Lenovo ThinkServer TD100 User manual

Installation instructions for manual installation of
Microsoft Windows Server 2008
First Edition
Updated: 10 October 2008
(C) Copyright Lenovo 2008. Portions copyright IBM 2008. All rights reserved.
NOTE: Before using this information and the product it supports, read the general
information in Section 5.0 Notices this document.
Follow the network operating system (NOS) installation instructions provided in this
document in sequential order unless these instructions advise you otherwise. Windows
and messages might differ from those in this document.
1.0 What you will need
You must have the following software and hardware for the installation:
A licensed copy of Microsoft® Windows® Server 2008 Enterprise Edition.
An external DVD reader device might be required. (to create the DVD).
Supported hard disk drives. Go to http://www.lenovo.com/thinkserver/ for the
Lenovo® ThinkServer® Proven list of supported options and part numbers for the
server.
2.0 Where to download device drivers and files
You can download the device drivers from the Device Drivers matrix on the Lenovo
Support Web site: http://www.lenovo.com/support
3.0 Installation instructions for Microsoft Windows
Server 2008
You must first download the RAID device driver onto a diskette.
3.1 Creating a RAID device driver diskette
To create the RAID device driver diskette, complete the following steps:
1. From an Internet-connected system with a diskette drive, go to:
http://www.lenovo.com/support and select Driver matrices from the Quick links.

2. Click ThinkServer and then click your machine type to view the Drivers and
software list.
3. Locate and click the link for the controller driver, and then click the executable
file link.
4. Click I agree to accept the license agreement.
5. Insert a blank, formatted diskette, and click OK. The device driver files are then
extracted to the diskette.
Note: Adaptec drivers must be in the root directory of the diskette to install properly.
6. When prompted, click Quit.
3.2 Creating a logical array
To create a logical array, complete the following steps:
1. Switch on the server. While the server is starting, press Ctrl + A.
2. Select Array Configuration Utility and press Enter.
3. Select Initialize drives.
4. Press the space bar to select the drives that you want to include in the array and
press Enter.
5. Select Yes.
6. Press the space bar to select the drive.
7. For the Array Type, select Volume and press Enter.
8. Type an Array Label and press Enter.
9. Select Manage array to verify that the array was created successfully.
10. Press Esc, and then press Esc again.
11. Select Yes.
12. The server reboots.
13. Press F12 to open the Boot menu and select and select CD Drive to set the server
to boot from the Windows Server 2008 Setup CD.
3.3 Installing Windows Server 2008
To install Microsoft Windows Server 2008, complete the following steps:
1. Connect the server to a network as required.
2. Depending on your server, you might need to attach an external DVD reader
device.
3. Turn on the server and insert the Windows Server 2008 Setup DVD into the DVD
drive.
4. When you are prompted with the message "press any key to boot from cd or dvd",
press any key. Windows Server 2008 Setup copies the files from the Setup DVD.
Windows load the files (this process takes several minutes).
5. In the Windows Server 2008 window, select the following:
a. For Language to install, select English.
b. For Time and currency format, select English (United States).

c. For Keyboard or input method, select US.
6. Click Next.
7. Click Install Now.
8. Type your product key.
a. Check the Automatically activate Windows when I'm online check box
and click Next.
b. Scroll down and read the license agreement.
c. Click I accept the license terms and click Next.
9. Select Custom (advanced).
10. When Windows Server 2008 Setup displays all hard disk storage that is available
on the server, select one of the following options to choose or create a drive
partition in which to install Windows Server 2008:
oAllow Setup to create a partition: To partition the entire hard disk as one
primary partition, highlight Disk0 unallocated space for the hard disk
drive on which you want to install Windows Server 2008 and press Next.
oCreate a partition: To create a partition, highlight Disk0 unallocated
space for the hard disk drive on which you want to install Windows
Server 2008, click Drive options (advanced); then, click New. You are
prompted to indicate how much available space to allocate from the
nonpartitioned drive. Type the amount of space (in MB), click Apply;
then, click Next.
oDelete a partition.
11. Setup formats the selected partition and copies the applicable files to the drive
partition. This process takes several minutes.
When Windows Server 2008 Setup has completed installation, the server
automatically restarts.
12. After Windows Server 2008 restarts, you will be prompted to change the
administrator password before you can log on.
13. After you are logged on as the Administrator, a configuration wizard window is
displayed. Use the wizard for naming and basic networking setup.
14. Next, use the Microsoft Server 2008 Roles and Features functions to setup the
server to your specific needs.
4.0 Post installation instructions: Installing and
updating device drivers
After the installation is complete, make sure that you have the latest device drivers and
firmware for the server. To install the device drivers and to identify hardware that is not
functioning, open Device Manager. In Device Manager, non-functioning devices are
usually listed under Other Devices and are indicated by a yellow exclamation point. To
open Device Manager, complete the following steps:
1. Click Start.

2. Right-click Computer.
3. Select Manage and then click Continue; then, select Device Manager in the left
pane.
The following sections include instructions for installing some device drivers. More
device drivers might be available in the Driver matrices on the Lenovo Support Web site.
4.1 Installing the Intel chipset device driver
To install the Broadcom NetXtreme Gigabit Ethernet device driver, complete the
following steps:
1. From an Internet-connected system with a diskette drive, go to:
http://www.lenovo.com/support and select Driver matrices from the Quick links.
2. Click ThinkServer and then click your machine type to view the Drivers and
software list.
3. Locate and click the link for the controller driver, and then click the executable
file link.
4. Type c:\drivers\nic for the folder where the files are to be saved. Click
Finish.
5. Click Yes to create the folder.
6. When the message "The package has been delivered successfully" is displayed,
click OK.
7. Navigate to c:\drivers\nic, and open launch.exe.
8. Click Driver Installer.
9. In the Welcome window, click Next.
10. In the License Agreement window, read the agreement, then select I accept the
terms in the license agreement, and click Next to continue.
11. Click Install to begin the installation.
12. When prompted to restart the server, select No, and click Finish.
To configure the network, click: Start -> Control Panel -> Network Connections, and
select New Connection Wizard to set up the network connection.
To configure network protocols, right-click Local Area Connection in the Network
connections window, and click Properties.
To join a domain, click Start, Control Panel, System, click the Computer Name tab,
and then click Change.
4.2 Installing the ATI video device driver
To install the ATI RN50/ ES1000 video device driver, complete the following steps:
1. From an Internet-connected system, go to: http://www.lenovo.com/support and
select Driver matrices from the Quick links.

2. Click ThinkServer and then click your machine type to view the Drivers and
software list.
3. Locate and click the link for the controller driver, and then click the executable
file link.
4. Locate and right-click the .zip file, and then select Extract All.
5. Click Next, select a location to extract the device driver; then click Next.
6. Leave "Show extracted files" checked, and click Finish. A window will open
showing the extracted files.
7. Click Setup.exe to run the downloaded executable file.
8. In the Welcome window, click Next.
9. In the License Agreement window, read the license agreement, and then click
Yes.
10. Click Express.
11. Select No, I will restart my computer later, and click Finish.
