Lenovo IdeaCentre B310 7722 User manual

Personal Systems Reference
Lenovo IdeaCentre Desktops
October 2009 - Version 364
Visit www.lenovo.com/psref for the latest version

57-078915 4x5 Celeron E1200 1.60 512KB 2 2GB 16-in-1 320GB2DVD±RW GMA 3100 Camera Home Prem May 08
57-078894 4x5 Pentium E2140 1.60 1MB 2 4GB 16-in-1 500GB DVD±RW GMA 3100 Camera Home Prem May 08
57-076245 4x5 Pentium E2180 2.00 1MB 2 1GB 16-in-1 320GB DVD±RW GMA 3100 Mod Home Basic May 08
57-076162 4x5 Pentium E2180 2.00 1MB 2 2GB 16-in-1 320GB DVD±RW GMA 3100 Mod Camera Home Prem May 08
57-076161 4x5 Pentium E2180 2.00 1MB 2 3GB 16-in-1 500GB DVD±RW GMA 3100 Mod Home Prem May 08
57-076522 4x5 Pentium E2180 2.00 1MB 2 3GB 16-in-1 500GB DVD±RW GMA 3100 Mod L222 Camera Home Prem May 08
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel Celeron Dual-Core Processor E1200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 512KB L2 cache or
Intel Pentium®Dual-Core Processor E2140 or E2180 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 1MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB, 2GB, 3GB,or 4GB std, 4GB max8, PC2-5300 667MHz
DDR2, non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available;
Non-italics: standard memory in one socket; 1 socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
320GB or 500GB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7DH
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
One
None
None
16-in-1 media reader, internal USB 2.0
Intel G31 Express Chipset; I/O Controller Hub 7 Digital Home (ICH7DH) for
SATA 3.0Gb/s, PCI Express®x1, PCI 2.3, USB, LPC bus / Winbond®W83627DHG
Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
Some: 56K10 V.92 data/fax soft modem, PCI adapter
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K210 (Celeron®and Pentium®)
GHz
Part
number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced May 12, 2008
© Lenovo
(KW1-1) May 2008
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black and silver bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x1 Ver 1.1
Slot 2: half-length,full-height, PCI Express x16 Ver 1.1
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* modem in slot in some models
Lenovo L222 Wide
• Widescreen 22-inch flat panel monitor
• Active Matrix TFT LCD screen
• Supports WSXGA+ 1680x1050 resolution
• 16:10 aspect ratio
• 22.0" (559mm) viewable image size
(diagonal)
• 300 nits brightness (typical)
• 1000:1 contrast ratio (typical)
• 5ms pixel response time
• Dual video input: one analog D-sub
connector and one digital DVI-D
connector
• HDCP-compliant
• Ergonomic stand tilts and swivels
• High-gloss black case
• Touch-sensitive control button
• Soundbar with speakers included
Lenovo L222 Wide Monitor is only bundled
with some models
Camera
Monitor
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
• (Select models) Healthcare eyesight protection software detect distance between user and monitor
and adjusts monitor brightness based on environment
• (Select models) Lenovo Bright Eye camera and VeriFace face recognition software help control access to
your computer by recognizing your face
Vista
preload
Available at these retailers
•B&H™
•J&R™
•Newegg®
•TigerDirect
•ASI Computer Systems
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Basic 32
- Some: Genuine Windows Vista
Home Premium 32
✧57-076245: Vista Basic logo
✧Others: Vista Premium logo
Preloaded applications5
• Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Lenovo Media Studio
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•EarthLink®
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)

57-076523 4x5 Core 2 Duo E4600 2.40 2MB 2 3GB 16-in-1 500GB2DVD±RW GMA 3100 Mod None None Home Prem May 08
57-082791 4x5 Core 2 Duo E7200 2.53 3MB 2 3GB 16-in-1 500GB DVD±RW GMA 3100 None Cam Home Prem Aug 08
57-076158 4x5 Core 2 Quad Q6600 2.40 8MB 4 3GB 16-in-1 500GB DVD±RW GMA 3100 Mod None None Home Prem May08
57-076244 4x5 Core 2 Quad Q6600 2.40 8MB 4 3GB 16-in-1 500GB Blu-ray HD 2600 PRO Mod None None Home Prem May 08
57-082788 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 500GB DVD±RW 9300 GE Mod None Cam Home Prem Aug 08
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Core™2 Duo Processor E4600 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo Processor E7200 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q6600 with quad-core
(dual-core on dual-die), Intel 64 Technology,
Virtualization Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 8MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
3GB or 4GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
Some: ATI™ Radeon™ HD 2600 PRO, PCI Express x16,
256MB memory, DirectX®10, ATI Avivo™, one D-sub
connector and one DVI-D connector, HDCP-compliant
Some: NVIDIA®GeForce®9300 GE, PCI Express x16,
256MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out, VGA connector,
DVI-I connector, HDCP-compliant
500GB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7DH
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning),
supports HD-DVD playback, DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
One
None
None
16-in-1 media reader, internal USB 2.0
Intel G31 Express Chipset; I/O Controller Hub 7 Digital Home (ICH7DH) for
SATA 3Gb/s, PCI Express®x1, PCI 2.3, USB, LPC bus / Winbond®W83627DHG
Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15, DVI-D in some models)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
Some: 56K10 V.92 data/fax soft modem, PCI adapter
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key anti-bacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K210
GHz
Part
number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞ US models announced July 15, 2008; previous models on May 12, 2008
© Lenovo
(KW1-2) July 2008
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
☞
•Black and silver bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x1 Ver 1.1
Slot 2: half-length,full-height, PCI Express x16 Ver 1.1**
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* modem in slot
** used in some models
Cam-
era
Monitor
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
• (Select models) Healthcare eyesight protection software detect distance between user and monitor
and adjusts monitor brightness based on environment
• (Select models) Lenovo Bright Eye camera and VeriFace face recognition software help control access to
your computer by recognizing your face
Vista
preload
Available at these retailers
•B&H™
•J&R™
•MICROCENTER®
•Newegg®
•TigerDirect
Modem
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 32
✧Vista Premium logo
Preloaded applications5
• Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Lenovo Media Studio
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•EarthLink®
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)

