Lenovo System x3850 X6 Installation and maintenance instructions

System x3850 X6 and x3950 X6
Installation and Service Guide
Machine Type: 6241

Note
Be ore using this in ormation and the product it supports, read the general in ormation in Appendix F
“Notices” on page 1955 and the Safety Information, and Environmental Notices and User's Guide, and the
Warranty document that comes with the server.
Thirteenth Edition (May 2019)
© Copyright Lenovo 2014, 2019
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No
GS-35F-05925

Contents
Safety v
Sa ety statements . . . . . . . . . . . . . . . vi
Chapter 1 The Lenovo System
x3850 X6 and x3950 X6 Type 6241
server 1
Related documentation . . . . . . . . . . . . . 4
Notices and statements in this document. . . . . . 5
Server eatures and speci ications . . . . . . . . 5
What your server o ers . . . . . . . . . . . . 12
Reliability, availability, and serviceability . . . . . 17
Server scalability . . . . . . . . . . . . . . 19
FlexNode support . . . . . . . . . . . . . . 19
Lenovo XClarity Administrator . . . . . . . . . 20
Server components . . . . . . . . . . . . . 22
Front view o the server . . . . . . . . . . 24
Rear view o the server . . . . . . . . . . 31
Jumpers, switches, and buttons on standard
I/O book board . . . . . . . . . . . . . 37
Server power eatures . . . . . . . . . . 39
x3950 X6 4-socket to 8-socket upgrade kit . . . . 41
Chapter 2 Installing optional
devices 43
Instructions or Business Partners. . . . . . . . 43
How to send DSA data . . . . . . . . . . . . 44
Installation guidelines . . . . . . . . . . . . 44
System reliability guidelines . . . . . . . . 45
Handling static-sensitive devices . . . . . . 46
Installing a memory module . . . . . . . . . . 46
eXFlash DIMMs . . . . . . . . . . . . . 50
Memory mirroring . . . . . . . . . . . . 52
Memory rank sparing . . . . . . . . . . . 52
Independent memory mode . . . . . . . . 53
Lockstep memory mode . . . . . . . . . 57
DIMM installation instructions . . . . . . . 59
Installing a compute book . . . . . . . . . . . 63
Installing drives . . . . . . . . . . . . . . . 66
Drive IDs. . . . . . . . . . . . . . . . 67
Supported drive backplane con igurations . . 69
Installing 2.5-inch and 1.8-inch hot-swap
drives . . . . . . . . . . . . . . . . . 76
Installing the hal -length and ull-length I/O
books. . . . . . . . . . . . . . . . . . . 78
Installing the hal -length I/O book . . . . . . 79
Installing the ull-length I/O book . . . . . . 80
Installing an adapter . . . . . . . . . . . . . 83
Supported adapters and Features on Demand
so tware . . . . . . . . . . . . . . . . 85
Installing an adapter in the standard or hal -
length I/O book . . . . . . . . . . . . . 90
Installing an adapter in the ull-length I/O
book . . . . . . . . . . . . . . . . . 91
Installing speci ic optional adapters . . . . . 93
Installing a RAID cache card . . . . . . . . . . 97
Installing a RAID adapter lash power module in
the storage book . . . . . . . . . . . . . . 97
Installing a RAID adapter lash power module in
the standard I/O book . . . . . . . . . . . . 98
Installing power supplies . . . . . . . . . . . 100
Installing a 750-watt -48 volt to -60 volt dc
power supply . . . . . . . . . . . . . . 102
Installing a 1400-watt or 900-watt hot-swap
power supply . . . . . . . . . . . . . . 107
Installing a USB embedded hypervisor lash
device . . . . . . . . . . . . . . . . . . 110
Installing the drive backplanes . . . . . . . . . 111
Installing the 8x1.8-inch hot-swap drive
backplane assembly . . . . . . . . . . . 111
Installing the 4x2.5-inch hot-swap drive
backplane . . . . . . . . . . . . . . . 112
Installing the 4x2.5-inch NVMe PCIe Gen3
solid state drive backplane. . . . . . . . . 115
Completing the installation . . . . . . . . . . 117
Updating the server con iguration . . . . . . 117
Chapter 3 Configuration information
and instructions 119
Updating the irmware . . . . . . . . . . . . 119
Con iguring the server . . . . . . . . . . . . 120
Using the ServerGuide Setup and Installation
DVD . . . . . . . . . . . . . . . . . 121
Using the Setup utility . . . . . . . . . . 123
Using the Boot Manager . . . . . . . . . 129
Starting the backup server irmware . . . . . 130
The UpdateXpress System Pack Installer . . . 130
Con iguring a multinode system. . . . . . . 131
Using the integrated management module . . 133
Setting power supply power policy and
system power con igurations . . . . . . . . 137
Using the embedded hypervisor so tware . . . 138
Con iguring the Ethernet controller . . . . . 139
Enabling Features on Demand Ethernet
so tware . . . . . . . . . . . . . . . . 139
Enabling Features on Demand RAID
so tware . . . . . . . . . . . . . . . . 139
Con iguring RAID arrays. . . . . . . . . . 140
© Copyright Lenovo 2014, 2019 i

