
3" (76 mm) net effective height to the total
chimney system.
Install Model F8-S4 or F10-S4 stabilizer by
fittinginnersection downintorespectivesec-
tion of proceeding flue pipe and locking outer
stabilizer section into place over the outer
chimney pipe. Position for proper clearance
through framed opening and nail straps se-
curely(undertensionin“shear”)intoplaceon
framing. Use 8d nails or equivalent. Attach
successivelengthsofchimneypipedirectlyto
stabilizerusingsametechniquesasdescribed
in Step 4 ( Figure 26 ).
Figure 26
**Note:1" (25mm)wheninstalledwithFTF10
in the U.S. only.
2" (51mm)** ( See **Note )
Min. Air Space to
Combustibles
Stabilizer

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
10
Note: If chimney extends more than 8' above
roofsurface,guywiresarealsorecommended.
Usethree(3) guywires,attachto lockingband
assembly,extend and secure to roof in atrian-
gular pattern (Figure 30 ). Guy wires are not
supplied by the manufacturer.
Roof Ridge
120°
CTD
Termination Chimney
Figure 30
Step 10. Using a CTD Round Termination:
1. Hold the CTD over top of last chimney
section ( Figure 31 ).
2. Center inner slip section in inner flue pipe-
slip down.
3. Center outer locking section over outer flue
pipe. Push down until locking tabs are firmly
engaged.
4.PullupslightlyonCTDtoensurelockingjoint
has firmly engaged.
Note: Do not apply excessive pressure to any
subsequent chimney sections following the
stabilizer when installing. Ensure each subse-
quent chimney section is securely attached by
testing as noted in Step 4.
Step 6. Select the proper Security Chimneys
roofflashing basedon pitchofroof.Usechart
below for selection:
Next,slideroofflashingoverextendedchimney
sectionthatpreviouslyhasbeeninstalledabove
theroofopeninginStep4.Slideflashingallthe
way down until the flashing base rests flat on
the roof. Again, check the vertical position of
the chimney and the 2" (51 mm) minimum air
space to combustibles (
See **Note ).
Next,slideroofflashingoverextendedchimney
sectionthatpreviouslyhasbeeninstalledabove
the roof opening in Step 4. FTF8 flashings
require flashing spacers. Slide flashing all the
way down until the flashing base rests flat on
the roof ( Figure 27 ). Again, check the vertical
positionofthechimneyandthe2"minimumair
space to combustibles.
Figure 27
Note: Do not caulk or seal the ventilating
openings.
Step 7. Secure flashing by nailing along the
perimeter into roof using 8d nails. If shingled
roof,slide upperendand sidesofroof flashing
undershingles(trim ifnecessary),sealthe top
and both sides of the flashing to the roof with
roofcaulking.Covernailheadswithroofcaulk-
ing ( Figure 28 ).
**Note:1" (25mm)wheninstalledwithFTF10
in the U.S. only.
Figure 28
Step 8. The standard Security Chimneys roof
flashingassembliesincludeastormcollar.Slide
storm collar over outer chimney, align with top
surface of flashing, insert tab in slot, pull tight
andbendtabbackoverslot. Sealstormcollarto
outer chimney with waterprood roof caulking
around entire circumference of pipe. Also add
extra roof caulking where storm collar meets
flashing and to the tab/slot area to seal com-
pletely against water penetration ( Figure 29 ).
Checkalljointsverycarefullytoensurenowater
intrusion can take place.
Figure 29
Step 9. Security Chimneys locking bands,
Model FLB, may be required if the chimney
extendstoohighabovethe roof flashing. As a
generalrule,ifthechimneyextendsmorethan
6' above the roof flashing, the use of locking
bands is advisable to strengthen the chimney
assembly. Align the locking band at the chim-
ney joint. Locking bands wrap around pipe
joints equally covering the joints of both pipe
sections. Use the nut provided and TIGHTEN
snugly.Donotovertightenasthismightdam-
age the chimney section ( refer to Figure 29 ).
FTF8 Chimney
FTF8 Flashing
Flashing Spacers
Do Not Seal
Figure 31
Using a FTF8/10-CTDT Chase Termination:
Refer to specific installation instructions in-
cluded with the FTF8/10-CTDT chase termina-
tion for clearance and installation details.
Roof Pitch FTF8 FTF10
Flat to 6/12 F8-F6 F10-F6
6/12 to 12/12 F8-F12 F10-F12
Locking Band
Waterproof
Caulk

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 11
Figure 32
Figure 33
This suggestion is provided in the interest of
betteroperation.Iftheterminationsarelocated
too close to each other, smoke may migrate
from one flue into the other.
CTD
18"
18"
24" 24"
CTDT
CTDT
Less Than 10'
3'
Min
2' Min.
10' 3'
Min
Using a FTF8/10-CT1 Chase Termination:
Refer to specific installation instructions in-
cluded with FTF8/10-CT1 chase terminations
for clearance and installation details.
Using a FTF8/10-CT2 Chase Termination:
Refer to specific installation instructions in-
cluded with FTF8/10-CT2 chase terminations
for clearance and installation details.
Note: It is recommended that all exterior ex-
posed metal fireplace components; such as
terminations, flashings, storm collars and/or
flue be painted with a premium quality, high
temperature,rustpreventativepaint designed
for metal. This is especially important when
installations are made in abnormally adverse
orcorrosiveenvironments;suchasnearlakes,
oceans or in areas with consistently high hu-
midityconditions.Consult thepaintmanufac-
turersinstructionsforproper preparation and
application.
TEN FOOT RULE SUMMARY
The minimum chimney height above the roof
and/ortoadjacentwallsandbuildingsisspeci-
fied by all major building codes.
If the horizontal distance from the peak of the
roof is less then 10', the top of the chimney
must be at least 2' above the peak of the roof.
If the horizontal distance from the chimney
edge to the peak of the roof is more than 10' a
chimney height reference point is established
on the roof surface 10' horizontally from the
chimneyedge.Thetopofthechimneymustbe
at least 2' above this reference point. In all
cases, the chimney cannot be less then 3'
above the roof at the edge of the chimney.
The2'in 10' rule isnecessaryinthe interest of
safety but does not ensure smoke-free opera-
tion. Trees, buildings, adjoining roof lines, ad-
versewindconditions,etc.,mayrequireataller
chimneyshouldthefireplacenotdraftproperly
(
see Figure 32 ).
MULTIPLE TERMINATIONS
If more than one termination is located in the
samechaseorwithinthesamegeneralproxim-
ity, we suggest they should be separated in
distanceatleast24"horizontallyfromfluecen-
ter to flue center and stacked or staggered
vertically at least 18" apart, from the termina-
tion of one smoke exit to the termination of
another smoke exit ( Figure 33 ).
FTF8ANDFTF10CHIMNEYCOMPONENT
CALCULATIONS
Theminimuminstalledheightofthecompleted
fireplacesystemsis 15'2"(4.67 m). Themaxi-
mumheightforallsystemsis50'0"(15.24m).
To determine the number of chimney sections
andchimneycomponentsrequired,followthese
steps:
1. Determine total vertical height of the fire-
place installation. This dimension is the dis-
tancefromthe surface the fireplacesetsonto
thepointwheresmokeexitsfromthetermina-
tion.
