Lenovo IdeaPad U130 Operation and maintenance manual

P/N: 147002117
Printed in China
©Lenovo China 2008
New World. New Thinking.TM
www.lenovo.com
U130 Regulatory Notice V1.0 cover_1-4
Lenovo
U130 Regulatory Notice V1.0

U130 Regulatory Notice V1.0 cover_2-3

i
Contents
Lenovo Regulatory Notice
US .......................................................................... 1
EU ........................................................................ 14
Non_EU ............................................................... 69
AP ........................................................................ 72
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page i Monday, December 8, 2008 10:12 AM

ii
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page ii Monday, December 8, 2008 10:12 AM

1
Lenovo Regulatory Notice (US)
Read first — regulatory information
Please read this document before you use the Lenovo computer.
Lenovo computer complies with the radio frequency and safety
standards of any country or region in which it has been approved for
wireless use. You must install and use your computer in strict
accordance with the instructions as described hereafter.
If your Lenovo computer contains a Wireless WAN adapter, be sure to
also read Lenovo Regulatory Notice for Wireless WAN adapter, included
with your computer.
Note: You cannot use the Wireless WAN adapter and the Wireless
LAN adapter (Models: 512AN_MMW ,512ANX_MMW)
simultaneously. If one of the adapters has established the
connection to the network, the other will be disconnected
automatically. To confirm the status of the network connection,
check the power status indicators of your computer. For more
information about the power-status indicators, see the “Power-
status indicators” section in Access Help.
Veuillez lire ce document avant d’utiliser l’ordinateur Lenovo.
L’ordinateur Lenovo est conforme aux normes de sécurité et de
radiofréquence du pays ou de la région où son utilisation sans fil est
agréée. Vous devez installer et utiliser votre ordinateur en respectant
scrupuleusement les instructions décrites ci-après.
US
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 1 Monday, December 8, 2008 10:12 AM

2
Si votre ordinateur Lenovo contient une carte de réseau étendu (WAN)
sans fil, veillez à lire également la consigne réglementaire Lenovo
Regulatory Notice for Wireless WAN adapter, fournie avec votre
ordinateur.
Remarque: Vous ne pouvez pas utiliser simultanément la carte de
réseau étendu sans fil et la carte de réseau local sans fil
(Modéle: 512AN_MMW ,512ANX_MMW). Si l’une de ces
cartes a établi la connexion avec le réseau, l’autre carte sera
automatiquement déconnectée. Pour confirmer l’état de la
connexion réseau, contrôlez les voyants d’état
d’alimentation. Pour plus d’informations, reportez-vous à
la section “Voyants d’état de l’alimentation” dans l’aide
Access.
USA — Federal Communications Commission (FCC)
I. User installable Wireless LAN module
WLAN Mini Express Card®/34:
• FCC ID: PD9LEN512ANMU(Model:512AN_MMW)
• FCC ID:PD9LEN512ANXMU(Model:512ANX_MMW)
Wireless LAN Mini Express Card/34 marketed in the USA and Canada
do not support nor function in the extended channels (12ch, 13ch).
For information concerning the wireless cards announced after the
publication of this notice, visit the Web site at
http://www.lenovo.com/support/site.wss/
document.do?sitestyle=lenovo&lndocid=tpad-matrix
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 2 Monday, December 8, 2008 10:12 AM

3
i) The FCC RF Exposure compliance:
The radiated output power of the Wireless LAN Mini Express Card/34
authorized to use for the your Lenovo computer is far below the FCC
radio frequency exposure limits. Nevertheless, it shall be used in such a
manner that the potential for human contact during normal operation is
minimized as follows:
Caution: To comply with FCC RF exposure compliance requirements,
a separation distance of at least 20 cm (8 inches) must be maintained
between the antennas for the integrated Wireless LAN Mini Express
Card/34 built into the screen section and all persons. You are not
allowed to disable “sleep (standby) mode” for the power management
function, if you cannot maintain the sufficient antenna separation (at
least 20 cm) in any case the LCD is left opened or closed.
For the location of the antenna, see the “Location of the UltraConnect
wireless antennas” section in Access Help.
Note: The transmission diversity function is implemented for this
product. For WLAN card (Models: 512AN_MMW
,512ANX_MMW) using Main and Auxiliary antennas for
transmission in the IEEE 802.11 b/g transmission mode, radio
frequency energy is not emitted simultaneously from both Main
and Auxiliary antennas. One of the antennas is selected
automatically or manually (by users) to have good quality of
radiocommunication (transmission diversity function).
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 3 Monday, December 8, 2008 10:12 AM