5313-3AU 4x5 Celeron E1200 1.60 512KB 2 1GB 160GB2DVD GMA 3100 None Home Basic Jul 08
5313-3BU 4x5 Celeron E1200 1.60 512KB 2 1GB 16-in-1 250GB DVD±RW GMA 3100 Mod None Home Prem Jul 08
5313-4AU 4x5 Pentium E2180 2.00 1MB 2 2GB 16-in-1 320GB DVD±RW GMA 3100 Mod None Camera Home Prem Jul 08
5313-4BU 4x5 Pentium E2180 2.00 1MB 2 3GB 16-in-1 500GB DVD±RW GMA 3100 None Camera Home Prem Jul 08
5313-4DU 4x5 Pentium E2200 2.20 1MB 2 2GB 250GB DVD±RW GMA 3100 None Home Prem Oct 08
5313-4EU 4x5 Pentium E2200 2.20 1MB 2 3GB 320GB DVD±RW GMA 3100 None Home Prem Oct 08
5313-4CU 4x5 Pentium E2200 2.20 1MB 2 4GB 16-in-1 500GB DVD±RW GMA 3100 None Camera Home Prem Jul 08
5313-5CU 4x5 Pentium E5200 2.50 2MB 2 4GB 16-in-1 640GB DVD±RW GMA 3100 None Home Prem Nov08
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel Celeron Dual-Core Processor E1200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 512KB L2 cache or
Intel Pentium®Dual-Core Processor E2180,E2200,or E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus;
E2180/E2200: 1MB L2 cache; E5200: 2MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB, 2GB, 3GB,or 4GB std, 4GB max8, PC2-5300 667MHz
DDR2, non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available;
Non-italics: standard memory in one socket; 1 socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
160GB, 250GB, 320GB, 500GB, or 640GB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7DH
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max4
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
One
None
None
Some: 16-in-1 media reader, internal USB 2.0
Intel G31 Express Chipset; I/O Controller Hub 7 Digital Home (ICH7DH) for
SATA 3Gb/s, PCI Express®x1, PCI 2.3, USB, LPC bus / Winbond®W83627DHG
Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
Some: 56K10 V.92 data/fax soft modem, PCI adapter
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K210 (5313) - Celeron®and Pentium®
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced November 12, 2008; previous models on July 15 or October 22, 2008
© Lenovo
(KW1-3) November 2008
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black and silver bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x1 Ver 1.1
Slot 2: half-length,full-height, PCI Express x16 Ver 1.1
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* modem in slot in some models
Camera
Monitor
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
• (Select models) Healthcare eyesight protection software detect distance between user and monitor
and adjusts monitor brightness based on environment
• (Select models) Lenovo Bright Eye camera and VeriFace face recognition software help control access to
your computer by recognizing your face
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Basic 32
- Some: Genuine Windows Vista
Home Premium 32
✧5313-3AU/3BU: Vista Basic logo
✧Others: Vista Premium logo
Preloaded applications5
• Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Lenovo Media Studio
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•EarthLink®
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
•Corel®WinDVD®(DVD, DVD±RW)
•CyberLink Power2Go (DVD, DVD±RW)
☞

5313-1FU 4x5 Core 2 Duo E7200 2.53 3MB 2 4GB 16-in-1 640GB2DVD±RW GMA 3100 None None Home Prem Oct 08
5313-2BU 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 500GB DVD±RW GMA 3100 None None Cam Home Prem Jul 08
5313-2CU 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 500GB Blu-ray 9300 GE None None Home Prem Jul 08
5313-2FU 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 1TB Blu-ray 9300 GE None None Home Prem Oct 08
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Core 2 Duo™Processor E7200 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q6600 with quad-core
(dual-core on dual-die), Intel 64 Technology,
Virtualization Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 8MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
256MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out, VGA connector,
DVI-I connector, HDCP-compliant
500GB, 640GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7DH
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
supports HD-DVD playback, DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
One
None
None
16-in-1 media reader, internal USB 2.0
Intel G31 Express Chipset; I/O Controller Hub 7 Digital Home (ICH7DH) for
SATA 3Gb/s, PCI Express®x1, PCI 2.3, USB, LPC bus / Winbond®W83627DHG
Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15, DVI-I in some models)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
None
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key anti-bacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K210 (5313)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced October 22, 2008; previous models on July 15, 2008
© Lenovo
(KW1-4) February 2009
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
☞
•Black and silver bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x1 Ver 1.1
Slot 2: half-length,full-height, PCI Express x16 Ver 1.1**
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
** used in some models
Cam-
era
Monitor
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo®Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
• (Select models) Healthcare eyesight protection software detect distance between user and monitor
and adjusts monitor brightness based on environment
• (Select models) Lenovo Bright Eye camera and VeriFace face recognition software help control access to
your computer by recognizing your face
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Modem
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 32
✧Vista Premium logo
Preloaded applications5
• Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Lenovo Media Studio
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•EarthLink®
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)

57092255 4x5 E5200 2.50 2MB 2 4GB 16-in-1 500GB2Blu-ray GMA 4500 None Prem 64 Basic Jan 09
57094704 4x5 E5200 2.50 2MB 2 4GB 16-in-1 640GB DVD±RW GMA 4500 L222 HD Camera None Prem 64 Basic Jan 09
57092262 4x5 Q8200 2.33 4MB 4 4GB 16-in-1 1TB Blu-ray GMA 4500 11b/g Prem 64 Basic Mar 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Dual-Core Processor E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB std, 4GB max8, PC3-8500 1066MHz DDR3,
non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available
Intel Graphics Media Accelerator 4500 (GMA 4500),
integrated graphics in G43, uses main memory, DirectX®10,
one 15-pin analog VGA DB-15 connector
500GB , 640GB, or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH10
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G43 Express Chipset (PCI Express®2.0 x16), I/O Controller Hub 10
[ICH10] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB, LPC bus),
SMSC®SCH5147-NW Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Six USB 2.0, one serial (9-pin), keyboard (PS/2), mouse (PS/2), ethernet (RJ-45),
monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, RealTek®RTL8102E
Some: 11b/g wireless4, Broadcom BCM4312, PCIe x1 adapter
None
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K220
GHz
Part
number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞ US model announced March 17, 2009; previous models on January 27, 2009
© Lenovo
(KW2-1) March 2009
Monitor
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
•Black bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 2.0
Slot 2: half-length,full-height, PCI Express x1 Ver 2.0 *
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter in slot in some models
802.11
wireless
Camera
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•Newegg®
•TigerDirect
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
Lenovo L222 Wide (HD)
• Widescreen 22-inch flat panel monitor
• Active Matrix TFT LCD screen
• Supports WUXGA 1920x1200 resolution
• High Definition (HD) ready; supports
1080p video
• 16:10 aspect ratio
• 22.0" (559mm) viewable image size
(diagonal)
• 300 nits brightness (typical)
• 1000:1 contrast ratio (typical)
• 5ms pixel response time
• Dual video input: one analog D-sub
connector and one digital DVI-D
connector
• HDCP-compliant
• Ergonomic stand tilts and swivels
• High-gloss black case
• Touch-sensitive control button
• Soundbar with speakers included
Lenovo L222 Wide (HD) Monitor is only
bundled with some models
Vista
logo