2. Determine the number of chimney compo-
nents required, except chimney sections. This
wouldincludefirestopspacers,stabilizers,roof
flashing, etc.
3.Theeffectiveheightsofthecomponentsare:
The Fireplace = 39 ¹⁄₂" (1003 mm)
FTF8/FTF10-12 = 10 ¹⁄₄" (260 mm)
FTF8/F10-18 = 16 ¹⁄₄" (413 mm)
FTF8/F10-36 = 34 ¹⁄₄" (870 mm)
FTF8-48 = 46 ¹⁄₄" (1175 mm)
CTD Termination = 4" (102 mm)
CT1 Termination = 12" to 18"
(305 mm to 457 mm)
CT2 Termination = 15" to 23"
(381 mm to 584 mm)
SS Starter Section = 19 ¹⁄₄" (489 mm)
S4 Stabilizer * = 3" (76 mm)*
* Required for every 30' (9.1 m) of vertical
chimney and/or 10' of offset chimney.
4. Determine amount of chimney height re-
quiredbysubtractingtotalcombinedheightof
all pre-selected components (fireplace and
chimneycomponentsfromtotaldesiredheight.)
Reference Vertical Elevation Chart and deter-
minethenumberofchimneysections(quantity
and length) required.
SPECIAL OFFSET INSTRUCTIONS
To clear any overhead obstructions, you may
offset your chimney system using Security's
30°offset and return elbows. Use two elbows
— an offset elbow to initiate the offset and a
return elbow to terminate it.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
12
The offset and return elbows may be attached
together, or a section or sections of chimney
maybeusedbetween,butdonotexceed20'in
totallengthbetweenelbows.Ifsectionsofpipe
exceed 10' between elbows, a chimney stabi-
lizermust beused atthemidpoint(
Figure34 ).
Thestabilizersupportstrapsmustbeattached
under tension (in shear) to structural framing
members above. When two sets of elbows are
used, the maximum combined length of chim-
ney used between elbows cannot exceed 20'
(
Figure35 ).Example:IfC1=10'thenC2cannot
exceed 10'.
If an offset exceeds 6' in length, each chimney
joint beyond the first 6' of offset to the return
elbow, must be secured by a No. 8 x ¹⁄₂" sheet
metalscrewlocatedattheundersideofthejoint
( Figure 36 ).
A ¹⁄₈" diameter hole must be drilled in the
chimney joint using a ¹⁄₈" diameter drill. Hole
should be drilled in center of joint overlap
( Figure 37 ). Be sure to drill only through the
outer chimney casting. Do not puncture the
inner flue.
Maximum offset of chimney system is 30°.
Two offsets must not be assembled to form a
60°offset. However, two sets of offset and
return elbows may be used on a single flue
system, provided the total height of the sys-
tem exceeds 25'.
Return elbow support straps must be se-
curely attached under tension (in shear) to
structural framing members above. Do not
substituteaFTF8/10-30offsetelbowinplace
of a FTF8/10-E30 return elbow.
Figure 35
Figure 34
Stabilizer
A
1
20'
Max.
B
1
10' Max.
Offset
Elbow
Return
Elbow
A
1
C
1
B
1
B
2
C
2
A
2
A
1
C
1
B
1
B
2
C
2
A
2
OFFSET CALCULATIONS
Step 1. Use Offset Chart to determine amount
of horizontal offset (A) and height (B) for vari-
ous chimney section assemblies.
Step 2. Use “Height of Chimney Only” column
in The Vertical Elevation Chart to determine
combinations of chimney used above return
elbow to achieve desired heights. Reference
Components Effective Height Chart in vertical
elevation chart section.
Step 3. Use Elevation Chart as job estimator
only.Addnecessaryfirestopspacersandstabi-
lizers as required. Firestop spacers must be
usedasshownin
Figures21and22 andstabi-
lizers as shown in
Figure 26 .

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 13
FTF8 VERTICAL ELEVATION CHART
10 ¹⁄₄ 010¹⁄₄ 1 0 0 0 0 – 0.26
16 ¹⁄₄ 14¹⁄₄ 0 1 0 0 0 – 0.41
22 ¹⁄₄ 110¹⁄₄ 0 0 1 0 0 – 0.57
26 ¹⁄₂ 22¹⁄₂ 1 1 0 0 0 – 0.67
32 ¹⁄₂ 28¹⁄₂ 1 0 1 0 0 – 0.83
34 ¹⁄₄ 210¹⁄₄ 0 0 0 1 0 – 0.87
38 ¹⁄₂ 32¹⁄₂ 0 1 1 0 0 – 0.98