4
ii) FCC ID of wireless module:
There is no FCC ID for Mini Express Card/34 shown on the enclosure of
your Lenovo computer. Instead you will find an indicator pointing to the
location of the FCC ID on the bottom side of your Lenovo computer. For
the location of the FCC ID indicator, see the “Location of the FCC ID and
IC Certification number label” section in Access Help. The FCC ID is
affixed on the approved module installed in the Mini Express Card/34
slot. For the location of the slot, see the “PCI Express Mini Card slot for
wireless LAN” section in Access Help.
iii) Installation of approved wireless module:
If no integrated wireless LAN Mini Express Card/34 has been
preinstalled in your Lenovo computer, you can install one, provided by
Lenovo as an option. Plug the wireless card option into the Mini
Express Card/34 slot. For the installation procedure, see the “Installing
and replacing the PCI Express Mini Card for wireless LAN connection”
section in Access Help.
Attention: The Lenovo computers contain an authentication
mechanism.If you install an unauthorized wireless LAN
Mini Express Card/34 that is not approved for use in your
computer, the computer will not start, but only displays an
error message and emits audible beeps.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 4 Monday, December 8, 2008 10:12 AM

5
iv) Radio Frequency interference requirements:
• The devices have been tested and found to comply with the limits
for a Class B digital device pursuant to FCC Part 15 Subpart B. The
model 512AN_MMW ,512ANX_MMW were was subject to DoC.
Refer to “Electronic emission notices” on page 12.
• Each device is restricted to indoor use due to its operation in the 5.15 to
5.25 GHz frequency range. FCC requires these products to be used
indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential
for harmful interference to co-channel Mobile Satellite systems.
• High power radar are allocated as primary users of the 5.25 to 5.35
GHz and 5.65 to 5.85 GHz bands. These radar stations can cause
interference with and/or damage this device.
II. Preinstalled integrated Bluetooth module
• FCC ID: TLZ-BT253 (Model: AW-BT253)
i) FCC ID and installation of the module:
If you find the FCC ID “TLZ-BT253” on the label at the bottom side of
your computer, your computer integrates the
Bluetooth transmitter
module (Model: AW-BT253). The
Bluetooth module is preinstalled by
Lenovo, and is not removable by users. If your card requires
replacement via the proper steps shown in “Getting help and service” of
the
Service and Troubleshooting Guide , shipped with your computer,
Lenovo will request you to send your computer with the card to Lenovo
so that Lenovo will repair it.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 5 Monday, December 8, 2008 10:12 AM

6
ii) The FCC RF safety requirement:
The radiated output power of the Bluetooth module is far below the
FCC radio frequency exposure limits. Therefore, a 20 cm of separation
between the Bluetooth antenna and human body is not required.
For the location of the Bluetooth module “AW-BT253” and its built-in
antenna, see the “About your computer” section in Access Help.
iii) Radio Frequency interference requirements:
The device has been tested and found to comply with the limits for
both a Class B digital device regarding FCC Part 15 Subpart B and an
intentional radiator regarding FCC Part 15 Subpart C; then it
underwent the certification processes for both rules. Thus the FCC ID
TLZ-BT253 of this device includes both certifications of Part 15 Subpart
B and C.
III. Simultaneous use of RF transmitters
Your Lenovo computer is approved for simultaneous use of the
transmitters listed below:
• Wireless LAN adapter (FCC ID: PD9LEN512ANMU,
PD9LEN512ANXMU)
•Bluetooth module (FCC ID: TLZ-BT253)
Please make sure of the following conditions on use of these wireless
features:
1. When you use any other RF option device, all other wireless features
including the above integrated devices in your Lenovo computer are
required to be turned off.
2. Users must follow the RF Safety instructions on wireless option
devices that are included in the RF option device’s user’s manual.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 6 Monday, December 8, 2008 10:12 AM