5358-4AU 4x5 E2220 2.40 1MB 2 2GB 16-in-1 250GB2Blu-ray GMA 4500 None None Prem 64 Basic Jan 09
5358-4BU 4x5 E2220 2.40 1MB 2 4GB 16-in-1 640GB Blu-ray GMA 4500 None None Prem 64 Basic Jan 09
5358-1FU 4x5 E5200 2.50 2MB 2 4GB 16-in-1 500GB DVD±RW GMA 4500 None None Prem 64 Basic Jan 09
5358-1BU 4x5 E5200 2.50 2MB 2 4GB 16-in-1 640GB DVD±RW 9300 GE None None 11b/g Prem 64 Prem Jan 09
5358-2CU 4x5 Q8200 2.33 4MB 4 4GB 16-in-1 640GB DVD±RW 9300 GE None None Prem 64 Prem Jan 09
5358-2DU 4x5 Q8200 2.33 4MB 4 4GB 16-in-1 1TB Blu-ray 9300 GE None None 11b/g Prem 64 Prem Jan 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Wireless
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Dual-Core Processor E2220 or E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus;
E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core™2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
2GB or 4GB std, 4GB max8, PC3-8500 1066MHz DDR3,
non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available;
Non-italics: standard memory in one socket; 1 socket available
Some: Intel Graphics Media Accelerator 4500 (GMA 4500),
integrated graphics in G43, uses main memory,
DirectX®10, one 15-pin analog VGA DB-15 connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
512MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out for TV-out,
VGA DB-15 connector, DVI-I connector, HDCP-compliant
250GB, 500GB, 640GB or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH10
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G43 Express Chipset (PCI Express®2.0 x16), I/O Controller Hub 10
[ICH10] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB, LPC bus),
SMSC®SCH5147-NW Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Six USB 2.0, one serial (9-pin), keyboard (PS/2), mouse (PS/2), ethernet (RJ-45),
1BU/2CU/2DU: monitor (VGA DB-15, DVI-I), S-Video out;
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
Some: 11b/g wireless4, Broadcom BCM4312, PCIe x1 adapter
10/100 ethernet on planar, Realtek®RTL8102E
None
None
None
None
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K220 (5358)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced January 13, 2009
© Lenovo
(KW2-2) March 2009
Monitor
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 2.0 **
Slot 2: half-length,full-height, PCI Express x1 Ver 2.0 *
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter in slot in some models
** used in some models
802.11
wireless
Camera
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
Vista
logo

57093697 4x5 E2220 2.40 1MB 2 5GB (2, 2, 1) 16-in-1 500GB2DVD±RW GMA 3100 None None None Prem 64 Jan 09
57093706 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 None None None Prem 64 Mar09
57093729 4x5 E7300 2.66 3MB 2 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW GMA 3100 None None None Prem 64 Jan 09
57094418 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 None None None Prem 64 Mar09
57093719 4x5 Q8200 2.33 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW GMA 3100 None None None Prem 64 Mar09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E2220 or E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus;
E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core 2 Duo™Processor E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB, 6GB, or 8GB std, 8GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, four 240-pin DIMM sockets
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G33, uses main memory,
one 15-pin analog VGA DB-15 connector
500GB , 640GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH9DH
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G33 Express Chipset (PCI Express®x16), I/O Controller Hub 9 Digital
Home [ICH9DH] (SATA 3.0Gb/s support, PCI Express x1, ethernet MAC, PCI 2.3,
USB, LPC bus), SMSC®SCH5617 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm),
SPDIF-out
High Definition (HD) audio, ADI1988 codec
None
None
Gigabit ethernet on planar, Intel 82256DC
None
None
None
None
None
None
104-key anti-bacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K230
GHz
Part
number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞ US models announced March 17, 2009; previous models on February 24, 2009
© Lenovo
(KW3-1) March 2009
☞
☞
☞
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
Cam-
era
TV
tuner
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo®Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•TigerDirect
Remote
control
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧Vista Basic logo
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)
DIMM
capacity

5359-1BU 4x5 E2220 2.40 1MB 2 5GB (2, 2, 1) 16-in-1 500GB2DVD±RW GMA 3100 Prem 64 Jan 09
5359-2EU 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-2BU 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-3EU 4x5 E7300 2.66 3MB 2 6GB (2, 2, 2) 16-in-1 1TB DVD±RW GMA 3100 11b/g Prem 64 Jan 09
5359-3AU 4x5 E7400 2.80 3MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-4CU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-4DU 4x5 Q8200 2.33 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW 9300 GE 11b/g Prem 64 Jan 09
5359-4GU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Feb 09
5359-5AU 4x5 Q9400 2.66 6MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB Blu-ray 9300 GE TV Remote 11b/g Prem 64 Jan 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E2220 or E5200
with dual-core, 800MHz system bus;
E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core™2 Duo Processor E7300 or E7400 with dual-core
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8200 or Q9400 with quad-core
(dual-core on dual-die), 1333MHz system bus;
Q8200: 4MB L2 cache; Q9400: 6MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB, 5GB, 6GB,or 8GB std, 8GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, four 240-pin DIMM sockets
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G33, uses main memory,
one 15-pin analog VGA DB-15 connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
512MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out for TV-out,
VGA DB-15 connector, DVI-I connector, HDCP-compliant
500GB, 640GB, or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH9DH
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G33 Express Chipset (PCI Express®x16), I/O Controller Hub 9 Digital
Home [ICH9DH] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB,
LPC bus), SMSC®SCH5617 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45),
4DU/5AU: monitor (VGA DB-15, DVI-I), S-Video out;
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm),
SPDIF-out
High Definition (HD) audio, ADI1988 codec
None
None
Gigabit ethernet on planar, Intel 82256GC
Some: 11b/g wireless4, Broadcom®BCM4312, PCIe x1 adapter
None
None
Some: Hybrid tuner, support analog (NTSC) and digital ( ATSC) signal ,
Hauppauge WinTV-HVR-1250,PCIe x 1
Some: Philips®Vista MCE remote control (40-button), IR receiver via USB
None
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K230 (5359)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞ US model announced February 24, 2009; previous models on January 13, 2009
© Lenovo
(KW3-2) March 2009
TV
tuner
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
•Black color bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1 **
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter or TV tuner in slot in some models
** used in some models
802.11
wireless
Remote
control
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧5359-4DU/5AU: Vista Premium logo
✧Others: Vista Basic logo
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
DIMM
capacity

