Lenovo IdeaCentre A320 Guide User manual

1. Unpack
2. Computer instructions 3. Computer stand 4. Carry the computer
1
4
2
3
5
6
7
2 3 4 5 6 78 9107
1
Do not put any fluid container on the
base stand.
The buttons at the bottom of the screen
are touch buttons. When you touch
these, the indicator lights turn on.
1
2
1
2
Connect the power cords properly to
grounded electrical outlets.
Connect the
keyboard cable to
the appropriate
keyboard connector
(USB connector).
Connect the mouse
cable to the
appropriate mouse
connector (USB
connector).
Adjust the angle for the best viewing
experience. It can be rotated from
horizontal or vertical.
The stand provides stability to the
computer; it is not a removable part.
Hold the computer tightly when you carry it.
10
10
318
Adjust the panel angle
for the best viewing
from the vertical.
Do not only use one
hand to adjust the panel
angle to avoid the
computer falling over.
Adjust the panel angle
for the best viewing
from the horizontal.
Version: 2.1
Connecting the wired keyboard and
mouse to your computer
(Selected models only)
Press the power button on the top of the
base stand to turn on the computer.
Camera
Built-in microphone
Hard Disk Drive Indicator
Bluetooth status indicator
WIFI status indicator
Menu/OK button
Direction buttons
1
8
4
2
7
3
5
6
9
10
Power button
TV tuner connector
(Selected models only)
Power connector
Ethernet connector
HDMI-OUT connector
(Selected models only)
HDMI-IN connector
(Selected models only)
USB ports (4)
Memory card reader
(Selected models only)
Microphone connector
Headphone connector
Bluetooth connect button
Mode switch button
(Selected models only)
The computer stand must
remain installed at all
times to ensure maximum
system stability.
12
74 63 5
TV
31045828

5. Wireless keyboard and mouse instructions (Only some models are equipped with wireless keyboard and mouse)
The wireless keyboard and mouse are pre-synchronized, for your convenience, to work with your Lenovo PC. The keyboard and mouse should work immediately after you pull the battery tabs to activate the preinstalled
batteries(or install the batteries), and then turn on the mouse.
You may need to manually synchronize the wireless keyboard or mouse if they are not functioning.
To synchronize them, do the following:
Remove the battery tabs from both the keyboard and the mouse (or install the batteries into the battery
compartments).
Make sure the power switch
on the back of the mouse is
in the ON position (the
keyboard does not have a
power switch).
Remove the battery tabs from
both the keyboard and the
mouse.
CONNECT LASER
OFF ON
CONNECT
OFF ON
CONNECT
Press the wireless connect
buttons on the right side of the
keyboard and the back of the
mouse.
1. Press the wireless connect button.
2. Make sure the indicator lights blink and press the bluetooth connect button.
When the keyboard and mouse wireless indicator lights blink green, press the bluetooth connect button on the base stand for
over 5 seconds until the indicator lights of the keyboard and mouse turned off.
If connection is not established successfully,
refer to “Wireless keyboard and mouse
instructions” in the User Guide.
Bluetooth
connect button
Mode switch
button
CONNECT LASER
OFF ON
