Lenovo ThinkPad Edge E130 User manual

PN: 0B49200
Printed in China
Second Edition (October 2012)
© Copyright Lenovo 2012.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use,
reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
Safety, Warranty, and Setup Guide
ThinkPad Edge E130 and E135
http://www.lenovo.com/support
Lenovo®electronic manuals... for a greener planet!
Refer to the electronic User Guide for detailed product information:
http://www.lenovo.com/thinkuserguides
Unpack
ThinkPad®
computer
Battery Power cord ac power adapter Publications
Note: Recovery discs are not provided. Instead, everything needed for recovering factory-installed files and
applications is provided in the Lenovo_Recovery partition on your hard disk drive. If you decide to remove
the Lenovo_Recovery partition, be sure to create a recovery disc first. For more information, see “Recovery
overview” in the User Guide. See “Accessing your User Guide” for instructions on opening the electronic
User Guide provided on your computer.
Initial setup instructions
1. Install the battery pack.
This system supports only batteries specially designed for this
specific system and manufactured by Lenovo or an authorized
builder. The system does not support unauthorized batteries or
batteries designed for other systems. If an unauthorized battery or
a battery designed for another system is installed, the system will
not charge.
Attention: Lenovo has no responsibility for the performance or
safety of unauthorized batteries, and provides no warranties for
failures or damage arising out of their use.
2. Connect to power.
3. Press the power button to turn on the computer.
4. Configure the operating system following the on-screen instructions to complete the initial setup. This
process takes several minutes.
Additional information about using your ThinkPad computer is in the User Guide. See “Accessing your
User Guide” later in this document.
Controls and indicators
Integrated camera
: Power button
Function keys
: Volume controls
: Microphone mute
: Change camera and audio settings
: Change display settings
: Change display brightness
: Manage wireless connections
: Multimedia controls
Note: To use the F1 through F12 functions,
press the desired key directly.
TrackPoint®pointing stick
TrackPoint buttons
Touch pad
System status indicator
Accessing your User Guide
Your User Guide contains detailed information about your computer.
To access your User Guide, do the following:
Windows®8:
• From the desktop or the Start screen
1. Move the cursor to the top-right or bottom-right corner of the
screen to display the charms, and then click Search. If you are
using a touch screen, swipe in from the right edge of the screen
to display the charms, and then tap Search.
2. From the Apps screen, click or tap Help and Support. The
Windows Help and Support window opens.
3. Click or tap Lenovo User Guide.
• From the Start screen
1. Click or tap Lenovo Support.The Lenovo Support program
opens.
2. Click or tap User Guide.
Windows 7:
1. From the Windows desktop, click Start →Help and Support. The
Help and Support application opens.
2. Click Lenovo User Guide.
3. Click the link for your model and the User Guide opens.
Read before using your computer
The following sections provide critical safety and regulatory
information for Lenovo computers and instructions on how to access
electronic versions of the publications developed for your computer.
Read first — regulatory information
Computer models equipped with wireless communications comply
with the radio frequency and safety standards of any country or region
in which it has been approved for wireless use. In addition, if your
product contains a telecom modem, it complies with the requirements
for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your computer. To
obtain a PDF version of the Regulatory Notice, refer to the
“Downloading publications” section below.
Downloading publications
Electronic versions of your computer publications are available from
the Lenovo Support Web site. To download the publications for your
computer, go to http://www.lenovo.com/ThinkPadUserGuides and
follow the instructions on the screen.
Service and Support information
The following information describes the technical support that is
available for your product, during the warranty period or throughout
the life of your product. Refer to the Lenovo Limited Warranty for a full
explanation of Lenovo warranty terms. See “Lenovo Limited Warranty
notice” later in this document for details on accessing the full warranty.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
Telephone technical support
You can get help and information from the Customer Support Center
by telephone. Before contacting a Lenovo technical support
representative, please have the following information available: model
and serial number, the exact wording of any error message, and a
description of the problem.
Your technical support representative might want to walk you through
the problem while you are at your computer during the call.
Worldwide Lenovo Support telephone list
Important: Telephone numbers are subject to change without notice.
The most up-to-
date telephone list for the Customer Support Center is
always available at http://www.lenovo.com/support/phone.
If the telephone number for your country or region is not listed,
contact your Lenovo reseller or Lenovo marketing representative.
Country or region
Telephone number
