Lenovo Mirage Solo User manual

Mirage Solo with Daydream
User Guide

Content
Basics............................................................................................................................................................................................3
Play area..................................................................................................................................................................................... 4
Setting up a safe play area for VR.............................................................................................................................. 4
Getting Started.........................................................................................................................................................................5
Charging..................................................................................................................................................................................5
Putting on your headset...................................................................................................................................................5
Pairing your controller ..................................................................................................................................................... 6
Connecting to the Internet............................................................................................................................................. 6
Selecting items.....................................................................................................................................................................7
Managing the settings of your device........................................................................................................................... 8
Opening VR settings......................................................................................................................................................... 8
Changing settings .............................................................................................................................................................. 8
Notes ....................................................................................................................................................................................... 8
Re-centering your view & cursor..................................................................................................................................... 9
Syncing ....................................................................................................................................................................................... 9
Safety instructions for parents and adult supervisors ........................................................................................... 9
Health warnings .....................................................................................................................................................................10
Pre-existing health conditions.....................................................................................................................................10
Seizures .................................................................................................................................................................................10
Motion sickness..................................................................................................................................................................10
Repetitive strain injuries and eyestrain....................................................................................................................10
Physiological and psychological effects .................................................................................................................. 11
Appendix................................................................................................................................................................................... 12
Important safety and handling information........................................................................................................... 12
Electronic emission notices ..........................................................................................................................................14
Environmental, recycling, and disposal information.......................................................................................... 15
Export classification notice...........................................................................................................................................16

Basics
Before using this information and the product it supports, be sure to read the following:

Quick Start Guide and Safety & Warranty

Regulatory Notice

Important safety and handling information in Appendix
This device contains labels to indicate physical tampering or liquid damage. If evidence of tampering or liquid damage is
found during service, this will void the terms of the product warranty.
The Safety, Warranty & Quick Start Guide and the Regulatory Notice are available at http://support.lenovo.com.
NOTE: All pictures and illustrations in this document are for reference only and may differ from the actual product.

Play area
Setting up a safe play area for VR
Clear the area directly around you of objects and furniture and always stay aware of your physical surroundings!
Put the device on your head in the center of your clear area whether seated or standing.
Always check your physical space by lifting the headset or partially lifting it and peaking to make sure you are still in your
clear area before you start a session or manually recenter your view.
When you put the device on your head or when you manually recenter using the controller the device will use your
position at that moment as the starting point and fade your view to prevent accidental walking if you move too far from
this starting point.
Your view will fade anytime you move close to your arms distance away from your starting point. This play area is
approximately 0.8 m in radius but you will see your view gently start to fade after about 0.4 m of movement toward the
edge. When you notice your view starting to fade carefully move back towards the center of your clear area.
If you exit the safe play area, your view will be fully occluded. Carefully move back towards your original starting point
while being aware of your surroundings.
Listen to all warnings in the headset and always stay aware of your physical surroundings.
Tell friends or family that when you’re in VR you won’t be aware of their presence and for them to stay a safe distance
away.
Do not start sessions outside, near stairwells, drops or dangerous objects or environments. When you are in VR you are
effectively asleep to the real world. Consider if the chosen play space is a place where you would feel comfortable falling
asleep.

Getting Started
Charging
You may need to charge your headset and controller before using them. Insert the charger into the charging port.
Putting on your headset
1. Press and hold the Power button until the LED indicator lights up. You can connect the headphones to the headset
before use.
2. To ensure the clearest possible view, first make sure the lower part of the headset is pressed firmly against your face.
Then, turn the upper part of the headset in the direction of the arrow until your forehead is resting against the foam
cushioning.
3. Place the headset over your head so that it completely covers your eyes. Make sure you can see the screen clearly.
4. Adjust your headset for a better fit. Turn the adjustable dial until the headset fits firmly on your head.

5. Press and hold the Quick release button and move the lenses forwards or backwards until you can see the screen
clearly. Make sure the headset rests comfortably against your forehead and face.
Pairing your controller
During setup, you will be asked to pair your controller. Have your controller with you and follow the on-screen steps. Use
the controller to interact with objects in the VR world.
Note
: If your controller is not paired to your headset, do the following:
Check that the controller is charged
The controller may be paired to another device. If so, plug in the charger. Press and hold both the daydream button
and app button, and unplug the charger. You may now try re-pairing.
Connecting to the Internet
1. Click and turn on the WLAN switch.
2. Select an available WLAN network from the list to connect to the internet.
3. Sign in with your Google Account.

Selecting items
1. Move your controller to point the cursor at an item.
2. Click on the touchpad to select the item.
3. Click to bring up the app menu.
4. Click to go to the home screen.