5359-2HU 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 500GB2DVD±RW GMA 3100 Prem 64 Aug09
5359-3NU 4x5 E7500 2.93 3MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 11b/g Prem 64 Aug 09
5359-3JU 4x5 E7500 2.93 3MB 2 6GB (2, 2, 2) 16-in-1 500GB DVD±RW GMA 3100 Prem 64 Aug 09
5359-3LU 4x5 E7500 2.93 3MB 2 8GB (2, 2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Aug09
5359-4PU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 TV Remote 11b/g Prem 64 Aug 09
5359-4GU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Aug09
5359-4QU 4x5 Q8200 2.33 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW 9300 GE 11b/g Prem 64 Aug09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E5200 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core™2 Duo Processor E7500 with dual-core
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
6GB or 8GB std, 8GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, four 240-pin DIMM sockets
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G33, uses main memory,
one 15-pin analog VGA DB-15 connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
512MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out for TV-out,
VGA DB-15 connector, DVI-I connector, HDCP-compliant
500GB, 640GB, or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH9DH
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G33 Express Chipset (PCI Express®x16), I/O Controller Hub 9 Digital
Home [ICH9DH] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB,
LPC bus), SMSC®SCH5617 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45),
4QU: monitor (VGA DB-15, DVI-I), S-Video out;
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm),
SPDIF-out
High Definition (HD) audio, ADI1988 codec
None
None
Gigabit ethernet on planar, Intel 82256GC
Some: 11b/g wireless4, Broadcom®BCM4312, PCIe x1 adapter
None
None
Some: Hybrid tuner, support analog (NTSC) and digital ( ATSC) signal ,
Hauppauge WinTV-HVR-1250,PCIe x 1
Some: Philips®Vista MCE remote control (40-button), IR receiver via USB
None
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K230 (5359) - August 2009
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced August 19, 2009
© Lenovo
(KW3-3) August 2009
TV
tuner
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black color bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1 **
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter or TV tuner in slot in some models
** used in some models
802.11
wireless
Remote
control
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧5359-4QU: Vista Premium logo
✧Others: Vista Basic logo
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)
DIMM
capacity

Lenovo IdeaCentre K300
Lenovo IdeaCentre K300
Lenovo IdeaCentre K300
toolless disk drive removal
Lenovo IdeaCentre K300
(monitor not included)
Lenovo IdeaCentre K300
top button
Lenovo IdeaCentre K300
Power control switch

5316-1AU 4x5 Q8300 2.50 4MB 4 6GB (2, 2, 2) 16-in-1 640GB2DVD±RW GMA X4500 Prem 64 Oct 09
5316-1BU 4x5 Q8300 2.50 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW HD4350 TV Remote 11b/g11 Prem 64 Oct 09
5316-1GU 4x5 Q8300 2.50 4MB 4 6GB (2, 2, 2) 16-in-1 640GB Blu-ray HD4650 Prem 64 Oct 09
5316-1CU 4x5 Q8300 2.50 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW HD4650 11b/g Prem 64 Oct 09
5316-2AU 4x5 E5300 2.60 2MB 2 3GB (1, 2) 16-in-1 320GB DVD±RW GMA X4500 Prem 64 Oct 09
5316-2CU 4x5 E7500 2.93 3MB 2 4GB (2, 2) 16-in-1 640GB DVD±RW GMA X4500 Prem 64 Oct 09
5316-1EU 4x5 Q8300 2.50 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW HD4650 TV Remote Prem 64 Oct 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Wireless
Ethernet
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E5300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo™Processor E7500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8300 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
3GB, 4GB, 6GB, or 8GB std, 8GB max8, dual-channel capable,
PC3-8500 1066MHz DDR3, non-parity, four 240-pin DIMM sockets
Some: Intel Graphics Media Accelerator X4500 (GMA X4500),
integrated graphics in G43, uses main memory,
DirectX®10, one 15-pin analog VGA DB-15 connector
Some: ATI™Radeon™ HD 4350, PCI Express®x16,
512MB memory, DirectX®10, ATI Avivo™ HD,
VGA, DVI-I, HDCP-compliant
Some: ATI™Radeon™ HD 4650, PCI Express®x16,
1GB memory, DirectX®10, ATI Avivo™ HD,
VGA, HDMI, DisplayPort, HDCP-compliant
320GB, 640GB,or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH10R, RAID 0 support
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), five SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G43 Express Chipset (PCI Express®2.0 x16), I/O Controller Hub 10 RAID
[ICH10R] (SATA 3.0Gb/s with RAID 0 support, PCI Express x1, ethernet MAC,
PCI 2.3, USB, LPC bus), SMSC®SCH5147-NW Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Six USB 2.0, one serial (9-pin), keyboard (PS/2), mouse (PS/2), ethernet (RJ-45),
HD 4650 models: monitor (VGA DB-15, HDMI, DisplayPort)
HD 4350 models: monitor (VGA DB-15, DVI-I)
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
Some: 11b/g wireless4, Broadcom BCM4312, PCIe x1 adapter
10/100 ethernet on planar, Realtek®RTL8102E
None
None
Some: Hybrid tuner, support analog (NTSC) and digital ( ATSC) signal ,,PCIe x 1
Some: Philips®Win7 MCE remote control (40-button), IR receiver via USB
None
Full-size keyboard (PS/2 connector), Fn keys, black
Optical Wheel Mouse (USB connector), 1000 dpi, black
280 watts, universal, manual switch
IdeaCentre™K300 (5316) - Windows 7
GHz
Type-model
Pro-
cessor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced October 22, 2009
© Lenovo
(TNA1-1) October 2009
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black bezel
• 7.09" W X 17.32" D X 15.35" H
• 180mm W X 440mm D X 390mm H
•24.6 lb (11.2 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 2.0 **
Slot 2: half-length,full-height, PCI Express x1 Ver 2.0 *
Slot 3: half-length,full-height, PCI Express x1 Ver 2.0
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter in slot in some models
** Graphics adapter in slot in some models
802.11
wireless
Remote
control
•Power control switch on front to adjust power and energy for three modes (cool, auto, and turbo)
• Lenovo Rescue System provides OneKey recovery without booting into Windows
Win 7
preload
Preloaded operating system20
- Genuine Windows®7
Home Premium 64
Preloaded applications5(only some listed)
• Lenovo®OneKey Recovery
• Driver and Application Installation
• McAfee VirusScan®Plus
(30 days of virus defi nitions)
•Lenovo Power Dial
•Lenovo Healthcare Software
•Corel®WinDVD®(Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
TV
tuner
DIMM
capacity