Advanced Settings Utility program. . . . . . 140
Updating the Universal Unique Identi ier and
DMI/SMBIOS data . . . . . . . . . . . . 140
Chapter 4 Troubleshooting 145
Start here . . . . . . . . . . . . . . . . . 145
Diagnosing a problem . . . . . . . . . . 145
Undocumented problems . . . . . . . . . 147
Service bulletins . . . . . . . . . . . . . . 147
Checkout procedure . . . . . . . . . . . . . 148
About the checkout procedure . . . . . . . 148
Per orming the checkout procedure . . . . . 149
Diagnostic tools. . . . . . . . . . . . . . . 150
Light path diagnostics . . . . . . . . . . 152
Event logs . . . . . . . . . . . . . . . 161
POST . . . . . . . . . . . . . . . . . 164
Dynamic System Analysis program . . . . . 164
Automated service request (call home) . . . . . . 167
Service Advisor eature . . . . . . . . . . 167
Electronic Service Agent . . . . . . . . . 167
Error messages . . . . . . . . . . . . . . . 168
Troubleshooting by symptom . . . . . . . . . 170
Connectivity problems . . . . . . . . . . 171
General problems . . . . . . . . . . . . 173
Hard disk drive problems . . . . . . . . . 173
Hypervisor problems . . . . . . . . . . . 177
Intermittent problems. . . . . . . . . . . 178
Keyboard, mouse, or pointing-device
problems . . . . . . . . . . . . . . . 179
Memory problems . . . . . . . . . . . . 180
Microprocessor problems . . . . . . . . . 181
Monitor and video problems . . . . . . . . 181
Network connectivity problems . . . . . . . 182
Observable problems. . . . . . . . . . . 184
Optional-device problems . . . . . . . . . 186
Power problems. . . . . . . . . . . . . 187
Serial-device problems . . . . . . . . . . 189
ServerGuide problems . . . . . . . . . . 189
Server startup problems. . . . . . . . . . 191
So tware problems. . . . . . . . . . . . 193
Universal Serial Bus (USB) port problems . . . 193
Video problems . . . . . . . . . . . . . 194
Solving power problems . . . . . . . . . . . 194
Solving Ethernet controller problems . . . . . . 194
Solving undetermined problems . . . . . . . . 195
Problem determination tips . . . . . . . . . . 195
Recovering rom a UEFI update ailure or UEFI
image corruption . . . . . . . . . . . . . . 197
Automated boot recovery (ABR) . . . . . . . . 199
Nx boot ailure . . . . . . . . . . . . . . . 199
Chapter 5 Parts listing, System x3850 X6
and x3950 X6 Type 6241 201
Replaceable server components . . . . . . . . 201
Consumable parts . . . . . . . . . . . . 218
Power cords . . . . . . . . . . . . . . . . 219
Chapter 6 Removing and replacing
components 221
Returning a device or component . . . . . . . . 221
Removing and replacing server components . . . 221
Removing and replacing consumable
parts . . . . . . . . . . . . . . . . . 221
Removing and replacing Tier 1 CRUs . . . . 222
Removing and replacing Tier 2 CRUs . . . . 273
Removing and replacing FRUs . . . . . . . 284
Appendix A LCD display panel
messages 339
Appendix B DSA diagnostic test
results 345
DSA Broadcom network test results . . . . . . . 345
Test results or the DSA Broadcom network
test . . . . . . . . . . . . . . . . . . 345
DSA Brocade test results . . . . . . . . . . . 353
Test results or the DSA Brocade test . . . . 353
DSA checkpoint panel test results . . . . . . . 361
Test results or the DSA checkpoint panel
test . . . . . . . . . . . . . . . . . . 361
DSA CPU stress test results . . . . . . . . . . 362
Test results or the DSA CPU stress test . . . 362
DSA Emulex adapter test results . . . . . . . . 365
Test results or the DSA Emulex adapter
test . . . . . . . . . . . . . . . . . . 365
DSA EXA port ping test results . . . . . . . . . 368
Test results or the DSA EXA port ping test . . 368
DSA hard drive test results . . . . . . . . . . 370
Test results or the DSA hard drive test . . . . 370
DSA Intel network test results . . . . . . . . . 371
Test results or the DSA Intel network test . . . 371
DSA LSI hard drive test results . . . . . . . . . 377
Test results or the DSA LSI hard drive test . . 377
DSA Mellanox adapter test results . . . . . . . 378
Test results or the DSA Mellanox adapter
test . . . . . . . . . . . . . . . . . . 378
DSA memory isolation test results. . . . . . . . 380
Test results or the DSA memory isolation
test . . . . . . . . . . . . . . . . . . 380
DSA memory stress test results . . . . . . . . 445
Test results or the DSA memory stress
test . . . . . . . . . . . . . . . . . . 446
DSA Nvidia GPU test results . . . . . . . . . . 448
ii System x3850 X6 and x3950 X6 Installation and Service Guide

