Lenovo ThinkStation P340 User manual

Printed in China
PN: SPXXXXXXXX
Setup Guide

Initial Setup

*For selected models I For visse modeller I Tietyissä malleissa I Utvalgte modeller I Vissa modeller
Overview
1. System status indicator
2. Power button
3. Storage drive activity indicator
4. USB-C™ (3.2 Gen 1) connector
5. Always On USB 3.2 connector Gen 2
6. Headset connector
7. Security-lock slot
*8. Optional connectors
*9. Wi-Fi antenna slot
10. Ethernet connector
11. USB 3.2 connectors Gen 2
12. USB 3.2 connector Gen 1 (with smart
power-on)
13. HDMI™ 1.4 out connector
14. USB 3.2 connector Gen 1
15. DisplayPort 1.4 out connector
16. Power cord connector
Read the statement on USB transfer rate in the User Guide. Refer to the Safety and Warranty Guide for
accessing the User Guide.

*For selected models I For visse modeller I Tietyissä malleissa I Utvalgte modeller I Vissa modeller
Customer Replaceable Units (CRUs)
• ac power adapter
• Power cord
*• Keyboard
*• Mouse
*• Vertical stand
*• Rear Wi-Fi antenna
*• VESA mount bracket
*• External optical drive
*• External optical drive box
*• Power adapter bracket
*• Dust shield
• Computer cover
• Internal speaker
• Bottom cover
• M.2 solid-state drive
• Memory module
• System fan
• Coin-cell battery
*• PCIe card
*• PCIe converter
*• Wi-Fi card
*• Wi-Fi card shield
Refer to the User Guide for CRU definition.

Additional information
European Union — compliance with the
Radio Equipment Directive
Hereby, Lenovo (Singapore) Pte. Ltd., declares that
the radio equipment type ThinkStation P340 Tiny is
in compliance with Directive 2014/53/EU.
The full text of the system EU declaration of
conformity is available at the following Internet
address:
https://www.lenovo.com/us/en/compliance/eu-doc
This radio equipment operates with the following
frequency bands and maximum radio-frequency
power:
Technology
Frequency
band [MHz]
Maximum
transmit
power
WLAN
802.11b/g/n/ax
2400 - 2483.5 < 20 dBm
WLAN
802.11a/n/ac/ax
5150 - 5725 < 23 dBm
WLAN
802.11a/n/ac/ax
5725 - 5875 < 13.98 dBm
Bluetooth
BR/EDR/LE
2400 - 2483.5 < 20 dBm
Usage of all the radio devices is limited to indoor in
the band 5150 MHz to 5350 MHz (channels 36, 40,
44, 48, 52, 56, 60, 64).

E-manual
First Edition (June 2020)
© Copyright Lenovo 2020.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a
General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to
restrictions set forth in Contract No. GS-35F-05925.
Reduce I Reuse I Recycle
