Lenovo TB-Q706F User manual

Lenovo Tab P12 Pro
User Guide
Lenovo TB-Q706F
Lenovo TB-Q706Z
All information labeled with * in this guide refers only to the WLAN+5G model (Lenovo TB-
Q706Z).

Basics
Before using this information and the product it supports, be sure to read the following:
Safety, Warranty & Quick Start Guide
Regulatory Notice
"Important safety and handling information" in "Appendix".
The Safety, Warranty & Quick Start Guide and the Regulatory Notice are available on the website at
http://support.lenovo.com.
Note: All pictures and illustrations in this document are for your reference only and may differ
from the final product.
Technical specifications
Model Lenovo TB-Q706F Lenovo TB-Q706Z
CPU Qualcomm®Snapdragon™870 Qualcomm®Snapdragon™870
Battery 10200mAh 10200mAh
Wireless
communication Bluetooth 5.2; WLAN 802.11 a/b/g/n/ac/ax;
Bluetooth 5.2;
WLAN 802.11 a/b/g/n/ac/ax;
GPS/GLONASS
A-GPS
Note: Lenovo TB-Q706Z supports 5G Bands n1, n3, n7, n8, n20, n28, n38, n41, n77, n78 and LTE
Bands B1/B2/B3/B4/B5(B19)/B7/B8/B20/B26/B28/B38/B39/B40/B41, but in some countries 5G/LTE
Bands is not supported. To know if your device works with 5G networks in your country,
contact your carrier.
Home screen
The home screen is the starting point for using your device. For your convenience, the home screen is
already set up with some useful apps and widgets.

Note: Your device's features and the home screen may be different depending on your
location, language, carrier, and device model.
You can customize your home screen at any time.
Home screen
On the default home screen, there is a Google Search bar and some useful apps.
Entertainment Space
On the left of the default home screen, tap and open the entertainment space.
Add a widget to a home screen
Press and hold anywhere on the home screen except the icons. Tap , press and hold the widget
you want to add, then drag it to where you want to place it, and release.
Change the wallpaper
Press and hold anywhere on the home screen except the icons, tap , and then choose your
preferred wallpaper.
Go to Settings > Display > Wallpaper and choose your preferred wallpaper.
Move an app to another screen
Press and hold an app that you want to move, drag it to where you want to place it, then release.
Uninstall an app
1. Press and hold the app that you want to uninstall.
2. Drag to , and then release and tap OK.
Note: Some of the system apps cannot be uninstalled.
Find apps
Swipe up from the bottom of your screen to the top.
View recent apps
Swipe up from the bottom of your screen and release after 1 second. Then you can do the
following:
Tap an app window to open it.
Swipe an app window up to close it.
Swipe an app window down to lock it.
Tap "Clear all" to stop running all the apps.

Notifications and Quick Settings
The Notifications panel informs you of new messages, USB connection, and activities in progress such
as file downloading. The Quick Settings panel allows you to access frequently-used settings such as
the WLAN switch.
You can do any of the following:
To see notifications, swipe down from the top of the screen.
To close the Notifications panel, swipe up from the bottom of the screen.
To dismiss a notification, swipe left or right across the notification.
To dismiss all notifications, tap CLEAR ALL at the bottom of the Notifications panel.
To open the Quick Settings panel, swipe down from the top of the screen twice.
To close the Quick Settings panel, swipe up from the bottom of the screen.
Force shutdown
Press and hold the Power button and the volume down button for about 12 seconds until the device
turns off.

Split screen mode
Using split screen mode
Open the list of recently used applications, press and hold the application icon above the screen, and
then tap Split screen.
Note: Not all applications support split screen mode.
Split screen settings
In split screen mode you can do the following:
Adjust the split screen size
Slide the " " between the two screens to adjust the split sreen size.
Replace the second app
Back to homepage and choose another app.
Exiting split screen mode
You can exit split screen mode by:
Choosing an app that doesn't support split screen mode.
Or sliding the " " to the edge of the screen.

