Touch screen instruction
(Refer to these instructions if your computer is equipped with a touch screen.)
A touch screen is a computer display screen that is also an input device. The screens are
sensitive to pressure; allowing a user to interact with the computer by touching pictures or words
on the screen.
Attention:
• This computer is equipped with a resistive touch screen panel coated with a thin
metallic electrically conductive and resistive layer that causes a change in the electrical
currents that are registered as touch events and sent to the controller for processing.
The resistive layer can be damaged by sharp objects.
• Touch the resistive touch screen with your fingers only. Do not use a stylus to touch the
resistive touch screen panel.
• The cursor may not move quickly when it is dragged.
• The touch screen does not function in Rescue System mode.
Method of touch screen calibration
Note: The touch screen must be calibrated prior to use.
1. Click Start →All programs →IdeaCom TSC to launch the touch screen calibration
program.
2. Select a number of calibration points.
31041204_Touchscreen Instruction1 1 2009.10.15 10:06:10 AM

3. Touch the graphical target on the screen to calibrate the touch screen according to the
prompt information.
Notes:
1. The more calibration points, the higher your touch accuracy.
2. Recalibrate the touch screen when it is inaccurate.
3. To clean the touch screen thoroughly, shut down the computer and wipe the screen
gently with a soft dry cloth.
Normal operation
Once the calibration sequence is complete, you are ready to begin normal operation and start
sending touch events to the higher-level software.
1. A single touch on the screen will perform actions similar to the actions performed by clicking
the left mouse button.
2. Press your finger to the screen until a circle appears to perform actions similar to the actions
performed by clicking the right mouse button. A menu bar will pop-up after lifting your finger
from the touch screen.
