Lenovo ThinkPad X230 Tablet User manual

PN: 0B49104
Printed in China
Third Edition (August 2012)
© Copyright Lenovo 2012.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use,
reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
Safety, Warranty, and Setup Guide
ThinkPad X230 and X230i
http://www.lenovo.com/support
Lenovo®electronic manuals... for a greener planet!
Refer to the electronic User Guide for detailed product information:
http://www.lenovo.com/thinkuserguides
Unpack
ThinkPad®
computer
Battery
Power cord
AC power
adapter
Publications
Note: Recovery discs are not provided. Instead, everything needed for recovering factory-installed files and
applications is provided in the Lenovo_Recovery partition on your hard disk drive. If you decide to remove
the Lenovo_Recovery partition, be sure to create a recovery disc first. For more information, see “Recovery
overview” in the User Guide. See “Accessing your User Guide” for instructions on opening the electronic
User Guide provided on your computer.
Initial setup instructions
1.Install the battery pack.
This system supports only batteries specially designed for this
specific system and manufactured by Lenovo or an authorized
builder. The system does not support unauthorized batteries or
batteries designed for other systems. If an unauthorized battery or
a battery designed for another system is installed, the system will
not charge.
Attention: Lenovo has no responsibility for the performance or
safety of unauthorized batteries, and provides no warranties for
failures or damage arising out of their use.
2. Connect to power.
3.Press the power button to turn on the computer.
4.Configure the operating system following the on-screen instructions to complete the initial setup. This
process takes several minutes.
Additional information about using your ThinkPad computer is in the User Guide. See “Accessing your
User Guide” later in this document.
Controls and indicators
UltraConnect™ wireless antennas
Integrated camera
ThinkLight®light
Built-in microphones
Speaker mute button
Volume control button
Microphone mute button
Black button
Power button
TrackPoint®pointing stick
TrackPoint buttons
Touch pad
Fingerprint reader*
Wireless radio switch
Fn key
*On selected models
Accessing your User Guide
Your User Guide contains detailed information about your computer.
To access your User Guide, do the following:
Windows®8:
From the desktop or the Start screen
1. Move the cursor to the top-right or bottom-right corner of the
screen to display the charms, and then click Search.
2. From the Apps screen, click Help and Support. The Windows
Help and Support window opens.
3. Click Lenovo User Guide.
From the Start screen
1. Click Lenovo Support. The Lenovo Support program opens.
2. Click User Guide.
Windows 7:
1. From the Windows desktop, click Start and then click Help and
Support. The Help and Support program opens.
2. Click Lenovo User Guide.
3. In the Lenovo User Guide window, click the link for your model and
the User Guide opens.
Read before using your computer
The following sections provide critical safety and regulatory
information for Lenovo computers and instructions on how to access
electronic versions of the publications developed for your computer.
Read first —regulatory information
Computer models equipped with wireless communications comply
with the radio frequency and safety standards of any country or region
in which it has been approved for wireless use. In addition, if your
product contains a telecom modem, it complies with the requirements
for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your computer. To
obtain a PDF version of the Regulatory Notice, refer to the
“Downloading publications” section below.
Downloading publications
Electronic versions of your computer publications are available from
the Lenovo Support Web site. To download the publications for your
computer, go to http://www.lenovo.com/ThinkPadUserGuides and
follow the instructions on the screen.
Service and Support information
The following information describes the technical support that is
available for your product, during the warranty period or throughout
the life of your product. Refer to the Lenovo Limited Warranty for a full
explanation of Lenovo warranty terms. See “Lenovo Limited Warranty
notice” later in this document for details on accessing the full warranty.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
Telephone technical support
You can get help and information from the Customer Support Center
by telephone. Before contacting a Lenovo technical support
representative, please have the following information available: model
and serial number, the exact wording of any error message, and a
description of the problem.
Your technical support representative might want to walk you through
the problem while you are at your computer during the call.
Worldwide Lenovo Support telephone list
Important: Telephone numbers are subject to change without notice.
The most up-to-date telephone list for the Customer Support Center is
always available at http://www.lenovo.com/support/phone.
If the telephone number for your country or region is not listed,
contact your Lenovo reseller or Lenovo marketing representative.
