Lenovo IdeaCentre K210 5313 User manual

www.lenovo.com
Version 1.1 2008.2
WORLDWIDE PARTNER
IdeaCentre K User Guide
31033098
31033098_UG_FM_EN_V1.1.indd 1 2008.2.20 4:33:10 PM

Danger: Watch out for high risks
Caution: Watch out for medium risks
Attention: Pay attention to low risks
Prohibition: Dangerous operations
Recommendation: Helpful tips
Key to signs used in this manual
31033098_IdeaCentre K UG_EN.indd 1 2008.2.20 6:40:32 PM

Note
Before using this information and the product it supports, be
sure to read the Safety and Warranty Guide that came with this
product .
© Copyright Lenovo 2007, 2008. All rights reserved.
31033098_IdeaCentre K UG_EN.indd 2 2008.2.20 6:40:32 PM

1
Contents
Contents
Key to signs used in this manual
Chapter 1 Instructions for using computer hardware ........... 1
1.1 Front view of the Chassis .........................................................2
1.2 Rear view of the chassis ..........................................................3
1.3 Speaker (some models equipped with Speaker) ......................6
1.4 Notes on computer cabling and installation .............................7
1.5 Keyboard .................................................................................8
Chapter 2 Rescue System Operation Instruction .................. 9
2.1 Installing Drivers and Software Shipped with Computer .........10
2.2 OneKey Recovery .................................................................11
2.3 File Management ..................................................................15
2.4 OneKey Antivirus ...................................................................16
Chapter 3 Using the software ................................................ 19
3.1 Power2Go — Burning Discs ..................................................20
3.2 WinDVD ................................................................................21
3.3 Lenovo Healthcare Software ..................................................22
3.4 PC-cillin .................................................................................25
3.5 Lenovo Media Studio .............................................................26
3.6 Veriface ..................................................................................27
3.7 Earth link (Only for United States ) .........................................28
Chapter 4 System maintenance and recovery ..................... 29
4.1 Restoring the system .............................................................30
4.2 Cleaning up the disk ..............................................................30
4.3 Checking for, and correcting disk errors .................................31
4.4 Defragmenting the disk(s) ......................................................31
4.5 Performing daily maintenance tasks .......................................31
31033098_IdeaCentre K UG_EN.indd 1 2008.2.20 6:40:32 PM

2Contents
Chapter 5 Troubleshooting and Confirming Setup .............. 33
5.1 Troubleshooting display problems ..........................................34
5.2 Troubleshooting audio problems ............................................34
5.3 Troubleshooting software problems .......................................35
5.4 Troubleshooting problems with optical drives and hard
disks .....................................................................................36
31033098_IdeaCentre K UG_EN.indd 2 2008.2.20 6:40:32 PM

1
2
3
4
5
Chapter
Instructions for using computer
hardware
This chapter is organized under
the following topics:
ÿ Front view of the chassis (Instruction for the use
of buttons and functional keys on the front panel
of the chassis)
ÿ Rear view of the chassis (Instruction for the
use of all I/O interfaces on the rear panel of the
chassis)
ÿ Connection of the speakers
ÿ Notes on computer cabling and installation
ÿ Keyboard
These topics describe some of the operations
commonly performed during routine use of the
computer, including the proper connection of
components. Please read it carefully.
Note: The configuration of your computer
model may vary slightly from the illustrations
used in this document.
User Guide 1
31033098_IdeaCentre K UG_EN.indd 1 2008.2.20 6:40:02 PM

2User Guide
1.1 Front view of the Chassis
Instructions for the use of buttons and functional keys that are
located at the front of the computer.
F-1
D-1
MS/Pro/Duo/Pro Duo
CF/I/II/MD
xD
SD/Mini/HC/Min iHC MMC/RS/Plus/Mo b
D-2
D-3
D-4
D-2
F-1 Top Mounted Buttons: Including power switch.
[1-1] Power switch: Press
this button to turn the
computer on or off, or,
if the Power Option in
the Control Panel has
been set to allow it, to
hibernate or wake up
the computer.
[1-2] Hard Disk Drive
Indicator: Indicates the
read/write operations of
the hard disk.
[1-1]
[1-2]
31033098_IdeaCentre K UG_EN.indd 2 2008.2.20 6:40:02 PM