Lenovo IdeaCentre A600
(Remote control and wireless
keyboard/mouse on select models)
Lenovo IdeaCentre A600
(Remote control and wireless
keyboard/mouse on select models)
Lenovo IdeaCentre A600
Lenovo IdeaCentre A600
Lenovo IdeaCentre A600
Lenovo IdeaCentre A600

Intel®Pentium®processor T4200 with dual-core,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo processor T6400 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo processor P7450 with dual-core,
Intel HD Boost, 1066MHz system bus, and 3MB L2 cache
2GB, 3GB, or 4GB std / 4GB max7 / PC3-8500 1066MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets;
Italics: standard memory in both sockets; no sockets available
Non-italics: standard memory in one socket; one socket available
Some: DVD burner, dual-layer support, fixed, not removable, 12.7mm, slot-in
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM, no HD-DVD
playback, DVD recordable, not removable, 12.7mm high, slot-in
320GB, 500GB, 640GB, or 1TB, SATA 3.0Gb/s, 3.5" wide, 7200 rpm
21.5" (546.1mm) WUXGA (1920x1080) TFT color,VibrantView (glossy),
CCFL backlight, 300 nits, 16:9 aspect ratio, 1000:1 contrast ratio, frameless screen
Some: camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Some: camera on top of screen, 2.0-megapixel, fixed focus,
with dual array microphone
Touch-sensitive buttons for brightness, display on/off, and optical disk drive eject
Some: Intel Graphics Media Accelerator 4500MHD (GMA 4500MHD),
integrated graphics in GM45, uses main memory, DirectX®10
Some: ATI™ Mobility Radeon™ HD 3650, PCI Express®x16, 512MB memory,
DirectX®10, ATI Avivo™ HD
Mobile Intel GM45 Express Chipset (Graphics Memory Controller Hub),
ICH9M I/O Controller Hub (SATA 3.0Gb/s, USB 2.0, PCI Express 1.1, PCI 2.3,
ethernet MAC)
6-in-1 reader (MultiMedia Card, Memory Stick, Memory Stick PRO ™ ,
Secure Digital Card, Secure Digital Elite Pro Card, xD-Picture Card ™ )
Rear: Four USB 2.0, ethernet (RJ-45), TV antenna connector on some models;
Left: Two USB 2.0, IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Two Mini PCI Express slots
Some: 11a/b/g/n wireless
4,
Mini PCIe adapter, Intel WiFi Link 5100, 1x2 (Shirley Peak)
Some: 11b/g wireless4, Mini PCIe adapter, Broadcom®BCM4312
Some: AverMedia®Hybrid tuner, support analog and digital signal, Mini PCIe adapter
Some: Bluetooth 2.1 wireless + EDR, USB 2.0 interface via ICH9M, LED indicator
None
Gigabit ethernet on planar, Broadcom BCM5784
High Definition (HD) Audio, RealTek®ALC272 codec /
two speakers (3 watt) and subwoofer (8 watt), Dolby Home Theater Speaker System /
mono microphone or dual array microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Power-on password, hard disk password, supervisor password
Some: Wireless RF 2.4 GHz keyboard with touch pad, 6-row, 84-key,
touch-sensitive multimedia keys and shortcut keys
Some: USB full-size keyboard with USB hub (two USB ports)
Some: Wireless RF 2.4 GHz Laser Wheel Mouse, 800/1600 dpi (user switchable)
Some: USB Optical Wheel Mouse
Some: Vista MCE remote control (40-button), via IR
Some: 4-in-1 remote control, via bluetooth, acts as motion game controller (requires
games* support), VOIP headset, Vista MCE remote control, and air mouse
* Motion games CD included in 4-in-1 remote control models (requires installation)
(WxHxD): 20.47" x 18.22" x 1.06" to 2.36"; 520mm x 463mm x 27 to 60mm
27.7 lb (12.6 kg)
Black color, ABS plastic
Tilt stand (15° back, 5° forward)
Processor
Memory
S ATA DV D ±RW
SATA Blu-ray™
SATA disk
Widescreen
display
Camera
Controls
Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
Intel 510028
11b/g28
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
IdeaCentre™A600 (3011)
Some: 130-watt (GMA graphics) AC
adapter
Some: 150-watt (ATI graphics) AC
adapter
RoHS-compliant
3011-2AU T4200 2.00 2GB 21.5" WUXGA 1.3 GMA 320GB8DVD±RW 11b/g28 Mono USB Prem 64 Apr 09
3011-2BU T4200 2.00 3GB 21.5" WUXGA 1.3 GMA 500GB DVD±RW Intel 5100 Mono USB Prem 64 Apr 09
3011-2CU T4200 2.00 4GB 21.5" WUXGA 1.3 GMA 640GB DVD±RW Intel 5100 Mono USB Prem 64 Apr 09
3011-3AU T6400 2.00 3GB 21.5" WUXGA 1.3 GMA 640GB DVD±RW ✶ Intel 5100 Mono USB Prem 64 Apr 09
3011-3CU T6400 2.00 4GB 21.5" WUXGA 2.0 HD 3650 1TB DVD±RW ✶ Intel 5100 TV Remote Array Blue Wireless Prem 64 Apr 09
3011-4AU P7450 2.13 4GB 21.5" WUXGA 2.0 HD 3650 1TB BD player ✣Intel 5100 Array Blue USB Prem 64 Apr 09
3011-4BU P7450 2.13 4GB 21.5" WUXGA 2.0 HD 3650 1TB BD player ✣Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Apr 09
3011-3DU T6400 2.00 3GB 21.5" WUXGA 1.3 GMA 500GB DVD±RW ✶ Intel 5100 Mono Wireless Prem 32 Apr 09
3011-3HU T6400 2.00 4GB 21.5" WUXGA 2.0 HD 3650 640GB DVD±RW ✶ Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Apr 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Vista
preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(BL1-1) April 2009
See footnotes for important warranty information ✶Intel Centrino®processor technology
☞US models announced April 22, 2009; ✣Intel Centrino 2 processor technology
previous models on April 07, 2009
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Premium 32
- Some: Genuine Windows Vista
Home Premium 64
✧Vista Premium logo
Preloaded applications14
•Lenovo®OneKey Recovery
•Driver and Application Installation
•Lenovo Recovery Disk Maker
•Lenovo Healthcare Software
•VeriFace™
•Media Show
•Trend Micro™ PC-cillin™ Internet
Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Cyberlink Power2Go (DVD±RW,
BD player)
•Corel®WinDVD®(BD player)
•All-In-One design with 21.5" Full HD 16:9 widescreen, glossy display
•(Seleted models) Integrated TV tuner
•(Seleted models) 4-in-1 remote control acts as a motion game controller (requires
game support), VOIP handset, Vista Media Center remote and air mouse
• Integrated camera and Lenovo's VeriFace face recognition software helps control
access to your notebook by recognizing your face
•Dolby®Home Theater™premium audio system with two speakers and one subwoofer
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without
booting into Windows
Graphics
KBD/
Mouse
TV
tuner
Proc-
essor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Available at these retailers
•lenovo.com
•Fry's
Remote
control
Camera
(mega-
pixel)
Micro-
phone
Blue-
tooth
☞
☞

