Lenovo IdeaCentre A600 User manual

Lenovo IdeaCentre A600
(Remote control and wireless
keyboard/mouse on select models)
Lenovo IdeaCentre A600
(Remote control and wireless
keyboard/mouse on select models)
Lenovo IdeaCentre A600
Lenovo IdeaCentre A600
Lenovo IdeaCentre A600
Lenovo IdeaCentre A600

Intel®Pentium®processor T4200 with dual-core,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo processor T6400 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo processor P7450 with dual-core,
Intel HD Boost, 1066MHz system bus, and 3MB L2 cache
2GB, 3GB, or 4GB std / 4GB max7 / PC3-8500 1066MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets;
Italics: standard memory in both sockets; no sockets available
Non-italics: standard memory in one socket; one socket available
Some: DVD burner, dual-layer support, fixed, not removable, 12.7mm, slot-in
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM, no HD-DVD
playback, DVD recordable, not removable, 12.7mm high, slot-in
320GB, 500GB, 640GB, or 1TB, SATA 3.0Gb/s, 3.5" wide, 7200 rpm
21.5" (546.1mm) WUXGA (1920x1080) TFT color,VibrantView (glossy),
CCFL backlight, 300 nits, 16:9 aspect ratio, 1000:1 contrast ratio, frameless screen
Some: camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Some: camera on top of screen, 2.0-megapixel, fixed focus,
with dual array microphone
Touch-sensitive buttons for brightness, display on/off, and optical disk drive eject
Some: Intel Graphics Media Accelerator 4500MHD (GMA 4500MHD),
integrated graphics in GM45, uses main memory, DirectX®10
Some: ATI™ Mobility Radeon™ HD 3650, PCI Express®x16, 512MB memory,
DirectX®10, ATI Avivo™ HD
Mobile Intel GM45 Express Chipset (Graphics Memory Controller Hub),
ICH9M I/O Controller Hub (SATA 3.0Gb/s, USB 2.0, PCI Express 1.1, PCI 2.3,
ethernet MAC)
6-in-1 reader (MultiMedia Card, Memory Stick, Memory Stick PRO ™ ,
Secure Digital Card, Secure Digital Elite Pro Card, xD-Picture Card ™ )
Rear: Four USB 2.0, ethernet (RJ-45), TV antenna connector on some models;
Left: Two USB 2.0, IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Two Mini PCI Express slots
Some: 11a/b/g/n wireless
4,
Mini PCIe adapter, Intel WiFi Link 5100, 1x2 (Shirley Peak)
Some: 11b/g wireless4, Mini PCIe adapter, Broadcom®BCM4312
Some: AverMedia®Hybrid tuner, support analog and digital signal, Mini PCIe adapter
Some: Bluetooth 2.1 wireless + EDR, USB 2.0 interface via ICH9M, LED indicator
None
Gigabit ethernet on planar, Broadcom BCM5784
High Definition (HD) Audio, RealTek®ALC272 codec /
two speakers (3 watt) and subwoofer (8 watt), Dolby Home Theater Speaker System /
mono microphone or dual array microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Power-on password, hard disk password, supervisor password
Some: Wireless RF 2.4 GHz keyboard with touch pad, 6-row, 84-key,
touch-sensitive multimedia keys and shortcut keys
Some: USB full-size keyboard with USB hub (two USB ports)
Some: Wireless RF 2.4 GHz Laser Wheel Mouse, 800/1600 dpi (user switchable)