3
User Guide
D-1 Memory card reader Connector: Able to read/write data from Memory Stick
/Memory Stick Pro/ Memory Stick Duo /Memory Stick Pro Due
xD
SD/Mini SD/SD High Capacity /Mini SD High Capacity/ MMC/ RS-MMC/MMC
plus/MMC mobile
CF I/CF II/ MD.
D-2 USB Connectors: To connect USB devices.
D-3 Microphone Connector: To connect the microphone and pass the
microphone audio input to the computer.
D-4 Speakers/Headphones Connector: To connect speakers or headphones. If it
is necessary to connect the headphones, remove the speaker plug and insert
the headphones plug.
1.2 Rear view of the chassis
Instructions for the use of all I/O interfaces on the rear panel of the
computer.
The following illustrations show connections located at the rear of some computer
models. The locations of connectors on your computer will be similar to, but
possibly not identical to these. Following the illustrations is a key that explains the
symbol callouts used in the figures.
31033098_IdeaCentre K UG_EN.indd 3 2008.2.20 6:40:03 PM

4User Guide
X-1
X-2
DVI
Key to symbols used in the above illustrations of the rear of the
chassis:
——— Power Connector: To supply power to the computer.
———— PS/2 Mouse Connector: To connect a mouse having a PS/2
connector.
—— PS/2 Keyboard Connector: To connect a keyboard having a PS/2
connector.
—— Serial Connector: To connect devices requiring a serial connection
(COM Connector ).
——— Parallel Connector: To connect devices requiring a parallel
31033098_IdeaCentre K UG_EN.indd 4 2008.2.20 6:40:05 PM

5
User Guide
connection.
X-1 —— On-board VGA Card Connector: To connect with the signal cable
of a monitor. On computer models that have an external graphics
card, on-board graphics card signals are shielded and there are
no VGA signal outputs. (some models are equipped with this
connector.)
——— USB Connector: To connect USB devices.
—— Ethernet Connector: To connect LAN or broadband network
devices.
X-2 —— External VGA Card Connector: To connect with the signal cable
of a monitor. It connects with the data cable of the monitor. (Some
models are equipped with this connector.)
DVI —— External DVI Card Connector: To connect to the data cable of the
DVI connector. (Some models are equipped with this connector)
S-1 —— S Video Connector: To connect the data cable of the S video. (Some
models are equipped with this connector.)
——— Chassis Side Lock: After installing the side panel of the chassis,
push the lock upward to lock the side panel in place. To remove the
side panel, depress the lock first.
——— Audio Line-in Connector: To connect audio input to the computer.
— Audio Line-out Connector: To connect to the speakers or
headphones.
———— Microphone Jack: To connect to audio input from a microphone.
———— Used to attach your computer to a telephone line for modem use.
(some models equipped with this connector)
——— Used to attach a telephone line to your computer. (some models
equipped with this connector)
31033098_IdeaCentre K UG_EN.indd 5 2008.2.20 6:40:07 PM

6User Guide
—— Voltage: selection switch (Some models are equipped with this
switch)
Check the position of the voltage-selection switch on the rear of the computer. Use
a ballpoint pen to slide the switch, if necessary.
1. If the voltage supply range is 100-127 V ac, set the switch to 115 V.
2. If the voltage supply range is 200-240 V ac, set the switch to 230 V.
115
230
Figure 1 Figure 2
1.3 Speaker (some models equipped with Speaker)
[Y-3]
[Y-1]
[Y-2]
[Y-4]
[Y-5]
[Y-6]
Side elevation Back elevation
Y-1 Volume Adjusting Knob Y-4 Speaker Power Switch
Y-2 Bass Adjusting Knob Y-5 Speaker DC IN
31033098_IdeaCentre K UG_EN.indd 6 2008.2.20 6:40:08 PM