Intel®Core™2 Duo processor T6500 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo processor P7350 with dual-core,
Intel HD Boost, 1066MHz system bus, and 3MB L2 cache
4GB std / 4GB max7 / PC3-8500 1066MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets;
Italics: standard memory in both sockets; no sockets available
Some: DVD burner, dual-layer support, fixed, not removable, 12.7mm, slot-in
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM, no HD-DVD
playback, DVD recordable, not removable, 12.7mm high, slot-in
500GB, 640GB, or 1TB, SATA 3.0Gb/s, 3.5" wide, 7200 rpm
21.5" (546.1mm) WUXGA (1920x1080) TFT color,VibrantView (glossy),
CCFL backlight, 300 nits, 16:9 aspect ratio, 1000:1 contrast ratio, frameless screen
Some: camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Some: camera on top of screen, 2.0-megapixel, fixed focus,
with dual array microphone
Touch-sensitive buttons for brightness, display on/off, and optical disk drive eject
Some: Intel Graphics Media Accelerator 4500MHD (GMA 4500MHD),
integrated graphics in GM45, uses main memory, DirectX®10
Some: ATI™ Mobility Radeon™ HD 4650, PCI Express®x16, 512MB memory,
DirectX®10, ATI Avivo™ HD
Mobile Intel GM45 Express Chipset (Graphics Memory Controller Hub),
ICH9M I/O Controller Hub (SATA 3.0Gb/s, USB 2.0, PCI Express 1.1, PCI 2.3,
ethernet MAC)
6-in-1 reader (MultiMedia Card, Memory Stick, Memory Stick PRO ™ ,
Secure Digital Card, Secure Digital Elite Pro Card, xD-Picture Card ™ )
Rear: Four USB 2.0, ethernet (RJ-45), TV antenna connector on some models;
Left: Two USB 2.0, IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Two Mini PCI Express slots
11a/b/g/n wireless
4,
Mini PCIe adapter, Intel WiFi Link 5100, 1x2 (Shirley Peak)
Some: AverMedia®Hybrid tuner, support analog and digital signal, Mini PCIe adapter
Some: Bluetooth 2.1 wireless + EDR, USB 2.0 interface via ICH9M, LED indicator
None
Gigabit ethernet on planar, Broadcom BCM5784
High Definition (HD) Audio, RealTek®ALC272 codec /
two speakers (3 watt) and subwoofer (8 watt), Dolby Home Theater Speaker System /
mono microphone or dual array microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Power-on password, hard disk password, supervisor password
Some: Wireless RF 2.4 GHz keyboard with touch pad, 6-row, 84-key,
touch-sensitive multimedia keys and shortcut keys
Some: USB full-size keyboard with USB hub (two USB ports)
Some: Wireless RF 2.4 GHz Laser Wheel Mouse, 800/1600 dpi (user switchable)
Some: USB Optical Wheel Mouse
Some: MCE remote control (40-button), via IR
Some: 4-in-1 remote control, via bluetooth, acts as motion game controller (requires
games* support), VOIP headset, Vista MCE remote control, and air mouse
* Motion games CD included in 4-in-1 remote control models (requires installation)
(WxHxD): 20.47" x 18.22" x 1.06" to 2.36"; 520mm x 463mm x 27 to 60mm
27.7 lb (12.6 kg)
Black color, ABS plastic
Tilt stand (15° back, 5° forward)
Processor
Memory
S ATA DV D ±RW
SATA Blu-ray™
SATA disk
Widescreen
display
Camera
Controls
Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
Intel 510028
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
IdeaCentre™A600 (3011) - September 2009
Some: 130-watt (GMA graphics) AC
adapter
Some: 150-watt (ATI graphics) AC
adapter
RoHS-compliant
3011-3LU T6500 2.10 4GB 21.5" WUXGA 1.3 GMA 640GB8DVD±RW ✶ Intel 510028 Mono USB Prem 64 Sep 09
3011-3RU T6500 2.10 4GB 21.5" WUXGA 2.0 HD 4650 500GB DVD±RW ✶ Intel 5100 TV Remote Array Blue USB Prem 64 Sep 09
3011-3UU T6500 2.10 4GB 21.5" WUXGA 2.0 HD 4650 640GB DVD±RW ✶ Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Sep 09
3011-4EU P7350 2.00 4GB 21.5" WUXGA 2.0 HD 4650 1TB BD player ✣Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Sep 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Vista
preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(BL1-2) September 2009
See footnotes for important warranty information ✶Intel Centrino®processor technology
US models announced September 10, 2009 ✣Intel Centrino 2 processor technology
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧Vista Premium logo
Preloaded applications14
•Lenovo®OneKey Recovery
•Driver and Application Installation
•Lenovo Recovery Disk Maker
•Lenovo Healthcare Software
•VeriFace™
•Media Show
•Trend Micro™ PC-cillin™ Internet
Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Cyberlink Power2Go (DVD±RW,
BD player)
•Corel®WinDVD®(BD player)
•All-In-One design with 21.5" Full HD 16:9 widescreen, glossy display
•(Seleted models) Integrated TV tuner
•(Seleted models) 4-in-1 remote control acts as a motion game controller (requires
game support), VOIP handset, Vista Media Center remote and air mouse
• Integrated camera and Lenovo's VeriFace face recognition software helps control
access to your notebook by recognizing your face
•Dolby®Home Theater™premium audio system with two speakers and one subwoofer
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without
booting into Windows
Graphics
KBD/
Mouse
TV
tuner
Proc-
essor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Available at these retailers
•lenovo.com
Remote
control
Camera
(mega-
pixel)
Micro-
phone
Blue-
tooth

