Lenoxx CD-85 User manual

IB-CD85(21A-60C9)-WM-E-010603
OPERATING INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE
COMPACT DISC PLAYER
WITH ESP PLUSTM ANTI-SKIP PROTECTION
PLAYS MUSIC COMPACT DISCS
BASS BOOST SYSTEM
6 DIGIT LCD VISUAL DISPLAY
TRACK REPEAT & DISC REPEAT
60 SECOND ESP (ELECTRONIC SHOCK PROTECTION) PLUSTM SYSTEM
DELUXE STEREO HEADPHONES INCLUDED
USES 2 SIZE AA BATTERIES (NOT INCLUDED)
LINE OUT JACK - CONNECTS TO YOUR STEREO SYSTEM
MODEL CD-85
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM1

IB-CD85(21A-60C9)-WM-E-010603
LOCATION OF CONTROLS
1. CD DOOR OPEN BUTTON (slide to open)
2. CD DOOR
3. STOP AND POWER OFF BUTTON
4. BACKWARD SKIP/SEARCH BUTTON
5. REPEAT/RANDOM BUTTON
6. LCD DISPLAY
7. PROGRAM BUTTON (for programmed play)
8. FORWARD SKIP/SEARCH BUTTON
9. PLAY/PAUSE & POWER ON BUTTON
10. AC ADAPTOR JACK (AC ADAPTOR not included)
11. BASS BOOST SWITCH
12. LINE OUT JACK (for home stereo connection)
13. VOLUME CONTROL
14. PHONES JACK (headphones jack)
15. BATTERY DOOR
1
15
4
5
7
8
10
9
11
1
3
2
13
12
14
6
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM2

IB-CD85(21A-60C9)-WM-E-010603
POWER SOURCES
Using with Batteries
Insert 2 size AA alkaline batteries
according to the + and - markings in
the BATTERY COMPARTMENT.
2
WHEN SHOWS IN THE DISPLAY
ALKALINE BATTERY LIFE
Bear in mind that battery life expectancy is based upon volume and bass listening
levels.
Maximum battery power consumption happens at maximum settings. Typical life for 2
size AA alkaline batteries is above 7.5 hours of continuous use for CD play.
NOTE: You may use rechargeable batteries on this set. However, because
rechargeable batteries generally have lower voltage (1.2 volts instead of
1.5 volts). Your playing time will be much less than normal fresh alkaline
batteries.
While CD playing, if the alkaline batteries are weak and discharged, this symbol  
shows or flashes in the display, then the power automatically turns off. If this occurs,
replace the alkaline batteries (also if the display does not show anything, the batteries
are dead).
Power your CD player by connecting an optional AC ADAPTOR or by inserting 2 size
AA fresh alkaline batteries.
NOTE: Before you buy an optional AC Adaptor, please note the only AC ADAPTOR
suitable for this player is DC 4.5V 600mA, with polarity , others may
damage your player. Please check voltage and current (mA) before buying an
AC ADAPTOR.
TIPS ON BATTERY USE
Reversing polarities will damage the batteries and possibly your set. Be sure to
follow polarity ( + and - ) as indicated.
Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),
or old batteries with new ones.
When not in use for an extended period of time, or while internal batteries will not
be used, remove them to prevent possible acid leakage or corrosion resulting in
damage to your player.
When the batteries have become discharged, they must be disposed of in a safe
manner that complies with all applicable laws.
Installation of batteries should only be done by an adult (for safety).
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM3

IB-CD85(21A-60C9)-WM-E-010603
CONNECTING TO HOME STEREO SYSTEMS
The LINE OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the
cables mini plug to the LINE OUT jack on your player, and the other appropriate end
usually RCA JACKS to the CD/AUX INPUTS of your home stereo.
YOUR CD PLAYER
TO AUX IN JACKSTO LINE OUT JACK
YOUR STEREO
SYSTEM
OPTIONAL CABLE (3.5mm)
TO RCA JACKS
3
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM4

IB-CD85(21A-60C9)-WM-E-010603
CD PLAYING
4Adjust the Volume.
1Load the Disc.
2Connect the Headphones.
3Press the PLAY/PAUSE button.
1234
1234
1234
1234
Push
here
Disc
Label side up
Slide right to open
To PHONES jack
NOTE: The ESP PLUSTM function will turn on automatically when the PLAY/PAUSE
button is pressed.
4
TOTAL TRACKS TOTAL PLAYING
TIME OF THE CD
TRACK NUMBER
CURRENTLY
PLAYING
ELAPSED PLAYING
TIME OF THE
CURRENT TRACK
PLAY/PAUSE
button
VOLUME CONTROL
Stereo Headphones
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM5

