Lenovo THINKSTATION D10 User manual

THINKSTATION S10 & D10:
A WORKSTATION AS PROFESSIONAL AS YOU ARE.
Lenovo recommends Windows Vista®Business.

0? + 1/32 - Ap+ 1/2k2 (p + 3p) - ŠA ‡ -k2/2 (2p +
3p) p/y-k2
pe
w
p +2Hwp+ 1/2 ad-url ali=0, 0pv+Tu^p/
wx13 1k/16
Œ - µ
øEpw+3HEpw -cul Hpu+ k2/2 (p+p) o t2p = k2/2
3Ep•ß
-k2/6 [4peopw+
3K3+ 3H + 3(p-v)3]
H
pw + 3H §H pwc¸uEpv = k2/2pun3
Wv = 0, ¬,
V
wponÏ - wxp-2/3;{o-2/36} = -q3£
THINKSTATION S10 & D10:
THE WORLD’S BEST ENGINEERING IN ACTION.
Lenovo recommends Windows Vista®Business.
DESIGNED TO PERFORM
The ThinkStation’s chassis is designed to be user-friendly:
- The ThinkStation’s premium cover latch makes the cover easily
removable, assisting users to conveniently make upgrades
- The ThinkStation’s illuminated front panel and icons make ports
easily locatable, thereby improving connectivity
- The ThinkStation’s ergonomically designed removable handle
makes it easy to carry, move and manage
- Rack implementation is possible both in the ThinkStation S10
and ThinkStation D10
QUIET AND RELIABLE
- The ThinkStation is designed to offer you a quieter computing
experience: Its rock-solid engineering gives you workstation-class
performance at reduced noise levels
- Even when the ThinkStation is under load, it has an acoustic
profile similar to a standard PC
ENVIRONMENTALLY RESPONSIBLE
- The ThinkStation S10 and ThinkStation D10 contain over
50% recycled plastics, setting the standard for the industry
- All ThinkStation models are RoHS compliant
- Many ThinkStation models are Energy Star 4.0 compliant
The ThinkStation, the newest member of the Think legacy, is engineered exclusively for specialized professionals.
Its ground-breaking design ramps up simultaneous or parallel workflows, enabling professional users to innovate
faster and reduces the time between an idea and a product.
Equipped with the latest technology from Intel®, the ThinkStation delivers performance well beyond a standard
desktop PC. It is based on the upcoming Quad-Core Intel®Xeon®Processor 5400 series and Intel®Core™2
Extreme Processors—the first processors that use the new 45-nanometer technology. These processors nearly
double the density of transistors on the chips to offer new levels of energy-efficient performance.
In addition, the ThinkStation is equipped with ThinkVantage®technologies such as Rescue and Recovery™ and
Client Security Solution to provide the best of data security. From the world’s best engineers come the world’s
best-engineered PCs.

Lenovo recommends Windows Vista®Business.
PERFORMANCE YOU NEED
The ThinkStation is a high performance, high quality workstation
designed to run graphically and computationally intensive applications
for professional users who require a level of performance unattainable
with a standard desktop PC.
- Lenovo has partnered with workstation graphics leader NVIDIA®to
offer the QUADRO line of workstation graphics adapters
- The ThinkStation’s superior engineering allows simultaneous design
and analysis [(Run CAD (design) + CAE (analysis)] parallely
- The ThinkStation S10 and ThinkStation D10 both support RAID
configurations without requiring an additional adapter card
- The ThinkStation supports both Windows Vista®and Windows®XP,
giving you the flexibility you need
ISV CERTIFIED
Lenovo is working closely with leading software partners to ensure
optimum performance and stability in the demanding applications
you use everyday. Independent Software Vendors (ISVs) test system
and application compatibility, providing you the assurance of a robust
and reliable platform.
LEADING INTEL®TECHNOLOGIES
The new performance-driven Intel®Core microarchitecture combines
six key technologies to provide unparalleled efficiency.
- Intel®Wide Dynamic Execution delivers more instructions per
clock cycle, enhancing the efficiency of instruction execution
- Intel®Advanced Digital Media Boost enables 128-bit SSE
instructions to be completed at a rate of one per clock cycle,
effectively doubling the instructions’ execution speed as
compared to previous generations
- Intel®Advanced Smart Cache is a multi-core optimized cache
which increases the probability of each execution core of a
multi-core processor accessing data
- Intel®Smart Memory Access contains an important new built-in
intelligence to process out-of-order instructions more efficiently
- Intel®Intelligent Power Capability improves energy-efficient
performance and reduces noise and energy consumption
- Macro Fusion combines instructions into a single instruction
for execution, delivering more efficient processing and faster
throughput