Country or region
Telephone number
Africa
Africa: [phone]
South Africa: 0800110756 (English, Afrikaans)
Central Africa: Contact the nearest Lenovo Business
Partner
Algeria
[phone] (French, English)
Argentina
0800-666-0011 (Spanish)
Australia
131-426 (English)
Austria
01-24592-5901 (German)
Bahrain
Kanoo IT: 00 973 1771 1722
Bahrain Business Machine LLC: 00 973 1758 4302
Belgium
02-210-9820
[phone] (Warranty service and support)
(Dutch)
02-210-9800 (French)
Bolivia
0800-10-0189 (Spanish)
Brazil
Calls made from within the Sao Paulo region:
(11) 3889-8986
Calls made from outside the Sao Paulo region:
0800-701-4815
(Brazilian Portuguese)
Brunei
801-1041
(English and Bahasa Melayu)
Canada
1-800-565-3344 (English, French)
Caribbean
(Bermuda,
Jamaica, Tortola)
1-800 426 7378 (English)
Chile
800-361-213 (Spanish)
China
Technical Support Line
800-990-8888, 86-10-58851110 (Mandarin)
Colombia
1-800-912-3021 (Spanish)
Costa Rica
0-800-011-1029 (Spanish)
Croatia
0800-0426
Cyprus
80092537 (Greek)
Czech Republic
[phone]
Denmark
4520-8200
7010-5150 (Warranty service and support)
(Danish)
Dominican
Republic
1-866-434-2080 (Spanish)
Ecuador
1-800-426911 OPCION 4 (Spanish)
Egypt
800-0000-418 (Toll free)
002-02-2594-8500 (Standard charges apply)
(English, Arabic)
El Salvador
800-6264 (Spanish)
Estonia
[phone], [phone]
Finland
09-459-6960
[phone] (Warranty service and support)
(Finnish)
France
0238-557-450
Hardware: 0810-631-213 (Warranty service and
support)
Software: 0810-631-020 (Warranty service and
support)
(French)
Germany
01805-00 46 18 (Warranty service and support)
Country or region
Telephone number
(German)
Greece
0080044149702 (Greek)
Guatemala
1800-624-0051 (Spanish)
Honduras
Tegucigalpa: 232-4222
San Pedro Sula: 552-2234
(Spanish)
Hong Kong
ThinkPad (Technical enquiry hotline): 2516-3939
ThinkPad Service Center: 3140-2788
(Cantonese, English, Mandarin)
Hungary
[phone]
[phone]
(English, Hungarian)
India
1800-425-2666 or 1800-102-3692
Email: [e-mail]
(English)
Indonesia
[phone]
001-803-606-282 (Local number only)
[phone] (DID)
(English, Bahasa Indonesia)
Ireland
01-815-9202
01-881-1444 (Warranty service and support)
(English)
Israel
Givat Shmuel Service Center:
[phone]
(Hebrew and English)
Italy
02-7031-6101
[phone] (Warranty service and support)
(Italian)
Japan
0120-000-817
Jordan
Jordan Business Systems:
00 962 6 5000999 (ext. 713/127)
General Computer & Electronic (GCE):
00 962 6 551 3879
Korea
1588-6782 (Korean)
Kuwait
Easa Hussain Al Yousifi: 00 965 2244 5280
AM. KHORAFI: 00 965 2200 1100 1127
Khorafi Business Machines (KBM): 00 965 2259 4611
Diyar United Company: 00 965 4378 383
Redington Kuwait: 00 965 2433 3203, 25456250 /
25456251
Latvia
[phone]
Lebanon
Quantech: 00 961 1999 500
Computer Business Machine (CBM): 00 961 1680 180
El Haceb S.A.L: 00 961 1771 300
Lithuania
[phone]
Libya
[phone] (French, English)
Luxembourg
[phone]
[phone]
(French)
Macau
ThinkPad (Technical enquiry hotline): 0800-839
ThinkPad Service Center: 2871-5399
(Cantonese, English, Mandarin)
Malaysia
1800-88-1889 (Local number only)
[phone] (DID)
(English, Bahasa Melayu)
Malta
[phone]
Mexico
001-866-434-2080 (Spanish)
Middle East
[phone]
Morocco
[phone]
[phone]
(Arabic)
Netherlands
[phone] (Dutch)
New Zealand
0800-733-222 (English)
Nicaragua
001-800-220-1830 (Spanish)
Norway
6681-1100
8152-1550 (Warranty service and support)
(Norwegian)
Oman
Khimji Ramdas Computer Communication Systems:
Country or region
Telephone number
00 968 2469 6255
Overseas Business Machines (OBM): 00 968 2460
1072, 2460 5018
Gulf Business Machines Services (GBMS): 00 968
2455 9831
Pakistan
International Office Products (pvt) Ltd.:
00 92 212 422 569, 00 92 213 241 2023
Selling Business Systems:
00 92 21 568 9823
Panama
206-6047
001-866-434-2080 (Lenovo Customer Support Center
- Toll free)
(Spanish)
Paraguay
009-800-52-10026 (Spanish)
Peru
0-800-50-866 OPCION 2 (Spanish)
Philippines
1800-1601-0033 (Local number only)
[phone] (DID)
(English, Filipino)
Poland
[phone] (Polish)
Portugal
[phone] (Portuguese)
Qatar
Al Mana Computer Services: 00 974 4489 966 (ext.