44 ¹⁄₂ 38¹⁄₂ 1 0 0 1 0 – 1.13
46 ¹⁄₄ 310¹⁄₄ 0 0 0 0 1 – 1.17
50 ¹⁄₂ 42¹⁄₂ 0 1 0 1 0 – 1.28
56 ¹⁄₂ 48¹⁄₂ 1 0 0 0 1 – 1.44
62 ¹⁄₂ 52¹⁄₂ 0 1 0 0 1 – 1.59
68 ¹⁄₂ 58¹⁄₂ 0 0 1 0 1 – 1.74
72 ³⁄₄ 6³⁄₄ 1 1 0 0 1 – 1.85
78 ³⁄₄ 66³⁄₄ 1 0 1 0 1 – 2.00
84 ³⁄₄ 7³⁄₄ 0 1 1 0 1 – 2.15
90 ³⁄₄ 76³⁄₄ 1 0 0 1 1 – 2.31
92 ¹⁄₂ 78¹⁄₂ 0 0 0 0 2 – 2.35
96 ³⁄₄ 8³⁄₄ 0 1 0 1 1 – 2.46
102 ³⁄₄ 86³⁄₄ 1 0 0 0 2 – 2.61
108 ³⁄₄ 9³⁄₄ 0 1 0 0 2 – 2.76
114 ³⁄₄ 96³⁄₄ 0 0 1 0 2 – 2.91
119 9 11 1 1 0 0 2 – 3.02
125 10 5 1 0 1 0 2 – 3.18
131 10 11 0 1 1 0 2 – 3.33
137 11 5 1 0 0 1 2 – 3.48
138 ³⁄₄ 11 6 ³⁄₄ 0 0 0 0 3 – 3.52
143 11 11 0 1 0 1 2 – 3.63
149 12 5 1 0 0 0 3 – 3.78
155 12 11 0 1 0 0 3 – 3.94
161 13 5 0 0 1 0 3 – 4.09
165 ¹⁄₄ 13 9 ¹⁄₄ 1 1 0 0 3 – 4.20
171 ¹⁄₄ 14 3 ¹⁄₄ 1 0 1 0 3 – 4.35
177 ¹⁄₄ 14 9 ¹⁄₄ 0 1 1 0 3 – 4.50
183 ¹⁄₄ 15 3 ¹⁄₄ 1 0 0 1 3 – 4.65
185 15 5 0 0 0 0 4 – 4.70
189 ¹⁄₄ 15 9 ¹⁄₄ 0 1 0 1 3 – 4.81
195 ¹⁄₄ 16 3 ¹⁄₄ 1 0 0 0 4 – 4.96
201 ¹⁄₄ 16 9 ¹⁄₄ 0 1 0 0 4 – 5.11
207 ¹⁄₄ 17 3 ¹⁄₄ 0 0 1 0 4 – 5.26
211 ¹⁄₂ 17 7 ¹⁄₂ 1 1 0 0 4 – 5.37
217 ¹⁄₂ 18 1 ¹⁄₂ 1 0 1 0 4 – 5.52
223 ¹⁄₂ 18 7 ¹⁄₂ 0 1 1 0 4 – 5.68
229 ¹⁄₂ 19 1 ¹⁄₂ 1 0 0 1 4 – 5.83
231 ¹⁄₄ 19 3 ¹⁄₄ 0 0 0 0 5 – 5.87
235 ¹⁄₂ 19 7 ¹⁄₂ 0 1 0 1 4 – 5.98
241 ¹⁄₂ 20 1 ¹⁄₂ 1 0 0 0 5 – 6.13
Height Of Number Of FTF8 Height Of
Chimney Only Chimney Components Chimney Only
Inches Feet/Inches 12" 18" 24" 36" 48" -S4 Meters 247 ¹⁄₂ 20 7 ¹⁄₂ 0 1 0 0 5 – 6.29
253 ¹⁄₂ 21 1 ¹⁄₂ 0 0 1 0 5 – 6.44
257 ³⁄₄ 21 5 ³⁄₄ 1 1 0 0 5 – 6.55
263 ³⁄₄ 21 11 ³⁄₄ 1 0 1 0 5 – 6.70
269 ³⁄₄ 22 5 ³⁄₄ 0 1 1 0 5 – 6.85
275 ³⁄₄ 22 11 ³⁄₄ 1 0 0 1 5 – 7.00
277 ¹⁄₂ 23 1 ¹⁄₂ 0 0 0 0 6 – 7.05
281 ³⁄₄ 23 5 ³⁄₄ 0 1 0 1 5 – 7.16
287 ³⁄₄ 23 11 ³⁄₄ 1 0 0 0 6 – 7.31
293 ³⁄₄ 24 5 ³⁄₄ 0 1 0 0 6 – 7.46
299 ³⁄₄ 24 11 ³⁄₄ 0 0 1 0 6 – 7.61
304 25 4 1 1 0 0 6 – 7.72
310 25 10 1 0 1 0 6 – 7.87
316 26 4 0 1 1 0 6 – 8.03
322 26 10 1 0 0 1 6 – 8.18
323 ³⁄₄ 26 11 ³⁄₄ 0 0 0 0 7 – 8.22
328 27 4 0 1 0 1 6 – 8.33
334 27 10 1 0 0 0 7 – 8.48
340 28 4 0 1 0 0 7 – 8.64
346 28 10 0 0 1 0 7 – 8.79
350 ¹⁄₄ 29 2 ¹⁄₄ 1 1 0 0 7 – 8.90
356 ¹⁄₄ 29 8 ¹⁄₄ 1 0 1 0 7 – 9.05
365 ¹⁄₄ 30 5 ¹⁄₄ 0 1 1 0 7 1 9.28
371 ¹⁄₄ 30 11 ¹⁄₄ 1 0 0 1 7 1 9.43
373 31 1 0 0 0 0 8 1 9.47
377 ¹⁄₄ 31 5 ¹⁄₄ 0 1 0 1 7 1 9.58
383 ¹⁄₄ 31 11 ¹⁄₄ 1 0 0 0 8 1 9.73
389 ¹⁄₄ 32 5 ¹⁄₄ 0 1 0 0 8 1 9.89
395 ¹⁄₄ 32 11 ¹⁄₄ 0 0 1 0 8 1 10.04
399 ¹⁄₂ 33 3 ¹⁄₂ 1 1 0 0 8 1 10.15
405 ¹⁄₂ 33 9 ¹⁄₂ 1 0 1 0 8 1 10.30
411 ¹⁄₂ 34 3 ¹⁄₂ 0 1 1 0 8 1 10.45
417 ¹⁄₂ 34 9 ¹⁄₂ 1 0 0 1 8 1 10.60
419 ¹⁄₄ 34 11 ¹⁄₄ 0 0 0 0 9 1 10.65
423 ¹⁄₂ 35 3 ¹⁄₂ 0 1 0 1 8 1 10.76
429 ¹⁄₂ 35 9 ¹⁄₂ 1 0 0 0 9 1 10.91
435 ¹⁄₂ 36 3 ¹⁄₂ 0 1 0 0 9 1 11.06
441 ¹⁄₂ 36 9 ¹⁄₂ 0 0 1 0 9 1 11.21
445 ³⁄₄ 37 1 ³⁄₄ 1 1 0 0 9 1 11.32
451 ³⁄₄ 37 7 ³⁄₄ 1 0 1 0 9 1 11.47
457 ³⁄₄ 38 1 ³⁄₄ 0 1 1 0 9 1 11.63
463 ³⁄₄ 38 7 ³⁄₄ 1 0 0 1 9 1 11.78
465 ¹⁄₂ 38 9 ¹⁄₂ 0 0 0 0 10 1 11.82
469 ³⁄₄ 39 1 ³⁄₄ 0 1 0 1 9 1 11.93
475 ³⁄₄ 39 7 ³⁄₄ 1 0 0 0 10 1 12.08
481 ³⁄₄ 40 1 ³⁄₄ 0 1 0 0 10 1 12.24
486 40 6 1 0 1 1 9 1 12.34
Height Of Number Of FTF8 Height Of
Chimney Only Chimney Components Chimney Only
Inches Feet/Inches 12" 18" 24" 36" 48" -S4 Meters

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
14
FTF10 VERTICAL ELEVATION CHART
11 0 11 1 0 0 279 0.28
17 1 5 0 1 0 432 0.43
21 ¹⁄₄ 19¹⁄₄ 2 0 0 540 0.54
27 ¹⁄₄ 23¹⁄₄ 1 1 0 692 0.69
33 ¹⁄₄ 29¹⁄₄ 0 2 0 845 0.85
35 2 11 0 0 1 889 0.89
37 ¹⁄₄ 31¹⁄₄ 2 1 0 946 0.95
43 ¹⁄₄ 37¹⁄₄ 1 2 0 1099 1.10
51 ¹⁄₄ 43¹⁄₄ 0 1 1 1302 1.30
55 ¹⁄₄ 47¹⁄₄ 2 0 1 1403 1.40
61 ¹⁄₄ 51¹⁄₄ 1 1 1 1556 1.56
67 ¹⁄₄ 57¹⁄₄ 0 2 1 1708 1.71
69 ¹⁄₄ 59¹⁄₄ 0 0 2 1759 1.76
79 ¹⁄₄ 67¹⁄₄ 1 0 2 2013 2.01
85 ¹⁄₄ 71¹⁄₄ 0 1 2 2165 2.17
89 ¹⁄₂ 75¹⁄₂ 2 0 2 2273 2.27
95 ¹⁄₂ 711¹⁄₂ 1 1 2 2426 2.43
103 ¹⁄₄ 87¹⁄₄ 0 0 3 2622 2.62