Managing the settings of your device
Opening VR settings
1. Go to the settings bar.
2. On the right side, tap
.
Changing settings
Pairing a Daydream controller
During setup, you will be asked to pair your controller. Have your controller with you and follow the on-screen steps. Use
the controller to interact with objects in the VR world.
Switching between left and right-handed control mode
Go to > to select your preference.
Changing the keyboard language
Go to
> ALL SETTINGS > System > Languages, input & gestures > Languages > Add a language
and select a
language.
Changing notifications in VR
Go to
> ALL SETTINGS > Apps & notifications > Notifications
to select the kinds of notifications you want to
receive while in VR and when they appear.
Notes
You don't need to turn off your controller when you leave VR. It disconnects automatically to save battery.
The battery can’t be removed. Don’t attempt to open the controller.
The charger varies by country or region.

Re-centering your view & cursor
You should re-center your cursor in the following cases:
You need to turn your head to see part of the screen.
The cursor isn’t pointing in the same direction as your Daydream controller.
You can’t find your cursor.
You can't see the menu or the cursor.
In VR, you can re-center whenever you want, including when you're using an app, playing a game, watching a movie, or in
Daydream Home.
1. Look in the direction you want to face.
2. Point your Daydream controller (not the cursor) forward in the same direction.
3. Press and hold the Daydream button for a few seconds.
Syncing
You can transfer data, such as music, pictures, videos, and documents, between your Mirage Solo with Daydream and
other devices.
Transferring data to your Mirage Solo
You can transfer data to your Mirage Solo by following these steps:
1. Copy the files you want to transfer to a microSD card.
2. Insert the microSD card into the card slot in your Mirage Solo with Daydream.
3. Go to
> ALL SETTINGS > Storage > PHONE CARD
, and find the file you want to transfer.
4. Tap and hold the file until it is selected.
5. Tap to select your preferred option.
Note
: You can't transfer data by connecting your headset to a computer.
Safety instructions for parents and adult supervisors
Your mobile device is not a toy. Not recommended for children under 14 years of age to play with it. As with all electrical
products, precautions should be observed during handling and using of electrical products to reduce the risk of electric
shock.
If parents choose to allow children 14 or older to use the device, they should caution his or her child about the potential
hazard while using and handling the mobile device.
Parents should inspect the mobile device (including the ac power adapter and the small part, as applicable) periodically
for damage. Routinely check this mobile device to ensure that the device is working properly and is safe for children to
use.

Health warnings
Pre-existing health conditions
Consult your doctor before using the product if you have any pre-existing medical conditions that may prevent you from
having a safe VR experience. Such conditions include heart-and blood pressure-related ailments, and psychiatric disorders
such as anxiety or post-traumatic stress. Pregnant or elderly individuals should also consult a physician before using the
product.
Do not use the product if you are sick, tired, under the influence of drugs, alcohol or other intoxicants, or if you are feeling
generally unwell. Use under these conditions may exacerbate any symptoms you are already experiencing.
Seizures
This product produces visual effects which include flashing lights. A small percentage of individuals may experience
seizures, epileptic seizures, fainting, or severe dizziness when exposed to flashing lights or to certain light patterns,
including people who have no history of these conditions. If you have a previous history of epilepsy, seizures, loss of
awareness, or other symptoms linked to an epileptic condition, consult your doctor before using this product. Do not use
the product if you are tired.
If you are supervising or watching someone else using the product, immediately stop them and consult a doctor if they
experience any of the following:
•Convulsions
•Involuntary movements such as eye or muscle twitching
•Fainting or loss of awareness
•Disorientation
•Altered vision
Motion sickness
VR products can cause motion sickness for some users. If you or anybody else using the product feel dizzy or become
nauseous while playing, stop using the product and rest. Avoid operating heavy machinery, driving, or taking part in
strenuous activities while symptoms persist.
Repetitive strain injuries and eyestrain
Follow these guidelines to avoid problems such as skin irritation, carpal tunnel syndrome, tendinitis, or eyestrain:
Take regular breaks. Stretch your arms and legs and move about during this break to ensure proper circulation. The
required length and frequency of breaks may vary for individuals. Avoid playing for too long. Over-exertion and
fatigue increases the risk of injury.
If your limbs, body, or eyes become sore or tired, or if you experience burning, numbness, stiffness, or tingling during
use, stop and rest for a few hours before trying again.
Make sure your skin stays clean and dry when using the product. Stop using the product if you experience any itching,
swelling, eczema, or irritation of the skin.
If any of the above conditions or other conditions persist after use, stop using the product and consult your doctor.
