Lenoxx Sound CD-108 User manual

®
COMPACT DISC PLAYER
AM/FM STEREO CASSETTE RECORDER
MODEL CD-108
OPERATING INSTRUCTIONS
PLAYS ALL MUSIC COMPACT DISCS
FULLY PROGRAMMABLE CD PLAYER WITH REPEAT
RECEIVES AM/FM STEREO BROADCASTS
RECORDS FROM CD, RADIO, OR BUILT-IN MICROPHONE
FM STEREO AND POWER INDICATORS
2 WAY POWER - AC/DC
BASS BOOST SWITCH
REQUIRES 8 SIZE C BATTERIES
PLEASE READ CAREFULLY BEFORE USE
CD-108072799 v.1 E

SAFETY INSTRUCTIONS
The lightning flash and
arrow head within the
triangle is a warning
sign alerting you of
dangerous voltage
inside the product.
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point
within the triangle is a
warning sign alerting you of
important instructions
accompanying the product.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
THESE IMPORTANT SAFETY INSTRUCTIONS ARE INCLUDED, AS APPLICABLE TO THE
APPLIANCE, CONVEYING TO THE USER THE INFORMATION ITEMIZED BELOW:
1. Read Instructions - All the safety and operating instructions should be read before
the appliance is operated.
2. Retain Instructions - The safety and operating instructions should be retained for
future reference.
3. Heed Warnings - All warnings on the appliance and in the operating instructions
should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Water and Moisture - The appliance should not be used near water - for example near
a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool, and the like.
6. Wall or Ceiling Mounting - The appliance should not be mounted to a wall or ceiling.
7. Ventilation - The appliance should be situated so that its location or position does not
interfere with its proper ventilation. For example, the appliance should not be situated
on a bed, sofa, rug, or similar surface that may block the ventilation openings; or,
placed in a built-in installation, such as a bookcase or cabinet that impede the flow air
through the ventilation openings.
8. Heat - The appliance should be situated away from heat sources such as radiators,
heat registers, stoves, or other appliances (including amplifiers) that produce heat.
9. Power Sources - The appliance should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance.
10. Grounding or Polarization - Precautions should be taken so that the grounding or
polarization means of an appliance is not defeated.
11. Power Cord Protection - Power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenient receptacles, and the point where they exit
from the appliance.
12. Cleaning - The appliance should be cleaned only as recommended by the manufacturer.
13. Nonuse periods - The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
1CD-108072799 v.1 E

SAFETY INSTRUCTIONS
EXAMPLE OF ANTENNA GROUNDING AS PER
NEC - NATIONAL ELECTRICAL CODE
It is the intent of Lenoxx that this product be used in full compliance with the copyright
laws of the United States and that prior permission be obtained from copyright owners
whenever copying tapes or CDs.
Do not apply oil or petroleum products or solvents to any part of this set.
CAUTION
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
This compact disc player is classified as CLASS 1 LASER PRODUCT as stated on
the back of the set.
14. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids
are not spilled into the enclosure through openings.
15. Damage Requiring Service - The appliance should be serviced by qualified service
personnel when:
A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a marked change in
performance; or
E. The appliance has been dropped, or the enclosure damaged.
16. Servicing - The user should not attempt to service the appliance beyond that described
in the operating instructions. All other servicing should be referred to qualified service
personnel.
17. Power lines - An outdoor antenna should be located away from power lines.
18. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be
sure the antenna system is grounded so as to provide some protection against voltage
surges and built up static charges. Section 810 of the National Electrical Code, ANSI/
NFPA 70 provides information with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode. See Figure.
ANTENNA
LEAD IN WIRE
ANTENNA DISCHARGE UNIT (NEC
SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
GROUND CLAMPS
2CD-108072799 v.1 E