113 ¹⁄₂ 95¹⁄₂ 1 0 3 2883 2.88
119 ¹⁄₂ 911¹⁄₂ 0 1 3 3035 3.03
123 ³⁄₄ 10 3 ³⁄₄ 2 0 3 3143 3.14
129 ³⁄₄ 10 9 ³⁄₄ 1 1 3 3296 3.30
137 ¹⁄₂ 11 5 ¹⁄₂ 0 0 4 3493 3.49
147 ³⁄₄ 12 3 ³⁄₄ 1 0 4 3753 3.75
153 ³⁄₄ 12 9 ³⁄₄ 0 1 4 3905 4.91
158 13 2 2 0 4 4013 4.01
164 13 8 1 1 4 4166 4.17
171 ³⁄₄ 14 3 ³⁄₄ 0 0 5 4362 4.36
182 15 2 1 0 5 4623 4.62
188 15 8 0 1 5 4775 4.78
192 16 0 2 0 5 4877 4.88
198 16 6 1 1 5 5029 5.03
206 17 2 0 0 6 5232 5.23
215 ³⁄₄ 17 11 ³⁄₄ 1 0 6 5480 5.48
222 18 6 0 1 6 5639 5.64
226 ¹⁄₄ 18 10 ¹⁄₄ 2 0 6 5747 5.75
232 ¹⁄₄ 19 4 ¹⁄₄ 1 1 6 5899 5.90
240 20 0 0 0 7 6096 6.10
250 ¹⁄₄ 20 10 ¹⁄₄ 1 0 7 6356 6.36
256 ¹⁄₄ 21 4 ¹⁄₄ 0 1 7 6509 6.51
260 ¹⁄₂ 21 8 ¹⁄₂ 2 0 7 6617 6.62
266 ¹⁄₂ 22 2 ¹⁄₂ 1 1 7 6769 6.77
274 ¹⁄₄ 22 10 ¹⁄₄ 0 0 8 6966 6.97
284 ¹⁄₂ 23 8 ¹⁄₂ 1 0 8 7226 7.23
290 ¹⁄₂ 24 2 ¹⁄₂ 0 1 8 7379 7.38
294 ³⁄₄ 24 6 ³⁄₄ 2 0 8 7487 7.49
300 ³⁄₄ 25 0 ³⁄₄ 1 1 8 7639 7.64
308 ¹⁄₂ 25 8 ¹⁄₂ 0 0 9 7836 7.84
318 ³⁄₄ 26 8 ³⁄₄ 1 0 9 8096 8.10
324 ³⁄₄ 27 0 ³⁄₄ 0 1 9 8249 8.25
328 ³⁄₄ 27 4 ³⁄₄ 2 0 9 8350 8.35
334 ³⁄₄ 27 10 ³⁄₄ 1 1 9 8503 8.50
342 ³⁄₄ 28 6 ³⁄₄ 0 0 10 8706 8.71
352 ³⁄₄ 29 4 ³⁄₄ 1 0 10 8960 8.96
358 ³⁄₄ 29 10 ³⁄₄ 0 1 10 9112 9.11
363 30 3 2 0 10 9220 9.22
369 30 9 1 1 10 9373 9.37
376 ³⁄₄ 31 4 ³⁄₄ 0 0 11 9569 9.57
387 32 3 1 0 11 9829 9.83
393 32 9 0 1 11 9982 9.98
397 ¹⁄₄ 33 1 ¹⁄₄ 2 0 11 10090 10.09
403 ¹⁄₄ 33 7 ¹⁄₄ 1 1 11 10243 10.24
411 34 3 0 0 12 10439 10.44
421 ¹⁄₄ 35 1 ¹⁄₄ 1 0 12 10700 10.70
427 ¹⁄₄ 35 7 ¹⁄₄ 0 1 12 10852 10.85
431 ¹⁄₂ 35 11 ¹⁄₂ 2 0 12 10960 10.96
437 ¹⁄₂ 36 5 ¹⁄₂ 1 1 12 11113 11.11
445 ¹⁄₄ 37 1 ¹⁄₄ 0 0 13 11309 11.31
455 ¹⁄₂ 37 11 ¹⁄₂ 1 0 13 11570 11.57
Height Of Number Of FTF10 Height Of
Chimney Only Chimney Lengths Chimney Only
Inches Feet/Inches 12" 18" 36" MM M 461 ¹⁄₂ 38 5 ¹⁄₂ 0 1 13 11722 11.72
465 ¹⁄₂ 38 9 ¹⁄₂ 2 0 13 11824 11.82
471 ¹⁄₂ 39 3 ¹⁄₂ 1 1 13 11976 11.98
479 ¹⁄₂ 39 11 ¹⁄₂ 0 0 14 12179 12.18
489 ¹⁄₂ 40 9 ¹⁄₂ 1 0 14 12433 12.43
495 ¹⁄₂ 41 3 ¹⁄₂ 0 1 14 12586 12.59
499 ³⁄₄ 41 7 ³⁄₄ 2 0 14 12694 12.69
505 ³⁄₄ 42 1 ³⁄₄ 1 1 14 12846 12.85
513 ¹⁄₂ 42 9 ¹⁄₂ 0 0 15 13043 13.04
523 ³⁄₄ 43 7 ³⁄₄ 1 0 15 13303 13.30
529 ³⁄₄ 44 1 ³⁄₄ 0 1 15 13456 13.46
534 44 6 2 0 15 13564 13.56
540 45 0 1 1 15 13716 13.71
547 ³⁄₄ 45 7 ³⁄₄ 0 0 16 13913 13.91
558 46 6 1 0 16 14173 14.17
564 47 0 0 1 16 14326 14.33
568 ¹⁄₄ 47 4 ¹⁄₄ 2 0 16 14434 14.43
574 ¹⁄₄ 47 10 ¹⁄₄ 1 1 16 14586 14.59
582 48 6 0 0 17 14783 14.78
592 ¹⁄₄ 49 4 ¹⁄₄ 1 0 17 15043 15.04
598 ¹⁄₄ 49 10 ¹⁄₄ 0 1 17 15196 15.20
602 ¹⁄₄ 50 2 ¹⁄₄ 2 0 17 15297 15.30
608 ¹⁄₄ 50 8 ¹⁄₄ 1 1 17 15450 15.45
616 ¹⁄₄ 51 4 ¹⁄₄ 0 0 18 15653 15.65
626 ¹⁄₄ 52 2 ¹⁄₄ 1 0 18 15907 15.91
632 ¹⁄₄ 52 8 ¹⁄₄ 0 1 18 16059 16.06
636 ¹⁄₂ 53 0 ¹⁄₂ 2 0 18 16167 16.17
642 ¹⁄₂ 53 6 ¹⁄₂ 1 1 18 16320 16.32
650 ¹⁄₄ 54 2 ¹⁄₂ 0 0 19 16516 16.52
660 ¹⁄₂ 55 0 ¹⁄₂ 1 0 19 16777 16.78
666 ¹⁄₂ 55 6 ¹⁄₂ 0 1 19 16929 16.93
670 ³⁄₄ 55 10 ³⁄₄ 2 0 19 17037 17.04
676 ³⁄₄ 56 4 ³⁄₄ 1 1 19 17189 17.19
684 ¹⁄₂ 57 0 ¹⁄₂ 0 0 20 17386 17.39
694 ³⁄₄ 57 10 ³⁄₄ 1 0 20 17647 17.65
700 ³⁄₄ 58 4 ³⁄₄ 0 1 20 17799 17.80
705 58 9 2 0 20 17907 17.91
711 59 3 1 1 20 18059 18.06
718 ³⁄₄ 59 10 ³⁄₄ 0 0 21 18256 18.26
729 60 9 1 0 21 18517 18.52
735 61 3 0 1 21 18669 18.67
739 61 72 0 21 18771 18.77
745 62 1 1 1 21 18923 18.92
753 62 9 0 0 22 19126 19.13
763 63 7 1 0 22 19380 19.38
769 64 1 0 1 22 19533 19.53
773 ¹⁄₄ 64 5 ¹⁄₄ 2 0 22 19641 19.64
779 ¹⁄₄ 64 11 ¹⁄₄ 1 1 22 19793 19.79
787 65 7 0 0 23 19990 19.99
797 ¹⁄₄ 66 5 ¹⁄₄ 1 0 23 20250 20.25
803 ¹⁄₄ 66 11 ¹⁄₄ 0 1 23 20403 20.40
807 ¹⁄₂ 67 3 ¹⁄₂ 2 0 23 20511 20.51
813 ¹⁄₂ 67 9 ¹⁄₂ 1 1 23 20663 20.66
821 ¹⁄₄ 68 5 ¹⁄₄ 0 0 24 20860 20.86
831 ¹⁄₂ 69 3 ¹⁄₂ 1 0 24 21120 21.12
