Lenoxx CD-90 User manual

®
MODEL CD-90
OPERATING INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE
AM/FM DIGITAL RADIO
CD PLAYER WITH 20 SECOND ESP PLUS
TM
DIGITAL AM/FM RECEIVER
5 AM & 5 FM PRESET STATION BUTTONS
PLAYS ALL MUSIC COMPACT DISCS
6 DIGIT RADIO & CD VISUAL DISPLAY
TRACK REPEAT & DISC REPEAT
20 SECOND ESP (ELECTRONIC SHOCK PROTECTION) PLUSTM SYSTEM
AC ADAPTOR INCLUDED
USES 2 SIZE AA BATTERIES (NOT INCLUDED)
LINE OUT JACK - CONNECTS TO YOUR STEREO SYSTEM
CD90(90A-E2)030400 NL v.1 E
S1

ACCESSORIES INCLUDED
AC ADAPTOR STEREO HEADPHONES
INTRODUCTION
Your new Lenoxx Sound Model CD-90 portable compact disc player with digital
radio, uses the latest technology to give you crisp clean sound from all your
compact discs, and digital AM/FM radio reception.
Please read these operating instructions completely to take advantage of all the features
of this set.
1
LIMITED WARRANTY
We warrant this product to be free from defects in material and workmanship under
normal use for a period of 90 days after purchase and we will repair it free of charge or
replace it at no charge, should it become defective under this warranty, providing you
submit proof of purchase (sales slip) with the set.
During the initial 90 day period after original purchase, we will service or exchange,
at no charge, the set that is returned to LENOXX ELECTRONICS CORP. (LENOXX will
pay the shipping back to you). After the initial 90 day period expires, and for a period
of 12 months from original purchase, we will repair the unit covering any part(s) that
need to be replaced at no charge, but will charge for the cost of labor, return postage
paid by Lenoxx.
This warranty does not apply to any products which have been subject to misuse,
neglect or accident. This warranty does not cover broken headphones or cabinet.
UNDER NO CIRCUMSTANCES WILL LENOXX ELECTRONICS CORP. BE LIABLE FOR
ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitations
or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. The following charges apply to repairs beyond the
warranty period: $35.00. Be sure to pack carefully and return postage paid insured
together with your money order (personal checks will not be accepted) and sales
receipt to :
LENOXX ELECTRONICS CORP. 2 GERMAK DRIVE, CARTERET N.J. 07008

LOCATION OF CONTROLS
24
1
21
23
2
3
7
5
20
6
8
9
16
1.5 AM & 5 FM MEMORY PRESET BUTTONS
2.RADIO MEMORY STORE BUTTON
3.AM/FM BAND BUTTON
4.RADIO LCD DISPLAY
5.RADIO TUNING UP BUTTON
6.RADIO TUNING DOWN BUTTON
7.CD DOOR
8.PHONES JACK (headphone jack)
9.LINE OUT JACK
(for home stereo connection)
10.VOLUME CONTROL
11. FORWARD SEARCH BUTTON ( )
12.BACKWARD SEARCH BUTTON ( )
13.PLAY/PAUSE BUTTON (POWER ON)
14.STOP AND POWER OFF BUTTON
15.BASS BOOST SWITCH
16.CD DISPLAY
11
10
13
4
25
2
12
15 14
17
18
19
22
17.CD/RADIO FUNCTION SWITCH
18. RADIO ON INDICATOR LAMP
19. PROGRAM BUTTON
20. ESP (ELECTRONIC SHOCK
PROTECTION) BUTTON
21. REPEAT/RANDOM BUTTON
22. CD DOOR OPEN BUTTON
23. CD DOOR CLOSE AREA
24. BATTERY DOOR
25. AC ADAPTOR JACK