1. Use only the type and size of batteries mentioned in the operating instructions
booklet (batteries are not included with this set, please buy the proper batteries).
2. Do not dispose the batteries into a fire. The cells may explode. Check with local
codes for possible special disposal instructions.
3. Do not open or mutilate the batteries. Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be toxic if swallowed.
4. Be careful when handling batteries in order not to short the battery with conducting
materials such as rings, bracelets and keys. The battery or conductor may over
heat and cause burns.
5. Do not attempt to recharge non-rechargeable batteries. The batteries may leak
corrosive electrolyte or explode.
6. Do not attempt to rejuvenate the batteries identified for use with this product by
heating them. Sudden release of the battery electrolyte may cause burns or
irritation to eyes or skin.
7. All batteries should be replaced at the same time. Mixing fresh and discharged
batteries could increase internal cell pressure and rupture the batteries.
8. When inserting batteries into this product, the proper polarity ( and ) or
direction must be observed. Reverse insertion of some or all of the batteries may
result in battery eletrolyte leakage or explosion.
9. Remove the batteries from this product if the product will not be used for a long
period of time (several months or more) since during the period the batteries could
leak, damaging the product.
10. Discard weak or dead batteries as soon as possible since they are more likely to
leak in the product. Batteries should be replaced (depending on the product) when
the display gets dim or if the Low Battery Indicator shows or if the sound gets
distorted.
11. Do not store this product in high temperature areas. Batteries that are stored in a
freezer or refrigerator for the purpose of extending shelf life should be protected
from condensation during storage and defrosting. Batteries should be stabilized at
room temperature prior to use after cold storage.
12. If this product does not operate normally, see TROUBLE SHOOTING on page 18. If
you cant resolve the problem, or if the product is damaged, refer to the LENOXX
WARRANTY INFORMATION. Opening or removing covers may expose you to
dangerous voltages or other risks. Incorrect reassembly can cause electric shock
when the appliance is subsequently used.
13. If liquid leaks from the batteries, carefully wipe this liquid. Do not allow it to touch
your skin, and discard the leaking batteries.
14. Do not mix batteries (OLD and NEW or CARBON and ALKALINE, etc.).
15. The use of rechargeable batteries is not recommended for this set because their
voltage and life is lower than standard batteries.
16. Installation of batteries should be done by an adult only.
SAVE THESE INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY OR DAMAGE
TO YOUR SET, READ AND FOLLOW THESE INSTRUCTIONS.
BATTERY SAFETY INSTRUCTIONS
3CD-108072799 v.1 E

Playing a CD
1Slide the Function Switch to CD
position (power on).
3
4
1
2
Press the CD Door Open
button to open the CD Door
and place the CD in the CD
compartment.
The label side of the CD
should face you.
2
Press the CD Play
Button. The player plays
all the tracks once.
4
4
Connect the supplied AC power cord or batteries(see page 14).
Track
number
Play/Pause
Lamp
Close the CD door by pushing it
back.
3
CD OPEN
TAP E
CD RADIO
CD-108072799 v.1 E

Use these buttons for additional operations
To Press or Adjust
Adjust the volume Volume Control
Stop playback
Pause playback
The Lamp will flash during
pause. Press again to
resume play after pause.
Go to the next track
Go back to the previous
track
Locate a point in a song or while playing,
press and hold down until
you find the point.
Tip
When CD play is
paused, the Play/
Pause Lamp will
flash and no music
will play.
Remove the CD CD door Open Button
(press Stop first)
5
Volume Control
CD Open
Button
Function
Switch
Turn off the power Slide the Function Switch
to TAPE position
To resume play,
press the Pause
Button again, the
Play/Pause Lamp
will stop flashing
and music will play.
Play/Pause Lamp
CD-108072799 v.1 E

Playing CD tracks repeatedly (Repeat Play)
To repeat Press
a single track (song) Press the Repeat Button once
all the tracks (songs) Press the Repeat Button twice
1. Slide the Function Switch to CD position.
2. Press the CD Repeat Button.
You can play CD tracks repeatedly in normal or program play modes (see page 7).
programmed tracks Press the Program Button, and
then the Repeat Button twice
To cancel Repeat Play
Press the Repeat Button until the Repeat Lamp is off.
3. Select the track by pressing or , and then press .
6
Repeat ButtonFunction Switch
Repeat Lamp
Flashing
Steady on
Steady on
(the Program
Lamp flashing)
Program Lamp Repeat Lamp
CD-108072799 v.1 E

Creating your own music
program (Program Play)
You can make a program of up to 19
tracks in the order you want them to be
played.
1. Slide the Function Switch to CD position.
2. Press the Program Button. The number   and the
Program Lamp will flash.
3. Press or to select the tracks you want to
program in the order you want.
4. Press the Program Button to confirm. The number  
and the Program Lamp will flash.
5. Repeat steps 3 and 4. You can program up to 19
tracks.
6. Press to start program play. The Program Lamp will
remain flashing.
To change the current program
Just creat a new program following the Programing procedure.
7
To cancel Program Play
Press the Stop Button and the Program Lamp goes off.
Program
Program Lamp
CD-108072799 v.1 E

Listening to the radio
Connect the supplied AC power cord or batteries (see page 14).
Slide the Function Switch to
RADIO position (power on).
1
23
1
2
3
Slide the Band Switch to the proper
band position that you want.
Tune into the station you prefer
using the Tuning Control. Adjust
for the clearest sound.
8
4This indicator will light up when
receiving FM Stereo broadcasts.
FM STEREO
4
TAP E
CD RADIO
FM
AM FM ST.
BAND
CD-108072799 v.1 E

Use these buttons for additional operations
To Slide or Adjust
Adjust the volume Volume Control
Tip
If the FM broadcast is
noisy, slide the Band
Switch from FM Stereo
to FM position. Turn off the Radio Slide the Function Switch
to TAPE position
To improve broadcast reception
Reorient the antenna for FM or FM Stereo. Reorient
the player itself for AM.
9
Volume Control
Function Switch
•
CD-108072799 v.1 E