837 ¹⁄₂ 69 9 ¹⁄₂ 0 1 24 21273 21.27
841 ³⁄₄ 70 1 ³⁄₄ 2 0 24 21380 21.38
847 ³⁄₄ 70 7 ³⁄₄ 1 1 24 21533 21.53
855 ¹⁄₂ 71 3 ¹⁄₂ 0 0 25 21730 21.73
865 ³⁄₄ 72 1 ³⁄₄ 1 0 25 21990 21.99
871 ³⁄₄ 72 6 ³⁄₄ 0 1 25 22142 22.14
875 ³⁄₄ 72 11 ³⁄₄ 2 0 25 22244 22.24
881 ³⁄₄ 73 5 ³⁄₄ 1 1 25 22396 22.40
889 ³⁄₄ 74 1 ³⁄₄ 0 0 26 22600 22.60
899 ³⁄₄ 74 11 ³⁄₄ 1 0 26 22854 22.85
905 ³⁄₄ 75 5 ³⁄₄ 0 1 26 23006 23.01
910 75 10 2 0 26 23114 23.11
916 76 4 1 1 26 23266 23.27
924 77 0 0 0 27 23470 23.47
Height Of Number Of FTF10 Height Of
Chimney Only Chimney Lengths Chimney Only
Inches Feet/Inches 12" 18" 36" MM M

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 15
FTF8 OFFSET ELEVATION CHART
(With FTF8-SS Starter Section)
A B FTF10/8-ES30 FTF8-SS Number of FTF8 A B
Offset Height Offset/Return Starter FTF8-S4 Chimney Sections Offset Height
(Inches) (Inches) Elbow Set Section Stabilizer 12" 18" 36" 48" (mm) (mm)
14 32 ¹⁄₂ 1 1 0 0 0 0 0 356 826
19 41 ¹⁄₄ 1 1 0 1 0 0 0 483 1048
22 46 ¹⁄₂ 1 1 0 0 1 0 0 559 1181
24 ¹⁄₄ 50 ¹⁄₄ 1 1 0 2 0 0 0 616 1276
27 ¹⁄₄ 55 ¹⁄₄ 1 1 0 1 1 0 0 692 1403
30 ¹⁄₄ 60 ¹⁄₂ 1 1 0 0 2 0 0 768 1537
31 62 1 1 0 0 0 1 0 787 1575
32 ¹⁄₄ 64 ¹⁄₄ 1 1 0 2 1 0 0 819 1632
35 ¹⁄₄ 69 ¹⁄₄ 1 1 0 1 2 0 0 895 1759
36 ¹⁄₄ 71 1 1 0 1 0 1 0 921 1803
37 72 ¹⁄₂ 1 1 0 0 0 0 1 940 1842
38 ¹⁄₄ 74 ¹⁄₂ 1 1 0 0 3 0 0 972 1892
39 ¹⁄₄ 76 1 1 0 0 1 1 0 997 1930
41 ¹⁄₂ 79 ³⁄₄ 1 1 0 2 0 1 0 1048 2026
42 ¹⁄₄ 81 ¹⁄₄ 1 1 0 1 0 0 1 1073 2064
44 ¹⁄₄ 85 1 1 0 1 1 1 0 1124 2159
45 ¹⁄₄ 86 ¹⁄₂ 1 1 0 0 1 0 1 1149 2197
47 ¹⁄₄ 90 1 1 0 0 2 1 0 1200 2286
48 ¹⁄₄ 91 ³⁄₄ 1 1 0 0 0 2 0 1226 2330
49 ¹⁄₄ 93 ³⁄₄ 1 1 0 2 1 1 0 1251 2381
51 ¹⁄₂ 97 ¹⁄₄ 1 1 0 1 4 0 0 1308 2470
53 ¹⁄₄ 100 ¹⁄₂ 1 1 0 1 0 2 0 1353 2553
54 ¹⁄₄ 102 1 1 0 0 0 1 1 1378 2591
55 ¹⁄₂ 104 ¹⁄₄ 1 1 0 0 3 1 0 1403 2648
56 ¹⁄₄ 105 ³⁄₄ 1 1 0 0 1 2 0 1429 2686
58 ¹⁄₄ 109 ¹⁄₄ 1 1 0 2 0 2 0 1480 2775
59 ¹⁄₄ 111 1 1 0 1 0 1 1 1505 2819
60 ¹⁄₄ 112 ¹⁄₂ 1 1 0 0 0 0 2 1530 2858
61 ¹⁄₄ 114 ¹⁄₂ 1 1 1 1 1 2 0 1556 2908
65 ³⁄₄ 122 ¹⁄₄ 1 1 1 0 2 2 0 1670 3105
66 ³⁄₄ 124 1 1 1 1 0 0 2 1695 3150
68 126 1 1 1 2 1 2 0 1727 3200
69 ³⁄₄ 129 1 1 1 0 1 0 2 1772 3277
71 ³⁄₄ 132 ³⁄₄ 1 1 1 1 0 3 0 1822 3372
74 ³⁄₄ 138 1 1 1 0 1 3 0 1899 3505
77 141 ¹⁄₂ 1 1 1 2 0 3 0 1956 3594
78 ³⁄₄ 144 ³⁄₄ 1 1 1 0 0 1 2 2000 3677
80 146 ³⁄₄ 1 1 1 1 1 3 0 2032 3727
83 152 1 1 1 0 2 3 0 2108 3861
84 ³⁄₄ 155 1 1 1 0 0 0 3 2153 3937
89 162 ¹⁄₄ 1 1 1 1 0 4 0 2261 4121
89 ³⁄₄ 164 1 1 1 1 0 0 3 2280 4166
92 167 ¹⁄₂ 1 1 1 0 1 4 0 2337 4255
92 ³⁄₄ 169 1 1 1 0 1 0 3 2356 4293

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
16
Figure 36
Figure 37
Figure 38
Chimney
Section
Joints
No. 8 x 1/2" SMS
Screws Required At
Every Joint Past 6'
No Screws Required In
Joints For First 6' of Offset
4'
6'
Underside Of Chimney
FTF10 OFFSET ELEVATION CHART
A B FTF10-ES30 Number of FTF10 A B
Offset Height Offset/Return FTF10-S4 Chimney Sections Offset Height
(Inches) (Inches) Elbow Set Stabilizer 12" 18" 36" (mm) (mm)
415³⁄₄ 1 0 0 0 0 102 400
924¹⁄₂ 1 0 1 0 0 229 622
12 29 ³⁄₄ 1 0 0 1 0 305 756
14 ¹⁄₄ 33 ¹⁄₂ 1 0 2 0 0 362 851
17 ¹⁄₄ 38 ¹⁄₂ 1 0 1 1 0 438 978
20 ¹⁄₄ 43 ³⁄₄ 1 0 0 2 0 514 1111
21 45 ¹⁄₄ 1 0 0 0 1 533 1149
22 ¹⁄₄ 47 ¹⁄₂ 1 0 2 1 0 565 1207
25 ¹⁄₄ 52 ¹⁄₂ 1 0 1 2 0 641 1334
26 ¹⁄₄ 54 ¹⁄₄ 1 0 1 0 1 667 1378
28 ¹⁄₄ 57 ³⁄₄ 1 0 0 3 0 718 1467
29 ¹⁄₄ 59 ¹⁄₄ 1 0 0 1 1 743 1505
31 ¹⁄₄ 63 1 0 2 0 1 794 1600
32 ¹⁄₂ 65 1 0 4 1 0 826 1651
34 ¹⁄₄ 68 ¹⁄₄ 1 0 1 1 1 870 1734
36 ¹⁄₄ 71 ³⁄₄ 1 0 3 0 1 921 1822
37 ¹⁄₄ 73 ¹⁄₄ 1 0 0 2 1 946 1861
38 ¹⁄₄ 75 1 0 0 0 2 972 1905
39 ¹⁄₄ 77 1 0 2 1 1 997 1956
41 ¹⁄₂ 80 ¹⁄₂ 1 0 1 4 0 1054 2045
43 ¹⁄₄ 83 ³⁄₄ 1 0 1 0 2 1099 2127
44 ¹⁄₂ 85 ³⁄₄ 1 0 3 1 1 1130 2178
45 ¹⁄₄ 87 ¹⁄₂ 1 0 0 3 1 1149 2223
