Lenoxx EC06 User manual

www.lenoxx.com.au
1


ModelNumber:EC06
EvaporativeCooler
UserManual

Pleasereadandkeepmanualtoensuresafeandeffectiveuse
ofthisAppliance
HOUSEHOLDUSEONLY

www.lenoxx.com.au
2



TableofContents
ImportantSafetyandGeneralInstructions.......................................................................................3‐4
PartsListDiagram...............................................................................................................................5
OperatingInstructions.........................................................................................................................5
Cleaning,CareandMaintenance.........................................................................................................7
WarrantyDetailsandCustomerSupportHotline..............................................................................8‐9


www.lenoxx.com.au
3
ImportantSafetyandGeneralInstructions

Pleasekeepthisusermanualinasafeplacealongwithyourpurchasereceiptandcartonforfuturereference.
Thesafetyprecautionsenclosedhereinreducetheriskoffire,electricshockandinjurywhencorrectlyadhered
to.

1. ReadallinstructionsbeforeusingtheLenoxxEC06EvaporativeCooler.
2. Closesupervisionisnecessarywhenanyapplianceisusedbyornearchildren.
3. DoNOTusetheEvaporativeCoolerforotherthanitsintendeduse.
4. Beforeturningon,ensuretheelectricalvoltageandfrequencyofthecircuitcorrespondstothose
indicatedontheratinglabeloftheappliance.
5. Toprotectagainsttheriskofelectricshock,donotimmersethemotorunit,cordsetorpluginwateror
anyotherliquid,orrinseunderatap.
6. TheEvaporativeCoolerisnotintendedtobeoperatedbymeansofanexternaltimeroranytypeof
separateremotecontrolsystem.
7. Theuseofattachmentsnotrecommendedorsoldbythemanufacturermaycausefire,electricshockor
injury.
8. ThisEvaporativeCoolerisintendedtobeusedindoorsforhouseholduseonly.
9. Beforeuse,alwaysensuretheEvaporativeCoolercontainswater.Aftercleaning,thewatertankshould
beemptied.
10. Whenhumidityishigh,theEvaporativeCoolershouldbeoperatedatnormalfantype.
11. DoNOTuseanextensioncordunlesscompletelynecessarywiththisproduct.Ifanextensioncordis
usedpleaseensurethatithasaratingequalorexceedingtheratingofthisappliance.
12. DoNOTpullorcarrybycord,usecordasahandle,closeadooronthecord,orpullcordaroundsharp
edgesorcorners.Keepcordawayfromheatedsurfaces.
13. DoNOTbendordamagethepowercord.
14. Alwaysunplugtheappliancewhennotinuse.Todisconnectfromthepowersupply,griptheplugand
pullfromthepowersocket.Neverpullbythecord.Thepowerplugmustberemovedfromthepower
socketbeforecleaning,servicing,maintenanceormovingtheEvaporativeCooler.
15. DoNOTmoveorlifttheEvaporativeCoolerwhilethepowercordisstillconnectedtothewalloutletor
stillon.Alwaysensureitisswitchedoff.
16. Neverforcetheplugintoanoutlet.
17. Toreducetheriskofelectrocution,neveroperatethisproductwithwethands,submergeunderwater
orspillliquidsintotheproduct.
18. DoNOTleavetheEvaporativeCoolerunattendedwheninuse.
19. DoNOTplacetheappliancenearahotgasorelectricburner.
20. DoNOTcovertheappliancewhilstinuse.Ifitiscoveredthereisariskoffire.
21. Improperinstallationmayresultintheriskoffire,electricshockand/orinjurytopersons

www.lenoxx.com.au
4
22. Ifthesupplycordorplugisdamaged,donotusetheappliance.Pleasereturntoyourplaceofpurchase
alongwithyourreceiptforarefundorexchange.
23. Themanufacturerisnotresponsibleforanyeventualdamagescausedbyimproperorfaultyuse.
24. Theunithasnouser‐serviceablepartscontainedwithin.Donotattempttorepair,disassembleor
modifytheappliance.
25. Donotusethedeviceatroomtemperaturesabove40°C.
26. Donotleavetheapplianceexposedtoharshweatherconditions(directsunlight,rain,etc.).
27. DoNOTplacetheproductinornearanopenwindowasrainmayentertheproductandcauseelectrical
short‐circuiting.
28. DoNOTinsertfingersoranyotherobjectthroughthegrillesorintoanyopeningoftheproduct.
29. Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor
mentalcapabilitiesorlackofexperienceandknowledge,unlesstheyhavebeengivensupervisionor
instructionconcerninguseoftheappliancebyapersonresponsiblefortheirsafety.Childrenshouldbe
supervisedtoensuretheydonotplaywiththeappliance.
30. Donotoperateanyappliancewithadamagedcordorplugoraftertheappliancemalfunctionsoris
droppedordamagedinanymanner,takeittothestorewheretheunitwaspurchasedorcallLenoxx
customerserviceforfurtherassistanceon1300666848


www.lenoxx.com.au
5
Fill in the bottles and place in
freezer. Once frozen place inside
the cooler through the water tank
opening (6)
PartsList
1.ControlPanel
2.VerticalGrill
3.HorizontalGrill
4.MainBody
5.WaterLevelIndicator
6.WaterTankOpening
7.CastorWheels
8.Handle
9.ColdPAK
10.RemoteControl(notpictured,includes2xCR2032
lithiumcoinbatteries)
11. Ice tray opening









OperatingInstructions
Pleaseremoveallpartsfromthepackagingandreadthroughthemanualthoroughlybeforeusingforthefirst
time.Ensureallpartsindicatedintheabovepartslisthavebeenincludedinthegiftbox.