7
User Guide
Y-3 Connect to computer Audio-out Y-6 Primary and secondary speaker
cables
1.4 Notes on computer cabling and installation
C-1
C-3
C-2
C-1 Monitor power cord C-2 Monitor data cable
C-3 Speaker audio signal cable
1. Connect the monitor signal cable to the on-board graphics card connector if the
model you purchased is not equipped with an external graphics card.
2. If there is an external graphics card, connect the monitor signal cable to the
VGA or DVI connector in the external graphics card.
3. If both your computer and monitor have the DVI connector, you can connect the
computer to the monitor through your own DVI data cable.
4. If there is only DVI connector in the external graphics card and the monitor only
have the VGA connector, connect the monitor data cable and DVI connector by
the DVI-VGA converter.
Notes:
• Keep speakers away from the monitor to avoid magnetic interference.
• Ensure the monitor-to-computer cable connections are secure, with screws
tightened.
31033098_IdeaCentre K UG_EN.indd 7 2008.2.20 6:40:09 PM

8User Guide
• Connect the monitor signal cable to the on-board graphics card connector if
the model you purchased is not equipped with an external graphics card.
1.5 Keyboard
[B-1]
[B-2]
(This picture is only a sketch map for the keyboard, it does not show the detail of
the key)
[B-1] — Press this key under Windows system to launch the IE.
[B-2] — LVT key, available for models with the “Rescue System” feature. Press
this key to launch “Rescue System” when the “Lenovo” screen appears
during booting.
31033098_IdeaCentre K UG_EN.indd 8 2008.2.20 6:40:11 PM

1
2
3
4
5
Chapter
Rescue System Operation
Instruction
The following topics will be
introduced in this chapter:
ÿ Installing Drivers and Software
ÿ OneKey Recovery
ÿ File Management
ÿ OneKey Antivirus
You can recover drive C of the computer to factory
status or the last system backup status using
OneKey Recovery. With this operation, all of the
existing data in drive C will be lost while content
and format of the other partitions in the hard disk
drive will remain unchanged.
If you want to install operation system with
Windows Vista CD and backup it with OneKey
Recovery, you must format the partition C to be
NTFS format and install the operation system in the
partition C. Else the OneKey Recovery can not run.
User Guide 9
31033098_IdeaCentre K UG_EN.indd 9 2008.2.22 2:59:38 PM

10 User Guide
Note about service partition:
The files and relevant data of the rescue system are saved in the service partition.
Do not delete this partition. Otherwise, the rescue system will become unusable.
For detailed operations, see the following instructions:
By selecting Control Panel →Management Tools → Computer Management
→Disk Management, you can see the service partition, which must not be
deleted.
Note: The recovery files and relevant data of the rescue system are saved
in the service partition. If the service partition is deleted or damaged by
someone other than Lenovo maintainers, Lenovo shall not be liable for any
losses arising therefrom in any way.
Rescue system and keyboard operation
The rescue system works only if it runs together with the standard-configuration
keyboard of this model. If there is no keyboard of standard configuration, the
rescue system function will not work normally.
2.1 Installing Drivers and Software Shipped with
Computer
The “Installing drivers and software” in the rescue system provides a way for the
user to install the drivers and software shipped with the computer conveniently. It
can install all drivers and software shipped with the computer automatically, and
can selectively install some of the drivers and software as required by the user.
Method 1: Automatic Installation
Power on the computer. When the screen displays the “Lenovo” picture initially,
press the “LVT” key on the keyboard to start the Rescue System, select Install
drivers and software.
Install them as prompted. Click Install to start installing the drivers and software.
The system restarts. After the system is restarted, the installation process goes on
until completion.
Method 2: Manual Installation
Launch
In the Windows system, Click Start → All Programs → Lenovo → Drivers &
31033098_IdeaCentre K UG_EN.indd 10 2008.2.20 6:40:17 PM