46 ¹⁄₄ 89 1 0 0 1 2 1175 2261
48 ¹⁄₄ 91 ¹⁄₂ 1 0 2 0 2 1226 2324
49 ¹⁄₂ 94 ¹⁄₂ 1 0 1 5 0 1257 2400
51 ¹⁄₄ 97 ³⁄₄ 1 0 1 1 2 1302 2483
54 ¹⁄₄ 103 1 0 0 2 2 1378 2616
55 ¹⁄₄ 104 ¹⁄₂ 1 0 0 0 3 1403 2654
56 ¹⁄₂ 106 ¹⁄₂ 1 0 2 1 2 1435 2705
59 ¹⁄₂ 111 ³⁄₄ 1 0 1 2 2 1511 2838
61 ³⁄₄ 116 1 1 1 0 3 1568 2946
64 ³⁄₄ 121 ¹⁄₄ 1 1 0 1 3 1645 3080
67 124 ³⁄₄ 1 1 2 0 3 1702 3169
69 127 ³⁄₄ 1 1 1 3 2 1753 3245
70 130 1 1 1 1 3 1778 3302
73 135 ¹⁄₄ 1 1 0 2 3 1854 3435
75 138 ³⁄₄ 1 1 2 1 3 1905 3524
79 145 ¹⁄₂ 1 1 1 0 4 2007 3696
80 ¹⁄₄ 147 ¹⁄₂ 1 1 3 1 3 2038 3747
82 150 ³⁄₄ 1 1 0 1 4 2083 3829
87 159 ¹⁄₂ 1 1 1 1 4 2210 4051
Chimney Section (S)
FTF8-E30 Return Elbow*
FTF10-30 Offset Elbow* B
A
*Part of Offset/Return Package Model FTF10/8-ES30
FTF8-SS

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 17
Figure 40
Gas Line Connection
Install a ¹⁄₂" (13 mm) gas supply line through
fireplace wall for connection to a decorative
gas appliance inside the firebox. Outside, the
gassupplylinemustconnecttoagasshut-off
valve usually recessed flush into the wall or
floor. The valve should be controlled by a
removable valve key for safety.
CAUTION:PLUMBINGCONNECTIONSSHOULD
ONLY BE PERFORMED BY A QUALIFIED, LI-
CENSEDPLUMBER.MAINGASSUPPLYMUST
BEOFF WHENPLUMBINGGAS LINETO FIRE-
PLACE OR PERFORMING SERVICE.
Always plumb gas line installation per local
codes. Check all connections and test for gas
leaks, using a gas leak test solution (also
referred to as bubble leak solution).
Note: Usingasoapywatersolution(50%dish
soap, 50% water) is an effective leak test
solution but it is not recommended, because
the soap residue that is left on the pipes/
fittingscanresultincorrosionovertime. Never
use an open flame to check for leaks.
This provision is intended for connection to a
decorative gas appliance incorporating an au-
tomaticshut-offdeviceandcomplyingwiththe
Standard for Decorative Gas Appliances for
installation in vented fireplaces, ANSI Z21.60
(1991) or American Gas Association draft re-
quirementsforGas-FiredLogLightersforWood
Burning Fireplaces, Draft No. 4 dated August,
1993. Install in accordance with the National
Fuel Gas Code, ANSI Z223.1. This complies
with the revised U.L. 127 standard.
INSTALLING OFFSETS
First, review the Offset Elevation Chart and
Figure 38 for reference.
Step 1. Determine the offset distance where
chimney is to pass through the first ceiling-
dimension “A.” To find this point on your ceil-
ing, first determine the center point for a verti-
cal chimney following the instructions for ver-
tical installation.
Measure height to the ceiling from the top of
fireplace-dimension “B.” Use the appropriate
Offset Elevation Chart to find dimension “A.”
Mark point where you will drive your nail to
showthecenterpointforyouroffsetceilingcut.
Step2.ProceedbyusingtheStraightUpInstal-
lationInstructionsforcuttingandframingceil-
ing and roof openings.
Note:SeeFramingandDimensionChartforthe
sizesoftheceilingandroof openings. The size
of the roof opening varies with the degree of
pitch of the roof.
Offset Elbow Assembly
Offset elbows install the same as chimney
sections.First,snaptheinnersectionINTOthe
precedinginnersectionof flue. Check connec-
tion by pulling up slightly to ensure a tight fit.
Next, the outer sections snap lock OVER the
preceding outer section of chimney. Again,
check outer section by pulling up slightly to
ensure proper connection is made.
Return Elbow Assembly
Return elbows install the same way as round
terminations and stabilizers:
Step 1. Hold return elbow over top of last
chimney section.
Step 2. Centerinnerslip sectionintoinner flue
pipe-slip down.