1992)
Qatar Computer Services W.L.L: 00 974 4441 212
Gulf Business Machines: 00-974 462 1395
Romania
[phone]
Russia
8-800-555-0317 (Toll free number)
(Russian)
Saudi Arabia
8008445128 (English, Arabic)
Singapore
800 6011 343 (Local number only)
[phone] (DID)
(English)
Slovakia
[phone]
Slovenia
[phone] (Slovenian)
Spain
0901-100-000 (Spanish)
Sri Lanka
[phone], [phone] (English)
Sweden
08-477-4420
077-117-1040 (Warranty service and support)
(Swedish)
Switzerland
058-333-0900
0800-55-54-54 (Warranty service and support)
(German, French, Italian)
Taiwan
0800-000-702 (Mandarin)
Thailand
1 800-060-066 (Local number only)
66 2273 4088
[phone] (DID)
(Thai, English)
Turkey
0212 336 03 66
00800 448 825 165
(Turkish)
Ukraine
0800 502 235
(Ukrainian, Russian, English)
United Arab
Emirates
800 04447023 (English, Arabic)
United Kingdom
01475-897-163
08705-500-900 (Standard warranty support)
(English)
United States
1-800-426-7378 (Select “Option #1”)
(English)
Uruguay
000-411-005-6649 (Spanish)
Venezuela
0-800-100-2011 (Spanish)
Vietnam
For Northern Area and Hanoi City:
[phone] or [phone]
For Southern Area and Ho Chi Minh City:
[phone] or [phone]
(Vietnamese, English)
Yemen
Al Khirbash and Agencies:
00 967 1209 8278
Yemen Business Machines (YBM):

Country or region
Telephone number
00-967 3 213324,
00-967 3 214655,
00-967 3 213909
Lenovo product service information for Taiwan
Safety information
This section contains important safety information for Lenovo
products. Additional safety information is provided in the User Guide
for your product. See “Accessing your User Guide” for additional
information.
Plastic bag notice
CAUTION:
Plastic bags can be dangerous. Keep plastic bags away from
babies and children to avoid danger of suffocation.
Rechargeable battery notice (for notebook
computers)
DANGER
Do not attempt to disassemble or modify the battery pack.
Attempting to do so can cause an explosion, or liquid leakage
from the battery pack. A battery pack other than the one
specified by Lenovo, or a disassembled or modified battery pack
is not covered by the warranty.
If the rechargeable battery pack is incorrectly replaced, there is
danger of an explosion. The battery pack contains a small
amount of harmful substances. To avoid possible injury:
Replace only with a battery of the type recommended by
Lenovo.
Keep the battery pack away from fire.
Do not expose it to water or rain.
Do not attempt to disassemble it.
Do not short-circuit it.
Keep it away from children.
Do not drop the battery pack.
Do not put the battery pack in trash that is disposed of in
landfills. When disposing of the battery, comply with local
ordinances or regulations.
The battery pack should be stored at room temperature, charged
to approximately 30 to 50% of capacity. We recommend that the
battery pack be charged about once per year to prevent
overdischarge.
Lithium coin cell battery notice
DANGER
Danger of explosion if battery is incorrectly replaced.
When replacing the lithium coin cell battery, use only the same or an
equivalent type that is recommended by the manufacturer. The
battery contains lithium and can explode if not properly used, handled,
or disposed of.
Do not:
Throw or immerse into water
Heat to more than 100°C (212°F)
Repair or disassemble
Dispose of the battery as required by local ordinances or
regulations.
The following statement applies to users in the state of California,
U.S.A.
California Perchlorate Information:
Products containing manganese dioxide lithium coin cell batteries
may contain perchlorate.
Perchlorate Material - special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Polyvinyl Chloride (PVC) cable and cord notice
WARNING: Handling the cord on this product or cords associated
with accessories sold with this product will expose you to lead, a
chemical known to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash hands after handling.