7
Canada — Industry Canada (IC)
IC Certification number
I) User installable Wireless LAN modules:
• IC: 1000M-512ANMU (Model:512AN_MMW)
Wireless LAN Mini Express Card/34 marketed in the USA and Canada
do not support nor function in the extended channels (12ch, 13ch).
There is no certification number of Industry Canada for Mini Express
Card/34 shown on the enclosure of your Lenovo computer. Instead you
will find an indicator pointing to the location of the IC Certification
number on the bottom side of your Lenovo computer. For the location of
the IC Certification number indicator, see the “Location of the FCC ID
and IC Certification number label” section in Access Help. The IC
certification number is affixed on the approved module installed in the
Mini Express Card/34 slot. For the location of the slot, see the “PCI
Express Mini Card slot for wireless LAN” section in Access Help.
Attention: The Lenovo computer contains an authentication
mechanism.You can install or remove each wireless feature
by yourself. If you install an unauthorized wireless adapter
that is not approved for use in the Lenovo computer, the
computer will not start, but only displays an error message
and emits audible beeps.
II) Preinstalled integrated Bluetooth module:
• IC: 6100A-AWBT253 (Model: AW-BT253)
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 7 Monday, December 8, 2008 10:12 AM

8
If you find an indication “Contains Transmitter Module: Canada IC:
6100A-AWBT253 (Model:
AW- BT253)” on the label at the bottom side of
your computer, your computer integrates the
Bluetooth transmitter module.
The
Bluetooth module is preinstalled by Lenovo, and is not removable by
users. If your card requires replacement via the proper steps shown in
“Getting help and service” of the
Service and Troubleshooting Guide , Lenovo
will request you to send your computer with the card to Lenovo so that
Lenovo will repair it.
III) Low power license-exempt radiocommunication devices (RSS-210):
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. this device must accept any interference, including interference that
may cause undesired operation of the device.
The transmitter devices have been designed to operate with the antennas
integrated in Lenovo computer, and having a maximum gain of within 3 dBi.
The maximum antenna gain permitted for devices in the 5250-5350 MHz,
5470-5725 MHz, and 5725-5825 MHz bands complies with the e.i.r.p.
limit in section A9.2 of RSS-210.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 8 Monday, December 8, 2008 10:12 AM

9
IV) Exposure of humans to RF fields (RSS-102):
Lenovo computers employ low gain integral antennas that do not emit
RF field in excess of Health Canada limits for the general population;
consult Safety Code 6, obtainable from Health Canada’s Web site at
www.hc-sc.gc.ca/rpb
The radiated energy from the antennas connected to the wireless
adapters conforms to the IC limit of the RF exposure requirement
regarding IC RSS-102, Issue 2 clause 4.2.
Numéro d’homologation IC
I) Module sans fil installable par l’utilisateur:
Les cartes Express mini-PCI de réseau local sans fil:
• IC: 1000M-512ANMU (Model: 512AN_MMW)
Les cartes de réseau local sans fil Express mini-PCI commercialisées
aux Etats-Unis et au Canada ne prennent pas en charge les canaux
étendus (12ch, 13ch) et ne fonctionnent donc pas sur de tels canaux.
Le boîtier de votre ordinateur Lenovo ne comporte pas de numéro
d’homologation IC (Industry Canada) pour la carte mini-PCI Express ; mais
sous votre Lenovo, vous trouverez un indicateur pointant vers
l’emplacement du numéro d’homologation IC. Pour connaître
l’emplacement du numéro d’homologation IC, consultez la section
correspondante dans l’aide Access. Le numéro d’homologation IC est
apposé sur le module installé dans le logement pour carte mini-PCI Express.
Pour savoir où se trouve cet emplacement, consultez la section “Logement
pour cartes mini-PCI Express pour réseau local” dans Access Help.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 9 Monday, December 8, 2008 10:12 AM