Some: USB Optical Wheel Mouse
Some: Vista MCE remote control (40-button), via IR
Some: 4-in-1 remote control, via bluetooth, acts as motion game controller (requires
games* support), VOIP headset, Vista MCE remote control, and air mouse
* Motion games CD included in 4-in-1 remote control models (requires installation)
(WxHxD): 20.47" x 18.22" x 1.06" to 2.36"; 520mm x 463mm x 27 to 60mm
27.7 lb (12.6 kg)
Black color, ABS plastic
Tilt stand (15° back, 5° forward)
Processor
Memory
S ATA DV D ±RW
SATA Blu-ray™
SATA disk
Widescreen
display
Camera
Controls
Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
Intel 510028
11b/g28
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
IdeaCentre™A600 (3011)
Some: 130-watt (GMA graphics) AC
adapter
Some: 150-watt (ATI graphics) AC
adapter
RoHS-compliant
3011-2AU T4200 2.00 2GB 21.5" WUXGA 1.3 GMA 320GB8DVD±RW 11b/g28 Mono USB Prem 64 Apr 09
3011-2BU T4200 2.00 3GB 21.5" WUXGA 1.3 GMA 500GB DVD±RW Intel 5100 Mono USB Prem 64 Apr 09
3011-2CU T4200 2.00 4GB 21.5" WUXGA 1.3 GMA 640GB DVD±RW Intel 5100 Mono USB Prem 64 Apr 09
3011-3AU T6400 2.00 3GB 21.5" WUXGA 1.3 GMA 640GB DVD±RW ✶ Intel 5100 Mono USB Prem 64 Apr 09
3011-3CU T6400 2.00 4GB 21.5" WUXGA 2.0 HD 3650 1TB DVD±RW ✶ Intel 5100 TV Remote Array Blue Wireless Prem 64 Apr 09
3011-4AU P7450 2.13 4GB 21.5" WUXGA 2.0 HD 3650 1TB BD player ✣Intel 5100 Array Blue USB Prem 64 Apr 09
3011-4BU P7450 2.13 4GB 21.5" WUXGA 2.0 HD 3650 1TB BD player ✣Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Apr 09
3011-3DU T6400 2.00 3GB 21.5" WUXGA 1.3 GMA 500GB DVD±RW ✶ Intel 5100 Mono Wireless Prem 32 Apr 09
3011-3HU T6400 2.00 4GB 21.5" WUXGA 2.0 HD 3650 640GB DVD±RW ✶ Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Apr 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Vista
preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(BL1-1) April 2009
See footnotes for important warranty information ✶Intel Centrino®processor technology
☞US models announced April 22, 2009; ✣Intel Centrino 2 processor technology
previous models on April 07, 2009
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Premium 32
- Some: Genuine Windows Vista
Home Premium 64
✧Vista Premium logo
Preloaded applications14
•Lenovo®OneKey Recovery
•Driver and Application Installation
•Lenovo Recovery Disk Maker
•Lenovo Healthcare Software
•VeriFace™
•Media Show
•Trend Micro™ PC-cillin™ Internet
Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Cyberlink Power2Go (DVD±RW,
BD player)
•Corel®WinDVD®(BD player)
•All-In-One design with 21.5" Full HD 16:9 widescreen, glossy display
•(Seleted models) Integrated TV tuner
•(Seleted models) 4-in-1 remote control acts as a motion game controller (requires
game support), VOIP handset, Vista Media Center remote and air mouse
• Integrated camera and Lenovo's VeriFace face recognition software helps control
access to your notebook by recognizing your face
•Dolby®Home Theater™premium audio system with two speakers and one subwoofer