11
User Guide
Application Installation. In the main interface of software, install all the drivers and
software automatically, or install some of them selectively.
In the software list, check the software to be installed. It is recommended not to
install the software which is already on the computer.
Note: In order to use all software shipped with the computer properly,
the tool software pctype must be installed. Otherwise, certain software
shipped with the computer cannot work normally!
2.2 OneKey Recovery
Note: Do not delete or change the backup data in the service partition
without permission. Otherwise, it will affect or damage the rescue system
programs.
Main Functions:
OneKey Recovery in the LEOS (press the rescue system button to access system
rescue directly without starting the operating system)
If Windows operating system is installed in your computer before delivery, the
OneKey Recovery function works in the following way:
Recover
Factory
Backup
Recover the computer system
partition (drive C) to the state
which exists before delivery
Note: After this
operation, all existing
data in the system
partition will be lost,
and other partitions
on the disk will keep
unchanged. In order to
prevent loss of data,
be sure to backup
important data before
this operation.
Instant
Recovery
Recover the system partition
(drive C) of the computer to
the state which exists when
the user performs the previous
“Instant Backup” operation.
If the user has not performed
“instant backup”, the instant
recovery operation will recover
the system partition to the
“base backup” state directly.
31033098_IdeaCentre K UG_EN.indd 11 2008.2.20 6:40:18 PM

12 User Guide
Instant
Backup
This operation backs up the
current data of the system
partition (drive C) of the
computer quickly. When
the user performs “Instant
Recovery” later, the system
partition will be recovered to
this backup state quickly.
Note: In this operation,
other partitions are not
changed or backed up.
Recommendation: Keep
at least 1G of space
in the system partition
(drive C) to ensure
the space required for
instant backup.
If Windows operating system is not installed in your computer before delivery, the
OneKey Recovery function works in the following way:
Create Base
Backup
Without factory backup, the
Lenovo “OneKey Recovery”
enables you to backup all data
of the current system partition
manually after installing the
operating system and common
software. Upon completion of
“base backup”, you can use
the “Recover Base Backup”
function to recover the system
partition to the state of this
backup.
Note: Once the user has
performed the operation
of base backup, such
operation is disabled.
It is recommended to
perform that operation
after installing Windows
operating system and
the drivers & software
shipped together
with the computer.
Otherwise, the backup
space is deficient.
31033098_IdeaCentre K UG_EN.indd 12 2008.2.20 6:40:18 PM

13
User Guide
Recover
Base
Backup
This operation recovers the
computer system partition
(drive C) to the state of base
backup.
Note: After this
operation, all existing
data in the system
partition will be lost,
and other partitions
on the disk will keep
unchanged. In order to
prevent loss of data,
be sure to backup
important data before
this operation.
Instant
Recovery
This operation recovers the
system partition (drive C) of the
computer to the state which
exists when the user performs
the previous “Instant Backup”
operation. If the user has not
performed “Instant Backup”,
the instant recovery operation
will recover the system
partition to the “base backup”
state directly.
Instant
Backup
Backup the current data of the
system partition (drive C) of
the computer quickly. When
the user performs “Instant
Recovery” later, the system
partition will be recovered to
this backup state quickly.
Note: In this operation,
other partitions are not
changed or backed up.
Recommendation: Keep
at least 1G of space
in the system partition
(drive C) to ensure
the space required for
instant backup.
OneKey Recovery in Windows Operating System:
In addition to Instant Recovery and Instant Backup, Windows operating system
provides the functions enabled only in the Windows environment:
Create Base Backup — Backup data in system partition (drive C). This backup is
base data of instant backup.
Recover Base Backup — Recover the data of system partition (drive C) which
exists at the time of “creating base backup”.
Close Instant Backup and Recovery — After the Instant Backup and Recovery
function is cloesd, all Instant Backup and Base Backup data will be deleted. Make
sure you do not require such data before closing that function.
Update Base Backup — Use the system partition (drive C) data in the latest state
as Base Backup to overwrite the old Base Backup data. The old Base Backup
31033098_IdeaCentre K UG_EN.indd 13 2008.2.20 6:40:18 PM