1.866.426.1316
lenovo.com/thinkstation
Availability: Offers, prices, specifications and availability may change without notice. Lenovo is not responsible for photographic or typographic errors. Warranty: For a copy of applicable warranties, write to: Warranty
Information, 500 Park Offices Drive, RTP, NC, 27709, Attn: Dept. ZPYA /B600. Lenovo makes no representation or warranty regarding third-party products or services. Trademarks: Lenovo, the Lenovo logo, New World.
New Thinking., Access Connections, Rescue and Recovery, ThinkVantage, and ThinkVision are trademarks of Lenovo. Microsoft, Windows, and Vista are registered trademarks of Microsoft Corporation. Intel, the Intel logo,
Intel Inside, Intel Inside logo, Intel Core, Core Inside, Xeon and Xeon Inside are trademarks of Intel Corporation in the US and other countries. Other company, product and service names may be trademarks or service marks
of others.© 2008 Lenovo. All rights reserved.
Visit lenovo.com/safecomputing periodically for the latest information on safe and effective computing. TPDA61-0707-WWEN-00
Lenovo recommends Windows Vista®Business.
S10 D10
Operating Preloaded Genuine Windows Genuine Windows
Systems Vista®Business 32-bit Vista®Business 32-bit
Genuine Windows Genuine Windows
Vista®Business 64-bit Vista®Business 64-bit
Supported Genuine Windows Vista®Ge nuine W indows V ista®
downgrade to Genuine downgrade to Genuine
Windows®XP Windows®X P
(32 and 64 bit) (32 and 64 bit)
Red Hat®Enterprise Red Hat®Enterprise
Linux WS 64-bit Linux WS 64-bit
Graphics NVIDIA®Quadro NV290 NVIDIA®Quadro NV290
(256MB) (256MB)
NVIDIA®Quadro FX370 NVIDIA®Quadro FX370
(256MB) (256MB)
NVIDIA®Quadro FX170 0 NVIDIA®Quadro FX170 0
(512MB) (512MB)
NVIDIA®Quadro FX4600 NVIDIA®Quadro F X46 0 0
(768MB) (768MB)
Any two of the above Cards are supported.
Hard Drives SATA 7200 rpm SATA 7200 rpm
160, 250, 500, 750GB 160, 250, 500, 750GB
SAS 15K rpm SAS 15K rpm
73, 146, 300GB 73, 146, 300GB
* SAS requires adapter card on S10
Optical Drives DVD-ROM DVD-ROM
DVD +/- RW Dual Layer DVD +/- RW Dual Layer
BLU-RAY DVD Burner BLU-RAY DVD Burner
Physical Chassis Form Factor Mid-Tower Tower
Dimensions (HxWxD) 426x175x483mm 434x210x602mm
(without handle)
Weight (typical) ~32 lbs ~55 lbs
Internal Speaker Standard Standard
Rack mounting Via shelf only Via shelf or optional rail kit
S l o t s / B a y s Gen2 PCIe x16 Slots 2 2
PCIe x8 Slots 0 0
PCIe x4 Slots 1 (x16 mechanical) 2 (x 8 mechanical)
PCI-X Slots 0 2
PCI Slots 2 1
3.5" Internal Bays 3 5
3.5" External Bays 1 1
5.25" External Bays 2 3
Motherboard1Form Factor Full ATX Extended ATX
Chipset Intel®X38 (Express) Intel®540 0A
Ethernet Broadcom 5755/5754 Intel®8256 3EB
SATA / SAS Connectors 6/0 5/5
PATA Connectors None None
Memory Type DDR3 ECC DDR2 Fully Buffered
Memory Speed PC2-8500 (1067MHz) PC2-5300 (667MHz)
DIMM Slots 4 8
Maximum Memory 8GB 64GB*
Power Supply Wattage 650W 1000W
Efficiency 80%+ 80%+
Rating 100-127/200-240V 100-127/200-240V
8/4A 12/6A
Environmental Energy Star 4.0 Select models Select models
RoHS Compliant Yes Yes
Recycled Plastic Content 50+ % 50+ %
R e a r I / O PS/2 2 (Mouse/Keyboard) 2 (Mouse/Keyboard)
Parallel None None
Serial 1 (second optional) 1 (second optional)
Ethernet Dual Gigabit (RJ45) Dual Gigabit (RJ45)
USB 8 4
Analog Audio 5 ports 6 ports
Digital Audio Optical Coaxial
Front I/O USB 2 2
IEEE 1394 1 (6-pin) 1 (6-pin)
Analog Audio Headphone, Mic in Headphone, Mic in
Dual-Core
Intel®Core™2 Duo Proce sso r E6550 - 2.33GHz, 2MB x2 L 2, 1333MHz FSB
Intel®C ore™2 Duo Proce sso r E6750 - 2.66 GHz, 2MB x2 L2, 1333 MHz FSB
Intel®C ore™2 Duo Proce sso r E6 850 - 3.0 0GHz, 2MB x2 L2, 1333MHz FSB
Quad-Core
Intel®C ore™2 Quad Proc ess or Q6 600 - 2.40G H z, 4MB x2 L2, 1066MHz FSB
Intel®Core™2 Quad Process or Q6700 - 2.66GHz, 4MB x2 L2, 10 66MHz FSB
Extreme
Intel®Core™2 E x treme Proce ssor Q X6800 - 2.93GHz, 4MBx2 L2, 10 66MHz FSB
Intel®Core™2 E x treme Proce ssor Q X6850 - 3.00GHz, 4MBx 2 L 2, 1333MHz FSB
S10
Dual-Core
Intel®Xeon®Processor E5205 - 1.86GHz, 6 MB L2, 10 66MHz FSB
Intel®Xeon®Processor E526 0 - 3.33GHz, 6M B L 2, 1333MHz FSB
Quad-Core
Intel®Xeon®Processor E540 5 - 2.00GHz, 12MB L2, 1333MHz FSB
Intel®Xeon®Processor E5410 - 2.33G Hz, 12M B L 2, 1333MHz FSB
Intel®Xeon®Processor E5420 - 2.50GHz, 12MB L2, 1333MHz FSB
Intel®Xeon®Processor E543 0 - 2.66GHz, 12MB L2, 1333MHz FSB
Intel®Xeon®Processor E5440 - 2.83GHz, 12MB L 2, 1333MHz FSB
Intel®Xeon®Processor E5450 - 2.83GHz, 12MB L 2, 1333MHz FSB
Extreme
Intel®Xeon®Processor X5450 - 3.00GHz, 12MB, 1333MHz FSB