Using headphones or earphones
CAUTION:
Excessive sound pressure from earphones and headphones can
cause hearing loss. Adjustment of the equalizer to maximum
increases the earphone and headphone output voltage and the
sound pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time
at high volume can be dangerous if the output of the headphone or
earphone connectors do not comply with specifications of EN 50332-2.
The headphone output connector of your computer complies with EN
50332-2 Sub clause 7. This specification limits the computer’s
maximum wide band true RMS output voltage to 150 mV. To help
protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 Limits) or
a wide band characteristic voltage of 75 mV. Using headphones that
do not comply with EN 50332-2 can be dangerous due to excessive
sound pressure levels.
If your Lenovo computer came with headphones or earphones in the
package, as a set, the combination of the headphones or earphones
and the computer already complies with the specifications of EN
50332-1. If different headphones or earphones are used, ensure that
they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous
due to excessive sound pressure levels.
Lenovo Limited Warranty notice
This product is covered by the terms of the Lenovo Limited Warranty,
version L505-0010-02 08/2011. Read the Lenovo Limited Warranty
(LLW) at http://www.lenovo.com/warranty/llw_02. You can view the
LLW in a number of languages from this Web site. The LLW also is
displayed on your computer during the initial setup. After the initial
setup has completed, you can view the warranty on your computer by
doing the following:
Windows 8:
From the desktop or the Start screen
1. Move the cursor to the top-right or bottom-right corner of the
screen to display the charms, and then click Search.
2. From the Apps screen, click Warranty Viewer.
From the Start screen
1. Click Lenovo Support. The Lenovo Support program opens.
2. Click Service & Warranty.
Windows 7:
From the Windows desktop, click Start →All Programs →Lenovo
Device Experience →Lenovo Warranty.
If you cannot view the LLW either from the Web site or from your
computer, contact your local Lenovo office or reseller to obtain a
printed version of the LLW.
Warranty Information
ThinkPad X230 and X230i
Machine
Type
Country or Region of
Purchase
Warranty Period
Type of
Warranty
Service
2320, 2324
US, Canada, Mexico,
Brazil, Australia, Japan
Parts and Labor –3
years
Battery Pack –1 year
1, 3
1
Turkey
Parts and Labor –3
years
Battery Pack –2
years
1, 4
1
Other
Parts and Labor –3
years
Battery Pack –1 year
1, 4
1
2306, 2322
US, Canada, Mexico,
Brazil, Australia, Japan
Parts and Labor –1
year
Battery Pack –1 year
1, 3
1
Turkey
Parts and Labor –2
years
Battery Pack –2
years
1, 4
1
Other
Parts and Labor –1
year
Battery Pack –1 year
1, 4
1
2325
Turkey
Parts and Labor –3
years
Battery Pack –2
years
1, 2
1
Other
Parts and Labor –3
years
Battery Pack –1 year
1, 2
1
2330
US, Canada, Mexico,
Brazil, Australia, Japan
Parts and Labor –4
years
Battery Pack –1 year
1, 3
1
Turkey
Parts and Labor –4
years
Battery Pack –2
years
1, 4
1
Other
Parts and Labor –4
years
Battery Pack –1 year
1, 4
1
2333
Turkey
Parts and Labor –4
years
Battery Pack –2
years
1, 2
1
Other
Parts and Labor –4
years
Battery Pack –1 year
1, 2
1
Note: All batteries have a one year warranty unless otherwise
specified.
Types of Warranty Service
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Service
3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Customer Two-Way Mail-in Service
7. Product Exchange Service
For a full explanation of the types of warranty service, refer to the full
warranty. See “Lenovo Limited Warranty notice” for details on
accessing the full warranty.
Suplemento de Garantía para México
Este Suplemento se considera parte integrante de la Garantía
Limitada de Lenovo y seráefectivo única y exclusivamente para los
productos distribuidos y comercializados dentro del Territorio de los
Estados Unidos Mexicanos. En caso de conflicto, se aplicarán los
términos de este Suplemento.
Todos los programas de software precargados en el equipo sólo
tendrán una garantía de treinta (30) días por defectos de instalación
desde la fecha de compra. Lenovo no es responsable de la
información incluida en dichos programas de software y/o cualquier
programa de software adicional instalado por Usted o instalado
después de la compra del producto.
Los servicios no cubiertos por la garantía se cargarán al usuario final,
previa obtención de una autorización.