Test results or the DSA Nvidia GPU test . . . 448
DSA optical drive test results . . . . . . . . . 454
Test results or the DSA optical drive test . . . 454
DSA system management test results . . . . . . 458
Test results or the DSA system management
test . . . . . . . . . . . . . . . . . . 458
DSA tape drive test results . . . . . . . . . . 470
Test results or the DSA tape drive test . . . . 470
Appendix C Integrated management
module II (IMM2) error messages 475
List o IMM events . . . . . . . . . . . . . . 476
IMM Events that automatically noti y Support . . 1891
Appendix D UEFI/POST error
codes 1925
Finding the UEFI (POST) error code . . . . . . 1925
List o UEFI events. . . . . . . . . . . . . 1926
Appendix E Getting help and
technical assistance 1951
Be ore you call . . . . . . . . . . . . . . 1951
Using the documentation . . . . . . . . . . 1952
Getting help and in ormation rom the World Wide
Web . . . . . . . . . . . . . . . . . . 1952
How to send DSA data . . . . . . . . . . . 1952
Creating a personalized support web page . . . 1952
So tware service and support . . . . . . . . 1953
Hardware service and support . . . . . . . . 1953
Taiwan product service . . . . . . . . . . . 1953
Appendix F Notices 1955
Trademarks . . . . . . . . . . . . . . . 1956
Important notes . . . . . . . . . . . . . . 1956
Recycling in ormation . . . . . . . . . . . 1956
Particulate contamination . . . . . . . . . . 1957
Telecommunication regulatory statement. . . . 1957
Electronic emission notices . . . . . . . . . 1958
Federal Communications Commission (FCC)
statement . . . . . . . . . . . . . . 1958
Industry Canada Class A emission compliance
statement . . . . . . . . . . . . . . 1958
Avis de con ormité à la réglementation
d'Industrie Canada. . . . . . . . . . . 1958
Australia and New Zealand Class A
statement . . . . . . . . . . . . . . 1958
European Union EMC Directive con ormance
statement . . . . . . . . . . . . . . 1958
Germany Class A statement . . . . . . . 1959
Japanese electromagnetic compatibility
statements . . . . . . . . . . . . . . 1960
Korea Communications Commission (KCC)
statement . . . . . . . . . . . . . . 1960
Russia Electromagnetic Inter erence (EMI)
Class A statement . . . . . . . . . . . 1960
People's Republic o China Class A electronic
emission statement . . . . . . . . . . 1960
Taiwan Class A compliance statement . . . 1961
Taiwan BSMI RoHS declaration. . . . . . 1962
Index 1963
© Copyright Lenovo 2014, 2019 iii

iv System x3850 X6 and x3950 X6 Installation and Service Guide

Safety
Be ore installing this product, read the Sa ety In ormation.
Antes de instalar este produto, leia as In ormações de Segurança.
Læs sikkerheds orskri terne, ør du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschri ten.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Sa ety In ormation.
Avant d'installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le In ormazioni sulla Sicurezza.
Les sikkerhetsin ormasjonen (Sa ety In ormation) ør du installerer dette produktet.
© Copyright Lenovo 2014, 2019 v