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without
booting into Windows
Graphics
KBD/
Mouse
TV
tuner
Proc-
essor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Available at these retailers
•lenovo.com
•Fry's
Remote
control
Camera
(mega-
pixel)
Micro-
phone
Blue-
tooth
☞
☞

Partial list of accessories supported on:
IdeaCentre K210, K220, and K230
Storage and removable storage
USB 2.0 MyKey E10 Flash Drive 1GB 45J7701 ann 04/29/08
USB 2.0 MyKey E10 Flash Drive 2GB 45J7702 ann 04/29/08
USB 2.0 MyKey E10 Flash Drive 4GB 45J7703 ann 04/29/08
USB 2.0 MiniKey M10D1 Flash 2GB (gray) 45J7752 ann 05/20/08
USB 2.0 MiniKey M10D2 Flash 2GB (black) 45J7754 ann 05/20/08
USB 2.0 MiniKey M10E1 Flash 2GB (teal) 45J7756 ann 05/20/08
USB 2.0 MiniKey M10E2 Flash 2GB (pink) 45J7758 ann 05/20/08
USB 2.0 Essential Memory Key 4GB 45J7904 ann 06/24/08
USB 2.0 Essential Memory Key 8GB 45J7905 ann 07/15/08
USB 2.0 Essential Memory Key 32GB 45K1258 ann 10/28/08
USB 2.0 Security Memory Key 4GB 41U5120 ann 07/17/07
USB 2.0 DataSlim E16 Portable HD 160GB 45J7700 ann 04/29/08
USB 2.0 Portable 160GB Hard Disk 43R1784 ann 09/23/08
USB 2.0 Portable Secure 160GB Hard Disk 43R2018 ann 11/18/08
USB 2.0 Portable Secure 320GB Hard Disk 43R2019 ann 11/18/08
Keyboard
Preferred Pro USB Keyboard 73P5220 ann 06/21/05
Enhanced Performance USB Keyboard 73P2620 ann 03/23/04
Wireless Kybd & Opt Wheel Mouse (via USB) 73P4067 ann 12/07/04
USB Keyboard with UltraNav 31P8950 ann 01/28/03
USB Travel Keyboard with UltraNav 31P9490 ann 04/27/04
Mouse
Laser Tilt Wheel Mouse (USB, PS/2) 41U3074 ann 01/23/07
IdeaPad Mini Optical Mouse M10 (black) 47J7729 ann 06/17/08
IdeaPad Mini Optical Mouse M10A (black) 45J7730 ann 07/15/08
Lenovo Mini Optical Mouse M30 (black) 47J7735 ann 06/17/08
Lenovo Mini Optical Mouse M30 (white) 47J7736 ann 06/17/08
Lenovo Mini Optical Mouse M30 (red) 47J7737 ann 06/17/08
Lenovo Mini Optical Mouse M30 (blue) 47J7738 ann 06/17/08
Mini Wireless Laser Mouse N10 (black) 45J7731 ann 06/17/08
Mini Wireless Laser Mouse N10 (red) 45J7732 ann 06/17/08
Monitors
Lenovo
®
D185 Wide 18.5" Monitor 6318HB1 ann 01/27/09
Lenovo L215 Wide 21.5" Monitor 6325HB1 ann 01/27/09
Lenovo L215p Wide 21.5" Monitor 6325HC1 ann 01/27/09
ThinkVision
®
L174 17" Monitor 9227AE1 ann 04/15/08
ThinkVision L1700p 17" Monitor 9417HE2 ann 09/17/08
ThinkVision L1900p 19" Monitor 4431HE1 ann 11/11/08
ThinkVision L1940p Wide 19" Monitor 4424HB6 ann 09/17/08
ThinkVision L200p Wide 20.1" Monitor 4438HB6 ann 04/15/08
ThinkVision L2240p Wide 22" Monitor 4422HB6 ann 09/17/08
ThinkVision L2440p Wide 24" Monitor 4420HB2 ann 09/17/08
ThinkVision L2440x Wide 24" Monitor 4421HB2 ann 09/17/08
Monitor Accessories46
ThinkVision USB Soundbar 40Y7616 ann 08/23/05
ThinkVision Soundbar (L1900p, 24" Wide) 45K1263 ann 09/16/08
Kensington Cable Lock from Lenovo 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
ThinkPad Convertible Monitor Stand 40Y7620 ann 01/05/06
Radial Arm 19K4464 ann 05/05/00
46
Compatible on selected ThinkVision monitors.
