User Guide
IdeaCentre AIO 5

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
• Safety and Warranty Guide
• Generic Safety and Compliance Notices
• Setup Guide
First Edition (March 2022)
© Copyright Lenovo 2022.
IMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
Abo t this doc mentation . . . . . . . . iii
Chapter 1. Meet yo r comp ter . . . . . 1
Overview . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 2
Features and specifications . . . . . . . . . . . 3
USB specifications . . . . . . . . . . . . . . 3
Operating environment . . . . . . . . . . . . . 5
Chapter 2. Get started with yo r
comp ter . . . . . . . . . . . . . . . . . 7
Work with Windows . . . . . . . . . . . . . . 7
Windows help information . . . . . . . . . . 7
Use the touch screen (for selected models) . . . . . 8
Connect an external display . . . . . . . . . . . 9
Chapter 3. Explore yo r comp ter . . 11
Adjust the computer stand (for selected models) . . 11
enovo Vantage. . . . . . . . . . . . . . . 11
Set the power plan . . . . . . . . . . . . . 12
Transfer data . . . . . . . . . . . . . . . . 12
Connect to a Bluetooth-enabled device (for
selected models) . . . . . . . . . . . . 12
Purchase accessories . . . . . . . . . . . . 13
Chapter 4. Help and s pport . . . . . 15
Frequently asked questions . . . . . . . . . . 15
Self-help resources . . . . . . . . . . . . . 15
Call enovo . . . . . . . . . . . . . . . . 17
Before you contact enovo . . . . . . . . 17
enovo Customer Support Center . . . . . . 17
Purchase additional services. . . . . . . . . . 18
Appendix A. Notices and
trademarks . . . . . . . . . . . . . . . 19
© Copyright enovo 2022 i

ii User Guide

Abo t this doc mentation
• This guide applies to the enovo product models listed below. Illustrations in this guide may look slightly
different from your product model.
Model name Machine types (MT)
IdeaCentre AIO 5 24IAH7 F0GR
IdeaCentre AIO 5 27IAH7 F0GQ
• For further compliance information, refer to the Generic Safety and Compliance Notices at https://
pcsupport.lenovo.com/docs/generic_notices.
• Depending on the model, some optional accessories, features, and software programs might not be
available on your computer.
• Depending on the version of the operating systems and programs, some user interface instructions might
not be applicable to your computer.
• Documentation content is subject to change without notice. enovo makes constant improvements to the
documentation of your computer, including this User Guide. To get the latest documentation, go to https://
pcsupport.lenovo.com.
• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.
As a result, some information in this documentation might become outdated. Refer to Microsoft resources
for the latest information.
© Copyright enovo 2022 iii

iv User Guide

Chapter 1. Meet yo r comp ter
Overview
1. Microphones 2. Integrated camera activity indicator
3. Integrated camera* 4. Infrared camera*
5. Multi-touch screen* 6. Wireless charging pad*
7. USB 3.2 connector Gen 1
* for selected models
Related topics
• “Use the touch screen (for selected models)” on page 8.
• “USB specifications” on page 3.
© Copyright enovo 2022 1

Rear
1. Power button 2. PC/Monitor mode switcher
3. Power cord connector 4. Combo audio jack
5. HDMI in connector 6. Ethernet connector
7. HDMI 2.0 out connector 8. USB 2.0 connector
9. USB 3.2 connector Gen 2 (always-on) 10. USB-C® (3.2 Gen 2) connector
11. USB-C connector (support power output)
* for selected models
Power indicator
Show the system status of your computer.
• Blinking for three times: The computer is initially connected to power.
• On: The computer is on.
• Off: The computer is off or in hibernation mode.
• Blinking rapidly: The computer is entering sleep or hibernation mode.
• Blinking slowly: The computer is in sleep mode.
Related topics
• “Connect an external display” on page 9.
• “USB specifications” on page 3.
2User Guide

Feat res and specifications
For detailed specifications of your computer, go to https://psref.lenovo.com.
Hardware To view the hardware information of your computer, type device manager in the
Windows search box and then press Enter.
Power s pply • 180-watt automatic voltage-sensing power supply
• 230-watt automatic voltage-sensing power supply
Adaptability for power s pply
• Mainland China: 220 V±22 V, 50 Hz±1 Hz
• Adaptive voltage positioning: 90 V to 264 V, 50/60 Hz
• With voltage selection switch: 90 V to 264 V, 50 Hz±1 Hz
Microprocessor To view the microprocessor information of your computer, type system
information in the Windows search box and then press Enter.
Memory Double data rate 5 (DDR5) small outline dual in-line memory module (SODIMM)
Storage device
• M.2 solid-state drive
To view the storage drive capacity of your computer, type disk management in the
Windows search box and then press Enter..
Note: The storage drive capacity indicated by the system is less than the nominal
capacity.
Expansion • Memory slots
• M.2 solid-state drive slot
Network feat res
• Bluetooth
• Ethernet AN
• Wireless AN
USB specifications
Note: Depending on the model, some USB connectors might not be available on your computer.
Chapter 1.Meet your computer 3

Connector name Description
• USB 2.0 connector
• USB 3.2 connector Gen 1
• USB 3.2 connector Gen 2
Connect USB-compatible devices, such as a USB
keyboard, USB mouse, USB storage device, or USB
printer.
• USB-C (3.2 Gen 1) connector
• USB-C (3.2 Gen 2) connector
• Thunderbolt 3 connector (USB-C)
• Thunderbolt 4 connector (USB-C)
• Charge USB-C compatible devices with the output
voltage and current of 5 V and 3 A.
• Connect to an external display:
– USB-C to VGA: 1900 x 1200 pixels, 60 Hz
– USB-C to DP: 3840 x 2160 pixels, 60 Hz
• Connect to USB-C accessories to help expand your
computer functionality. To purchase USB-C
accessories, go to https://www.lenovo.com/accessories.
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 (USB-C) 40
Thunderbolt 4 (USB-C) 40