Antes de instalar este produto, leia as In ormações sobre Segurança.
Antes de instalar este producto, lea la in ormación de seguridad.
Läs säkerhetsin ormationen innan du installerar den här produkten.
Safety statements
These statements provide the caution and danger in ormation that is used in this documentation.
Important: Each caution and danger statement in this documentation is labeled with a number. This number
is used to cross re erence an English-language caution or danger statement with translated versions o the
caution or danger statement in the Safety Information document.
For example, i a caution statement is labeled Statement 1, translations or that caution statement are in the
Safety Information document under Statement 1.
Be sure to read all caution and danger statements in this documentation be ore you per orm the procedures.
Read any additional sa ety in ormation that comes with your system or optional device be ore you install the
device.
vi System x3850 X6 and x3950 X6 Installation and Service Guide

Statement 1
DANGER
Electrical current from power, telephone, and communication cables is hazardous
To avoid a shock hazard:
• Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm
• Connect all power cords to a properly wired and grounded electrical outlet
• Connect to properly wired outlets any equipment that will be attached to this product
• When possible, use one hand only to connect or disconnect signal cables
• Never turn on any equipment when there is evidence of fire, water, or structural damage
• Disconnect the attached power cords, telecommunications systems, networks, and modems
before you open the device covers, unless instructed otherwise in the installation and
configuration procedures
• Connect and disconnect cables as described in the following table when installing, moving, or
opening covers on this product or attached devices
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords rom outlet.
3. Remove signal cables rom connectors.
4. Remove all cables rom devices.
Statement 2
CAUTION:
When replacing the lithium battery, use only Part Number 33F8354 or an equivalent type battery
recommended by the manufacturer If your system has a module containing a lithium battery, replace
it only with the same module type made by the same manufacturer The battery contains lithium and
can explode if not properly used, handled, or disposed of Do not:
• Throw or immerse into water
• Heat to more than 100°C (212°F)
• Repair or disassemble
Dispose of the battery as required by local ordinances or regulations
© Copyright Lenovo 2014, 2019 vii

Statement 3
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are
installed, note the following:
• Do not remove the covers Removing the covers of the laser product could result in exposure to
hazardous laser radiation There are no serviceable parts inside the device
• Use of controls or adjustments or performance of procedures other than those specified herein
might result in hazardous radiation exposure
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser diode Note the following
Laser radiation when open Do not stare into the beam, do not view directly with optical
instruments, and avoid direct exposure to the beam
Statement 4
CAUTION: Use safe practices when lifting
≥ 18 kg (39.7 lb) ≥ 32 kg (70.5 lb) ≥ 55 kg (121.2 lb)
viii System x3850 X6 and x3950 X6 Installation and Service Guide

Statement 5
CAUTION:
The power control button on the device and the power switch on the power supply do not turn off the
electrical current supplied to the device The device also might have more than one power cord To
remove all electrical current from the device, ensure that all power cords are disconnected from the
power source
Statement 6
CAUTION:
If you install a strain-relief bracket option over the end of the power cord that is connected to the
device, you must connect the other end of the power cord to an easily accessible power source
Statement 8
CAUTION:
Never remove the cover on a power supply or any part that has the following label attached
Hazardous voltage, current, and energy levels are present inside any component that has this label
attached There are no serviceable parts inside these components If you suspect a problem with one
of these parts, contact a service technician
© Copyright Lenovo 2014, 2019 ix