More information at www.lenovo.com/support/monitoraccessories
Consumer monitors
Lenovo L195 Wide 19" LCD Monitor 4418HC1 ann 09/02/08
Lenovo L222 Wide 22" LCD Monitor 4432HF1 ann 09/02/08
Other accessories at www.lenovo.com/accessories
Accessories Guide pdf at www.lenovo.com/accessoriesguide
© Lenovo
(O-IC) February 2009
IdeaCentre™Accessories Personal Systems Reference (PSREF)

Availability: All offers subject to avail-
ability. Lenovo reserves the right to alter
product offerings and specifications at
any time, without notice. Lenovo is not
responsible for photographic or typo-
graphic errors.
Warranty: For a copy of applicable
product warranties, write to: Warranty In-
formation, P.O. Box 12195, RTP, NC, 27709,
Attn: Dept ZPYA/B676. Lenovo makes no
representation or warranty regarding third
party products or services.
1 Limited warranty: Support unrelated to
a warranty issue may be subject to ad-
ditional charges.
2 Hard disk drive: GB = billion bytes, TB =
trillion bytes. Accessible capacity is less;
up to 4GB is service partition.
3Customer Replacement Units (CRUs)
are designed to be replaced by custom-
ers during the applicable warranty pe-
riod. Lenovo will send a technician onsite
to perform a repair if remote telephone
diagnosis does not isolate the problem,
if customer replaceable parts are unable
to resolve the problem, or at the request
of the customer. For a list of customer
replaceable parts, contact Lenovo. Sup-
port unrelated to a warranty issue may
be subject to additional charges.
5Included software may differ from its
retail version (if available), and may not
include user manuals or all program
functionality. License agreements may
apply.
8Memory: For PCs without a separate
video card, memory supports both
system and video. Accessible system
memory is less than the amount stated,
depending on video mode.
9Service upgrade options: Service
period begins with the equipment date
of purchase. Service must be purchased
during the original limited product war-
rantyperiod. Service levels are response
time objectives and are not guarantees.
1 0 Modem speeds: Public network
download speeds are limited to 53Kbps.
Upload speeds are limited to 48Kbps for
V.92 modems. Actual speeds depend on
many factors and are often less than the
maximum possible. V.92 functions and
speeds require compatible phone line
and server equipment. Check with your
telephone and ISP service providers for
availability.
14 Response times may vary. May exclude
some holidays. Telephone support may
be subject to additional charges.
20 Operating System: Level of support var-
ies by operating system. Operating sys-
tems not preloaded on the system may
not provide full feature functionality. Refer
to lenovo.com/pc/support and enter your
machine type and model number for
more information.
This publication was developed for prod-
ucts and services offered in the United
States. Lenovo may not offer the products,
services or features discussed in this
document in other countries. Lenovo may
withdraw an offering at any time. Informa-
tion is subject to change without notice.
Consult your local representative for
information on offerings available in your
area.
Lenovo reserves the right to change spec-
ifications and other product information
at any time without prior notice. Lenovo is
not responsible for photographic or typo-
graphical errors. LENOVO PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WAR-
RANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
Some jurisdictions do not allow disclaimer
of express or implied warranties in certain
transactions; therefore this disclaimer may
not apply to you.
Trademarks: Lenovo, the Lenovo logo,
New World. New Thinking., Access Con-
nections, Rescue and Recovery, Think-
Vantage, and ThinkVision are trademarks
of Lenovo. Microsoft, Windows, and Vista
are registered trademarks of Microsoft
Corporation. Intel, the Intel logo, Intel
Inside logo, Intel Core and Core Inside
are trademarks of Intel Corporation in the
US and other countries. AMD, the AMD
logo, AMD Athlon, AMD Sempron, and
combinations thereof, are trademarks
of Advanced Micro Devices, Inc. PCI
Express is a trademark of PCI-SIG. Other
company, product, or service names may
be trademarks or service marks of oth-
ers.
Visit www.lenovo.com/safecomputing
periodically for the latest information on
safe and effective computing.
Visit www.lenovo.com/psref
for the latest version of
Personal Systems Reference.
© Lenovo, 2009.
All rights reserved.
Lenovo
1009 Think Place
Morrisville, NC 27560
U.S. A.
April 2009
icbook.pdf