14 User Guide
data will be lost. Make sure that you do not need the old Base Backup data any
longer before that operation.
Instant Recovery and Instant Backup are the same as the functions under LEOS.
Note:
1. Before performing the Instant Recovery and Instant Backup under LEOS,
execute “Create Base Backup” under Windows first.
2. In order to prevent failure of the recovery operation, do not change the size
of drive C after the backup operation.
3. Make sure to disable the Instant Backup and Recovery function or uninstall
the “OneKey Recovery” function before reinstalling the operating system.
Otherwise, the operating system cannot be reinstalled.
4. Before performing defragment of the operating system or the system
maintenance functions such as error detection or backup, disable the Instant
Backup and Recovery function first. Otherwise, the running of such software
will be disabled or affected.
5. Precondition of updating base backup:
1) After the system software or system state changes sharply, if you confirm
such change and do not require the system to recover the state existent
before the change, you can perform the update of Base Backup which
serves as base data of future instant backup. You can also free up the
hard disk drive space excessively occupied by the base backup.
2) When the system disk space is less than 1G, the OneKey Recovery
function will prompt you to perform disk cleanup and update base
backup.
6. The “OneKey Recovery” function will run automatically on the background
with the startup of the Windows. Certain antivirus software may regard
such automatically running process as risk and warn the user. In such
circumstances, choose to allow the software to go on automatically,
whereupon the antivirus software will not give such prompt any longer.
Detailed operation procedure (example: Recovering Factory
Backup):
Recover Factory Backup
1. Power on the computer. When the screen displays the “Lenovo” picture initially,
press the “LVT” key on the keyboard to start the Rescue System, where you
can select OneKey Recovery.
2. Select Recover Factory Backup to start the system recovery function.
31033098_IdeaCentre K UG_EN.indd 14 2008.2.20 6:40:19 PM

15
User Guide
Note: System Recovery will overwrite all of the data in drive C; please
backup relevant data before performing system recovery to prevent your
important data from missing.
3. Follow the onscreen instructions, and press E on the keyboard to start recovery
if you are sure to recover.
4. Please wait in the process of system recovery. Do not interrupt the operation.
5. After the system is recovered successfully, the software prompts to restart the
computer. Restart the computer and enter the system.
2.3 File Management
With the File Management module, you may access the critical data in directories
such as Desktop or Document of the system partition (usually drive C) when the
system crashes and is irrecoverable, and backup such data into other partitions or
storage devices.
Launch
Power on the computer. When the “Lenovo” picture appears on the screen initially,
press the “LVT” key to launch Rescue System. Then select File Management.
File Backup
Select the file and folder to be copied in the left dialog box, and select the target
folder and drive letter in the right dialog box. The drive letter of the source file must
be different with the target drive letter. Then click Copy.
File Backup
Wait while copying.
Note: Please wait while copying; time for this operation depends on the
quantity and size of files you need to copy. Do not turn off the power
forcefully, otherwise it might cause file system abnormality.
Configuring a Password
Click the key-shape icon on the upper right side of the main interface to configure
the password.
To ensure authentication of the user ID who is copying the files, the Lenovo file
management function enables you to configure a protection password - the user
is unable to access the files in your hard disk drive partitions without passing the
password authentication.
The default password is blank.
31033098_IdeaCentre K UG_EN.indd 15 2008.2.20 6:40:19 PM