POWER SOURCES
1.Using Battery Power
TIPS ON BATTERY USE
Reversing polarities will damage the batteries and possibly your set. Be sure to
follow polarity ( + and - ) as indicated.
Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),
or old batteries with new ones.
When not in use for an extended period of time, or while internal batteries will not
be used, remove them to prevent possible acid leakage or corrosion resulting in
damage to your player.
When the batteries have become discharged, they must be disposed of in a safe
manner that complies with all applicable laws.
Installation of batteries should only be done by an adult (for safety).
WHEN THIS SYMBOL SHOWS IN THE DISPLAY
If the alkaline batteries are weak and discharged, this symbol   shows in the
display, then the power automatically turns off. If this occurs, replace the alkaline
batteries (also if display does not show anything, the batteries are dead).
ALKALINE BATTERY LIFE
Bear in mind that battery life expectancy is based upon volume and bass listening
levels.
Maximum battery power consumption happens at maximum settings. Typical life
for 2 size AA alkaline batteries is above 8 hours of continuous use.
Insert two size AA alkaline batteries
according to the + and - markings in
the battery compartment.
3
NOTE: You may use rechargeable batteries on this set. However, because
rechargeable batteries generally have lower voltage (1.2 volts instead of
1.5 volts). Your playing time will be much less than normal fresh alkaline
batteries.
AA
+
AA
+

2.Using AC Wall Outlet Power
Your player may be powered from any household 120V AC outlet, using the AC
adaptor included. Insert the adaptors small connector plug into the DC 4.5V Jack
marked on player (on the rear of the set), and plug the adaptor into
an AC outlet.
NOTE: If the AC Adaptor is connected, and regular batteries are installed, the
player automatically switches to the AC Adaptor power and the batteries
are not used.
CAUTION:
To prevent electric shock, do not use this AC Adaptor with an extension cord or outlet,
unless it can be fully inserted without exposing any part of the blades. Do not use any
other adaptor to power this set or you may damage your set.
CONNECTING TO HOME STEREO SYSTEMS
The LINE OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the
cables mini plug to the LINE OUT jack on your player, and the other appropriate end
usually RCA JACKS to the CD/AUX INPUTS of your home stereo.
YOUR
CD PLAYER
TO AUX IN JACKSTO LINE OUT JACK
YOUR STEREO
SYSTEM
OPTIONAL CABLE
3.5mm TO RCA JACKS
4

DISC PLAYING
4Adjust the Volume.
1Load the Disc.
2Connect the Headphones.
3Press the PLAY/PAUSE Button.
1234
1234
1234
1234
1234
Push
here
Disc
Label side upPress to open
To PHONES
Stereo headphones
PLAY/PAUSE
button
VOLUME
CONTROL
5
VOLUME
TRACK NUMBER
CURRENTLY
PLAYING
ELAPSED PLAYING
TIME OF THE
CURRENT TRACK
TOTAL TRACKS TOTAL PLAYING
TIME ON THE CD

Other Operations
Operation Press Display window shows
To pause play
To release pause
and resume play
To stop
To skip to the next track(s)
To skip to the previous track(s)
once (or repeatedly)
once (or repeatedly)
To go ahead at high speed
(search)
Keep depressed and release when the
desired music section of the disc is found.
To go back at high speed
(search) Keep depressed and release when the
desired music section of the disc is found.
BASS BOOST switch
This switch enhances the low frequency (bass)
sounds at low listening levels. Slide this switch
to ON or OFF to suit your taste.
PLAY/PAUSE
button
PLAY/PAUSE
button
STOP button
To turn off the power STOP button once and wait 30 minutes, or press
STOP button twice
BASS BOOST switch
6
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
FLASHES
TRACK NUMBER
CURRENTLY PLAYING
PLAYING TIME
ADVANCES
TOTAL TRACKS TOTAL PLAYING TIME

Single Track Repeat
Plays one song over and over till you press STOP.
During play, select the song you want to repeat with
either of the SEARCH buttons ( or ), then press
the REPEAT/RANDOM button once, the symbol 
1