Multi-User
Multi-User Preferences
There are three user types:
Owner: An owner has full control over all user permissions and manages all user accounts.
Guest: There is only one Guest account. A Guest has restricted access to the device.
New User: There can be multiple standard user accounts.
Creating new user accounts
Swipe down from the top of the screen.
Tap > Add user to create a standard user account.
Tap > Add guest to create a guest account.
Or go to Settings > System > Multiple users.
Tap Add guest to create a guest account.
Tap Add user or profile, and then tap User to create a standard user account.
Switching between user accounts
On the home screen, swipe down from the top of the screen, and then tap the users icon to switch
between different user accounts.
On the lock screen interface, tap the USER icon on the left-top, then select the user you want to
switch to.
Go to Settings > System > Multiple users, then select the user account you want to switch to.
Deleting a user account

Swipe down from the top of the screen. Tap > MORE SETTINGS, Select the account you would
like to delete, then tap Delete user to delete accounts.
You can also goto Settings > System > Multiple users to delete accounts.

Fingerprint
Different users can set fingerprints to unlock the tablet or switch to their own user interface quickly.
Adding a fingerprint
You can add more than one fingerprint.
Go to Settings > Security > Fingerprint, follow the instructions on the screen.
Note: A lock screen pattern, PIN, or password is required to use fingerprint-related
functions. Other users can also set individual fingerprints following the above operations.
Delete a fingerprint
Go to Settings > Security > Fingerprint.
Confirm your screen lock pattern or enter your PIN or password.
Tap and then tap YES, REMOVE.

Camera
To open the Camera app, go to Camera.
Taking photos and videos
You can take photos and record videos with your device's built-in camera.
Tap to take a photo.
Tap to configure the other camera settings.
Tap to set the delay shooting.
Tap to select the color of background.
Tap to set flash settings.
Tap video to switch to video, and tap to record a video.
Tap Portrait, tap to blur the background and tap to apply beauty effects.
Taking screenshots
Press and hold the Power and the Volume down buttons at the same time to take a screenshot.
Viewing pictures and videos
Photos and videos are stored in your device's internal storage. You can view your photos and videos
by using the following methods:
Tap the thumbnail when using the Camera app.
Go to Photos.

Go to Files.
The screenshots are stored in your device's internal storage. You can view your screenshots by using
the following methods:
Go to Photos.
Go to Files.

Network
You need to set up a wireless network before connecting to the Internet.
Set up a WLAN network.
*Set up a mobile network.
Set up a VPN network.
You can also share your mobile network with others.
*Set up a hotspot.
Setting up a WLAN network
Go to Settings >Network & internet >WLAN. Turn on the WLAN switch and tap a WLAN hotspot in
the list to connect to the Internet. When you are connecting to a secure hotspot, you need to enter a
password to connect.
*Setting up a mobile network
Go to Settings > Network & internet > Mobile network.
Note: You need a valid SIM card with a data service. If you don't have a SIM card, contact your
carrier.
Setting up a VPN network
VPNs are used within organizations to allow you to communicate private information securely over a
non-private network. You may need to configure a VPN, for example, to access your work email. Ask
the network's administrator for the settings necessary to configure a VPN for your network.
1. Go to Settings >Network & internet >VPN.
2. Tap to edit the VPN profile, including the server name, type, and server address, and then tap
SAVE.
3. Tap the VPN server name, enter the username and password, and then tap CONNECT to connect
to the VPN network.
4. Tap to edit or delete the VPN.
*Setting up a hotspot
You can use personal hotspot to share an Internet connection with a computer or other device.
Go to Settings >Network & Internet > Hospot & Tethering and do the following:
Tap WLAN hotspot to configure the hotspot.
You can also use Bluetooth tethering or USB tethering.
Note: Tell your friends the Network name and password, and then they can connect to your
mobile network.