IB-CD85(21A-60C9)-WM-E-010603
OTHER OPERATIONS
Operation Press Display window shows
To pause play
To release pause and resume play
To stop
To skip to the next track(s)
To skip to the previous track(s)
SKIP(SEARCH) FORWARD button once (or
repeatedly).
SKIP(SEARCH) BACKWARD button once (or
repeatedly).
To go ahead at high speed
(search)
Keep SKIP(SEARCH) FORWARD button
depressed and release when the desired music
section of the disc is found.
To go back at high speed (search). Keep SKIP(SEARCH) BACKWARD button
depressed and release when the desired music
section of the disc is found.
BASS BOOST switch
This switch enhances the low frequency (bass)
sounds at low listening levels. Switch the BASS
BOOST switch ON or OFF to suit your taste.
PLAY/PAUSE
button
PLAY/PAUSE
button
STOP button
To turn off the power STOP button once and wait 30 seconds, or press STOP
button twice.
BASS BOOST switch
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
FLASHES
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
ADVANCES
5
TOTAL TRACKS TOTAL PLAYING TIME
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM6

IB-CD85(21A-60C9)-WM-E-010603
Single Track Repeat
Plays one song over and over till you press STOP.
During play, select the song you want to repeat with
either of the SKIP/SEARCH buttons ( or ), then
press the REPEAT/RANDOM button once, the symbol
REPEAT 1 will appear in the display.
The song currently playing will repeat over and over,
until you press STOP.
All Tracks Repeat
Repeats all songs in order, till you press STOP.
During play, press the REPEAT/RANDOM button twice,
the symbol REPEAT ALL
will show in the display.
All songs will keep playing in sequence 1, 2, 3, etc., and
when finished, will start all over again until you press the
STOP.
REPEAT, INTRO AND RANDOM PLAY
You may have repeat, intro or random play using the REPEAT/RANDOM button. Press
the REPEAT/RANDOM button several times, and the display will show the followings in
turn:
Intro Play
This plays the first 10 seconds of songs in sequential
order.
1. During play, press the REPEAT/RANDOM button
three times, the word INTRO will flash in the display.
2. Press the PLAY button, the word INTRO will stop
flashing and the first 10 seconds of each song on the
CD will play in sequential order.
3. When you find a song you like, press the PLAY button
again, the symbol INTRO will disappear from the
display, normal play will be resumed, that song (and
the following songs) will play NORMALLY.
Random Play
This plays the songs on the disc in a random order.
1. During play, press REPEAT/RANDOM button four times
the word SHUFF will flash.
2. Press the PLAY button, this will play all of the songs
in random order selected by the CD player. The word
SHUFF will stop flashing.
3. Press the SKIP/SEARCH button to skip to the
next random song.
REPEAT 1 --> REPEAT ALL --> INTRO --> SHUFF --> NORMAL PLAY
6
REPEAT
RANDOM
X 1
REPEAT 1
REPEAT
RANDOM
X 2
REPEAT ALL
REPEAT
RANDOM
X 3
REPEAT
RANDOM
X 4
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM7

IB-CD85(21A-60C9)-WM-E-010603
The tracks (songs) on the disc can be programmed (arranged in advance) to play in
any order you prefer (up to 20 tracks can be programmed).
Programming Example:
Program Number 12 3 4 5 6 7 8
Track Number (song number) 35 8 1 2 4 1 1
etc.
etc.
PROGRAMMED PLAY
During programming, the word PROG flashes in the display. To program songs to play
in your preferred order, follow steps below:
1.Press the PROGRAM button.
The word PROG and   will flash in
the display.
2.Press the SKIP/SEARCH button ( or
) to select track number 3 (example).
PROG and track number 03 will flash in
the display.
3.Press the PROGRAM button to confirm.
Track 3 is now programmed.
Program number 2 will now show in the
display, ready for your next selection of
track.
4.Repeat steps 2 and 3 to program other
tracks till you finish (up to 20
selections).
NOTE:
- The player will stop automatically after
all programmed tracks have been
played.
- To quit programmed play, press the
STOP button once. Then you may press
the PLAY button to re-start normal play.
Your programmed number will be
lost:
When the alkaline batteries are
exhausted or removed, or the optional
AC ADAPTOR is disconnected.
When the power is shut off.
SKIP/SEARCH
Program number
Track number
PROG
7
PROGRAM
5.After programming is finished, press
the PLAY button to begin programmed
play. The word PROG changes to be
steady on in the display, and music
begins to play in the order you
programmed.
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM8