En el caso de que se precise una reparación cubierta por la garantía,
por favor, llame al Centro de soporte al cliente al 001-866-434-2080,
donde le dirigirán al Centro de servicio autorizado más cercano. Si no
existiese ningún Centro de servicio autorizado en su ciudad,
población o en un radio de 70 kilómetros de su ciudad o población, la
garantía incluirácualquier gasto de entrega razonable relacionado
con el transporte del producto a su Centro de servicio autorizado más
cercano. Por favor, llame al Centro de servicio autorizado más
cercano para obtener las aprobaciones necesarias o la información
relacionada con el envío del producto y la dirección de envío.
Para obtener una lista de los Centros de servicio autorizados, por
favor, visite:
http://www.lenovo.com/mx/es/servicios
Importado por:
Lenovo México S. de R.L. de C.V.
Av. Santa Fe 505, Piso 15
Col. Cruz Manca
Cuajimalpa, D.F., México
C.P. 05349
Tel. [phone]
Customer Replaceable Units
Customer Replaceable Units (CRUs) are parts that can be upgraded
or replaced by the customer. If a CRU is determined to be defective
during the warranty period, a replacement CRU will be provided to the
customer. Customers are responsible for installing the self-service
CRUs for this product. Customers also can install optional-service
CRUs, which might require some technical skills or tools, or request
that a technician install the optional-service CRU under the terms of
the applicable warranty service type for your country or region. The
following tables list CRUs for your computer and tell where to find the
replacement instructions.
Self-service CRUs
CRU
This setup
sheet
User Guide
ac power adapter
X
X
Power cord for ac power adapter
X
X
Battery
X
X
Keyboard
X
Memory module
X
TrackPoint®cap
X
Hard disk drive
X
Solid state drive
X
Optional-service CRUs
CRU
This setup
sheet
User Guide
Backup battery
X
Palm rest
X
Speaker
X
Note: Your computer might not have the PCI Express Mini Card for
wireless WAN or PCI Express Mini Card for wireless LAN.
CRU installation instructions are provided in the User Guide for your
product. See “Accessing your User Guide” and “Downloading
publications” for additional information.
Electronic emission notices
This device has been tested and found to comply with the limits for a
Class B digital device. The User Guide for this product provides the
complete Class B compliance statements that are applicable for this
device. See “Accessing your User Guide” for additional information.
Korean Class B compliance statement
European Union conformity
Radio and Telecommunications Terminal
Equipment Directive
This product is in compliance with the essential requirements and
other relevant provisions of the Radio and Telecommunications
Terminal Equipment Directive, 1999/5/EC. The Declaration of
Conformity information is located in the Regulatory Notice, which you
can download from the Lenovo Support Web site. See “Downloading
publications” for additional information.
When attaching an external monitor
If you attach an external monitor, a video interface cable with a ferrite
core installed on the cable is required.
Recycling and environmental information
Lenovo encourages owners of information technology (IT) equipment
to responsibly recycle their equipment when it is no longer needed.
Lenovo offers a variety of programs and services to assist equipment
owners in recycling their IT products. For information on recycling
Lenovo products, go to:
http://www.lenovo.com/recycling
Important WEEE information
Country-specific information is available at:
http://www.lenovo.com/recycling
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://www.lenovo.com/recycling/japan
Recycling information for China
Additional recycling statements
Additional information about recycling computer components and
batteries is in your User Guide. See “Accessing your User Guide” for
details.
Restriction of Hazardous Substances Directive
(RoHS)
China RoHS
The information in the following table is applicable for products
manufactured on or after March 1, 2007 for sale in the People’s
Republic of China.
Turkish RoHS
The Lenovo product meets the requirements of the Republic of
Turkey Directive on the Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment (EEE).
Ukraine RoHS
India RoHS
RoHS compliant as per E-Waste (Management & Handling) Rules,
2011.
ENERGY STAR
Select models conform to ENERGY
STAR requirements. Additional
ENERGY STAR information is in your
User Guide. See “Accessing your User
Guide.”
Legal notices
Lenovo, For Those Who Do., the Lenovo logo, ThinkLight, ThinkPad,
TrackPoint, and UltraConnect are trademarks of Lenovo in the United
States, other countries, or both.
Windows is a trademark of the Microsoft group of companies.
Other company, product, or service names may be trademarks or
service marks of others.
For additional legal notices, refer to the User Guide for your computer.
See "Accessing your User Guide" for additional information.