Statement 12
CAUTION:
The following label indicates a hot surface nearby
Statement 19
CAUTION:
The power-control button on the device does not turn off the electrical current supplied to the device
The device also might have more than one connection to dc power To remove all electrical current
from the device, ensure that all connections to dc power are disconnected at the dc power input
terminals
Statement 26
CAUTION:
Do not place any object on top of rack-mounted devices
xSystem x3850 X6 and x3950 X6 Installation and Service Guide

Statement 31
DANGER
Electrical current from power, telephone, and communication cables is hazardous
To avoid a shock hazard:
• Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm
• Connect all power cords to a properly wired and grounded power source
• Connect to properly wired power sources any equipment that will be attached to this product
• When possible, use one hand only to connect or disconnect signal cables
• Never turn on any equipment when there is evidence of fire, water, or structural damage
• Disconnect the attached ac power cords, dc power sources, network connections,
telecommunications systems, and serial cables before you open the device covers, unless you
are instructed otherwise in the installation and configuration procedures
• Connect and disconnect cables as described in the following table when you install, move, or
open covers on this product or attached devices
To Connect: To Disconnect:
1. Turn OFF all power sources and equipment that is to
be attached to this product.
2. Attach signal cables to the product.
3. Attach power cords to the product.
• For ac systems, use appliance inlets.
• For dc systems, ensure correct polarity o -48 V dc
connections: RTN is + and -48 V dc is -. Earth
ground should use a two-hole lug or sa ety.
4. Attach signal cables to other devices.
5. Connect power cords to their sources.
6. Turn ON all the power sources.
1. Turn OFF all power sources and equipment that is to
be attached to this product.
• For ac systems, remove all power cords rom the
chassis power receptacles or interrupt power at
the ac power distribution unit.
• For dc systems, disconnect dc power sources at
the breaker panel or by turning o the power
source. Then, remove the dc cables.
2. Remove the signal cables rom the connectors.
3. Remove all cables rom the devices.
© Copyright Lenovo 2014, 2019 xi

Statement 34
CAUTION:
To reduce the risk of electric shock or energy hazards:
• This equipment must be installed by trained service personnel in a restricted-access location, as
defined by the NEC and IEC 60950-1, First Edition, The Standard for Safety of Information
Technology Equipment
• Connect the equipment to a properly grounded safety extra low voltage (SELV) source A SELV
source is a secondary circuit that is designed so that normal and single fault conditions do not
cause the voltages to exceed a safe level (60 V direct current)
• Incorporate a readily available approved and rated disconnect device in the field wiring
• See the specifications in the product documentation for the required circuit-breaker rating for
branch circuit overcurrent protection
• Use copper wire conductors only See the specifications in the product documentation for the
required wire size
• See the specifications in the product documentation for the required torque values for the wiring-
terminal screws
>240VA
Statement 35:
CAUTION:
Hazardous energy present.Voltages with hazardous energy
might cause heating when shorted with metal, which might
result in splattered metal, burns, or both.
The 8U version o the server is intended or use in a system/rack always installed on the load side o a Power
Distribution Unit (PDU) or Uninterruptible Power Supply (UPS) supplying a maximum 20 A branch circuit
protection. The overall system/rack connection to mains power is to be a Pluggable Type B connector.
This server is suitable or use on an IT power-distribution system whose maximum phase-to-phase voltage is
240 V under any distribution ault condition.
Important: Maschinenlärmin ormations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel beträgt 70
dB(A) oder weniger.
The product is not suitable or use at visual display workplaces according to §2 o the German Ordinance or
Work with Visual Display Units. Das Produkt ist nicht ür den Einsatz an Bildschirmarbeitsplätzen im Sinne §
2 der Bildschirmarbeitsverordnung geeignet.
xii System x3850 X6 and x3950 X6 Installation and Service Guide