appears in the display.
The song currently playing will repeat over and over,
until you press STOP.
All Tracks Repeat
Repeats all songs in order, over and over, till you press
STOP.
During play, press the REPEAT/RANDOM button twice,
the symbol ALL will show in the display.
All songs will keep playing in sequence 1, 2, 3, etc. and
when finished, will start all over again until you press the
STOP button.
REPEAT, INTRO AND RANDOM PLAY
You may have repeat, intro or random play using the REPEAT/RANDOM button.
Press the REPEAT/RANDOM button several times, and the display will show the
followings in turn:
1
-->
ALL
--> INTRO --> SHUFF --> NORMAL PLAY MODE
Intro Play
This plays the first 10 seconds of every song in
sequential order.
1. During play, press the REPEAT/RANDOM button
three times, the word INTRO will flash in the display.
2. Press the PLAY button, the word INTRO will stop
flashing and the first 10 seconds of each song on the
CD will play in sequential order.
3. When you find a song you like, press the PLAY button,
normal play will be resumed, that song (and the
following songs) will play NORMALLY.
Random Play
This plays the songs on the disc in a random order.
1. During play, press REPEAT/RANDOM button four times
the word SHUFF will flash during play.
2. Press the PLAY button, this will play all of the songs
in random order selected by the CD player. The word
SHUFF will be steady on.
3. Press the SEARCH button to skip to the next
random song.
7
REPEAT/
RANDOM
X1
1
REPEAT/
RANDOM
X2
ALL
REPEAT/
RANDOM
X3
REPEAT/
RANDOM
X4

The tracks (songs) on the disc can be programmed (arranged in advance) to play in
any order you prefer (up to 20 tracks can be programmed).
Programming Example:
Program Number 12 3 4 5 6 7 8
Track Number (song number) 35 8 1 2 4 1 1
etc.
etc.
PROGRAMMING YOUR OWN PLAY
During programming, the word PROG flashes in the display. To program songs to play
in your preferred order, follow steps below:
1.Press the PROGRAM button.
The word PROG will flash in the display.
2.Press the SEARCH button ( or )
to select track number 3 (example).
PROG will flash in the display.
3. Press the PROGRAM button. Track 3 is
now programmed.
Program #2 will now show in the
display, ready for your next selection of
track.
4.Repeat steps 2 and 3 to program other
tracks till you finish (up to 20 selections).
5.After programming is finished, press
PLAY to begin programmed play. PROG
changes to be steady on in the display,
and music begins.
NOTE:
- The player will stop automatically after
all programmed tracks have been
played.
- To quit programmed play, press STOP
button once. Then you may press PLAY
button to re-start normal play.
Your programming will be lost:
When the alkaline batteries are
exhausted or removed, or the AC
ADAPTOR is disconnected.
When the power is shut off or the CD
DOOR is opened.
8
PROGRAM
Program number
PROG
SEARCH
Track number
PROG
PROG
PLAY
PAUSE

This set is designed with 20 second ESP (Electronic Shock Protection) PLUSTM - which
allows virtually unlimited gentle skip protection, and 20 second normal shock protection.
Press the ESP button to turn on the ESP PLUSTM system. Press
it again to turn it off.
When the ESP button is pressed during play, the   (memory
basket) indicator will appear in the display, the digital data
equivalent to approximately 20 seconds of music is stored in the
read-ahead memory buffer before it is decoded and played.
The   mark changes to the   mark, indicating that the
memory buffer (basket) is full.
When the set is subject to a shock or a bump during play, the
data stored in memory continues to be decoded and played.
This gives the pickup time to stabilize and continue reading
new music. As the data is used from memory, the indicator
changes from   to  . Once the pickup returns to its
original position, new data is stored in memory and the display
changes back to the   mark.
If the set is subject to repeated shocks and all the data stored
in memory is used up, the   mark is displayed and the
sound will skip or stop for a brief period until the memory basket
has time to fill up again.
To turn off the 20 second ESP PLUS
TM
function, press the ESP
button again.
Keep the digital ESP function off when using the set in a stable,
no vibration area, where it will not receive shocks. The batteries
will last longer when the ESP function is off.
The ESP PLUS
TM
function prevents the sound from skipping by using a buffer memory
that stores music data. The new ESP PLUSTM system can store more music than
normal anti-skip systems.
EMPTY MEMORY
FULL MEMORY
SOME MEMORY USED
ALL MEMORY USED UP
When the ESP PLUS
TM
function is switched ON or OFF during
play, the sound will be interrupted for a few seconds. This is
normal.
NOTE:
- The music may stop if the player receives continuous shocking.
- You may hear noise or skipping if the CD is dirty or scratched.
- If during ESP play, you press PLAY/PAUSE, or SEARCH buttons,
the memory basket will empty itself temporarily.
20 SECOND ESP PLUSTM SYSTEM
This new design allows gentle swaying of the set without music skipping as in walking.
This set will not work during jogging.
9
ESP