Step3.Centerouter-lockingsectionoverouter
chimneypipe.Pushdownuntillockingjointhas
firmly engaged.
Step 4. Pull up slightly on return elbow to
ensure locking joint has firmly engaged.
Step 5. Secure support straps to framing
members by nailing under tension in sheer
( Figure 39 ).
Return
Elbow
Figure 39
Note: The return elbow assembly performs
thesamefunctionasastabilizer.Considerthis
when determining the need for a stabilizer.
Note: Do not apply excessive pressure to any
subsequent chimney section following return
elbow assembly when installing. Ensure that
each subsequent chimney section is securely
attached by testing as noted above.
Combustion Air Kits
Theseappliancesareequippedwithanoutside
(make-up) air door and integral actuator arm.
If the appliance is to be installed with an
outsideairventsystem,useonlyModelsFAOK-
4 or FAOK-4LD Combustion Air Kits. These
kits come complete with detailed installation
instructions and all components necessary in
completing a combustion air vent system.
After completing the installation of the op-
tionalcombustionairventsystemtheactuator
arm must be put in service and tested to
ensure proper operation before completing
anyenclosurearoundthefirebox. Failuretodo
so may result in extensive and costly rework.
The control lever that operates the outside
combustionair valvehas beenpre-installedon
yourfireplace.Acoverplate has been mounted
over this control lever only if the outside air kit
has not been attached. The control lever is
locatedontheclosedendofthefireplaceopen-
ingbehindthe screen.Toopen the airdamper,
turntheleverhandle1/2turncounterclockwise
(or until lever can be moved upward), then re-
tighten at desired open position. To close
damper, reverse procedure ( see Figure 40 ).
Operate the actuator through several cycles
including the "lock position. Ensuring proper
operation and freedom of movement. Return
the actuator arm to the locked position.
Control
Lever

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
18
Glass Doors
If glass doors are to be installed on these
fireplaces,refertospecificinstallationinstruc-
tionspackedwiththeglassdoors.Useonlythe
doors that are listed for use with these fire-
places. Use of other non-listed glass door on
thesefireplacesmayconstituteapotentialfire
hazard and is not recommended.
CAUTION:CERTAINGLASSDOORSOVERLAP
THE BLACK METAL FACING OF THE FIRE-
PLACE. IF THE FIREPLACE HAS BEEN FACED
WITHNONCOMBUSTIBLEMATERIALS,THERE
MIGHT NOT BE SUFFICIENT CLEARANCE TO
INSTALL THE GLASS DOORS OF YOUR
CHOICE. ENSURE ADEQUATE CLEARANCE IS
MAINTAINED AT ALL TIMES SO AS NOT TO
INTERFERE WITH THE INSTALLATION AND
OPERATION OF GLASS DOORS.
COLD CLIMATE INSULATION
If you live in a cold climate, it is especially
important to seal all cracks around the fire-
place opening with noncombustible material
and wherever cold air could enter the room.
Surroundingmaterialsmustbecaulkedwhere
itmeetsthe blackmetalfacingof thefireplace
to avoid cold air intrusion. Use noncombus-
tiblecaulkingmaterialonlyonfireplacefacing
to seal. Also, the outside air inlet duct should
bewrappedwithnoncombustibleinsulationto
minimize the formation of condensation. Do
not place insulation materials on top of fire-
place or against chimney sections.
Note: A 2" air space must be preserved for all
combustible materials extending for any con-
tinuous length adjacent to the chimney.
It is especially important to insulate between
thestudsofanoutsidechasecavityandunder
the floor if the floor is above ground level. Do
not place insulation directly against the fire-
place or chimney system.
FIREPLACE FINISHES
Mantels and Trim
It is sometimes best to frame your fireplace
after it is positioned and the chimney is in-
stalled.Frameenclosureforchimneyandfire-
place with 2 x 4’s (or heavier) lumber.
Note:Theheadermayrestonthetwo(2)metal
top spacers on top of the unit but the header
mustnotbenotchedtofitaroundthespacers.
Note: Only non-combustible wall finishing
materials are allowed on the front top of the
unit,fromthetopedgeofspacersdown. (See
Figures 41 and 42 ).
Hearth Extensions and Wall Shields
A hearth extension must be installed with
all fireplaces. It is to protect the combustible
floorinfrontofthe fireplacefrombothradiant
heat and sparks. The hearth extension must
extend 8" beyond both sides of the fireplace
opening and 16" beyond the front ( see Figure
43 ) . Use a hearth extension constructed of a
durable noncombustible material having an
equalorbetter(lowerkvalue)insulatingvalue
of k = .84 BTU IN/FT2 HR °F or a thermal
resistance that equals or exceeds r = 1.19 HR
°F FT2/BTU IN. With these values, determine
the minimum thickness/material required us-
ing the formula and
Page 19 .
Note: Any noncombustible material whose k
value is less than .84 or whose r value is more
than 1.19 is acceptable.
If the fireplace is installed on a combustible
floor, use the metal safety strips (provided)
on the floor extending half under the fire-
place and half under the hearth extension
(refer to Figures 6 & 7) .
A wall shield is required where a continuous
perpendicular side wall is within 12" of the
fireplace opening ( Figure 44 ) . Use a 40" W x
40" H wall shield constructed of a durable,
noncombustible material having an equal or
better(lowerkvalue)insulatingvaluethank=
.84 BTU IN/FT2HR °F. At no time may a
perpendicularsidewallbe located closer than
8" from the fireplace opening. See Figure 46 .
Iffireplace isinstalleddiagonally acrossa90°
corner; no wall shields are required.
Figure 42
Figure 41
Thesefireplacesmaysitdirectlyonacombus-
tible surface. A 2" air space is required be-
tween combustible framing and the chimney.
A1"airspaceisrequiredbetweencombustible
framingandfireplaceouterwrapper. InCanada,
theminimumheight foracombustible mantel
is 18" (457 mm) above the fireplace opening.
Figure 41 shows typical Canadian installa-
tions. For installations other than Canada,
combustible mantels and trim may be in-
stalled 12" above the fireplace opening as per
NFPA 211, Section 7-2.3.3. and Figure 42 . If
a mantel is of a noncombustible material, it is
exempt from these requirements as long as it
does not interfere with the installation or op-
eration of glass doors.
Canadian Installation
Fireplace
Opening
Header
Spacer
8" Max.
(203mm)
18" Min.
(457mm)
Combustible
Mantel
Finished
Wall
Typical Installation
*Both Of These Dimensions Must Be At Least 18”
When An Unvented Gas Log Set Rated At 26,000
BTU Or Higher Is Used. (Maximum 40,000 BTU)
12"*
Min.
8 3/8"*
Fireplace
Opening
Combustible
Mantel
and Trim
12"
Max. 1 1/2"
Header
Spacer
Finished Wall

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 19
Figure 43
Hearth Extension Dimensions
A20" (508 mm)
B38" (965 mm)
C8" (203 mm)
D20" (508 mm)
E12" (305 mm)
Answer - The minimum required thickness of the Micore 160 is .417”,
therefore round up to nearest standard thickness available which is 1/2”.
** If the hearth extension material(s) that is intended to be used is NOT listed
onTable1, the material can stillbeusedif the material(s) is noncombustible.