Chapter 1 The Lenovo System x3850 X6 and x3950 X6 Type
6241 server
Use this in ormation or a product overview o the Lenovo® System x3850 X6 and x3950 X6 server and links
to additional in ormation or users o the system and Business Partners. Read the sa ety in ormation be ore
installing and removing components in the server.
Note: This documentation includes re erences to IBM® web sites, products, and in ormation about
obtaining service. IBM is Lenovo's pre erred service provider or the Lenovo System x products.
The in ormation in this document provides instructions and in ormation or setting up your Lenovo System
x3850 X6 and x3950 X6 Type 6241 server, instructions or installing some optional devices, cabling and
con iguring the server, removing and replacing devices, and diagnostics and troubleshooting in ormation.
Note: The in ormation and installation procedures in this documentation apply to both the 4-socket and the
8-socket con igurations o the server, unless otherwise speci ied. Most o the illustrations in the
documentation show the 4-socket con iguration o the server.
In addition to the instructions in Chapter 2 “Installing optional devices” on page 43 or installing optional
hardware devices, updating irmware and device drivers, and completing the installation, Business Partners
must also complete the steps in “Instructions or Business Partners” on page 43.
The Lenovo System x3850 X6 and x3950 X6 server is a rack model, modular design server, or virtualization,
database, and computational intensive computing. The modular design allows or upgrade rom a 4-socket
(4U-high) to an 8-socket (8U-high) server, using the same building blocks that are used or the 4-socket
server. It is the next generation enterprise server based on the Intel Xeon™ EX E7-4xxx v2/v3/v4 and E7-
8xxx v2/v3/v4 processor technology. This high-per ormance, scalable server is ideally suited or enterprise
environments that require superior input/output (I/O) lexibility and high manageability.
Note: You must purchase the x3950 X6 4-socket to 8-socket Upgrade kit to upgrade to an 8-socket server.
In addition, the upgrade must be per ormed by a Lenovo approved warranty service provider.
Per ormance, ease o use, reliability, and expansion capabilities were key considerations in the design o the
server. These design eatures make it possible or you to customize the system hardware to meet your needs
today and provide lexible expansion capabilities or the uture.
The server comes with a limited warranty. For in ormation about the terms o the warranty and getting service
and assistance, see the Lenovo Warranty document that comes with the server.
The server contains next generation technologies, which help increase per ormance and reliability. For more
in ormation, see “What your server o ers” on page 12 and “Reliability, availability, and serviceability” on
page 17.
You can obtain up-to-date in ormation about the server and other Lenovo server products at http://
www.lenovo.com/data-center/. At http://datacentersupport.lenovo.com/, you can create a personalized support
page by identi ying Lenovo products that are o interest to you. From this personalized page, you can
subscribe to weekly email noti ications about new technical documents, search or in ormation and
downloads, and access various administrative services.
The server supports up to eight 2.5-inch hot-swap drives or sixteen 1.8-inch hot-swap drives, or a
combination o both 2.5-inch and 1.8-inch drives, using the supported drive backplanes. It supports 2.5-inch
hot-swap Serial Attached SCSI (SAS) or SATA hard disk drives, 2.5-inch hot-swap SATA solid state drives
(SSD), or 1.8-inch hot-swap SAS solid state drives. See “Supported drive backplane con igurations” on page
© Copyright Lenovo 2014, 2019 1

69 or a complete list o the supported con igurations. The illustrations in this document might di er slightly
rom your hardware.
The ollowing illustration shows the ront o the server.
Fan-pack 1
Fan-pack 2 Fan-pack 4 Fan-pack 6 Fan-pack 8
Storage
book Compute book 1 Compute book 2 Compute book 3 Compute book 4
Fan-pack 3 Fan-pack 5 Fan-pack 7
LCD display
panel
Front
operator
panel
Service
card
The ollowing illustration shows the rear o the server.
Power supply 1 Power supply 2 Power supply 3 Power supply 4
Fan-pack 9 Fan-pack 10I/O book 1 I/O book 2 Standard I/O book
I irmware and documentation updates are available, you can download them rom the World Wide Web.
The server might have eatures that are not described in the documentation that comes with the server, and
the documentation might be updated occasionally to include in ormation about those eatures, or technical
updates might be available to provide additional in ormation that is not included in the server documentation.
To check or irmware updates, go to http://datacentersupport.lenovo.com/ and or documentation updates
the https://systemx.lenovo iles.com/help/topic/com.lenovo.systemx.common.nav.doc/ic-homepage.html.
Record in ormation about the server in the ollowing table.
Table . Record of the system information
Product name Machine Type (s) Model number Serial number
Lenovo System x3850 X6
and x3950 X6
Type 6241 (record the model here) (record the serial number
here)
2System x3850 X6 and x3950 X6 Installation and Service Guide