Intel®Pentium®Processor T4300 with dual-core,
800MHz system bus, and 1MB L2 cache or
Intel Core™2 Duo processor T6600 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo processor P7550 with dual-core,
Intel HD Boost, 1066MHz system bus, and 3MB L2 cache
2GB, 3GB, or 4GB std / 4GB max7 / PC3-8500 1066MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets;
Non-italics: standard memory in one socket; one socket available
Italics: standard memory in both sockets; no sockets available
Some: DVD burner, dual-layer support, fixed, not removable, 12.7mm, slot-in
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM, no HD-DVD
playback, DVD recordable, not removable, 12.7mm high, slot-in
320GB, 500GB, 640GB, or 1TB, SATA 3.0Gb/s, 3.5" wide, 7200 rpm
21.5" (546.1mm) WUXGA (1920x1080) TFT color,VibrantView (glossy),
CCFL backlight, 300 nits, 16:9 aspect ratio, 1000:1 contrast ratio, frameless screen
Some: camera on top of screen, 1.3-megapixel, fixed focus, with mono microphone
Some: camera on top of screen, 2.0-megapixel, fixed focus,
with dual array microphone
Touch-sensitive buttons for brightness, display on/off, and optical disk drive eject
Some: Intel Graphics Media Accelerator 4500MHD (GMA 4500MHD),
integrated graphics in GM45, uses main memory, DirectX®10
Some: ATI™ Mobility Radeon™ HD 4650, PCI Express®x16, 512MB memory,
DirectX®10, ATI Avivo™ HD
Mobile Intel GM45 Express Chipset (Graphics Memory Controller Hub),
ICH9M I/O Controller Hub (SATA 3.0Gb/s, USB 2.0, PCI Express 1.1, PCI 2.3,
ethernet MAC)
6-in-1 reader (MultiMedia Card, Memory Stick, Memory Stick PRO ™ ,
Secure Digital Card, Secure Digital Elite Pro Card, xD-Picture Card ™ )
Rear: Four USB 2.0, ethernet (RJ-45), TV antenna connector on some models;
Left: Two USB 2.0, IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Two Mini PCI Express slots
Some: 11a/b/g/n wireless
4,
Mini PCIe adapter, Intel WiFi Link 5100, 1x2 (Shirley Peak)
Some: 11b/g wireless4, Mini PCIe adapter, Broadcom®BCM4312
Some: AverMedia®Hybrid tuner, support analog and digital signal, Mini PCIe adapter
Some: Bluetooth 2.1 wireless + EDR, USB 2.0 interface via ICH9M, LED indicator
None
Gigabit ethernet on planar, Broadcom BCM5784
High Definition (HD) Audio, RealTek®ALC272 codec /
two speakers (3 watt) and subwoofer (8 watt), Dolby Home Theater Speaker System /
mono microphone or dual array microphone, microphone input jack (3.5 mm),
headphone jack (3.5 mm)
Power-on password, hard disk password, supervisor password
Some: Wireless RF 2.4 GHz keyboard with touch pad, 6-row, 84-key,
touch-sensitive multimedia keys and shortcut keys
Some: USB full-size keyboard with USB hub (two USB ports)
Some: Wireless RF 2.4 GHz Laser Wheel Mouse, 800/1600 dpi (user switchable)
Some: USB Optical Wheel Mouse
Some: V MCE remote control (40-button), via IR
Some: 4-in-1 remote control, via bluetooth, acts as motion game controller (requires
games support), VOIP headset, MCE remote control, and air mouse
(WxHxD): 20.47" x 18.22" x 1.06" to 2.36"; 520mm x 463mm x 27 to 60mm
27.7 lb (12.6 kg)
Black color, ABS plastic
Tilt stand (15° back, 5° forward)
Processor
Memory
S ATA DV D ±RW
SATA Blu-ray™
SATA disk
Widescreen
display
Camera
Controls
Graphics
Chipset
Multicard reader
Ports
Mini PCI Express
Intel 510028
11b/g11
TV tuner
Bluetooth™
Modem
Ethernet
Audio support
Security
Keyboard
Mouse
Remote control
Dimensions3
Weight
2
Chassis
Stand
IdeaCentre™A600 (3011) - Windows 7
Some: 130-watt (GMA graphics) AC
adapter
Some: 150-watt (ATI graphics) AC
adapter
RoHS-compliant
3011-6CU T4300 2.10 2GB 21.5" WUXGA 1.3 GMA 320GB8DVD±RW Intel 510028 Mono USB Prem 64 Oct 09
3011-6DU T4300 2.10 4GB 21.5" WUXGA 2.0 HD 4650 320GB DVD±RW 11b/g TV Array Blue USB Prem 64 Oct 09
3011-CGU T6600 2.20 4GB 21.5" WUXGA 2.0 HD 4650 640GB DVD±RW ✶Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Oct 09
3011-CJU T6600 2.20 3GB 21.5" WUXGA 2.0 HD 4650 500GB DVD±RW ✶Intel 5100 TV Remote Array Blue USB Prem 64 Oct 09
3011-CKU T6600 2.20 4GB 21.5" WUXGA 2.0 HD 4650 500GB DVD±RW ✶Intel 5100 TV Remote Array Blue Wireless Prem 64 Oct 09
3011-4LU P7550 2.26 4GB 21.5" WUXGA 2.0 HD 4650 1TB BD player ✣Intel 5100 TV 4-in-1 Array Blue Wireless Prem 64 Oct 09
Type-model GHz
Widescreen
displayMemory
SATA
disk
SATA
optical
Mini PCIe
802.11
wireless Win7
preload
Avail
date
Personal Systems Reference (PSREF)
© Lenovo
(BL1-3) October 2009
See footnotes for important warranty information ✶Intel Centrino®processor technology
US models announced October 23, 2009 ✣Intel Centrino 2 processor technology
Preloaded operating system20
- Genuine Windows®7
Home Premium 64
Preloaded applications14 (only some
listed)
•Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Media Show
•McAfee VirusScan®Plus 2009
(30 days of virus definitions)
•Cyberlink Power2Go (DVD±RW,
BD player)
•Corel®WinDVD®(BD player)
•All-In-One design with 21.5" Full HD 16:9 widescreen, glossy display
•(Seleted models) Integrated TV tuner
•(Seleted models) 4-in-1 remote control acts as a motion game controller (requires
game support), VOIP handset, Vista Media Center remote and air mouse
•Dolby®Home Theater™premium audio system with two speakers and one subwoofer
• Lenovo Rescue System provides OneKey recovery without booting into Windows
Graphics
KBD/
Mouse
TV
tuner
Proc-
essor
Limited Warranty12
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite
service for selected parts3,
8 am - 5 pm, Mon - Fri coverage
excluding holidays, next business
day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Remote
control
Camera
(mega-
pixel)
Micro-
phone
Blue-
tooth