However, the manufacturer of the material must provide either the listed k-
value per inch or r-value per inch with listed thickness so that the minimum
thickness required for the hearth can be calculated (per instructions on this
Page and/or as specified in the NFI Certification manuals).
Note:AlsoseeNFI(NationalFireplaceInstitute)CertificationManualsshowing
other acceptable calculation methods and acceptable alternate materials
which can be used.
Listed Material
k (per inch) r (per inch) Listed Min.Thickness
Listed Material .84
KL
1.19
r
L
1
"
T
L
** Approved Alternate Materials for Floor/Hearth Protection
AlternativeMaterials Thermal Values MinimumThickness
(rounded to nearest 1/8 inch)
k (per inch)
KM
r (per inch)
r
M
Min. Thickness
T
M
Kaowool M Board .47 2.13 .56" (1/2")
Micore 160™
U.S. Gypsum
.35 2.86 .42" (3/8")
Micore 300™
U.S. Gypsum
.46 2.17 .55" (1/2")
Durock™ Cement Board
U.S. Gypsum
1.92 .52 2.29" (2-1/4")
Hardibacker™ 1.95 .513 2.32" (2-3/8")
Hardibacker 500™ 2.30 .435 2.74" (2-3/4")
Cultered Stone Hearth-
stone™ 2.82 .355 3.36" (3-3/8")
Wonderboard 3.23 .31 3.85" (3-7/8")
Super Firetemp M
Johns-Manville
.61 1.64 .73" (3/4")
Super Firetemp L
Johns-Manville
.54 1.85 .64" (5/8")
Face brick 9.00 .111 10.71" (10-3/4")
Common brick 5.00 .20 5.95" (6")
Cement mortar 5.00 .20 5.95" (6")
Ceramic tile 12.5 .08 14.88" (14-7/8")
Marble 11 .09 13.10" (13-1/8")
Table 1
Methods of Determining Hearth Extension and Wall Shield
Equivalents - To determine the thickness required for the alternate
material when either the “k” value or “r” value is known, use either the
k formula or r formula.
Example: If Micore 160 is to be used for the hearth extension fireplace,
how thick must this material be?
kM= k value per inch of
alternate material
rM= r value per inch of alternate material
TM= minimum thickness required for alternate material
TS = standard thickness of the alternate material
kL= k value per inch of listed material
rL= r value per inch of listed material
TL= minimum thickness of listed material
Note: An asterix “*” indicates, it is a value taken from Table 1 .
Using the k formula:
Minimum k-value (per Inch) of Specified min.
thickness of = alternate material (kM) x thickness
alternate k-value (per inch) of listed
material (TM) of listed material (kM) material (TL)
TM(inches) = kMxT
L
*.84
TM(inches) = *.35 x 1"
*.84
.416 (inches) = .416 x 1"
Answer - The minimum required thickness of the Micore 160 is .417”,
thereforerounduptoneareststandardthicknessavailablewhichis1/2”.
Using the r formula:
Minimum r-value (per Inch) Specified min.
thickness of = of listed material x thickness
alternate r-value (per inch) of listed
material of alternate material material
TM(inches) = rLxT
L
rM
TM(inches) = *1.19 x 1"
*2.86
.416 (inches) = .416 x 1"
8"
(203mm)
20"
(508mm)
12"
(305mm)
Min.
Outside Corner
Metal Safety Strip
20"
(508mm)
D
BA
C
E

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
20
FINISH TO YOUR TASTE
There are a wide variety of “finished looks” for
these fireplaces, from formal wall decor with
elaborate mantels to rustic wood paneling or
warm brick facings.
Only noncombustible materials like stone, tile,
brick, etc., may overlap the black front facing.
Donotextendthesematerialsbeyondtheblack
facing and into the firebox area. Be sure not to
interfere with the installation and operation of
glassdoors orblockthe upperorlower grilles.
Sealalljointsbetweentheblackfacingandwall
surrounds to prevent air intrusion. Use non-
combustible caulking material only to seal the
black metal facing to the surround material on
the finished wall.
Combustiblematerialsmayprojectbeyondthe
sides of the fireplace opening as long as they
are kept within the shaded areas illustrated in
Figure 46 .
Model Part Number Weight
CR-3835R P/N 015014 210 lbs.
CR-3835L P/N 015013 210 lbs.
12" Min. Distance To
Unprotected Side Wall
8"
45°
Combustible
Materials
Allowed In
Shaded Area
“Safe Zone” 8"
Min. Distance To
Protected Side Wall
Fireplace
11 ⁷⁄₈”
15 ⁷⁄₈”
Figure 46
Figure 45
Secure the hearth extension to the floor to
prevent possible shifting.
6"
Max. Thickness Of Hearth Extension
When Models Are On The Floor
Figure 44
20"
(508mm)
Inside Corner
If Less Than 12"
(305mm) Wall
Shield Required
20"
(508mm)
40"
(1016mm)
Wall
Shield
40"
(1016mm)
Metal Safety
Strip
Wall Shield
Not Required
On This Wall
WARNING: THE CRACK BETWEEN THE
FIREPLACE AND THE HEARTH EXTEN-
SION MUST BE SEALED WITH A NON-
COMBUSTIBLE MATERIAL.
Calculating Minimum Thickness if Multiple
Materials are Used
At times it is important to know what
combination of materials are acceptable for
use as floor protection. The “R values” are
usedtodetermineacceptablecombinationsof
materialsbecause“Rvalues”areadditivewhere
r and k values are not.
“Rvalue”= 1/k = “r”xthicknessofmaterial
used
Example: Given that the required “R value”
for a suitable floor protector used must be
equal to or greater than:
“R” = rLx TL= 1.19 x 1” = 1.19.”
If it is desired to elevate a marble hearth ex-
tensionto alevelof5”ormoreabove thefloor
surface. What combination of noncombus-
tiblematerialscanbeusedtoaccomplishthis?
If common brick is used so that the 3 1/2”
dimension is the height, “R” for the common
brick becomes:
brick
“R”M= rMx TS= 0.20 x 3 1/2" = .70
Using 1/2” of mortar to set the brick, “R” for
the mortar is calculated as follows:
mortar
“R”M= rMx TS= 0.20 x 1/2" = .10
Next,a3/4"marbleslabsetin1/2"mortarcov-
ers the brick, “R” for the marble and mortar
becomes:
marble
“R”M= rMx TS= 0.05 x 3/4" = .038
mortar
“R”M= rMx TS= 0.20 x 1/2" = .10
The sum of all “R values” is: .70 + .10 +. 038
+ .10 = .938
ThiswouldNOTbeanacceptablecombination
of material for the hearth extension since the
totalcalculated“Rvalue”ofthematerialsused
is under the required “R value” of 1.19. An
additional layer of insulating materials must
be used.
Note: Also see NFI Certification Manuals for
expanded explanation on calculating “R val-
ues” when multiple materials are used.
WARNING: WHEN INSTALLING HEARTH
EXTENSION IN FRONT OF A NON-CIRCU-
LATING FIREPLACE MODEL, THE FIRE-
PLACE MUST BE RAISED IF HEIGHT OF
HEARTH EXTENSION EXCEEDS 7" ABOVE
THEBOTTOMOFFIREPLACE( FIGURE45 ).