The model number and serial number are on the ID label on the ront o the server, as shown in the ollowing
illustrations. You can also add other system in ormation labels to the ront o the server in the customer label
spaces.
Note: The illustrations in this document might di er slightly rom your hardware.
Machine type and
model number
Customer
label space
Customer
label space
Machine type and
model number
Customer
label space
Customer
label space
QR Codes
In addition, the system Service Card that is located between the le t EIA bracket and the X6 Storage Book in
the ront o the server, provides a quick re erence (QR) code or mobile access to service in ormation. You
can scan the QR code with a mobile device using a QR code reader application and get quick access to the
Chapter 1.The Lenovo System x3850 X6 and x3950 X6 Type 6241 server 3

Service In ormation Web page. The Service In ormation Web page provides additional in ormation or parts
installation and replacement videos, and error codes or server support.
The ollowing illustration shows the location o the server Service Card, which contains the QR code. To
remove the Service Card, grasp the blue tab and pull the card out.
QR code
Service
Information
http://ibm.co/17uSjYn
USB 2.0
Connector
BRD
12
11
LCD Display
Power
Button/
LED
Reset
Button
System
Error
LED
System
Identification
Button/LED
Check
Log
LED
Internal
PCIe
Slot 11
Error LED
Internal
PCIe
Slot 12
Error LED
Internal
Storage Board
Error LED
Light Path Diagnostics
Errors
Error 1
Error 2
Error 3
Error n
System
VPD
MTM #
Serial #
UUID
String
pDSA Code
System
FW Levels
UEFI
Primary Level
UEFI
Backup Level
IMM Primary
Level
IMM Backup
Level
IMM Hostname
IMM2
Network Info.
IMM2 Ext MAC
IMM2
Shared MAC
IP Add.
DNS Primary
DNS Secondary
DNS Tertiary
System
Environmental
Ambient Temp
CPU1...CPU4
Temps
Estimated Power
Consumption
AC Input Voltage
Subnet Gateway IPV6 Add.
Scroll Up Button
Select Button
Scroll Down Button
Tab
Service
card
You can download an Lenovo ServerGuide™ Setup and Installation DVD to help you con igure the hardware,
install device drivers, and install the operating system.
For a list o supported optional devices or the server, go to http://www.lenovo.com/serverproven/.
Go to http://systemx.lenovo iles.com/help/topic/com.lenovo.sysx.6241.doc/printable_doc.html or the Rack
Installation Instructions document which contains complete rack installation and removal instructions.
Related documentation
Use this in ormation to identi y and locate server - related documentation.
This Installation and Service Guide contains general in ormation about the server including how to set up and
cable the server, how to install supported optional devices, how to con igure the server, and in ormation to
help you solve problems yoursel and in ormation or service technicians. The ollowing documentation is
also available:
• Rack Installation Instructions
Go to http://systemx.lenovo iles.com/help/topic/com.lenovo.sysx.6241.doc/printable_doc.html or this
document which contains instructions or installing the server in a rack.
• Safety Information
This document contains translated caution and danger statements. Each caution and danger statement
that appears in the documentation has a number that you can use to locate the corresponding statement
in your language in the Safety Information document.
• Important Notices
This document contains in ormation about the sa ety, environmental, and electronic emission notices or
your Lenovo product.
• Warranty Information
This document contains in ormation about the terms o the server warranty.
4System x3850 X6 and x3950 X6 Installation and Service Guide