ControlPanel(onUnit)

1
9
23
4
5
6
11

www.lenoxx.com.au
6



1.ON/OFF
Toswitchevaporativecooleron,presstheON/OFF(1)button.Pressagaintoturnoff.

2.SpeedSelector–Youcanchoosefrom3speedsbypressingtheSPEEDselectorbutton(2)
LOW,MEDIUMandHIGH.

3.Mode–PresstheMODEbutton(3)tochoosefromthebelowoptions:

Normal–Continuousoperationatyourchosenspeedsetting.

Natural–Innaturalmode,theCoolerwillcycledependingonthespeedsettingchosen:
HIGH–cyclesbetweenHIGH/MED/LOW/OFF
MEDIUM–cyclesbetweenMED/LOW/OFF
LOW–cyclesbetweenLOW/OFF

Sleep–Inthismode,theCoolercyclesbetweenMED/LOW/OFF.Toactivatesleepmode,youwillneedtosetthe
TIMERtotheperiodofthetimethatyoudesire.Afterthetimerhasexpired,theEvaporativeCoolerwillswitch
OFFautomaticallyandgotosleep.

NOTE:ONEfullcycleisapproximately100seconds.TheCoolerwillstopblowingairduringthiscycleforafew
seconds.ThisisanormalpartoftheNaturalandSleepmodecycle.

4.Timer‐Thetimeroptionsarefor0.5,1.5,3.5or7.5hours.PresstheTIMERbutton(4)oncetoselect0.5hours.
The0.5willilluminateonthecontrolpanel.Pressagaintoselect1.5hours(both0.5and1willilluminate).
Pressing3timeswillsetthetimerfor3.5hours(0.5,1and2willilluminate).Tosetthemaximumof7.5hours,
presstheTIMERfourtimes(all4lightswillbeilluminated).

NOTE:Thenumbersilluminatedonthedisplayneedtobeaddedtogether,andthetotalwillequalthelengthof
timethattheEvaporativeCoolerstaysonfor.Thesenumbersarerepresentedby0.5,1,2and4onthecontrol
panel.

5.Oscillate–PresstheOSCILLATEbutton(5)toturnontheautomatichorizontallouvrefunction.Theindicator
lightwillilluminatewhenthisfunctionischosen.Theverticaldirectioncanalsobeadjustedmanuallybymoving
thelouvreinthedirectionyouwish.


6.Cool–PresstheCOOLbutton(6)toswitchtocoolairflow.


www.lenoxx.com.au
7
RemoteControl–TheEvaporativeCoolercomeswitharemotecontrolunitformoreconvenience.Theremote
requires2xCR2032lithiumcoinbatteries(included).Thefunctionsontheremotecontrolarethesameasthose
onthecontrolpanelofthemainunit.


Operation
1. PlacetheEvaporativeCooleronalevel,drysurface.
2. Openthewatertankcoverandpourincleanwaterorice.Ifyouuseice,youwill
actuallygetacoolerairtemperature.DoNOTfillthewatertankaboveMAXlevel
indicatorinthewatertank.
NOTE:Iffreshwater/iceisrequiredfornextuse,(ortoemptythewatertank)placeawatercontainerorbucket
undertheplughole(foundonthebottomoftheunit)andremovetherubberplug.Theresidualwaterwillthen
drainoutfromthewatertank.



3. SelectthewindspeedbypressingtheSPEEDbutton.Pleasenotethedefaultwindspeedismediumwhen
youfirstpresstheONbutton.
4. PresstheMODEbuttontochooseyourdesiredsetting.
5. SetthetimerbypressingtheTIMERbutton.Theminimumsettingis0.5hrandmaximumis7.5hr.
6. Toturnonhorizontaloscillation,presstheOSCILLATEbutton.Youcancontroltheverticalflowbymanually
adjustingtheverticallouvresontheEvaporativeCooler.
7. Toutilisethehumidifyingfunction,filltheColdPAKwithcoldwaterthenplaceinthefreezeruntiltheyare
frozen.Next,placeinsidethewatertank.Thiswilllowerthewatertemperature,andtheEvaporativeCooler
willbegintohumidifytheair.

Figure: 1 Figure: 2

www.lenoxx.com.au
8
Cleaning,CareandMaintenance

NOTE:AlwaysunplugtheEvaporativeCoolerfromtheelectricaloutletandallowittocoolbeforeservicing,
relocating,cleaning,orstoringit.

Removetherubberplugfromthebackoftheunitanddrainthewater(placeabucketbeneaththeplugforthe
watertodraininto).(seeabovefigure1&2whererubberplugisfound)
Cleanthebodywithasoft,slightlydampcloth;donotuseabrasiveorcorrosiveproducts.
Cleantheexteriorsurfacesonlybywipingwithasoft,dampcloth.Dustcanberemovedfromthegrilleusinga
smallvacuum.
DoNOTdisassemblethemotorhousingofthisproductforcleaningofinternalparts,asdoingsomayresultin
productdamageandwillvoidthewarranty.
DonotimmerseanypartoftheEvaporativeCoolerinwaterorotherliquid:
Itisessentialthatthemotor'sairventsbekeptfreefromdustandlint.
IftheEvaporativeCoolerisnotusedforlongperiods(eg.overwinter),itisrecommendedtostoretheCooler
awayinitsoriginalpackaginginacooldryplace.








www.lenoxx.com.au
9
EC06 PR3264