Lenovo IdeaCentre Q100
Lenovo IdeaCentre Q100
Lenovo IdeaCentre Q100
(Monitor is not included)
Lenovo IdeaCentre Q100
Lenovo IdeaCentre Q100
Lenovo IdeaCentre Q100

3014-1CU Atom 230 1.60 512KB 1GB None 160GB2None Mirage 3+ None None None Black None XP Home Sep 09
3014-1BU Atom 230 1.60 512KB 1GB None 160GB None Mirage 3+ None None None Black None XP Home Sep 09
Processor
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
Media reader
Chipset
Front ports
Rear ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
11b/g28
TV tuner
Remote control
Camera
Keyboard
Mouse
Stand
Mount bracket
Intel®Atom™processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache
1GB std, 2GB max8, PC2-5300 667MHz DDR2,
non-parity, single-channel capable, one 200-pin SO-DIMM socket;
standard memory in socket; no sockets available
SiS®Mirage™3+ Graphics Engine, integrated graphics in SiS672,
uses main memory, one VGA DB-15 connector
160GB, SATA 3.0Gb/s, 2.5" wide, 5400 rpm
Serial ATA, SATA 3.0Gb/s, integrated in SiS968
None
None
SiS672 Northbridge /
SiS968 Southbridge (SATA 3.0Gb/s, ethernet MAC, USB)
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, ethernet (RJ-45), monitor (VGA DB-15), line-out (stereo, 3.5mm)
High Definition (HD) audio, RealTek®ALC662 codec
None
None
Gigabit ethernet on planar, Realtek®RLT8111DL
None
None
None
None
None
None
None
None
None
Detachable stand (matching color with chassis)
None
IdeaCentre™Q100 (3014)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Personal Systems Reference (PSREF)
Tiny Desktop (0.5L)
L2
cache
See footnotes for important warranty information
US models announced September 15, 2009
© Lenovo
(NR1-1) October 2009
TV
tuner
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
often next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair 9x5
often Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
•Black color
• 6.01" W X 0.8" D X 6.8" H
• 153mm W X 20mm D X 172mm H
•1.67 lb (0.76kg) include stand
•No bays, no slots
802.11
wireless
Remote
control
• IdeaCentre Q series provide ultimate multimedia experience for home entertainment
• An Ultra-slim and fashionable desktop PC (only 0.5L)
• Super powersaving, saving up to 90% power compared to traditional desktop
• Ultra quiet with low power platform
• Basic one key system recovery function
Preload
65-watt AC adapter
RoHS-compliant
Blue-
toothColor
Preloaded operating system20
- Genuine Windows®XP Home Edition
Preloaded applications14 (only some
listed)
•Recovery wizard
•Driver and Application Installation
•Trend Micro™PC-cillin™Internet
Security 2008

3016-1BU Atom 230 1.60 512KB 2GB None 160GB2None NVIDIA ION None None None Black None Prem 32 Sep 09
Processor
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
Media reader
Chipset
Front ports
Rear ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
11b/g28
TV tuner
Remote control
Camera
Keyboard
Mouse
Stand
Mount Bracket
Intel®Atom™processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache
2GB std, 3GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, one 200-pin SO-DIMM socket;
Italics: standard memory 1GB soldered to systemboard,
1GB in socket; no sockets available
NVIDIA®ION™graphics processor, DirectX 10,
PureVideo®HD technology, Full HD decode (1080i/p)
uses main memory, one HDMI connector, HDCP-compliant
160GB, SATA 3.0Gb/s, 2.5" wide, 5400 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ION graphics processor
None
None
NVIDIA®ION chipset (MCP7A-ION), integrates all features of a modern chipset's
North and South bridges into a single chip package
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm),
Four USB 2.0, ethernet (RJ-45), monitor (HDMI), line-out (stereo, 3.5mm)
High Definition (HD) audio, RealTek®ALC662 codec
None
None
Gigabit ethernet on planar, Realtek®RLT8111DL
None
None
None
None
None
None
None
None
None
Detachable stand (matching color with chassis)
Mount bracket (black), meets the VESA 75mm and 100mm mount standard
IdeaCentre™Q110 (3016)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Personal Systems Reference (PSREF)
Tiny Desktop (0.5L)
L2
cache
See footnotes for important warranty information
US model announced September 15, 2009
© Lenovo
(NR1-2) October 2009
TV
tuner
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
often next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair 9x5
often Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
•Black color
• 6.01" W X 0.8" D X 6.8" H
• 153mm W X 20mm D X 172mm H
•1.67 lb (0.76kg) include stand
•No bays, no slots
802.11
wireless
Remote
control
• IdeaCentre Q series provide ultimate multimedia experience for home entertainment
• An Ultra-slim and fashionable desktop PC (only 0.5L)
• Attaches to the back of selected VESA-compatible monitor for more space saving
• Super powersaving, saving up to 90% power compared to traditional desktop
• Ultra quiet with low power platform
• Support 1080p full HD multimedia playback and 3D gaming
• Basic one key system recovery function
Vista
preload
65-watt AC adapter
RoHS-compliant
Blue-
toothColor
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 32
Preloaded applications14 (only some
listed)
•Recovery wizard
•Driver and Application Installation
•Trend Micro™PC-cillin™Internet
Security 2008
•CyberLink PowerDVD

Lenovo IdeaCentre Q700
Lenovo IdeaCentre Q700
Lenovo IdeaCentre Q700
(TV IN and AV IN on some models)
Lenovo IdeaCentre Q700
Lenovo IdeaCentre Q700
(TV IN and AV IN on some models)
Lenovo IdeaCentre Q700