Internet
You can browse the web if your device is connected to a wireless network or a cellular network.
To open the browser app, go to Chrome.
Visiting websites
You can use the Chrome app to visit websites.
Type a web address
You don't need to type the full web address of an "http://" website to access it.
To visit "http://www.lenovo.com", simply type "www.lenovo.com" into the address bar and Tap .
Search for keywords
You can also type keywords into the address bar to search for webpages.
You can set a search engine in > Settings > Search engine.
Add a new webpage
Tap > New tab to add a new webpage tab.
Tap > New incognito tab to visit a website without leaving any traces of your visit.
Close a webpage
Tap to close a webpage tab.
Refresh a webpage
Tap to refresh a webpage.
Tap to return to the previous webpage.
Tap to go forward to a recent webpage.
Saving webpages
You can save images and webpages in your device's internal storage.

Save images
Press and hold the image, then tap Download image.
Bookmark webpages
Tap to add a webpage to Bookmarks.
Tap > Bookmarks to view bookmarks.
Setting accessibility preferences
Tap > Settings > Accessibility to set the text scaling and the webpage zoom.

Gmail
You can send and receive emails if your device is connected to a wireless network.
To access the Gmail app, go to Gmail.
Setting up a Gmail account
You can sign into Gmail if you have a Gmail account. If not, you will need to create a Gmail account.
You can also sign in with email accounts provided by other companies.
Using Gmail
After setting up your gmail account, you can use the Gmail app to send and receive emails.

Maps
You need to select the following settings before you can use Maps.
Go to Settings >Location and enable location access for Google apps.
Finding a location
Type the address that you want to find, then press Search here.
You can also tap to speak the address you want to search for.
Current location
Tap to see your current location.
Then tap Explore around you to check what is nearby.
Note: Positioning accuracy depends on your network type.
Planning a route
Tap and type in "Your location" and "Choose destination".
Choose the travel mode: by car, by bus or on foot.

Digital Wellbeing &
parental controls
Go to Settings > Digital Wellbeing & parental controls, and then set the related functions.
Digital Wellbeing
Tap Dashboard to view your screen time, Notifications received and times opened. And you can
set times for your apps.
Tap Bedtime mode, you can turn on the bedtime mode, and you can select Do Not Disturb or
Grayscale.
Tap Focus mode, you can select distracting apps, then tap TURN ON NOW to pause distracting
apps and hide their notifications.
Tap Manage notifications to set receiving or refusing the notifications.
Tap Do Not Disturb to set apps that can interrupt, Alarms & other interruptions, and other settings.
Parental controls
Tap Set up parental controls and follow the on-screen instructions, you can connect your
parent/child device by Google's Family Link.
After finishing the connection, if you are a parent, you can manage controls for things like mature
content, website, location, and others for your child.

AI Experience Center
You can experience different kinds of smart functions, such as Smart attention, Close to wake up, and
others.
Go to Settings > AI Experience Center and then set the related functions.
Smart attention(Preview)
The screen will be kept on if your face is found in front of the screen.
Close to wake up(Preview)
The display will be automatically wake up when you appear in front of the locked screen.
Distance reminder
If the viewing distance is too close, you will be reminded to stay a bit far away from the screen.
You can also set the Notification-free mode to prevent from distraction when using any app in the
list.

Keyboard
Pairing the keyboard manually
1.When the keyboard and the tablet are not connected, press and hold the Bluetooth button on the
upper right corner of the keyboard for 5 seconds, and then the Bluetooth indicator flashes slowly.
2.Turn on Bluetooth on the tablet. Tap Settings > Connected devices.
3.Select the name of the keyboard and tap Pair. At the same time, the Bluetooth indicator on the
keyboard flashes quickly.
4.After the pairing is successful, the Bluetooth indicator on the keyboard will be solid on for 5
seconds and then goes out.
Note: When the keyboard and the tablet are not connected through the 4-point pogo-pin smart
connector, short press the Bluetooth button on the keyboard, and then the Bluetooth indicator
will be solid on for 5 seconds, which means that Bluetooth is connecting.
Checking the keyboard battery level
After the keyboard is successfully paired, you can go to Settings > Connected devices to check the
keyboard battery level.