10
Attention: L’ordinateur Lenovo contient un mécanisme
d’authentification.Vous pouvez installer ou désinstaller
tout dispositif sans fil. Si vous installez une carte sans fil
qui n’est pas homologuée dans votre ordinateur Lenovo,
l’ordinateur ne démarrera pas mais affichera un message
d’erreur et générera des bips sonores.
II) Module Bluetooth intégré préinstallé:
• IC: 6100A-AWBT253 (Model: AW-BT253)
Si la mention “Contains Transmitter Module: Canada IC:
6100A-AWBT253 (Model: AW-BT253)” figure sur l’étiquette située au
bas de votre ordinateur, cela signifie que ce dernier intègre le module
de transmission Bluetooth. Le module Bluetooth est préinstallé par
Lenovo et ne peut pas être retiré par les utilisateurs. Si votre carte doit
être remplacée conformément aux étapes du Chapitre relatif à l’aide et
la maintenance dans le manuel Guide de maintenance et d’identification
des incidents, Lenovo vous demandera de lui envoyer votre ordinateur
accompagné de la carte pour réparation.
III) Remarque relative aux appareils de communication radio de
faible puissance sans licence (CNR-210):
Le fonctionnement de ce type d’appareil est soumis aux deux
conditions suivantes:
1. Cet appareil ne doit pas perturber les communications radio, et
2. cet appareil doit supporter toute perturbation, y compris les
perturbations qui pourraient provoquer son dysfonctionnement.
Les périphériques d’émission sont conçus pour fonctionner avec des antennes
intégrées aux Lenovo et ayant un gain maximal de moins de 3 dBi.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 10 Monday, December 8, 2008 10:12 AM

11
Le gain d’antenne maximal pour les périphériques dans les bandes de
fréquence 5250-5350 MHz, 5470-5725 MHz, et 5725-5825 MHz est conforme à
la limite p.i.r.e énoncée dans la section A9.2 de la CNR-210.
IV) Exposition des êtres humains aux champs radioélectriques
(RF) (CNR-102):
L’ordinateur Lenovo utilise des antennes intégrales à faible gain qui
n’émettent pas un champ électromagnétique supérieur aux normes
imposées par le Ministére de la santé canadien pour la population.
Consultez le Safety Code 6 sur le site Web du Ministére de la santé
canadien à l’adresse “www.hc-sc.gc.ca/rpb”.
L’énergie émise par les antennes reliées aux adaptateurs sans fil respecte
la limite d’exposition aux radiofréquences telle que définie par Industrie
Canada dans la clause 4.2 du document CNR-102.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 11 Monday, December 8, 2008 10:12 AM

12
Electronic emission notices
Federal Communications Commission (FCC) Statement
Note: The model AW-BT253 underwent certification process for the FCC
Part 15 Subpart B compliance under each respective FCC ID number.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult an authorized dealer or service representative for help.
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 12 Monday, December 8, 2008 10:12 AM

13
Lenovo is not responsible for any radio or television interference
caused by unauthorized changes or modifications to this equipment.
Unauthorized changes or modifications could void the user’s authority
to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Responsible Party:
Lenovo (United States) Incorporated
1009 Think Place - Building One
Morrisville, NC 27560
Telephone: [phone]
FOR HOME OR OFFICE USE
Industry Canada Class B Emission Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
Tested To Comply
With FCC Standards
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 13 Monday, December 8, 2008 10:12 AM

14
Lenovo Regulatory Notice
Europe — EU Declaration of Conformity
Products intended for sale within the European Union are marked with the
Conformité Européenne (CE) Marking, which indicates compliance with
the applicable Directives and European Norms, and amendments,
identified below.
For model: 512AN_MMW
For model: AW-BT253
EU
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 14 Monday, December 8, 2008 10:12 AM

15
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 15 Monday, December 8, 2008 10:12 AM

16
U130 RegulatoryNoticeV1.0 (US,EU,Non_EU,AP).book Page 16 Monday, December 8, 2008 10:12 AM