IB-CD85(21A-60C9)-WM-E-010603
This set is designed with the latest 60 second ESP PLUSTM (Electronic Shock Protection)
- which allows virtually unlimited gentle skip protection above the normal 60 second
shock protection.
When the PLAY/PAUSE button is pressed, the   (memory
basket) indicator will appear in the display, the digital data (music)
is stored in the read-ahead memory buffer before it is decoded
and played.
The 60 second ESP PLUSTM function prevents the sound from skipping by using a
buffer memory that stores music data. The new 60 second ESP PLUSTM system can
store more music than normal 60 second anti-skip systems.
60 SECOND ESP PLUSTM ANTI-SKIP SYSTEM
This new design allows gentle swaying of the set (as in walking) without music skipping.
This function (CD ESP PLUSTM) may not work during heavy jogging.
8
The 60 second ESP PLUSTM function will turn on automatically when the PLAY/PAUSE
button is pressed.
EMPTY MEMORY
The   mark changes to the   mark, indicating that the
memory buffer (basket) is full.
When the set is subject to a shock or a bump during play, the
data stored in memory continues to be decoded and played.
This gives the pickup time to stabilize and continue reading
new music. As the data is used from memory, the indicator
changes from   to  . Once the pickup returns to its
original position, new data is stored in memory and the display
changes back to the   mark.
If the set is subject to repeated shocks and all the data stored
in memory is used up, the   mark is displayed and the
sound will skip or stop for a brief period until the memory basket
has time to fill up again.
NOTE:
- The music may stop if the player receives continuous shocking.
- You may hear noise or skipping if the CD is dirty or scratched.
- If you press PLAY/PAUSE, or SKIP (SEARCH) buttons, the
memory basket will empty itself temporarily.
FULL MEMORY
SOME MEMORY USED
ALL MEMORY USED UP
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM9

IB-CD85(21A-60C9)-WM-E-010603
Cleaning the cabinet
Wipe with a soft cloth. If the cabinet is
very dirty, dampen (not dripping wet) the
cloth with a weak solution of soapy water,
and then wipe clean.
Cleaning the lens
A dirty lens will cause sound skipping. If
the lens is very dirty, the player may not
work. We suggest using a special cleaning
disk (not included) available in most music
and Hi-Fi stores. However, if you do not
have one, you may use a cotton swab
very slightly dampened with alcohol to
clean the lens.
MAINTENANCE
To remove the Disc
Open the CD DOOR by sliding the DOOR
OPEN button, hold the disc by the edge
while slightly pressing on the center
spindle as illustrated, then lift it from the
edge to release and remove.
Cleaning the Discs
Fingerprints should be carefully wiped
from the surface of disc with a soft cloth.
Unlike conventional records, compact
discs have no grooves to collect dust
and microscopic dirt, so gently wiping
them with a soft cloth should remove
most particles. Wipe in a straight
motion from the center to the edge.
Handling Compact Discs
Dirty, scratched or warped discs may
cause skipping or noise.
Handle the disc only by the edges. To
keep clean, do not touch its surface.
Never use thinner, benzine, record
cleaner or antistatic spray on a compact
disc. Such chemicals can damage its
plastic surface.
Discs should be stored in their cases
after use to avoid scratches.
Do not expose discs to direct sunlight,
high humidity, high temperatures, or
dust, etc. Prolonged exposure to
extreme temperatures can warp the disc
(such as leaving the discs in your car
during summertime).
Do not stick or write anything on either
side of disc. Sharp writing instruments, or
the inks used in some felt-tip pens, may
damage its surface.
NOTE:
Always press STOP button and wait for
the disc to stop rotating before sliding the
DOOR OPEN button to remove the disc.
9
IB-CD85(21A-60C8)-WM-E-010603.p65 1/13/03, 12:20 PM10