• Environmental Notices and User Guide
This document contains translated environmental notices.
• License Agreement for Machine Code
This document provides translated versions o the License Agreement or Machine code or your server.
• Licenses and Attributions Document
This document provides in ormation about the open-source notices.
To check or updated documentation, go to http://datacentersupport.lenovo.com/.
You can also ind documentation that is related to System x products at http://www.lenovo.com/data-center/.
The ToolsCenter or Lenovo x86 servers is an online in ormation center that contains in ormation about tools
or updating, managing, and deploying irmware, device drivers, and operating systems. The ToolsCenter or
Lenovo x86 servers is at https://support.lenovo.com/solutions/LNVO-BOMC.
The server might have eatures that are not described in the documentation that you received with the server.
The documentation might be updated occasionally to include in ormation about those eatures, or technical
updates might be available to provide additional in ormation that is not included in the server documentation.
To check or updates, go to http://datacentersupport.lenovo.com/.
Notices and statements in this document
The caution and danger statements in this document are also in the multilingual Safety Information
document. Each statement is numbered or re erence to the corresponding statement in your language in the
Safety Information document.
The ollowing notices and statements are used in this document:
• Note: These notices provide important tips, guidance, or advice.
• Important: These notices provide in ormation or advice that might help you avoid inconvenient or
problem situations.
• Attention: These notices indicate potential damage to programs, devices, or data. An attention notice is
placed just be ore the instruction or situation in which damage might occur.
• Caution: These statements indicate situations that can be potentially hazardous to you. A caution
statement is placed just be ore the description o a potentially hazardous procedure step or situation.
• Danger: These statements indicate situations that can be potentially lethal or extremely hazardous to you.
A danger statement is placed just be ore the description o a potentially lethal or extremely hazardous
procedure step or situation.
Server features and specifications
Use this in ormation or an overview o the server eatures and speci ications.
The ollowing in ormation is a summary o the eatures and speci ications o the 4-socket and 8-socket
server, unless otherwise speci ied. Depending on the model, some eatures might not be available, or some
speci ications might not apply.
Chapter 1.The Lenovo System x3850 X6 and x3950 X6 Type 6241 server 5

• Microprocessor (depending on the model):
– The server supports up to our (4-socket server) or eight (8-socket server) Intel Xeon™ EX versions o
the E7-48xx v2, E7-88xx v2, E7-48xx v3, E7-88xx v3, E7-48xx v4, and E7-88xx v4 Series
microprocessors.
– Up to i teen-core Turbo 2.0 with up to 37.5 MB cache shared among cores
– Up to 37.5 MB Level-3 cache
– Two QuickPath Interconnect (QPI) links with the ollowing:
– Operating speeds o up to 8 gigatrans ers (GT) per second
Note: Link speed can range rom 6.4 GT/s, 7.2 GT/s, or 8 GT/s
– Three QPI links per microprocessor (depending on the microprocessor)
– Two 20-lane point-to-point data links (one in each direction) per QPI link
– Four Scalable Memory Interconnect 2 (SMI2) links per microprocessor at up to 6.4 GT/s
– Each microprocessor has our memory channels, each memory channel has two DDR channels, and
each DDR channel supports three DIMMs
– Intel EX microprocessor + C600 series chipset (PCH)
– HyperThreading Technology
– Up to 32 PCIe Gen3 lanes per processor
Note: Use the Setup utility to determine the type and speed o the microprocessors in the server.
• Memory (depending on the model):
– DIMM connectors: 96 or the 4-socket and 192 or the 8-socket
– 24 DIMM connectors per compute book
– DDR3 compute book:
– Type: PC3-12800R 1600 MHz, PC3L-12800 1600 MHz or PC3L-10600 1333 MHz Load Reduced
(LR) single-rank, double-rank, or quad-rank, ECC, 240 pin, DDR3 registered SDRAM DIMMs only
– Supports standard 4 GB, 8 GB, 16 GB RDIMMs, and 16 GB, 32 GB, and 64 GB LR-DIMMs
– Supports l.35-volt registered DIMMs (see “Installing a memory module” on page 46 or more
in ormation)
– DDR4 compute book:
– Type: PC4-17000, registered, ECC, 288 pins at 2400 MHz Capable o running at 1333 MHz, 1600
MHz, or 1866 MHz
– Supports:
• 4 GB, 8GB, 16 GB RDIMMs
• 16 GB, 32 GB, and 64 GB LR-DIMMs
• 128 GB 3DS RDIMMs
– Supports 1.2-volt registered DIMMs (see “Installing a memory module” on page 46 or more
in ormation)
– Single rank x4, dual rank x4, quad rank x4, single rank x8, dual rank x8, quad rank x8 RDIMM
con igurations
– The server also supports 200 GB and 400 GB eXFlash™ DIMMs that you can install in unused DIMM
slots to increase high per ormance storage capabilities.
• Drive expansion bays (depending on the model):
6System x3850 X6 and x3950 X6 Installation and Service Guide
