Lenovo V330-20ICB User manual

Lenovo V330-20ICB AIO User Guide and
Hardware Maintenance Manual
Energy Star Machine Types: 10U and 10UL

Note: Before using this information and the product it supports, be sure to read and understand the
Important Product Information Guide and Appendix A “Notices” on page 49.
First Edition (June 2018)
© opyright Lenovo 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
hapter 1. Overview. . . . . . . . . . . 1
Front view . . . . . . . . . . . . . . . . . . 1
Rear view . . . . . . . . . . . . . . . . . . 3
System board . . . . . . . . . . . . . . . . 4
Machine type and model label . . . . . . . . . . 5
Adjusting the computer stand . . . . . . . . . . 5
hapter 2. Specifications . . . . . . . . 7
hapter 3. omputer locks . . . . . . . 9
hapter 4. Replacing hardware . . . . 11
Before replacing hardware . . . . . . . . . . 11
nowing FRUs (including CRUs) . . . . . . . . 11
Locating FRUs (including CRUs) . . . . . . . . 12
Replacing the computer stand . . . . . . . . . 14
Removing the computer cover . . . . . . . . . 16
Replacing the optical drive . . . . . . . . . . 17
Replacing the system board shield . . . . . . . 20
Replacing the storage drive . . . . . . . . . . 20
Replacing the internal microphone board . . . . . 22
Replacing the card reader . . . . . . . . . . . 23
Replacing the internal speakers . . . . . . . . 24
Replacing the serial connector and parallel
connector module . . . . . . . . . . . . . . 25
Replacing the system fan . . . . . . . . . . . 27
Replacing the power button board . . . . . . . 28
Replacing the M.2 solid-state drive . . . . . . . 29
Replacing the coin-cell battery . . . . . . . . . 32
Replacing a memory module. . . . . . . . . . 34
Replacing the Wi-Fi card . . . . . . . . . . . 36
Replacing the heat sink . . . . . . . . . . . . 37
Replacing the microprocessor . . . . . . . . . 39
Replacing the internal camera . . . . . . . . . 43
Replacing the Wi-Fi antennas . . . . . . . . . 43
Replacing the system board . . . . . . . . . . 44
Replacing the LCD panel . . . . . . . . . . . 45
Completing the parts replacement . . . . . . . 47
Appendix A. Notices. . . . . . . . . . 49
Appendix B. Trademarks . . . . . . . 51
© Copyright Lenovo 2018 i

ii Lenovo V330-20ICB AIO User Guide and Hardware Maintenance Manual

hapter 1. Overview
This chapter provides basic information to help you get familiar with your computer.
Front view
Note: Your computer model might look slightly different from the illustration.
Figure 1. Front view
1 Internal camera activity indicator (optional) 2 Internal camera shield control slider (optional)
3 Internal camera (optional) 4 Power indicator
5 Power button 6 Headset connector (also known as combo audio jack)
7 USB 3.1 Gen 1 connector 8 USB 3.1 Gen 2 connector
9 Internal microphones (2) 10 Card reader slot (optional)
11 Serial connector (optional) 12 Parallel connector (optional)
13 Internal speakers (2) 14 Screen
1 Internal camera activity indicator
When the indicator is on, the camera is in use.
2 Internal camera shield control slider
Used to cover the camera lens.
3 Internal camera
© Copyright Lenovo 2018 1

Used to take pictures or hold a video conference.
4 Power indicator
This indicator is on when the computer is on.
5 Power button
Used to turn on your computer. When you cannot shut down the computer from the operating system, press
and hold the power button for four or more seconds to turn off the computer.
6 Headset connector
Used to connect a headset or headphones to your computer.
7 USB 3.1 Gen 1 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 1 device to a
USB 3.1 Gen 2 or USB 3.1 Gen 1 connector instead of a USB 2.0 connector.
8 USB 3.1 Gen 2 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 2 device to a
USB 3.1 Gen 2 connector instead of a USB 3.1 Gen 1 or USB 2.0 connector.
9 Internal microphones
Used to record sounds or use speech-recognition software without using a microphone.
10 ard reader slot
Used to read data from a supported memory card.
11 Serial connector
Used to connect an external modem, a serial printer, or other devices that use a serial connector.
12 Parallel connector
Used to connect a parallel printer, a scanner, or other devices that use a parallel connector.
13 Internal speakers
Used to listen to the sounds from your computer without using a headset or headphones.
14 Screen
Depending on the computer model, your computer screen might support the multi-touch feature. This
feature enables you to use one or two fingers to interact with the computer.
2Lenovo V330-20ICB AIO User Guide and Hardware Maintenance Manual

Rear view
Note: Your computer model might look slightly different from the illustration.
Figure 2. Rear view
1 VESA threaded holes (screws: M4 x 8 mm x 4 pcs) 2 Optical drive activity indicator (optional)
3 Optical drive eject/close button (optional) 4 HDMITM 1.4 out connector
5 Power adapter connector 6 Ethernet connector
7 USB 3.1 Gen 1 connectors (3) 8 USB 3.1 Gen 2 connector
9 Security-lock slot
1 VESA threaded holes
Used to connect the matched VESA mount with the matched screws when you install the computer on a
wall.
2 Optical drive activity indicator
This indicator is on when the optical drive is in use.
3 Optical drive eject/close button
Used to eject the tray of the optical drive. After you insert a disc into the tray, press the eject/close button to
close the tray.
4 HDMI 1.4 out connector
Used to send audio and video signals from the computer to another audio or video device, such as a high-
performance monitor.
Chapter 1.Overview 3

5 Power adapter connector
Used to connect the power adapter to the computer for power supply.
6 Ethernet connector
Used to connect an Ethernet cable for network access.
7 USB 3.1 Gen 1 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 1 device to a
USB 3.1 Gen 2 or USB 3.1 Gen 1 connector instead of a USB 2.0 connector.
8 USB 3.1 Gen 2 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 2 device to a
USB 3.1 Gen 2 connector instead of a USB 3.1 Gen 1 or USB 2.0 connector.
9 Security-lock slot
Used to secure a ensington-style cable lock.
System board
Note: See “Front view” and “Rear view” for additional component descriptions.
Figure 3. System board
1 M.2 Wi-Fi card slot 2 Internal camera connector
3 Microprocessor socket 4 Memory slot (DIMM1)
4Lenovo V330-20ICB AIO User Guide and Hardware Maintenance Manual

5 Memory slot (DIMM2) 6 System fan connector
7 SATA connector (connecting to the optical drive) 8 LCD LVDS connector
9 Serial (COM1) connector 10 SATA connector (connecting to the storage drive)
11 Parallel connector 12 M.2 solid-state drive slot
13 Coin-cell battery 14 CLR1 button
15 PCH 16 LCD power connector
17 SATA power connector (connecting to the storage
drive)
18 Internal speaker connector
19 Internal microphone board connector 20 Card reader connector
21 Power button board connector
Machine type and model label
The machine type and model label identifies the computer. When you contact Lenovo for help, the machine
type and model information helps support technicians to identify the computer and provide faster service.
The machine type and model label is attached on the computer as shown.
Figure 4. achine type and model label
Adjusting the computer stand
Note: The computer stand is optional.
Chapter 1.Overview 5

Figure 5. Tilting the screen forward and back
Figure 6. Turning the screen to the left and right
6Lenovo V330-20ICB AIO User Guide and Hardware Maintenance Manual
