Leupold RX-1200i User manual

RX
®
-1200i AND 1200iTBR/W
COMPACT DIGITAL
LASER RANGEFINDER
Complete Operation Manual

Introduction .................................................. Page 1
Specifications ................................................ Page 10
Operation ................................................... Page 11
Cleaning/Maintenance......................................... Page 31
Helpful Hints for Using the Leupold
RX-1200iDigital Laser Rangefinders ............................. Page 32
Warranty / Repair ............................................. Page 34
Table of Contents

1
Congratulations! You have purchased a Leupold
®
RX
®
-1200iSeries digital laser
rangefinder that has been designed by Leupold’s engineers and designers to
be the best rangefinder on the market and to provide you with years of solid
performance in the field. Following are detailed instructions regarding the
proper use and employment of your RX -1200iSeries rangefinder. To ensure top
performance for the life of the product, please read these instructions before
operating your RX -1200i. This manual was written in order to provide you with
all the information needed to properly operate and obtain years of beneficial
use from the RX -1200i. Keep it in a safe place and refer to it as needed.
Your new Leupold RX-1200iSeries digital laser rangefinder is a revolutionary,
range-finding device that incorporates advanced digital electronics with
state-of-the-art ballistics algorithms. The next generation Digitally eNhanced
AccuracyTM (DNA
®
) engine incorporates additional signal processing techniques
to generate better ranging distance with more accurate rangefinding. All
RX-1200i rangefinders feature an incredibly bright OLED display, while the
RX-1200iTBR/W adds an inclinometer, Last Target Mode and True Ballistic
Range/Wind (TBR/W) functionality. TBR/W algorithms were developed by the
same engineers who developed Sierra Infinity
®
Exterior Ballistics Software and
who helped develop navigation and guidance systems for ICBMs and other
missiles with far more demanding trajectory requirements than a hunting
Introduction

2
bullet. TBR/W is a marriage of laser ranging, an inclinometer, and an advanced
computerized ballistics program. The result is distance measurements accurate
to less than a yard, no matter the angle at which the laser is fired. Bullets and
arrows travel in a ballistic arc, yet conventional rangefinders only provide a linear
or horizontal distance to your target. TBR delivers the ballistic equivalent range
to the target, accounting for the effects of inclines or declines on the path of
your bullet or arrow. For rifle shooters, the Leupold team has added to the TBR
functionality by adding wind hold calculations that will provide a fixed 10 MPH
full wind value. Other features that are provided for firearms are outputs that
display either MOA adjustments, or inches / centimeters / mils of holdover at that
specific distance. TBR eliminates any potentially significant error, and provides
a precise range for your aiming calculations. TBR is matched to each of twenty-
five firearm ballistics groups or archery ballistics, allowing use with most popular
firearms and bows.
HOW THE RX -1200i WORKS
The RX -1200 i is a top-quality 6x22mm monocular that incorporates the
additional benefit of a state-of-the-art laser rangefinder capable of measuring
the distance of a deer-sized animal from 5 yards to 800 yards, an inanimate
object from 5 yards to 900 yards, and a reflective target from 5 yards to 1,200
yards. It emits a series of invisible, infrared energy pulses that are reflected
off the selected target back to the optical unit. State-of-the-art circuitry and

3
The Leupold RX -1200 i 6x22mm rangefinder does employ an eye safe FDA Class 1
laser in its operation. Outside of the United States, the IEC is the governing body
over laser products and has classified the RX-1200ias Class 3R. Even so, there are
a few precautions that are important to remember:
• Do not depress the POWER button while aiming at a human eye or while
looking into the optics from the objective side
• Do not leave the RX-1200 i within the reach of small children
• Do not take the product apart as it has a self-protection device in the
electronic control module and may cause an electric shock
• Do not attempt to use any power source other than a CR2 battery
(or equivalent) — the RX -1200 i is designed to prohibit accessing any
other external power supply
Safety and Operation Precautions
CLASS 3R LASER PRODUCT INVISIBLE LASER RADIATION
AVOID DIRECT EXPOSURE This product complies with IEC 60825-1
2007-03 Ed 2.0 and Complies with FDA performance standards for laser
products except for deviations pursuant to Laser Notice No. 50,
Dated June 24. 2007.
Po:< 5.14mW. λ:895nm-915nm. T:20ns.
LEUPOLD & STEVENS, Inc,
14400 NW Greenbrier Parkway, Beaverton, OR 97006
precision computing circuits are used to calculate the distance by measuring
the time it takes for each pulse to travel from the RX-1200 i to the object and
back.

4
Safety and Operation Precautions (cont.)
• Make certain that the laser beam does not strike on highly reflective
surfaces
• Read this instruction manual in its entirety before using this
rangefinder. If the product is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired
• Caution: Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
exposure
• When you see the display through the eyepiece, please be aware
that the product is active and emitting an invisible laser and the laser
aperture should not be pointed toward anyone
(Display as seen through the eyepiece)
BAS Display BOW Display LOS Display

5
RX -1200iFeatures at a Glance
POWER
BATTERY
MODE
FOCUS
• Laser Radiation: FDA Class 1 / IEC Class 3R
• Measurement Range: 5 yds – 1,200 yds
• Measuring Time: Less than 1 second
• Auto Power Off after 20 seconds
• Power: CR2 battery or equivalent
• Battery Life: At least 5,000
measurements
• The RX-1200 i is weatherproof

6
READING THE INTERNAL DISPLAY
The Organic Light Emitting Diode (OLED) display reflected into the optical path
can be manually switched between ranging modes, as measured in meters
(M) or yards (YD), or used to obtain distance while simultaneously viewing
the target. (The RX -1200ican also simply be used as a 6x monocular without
activating the OLED.)
INTERNAL DISPLAY AS SEEN THROUGH THE RX-1200iTBR/WWHEN THE
POWER BUTTON IS DEPRESSED
– Indicates the distance to the target
in either yards or meters. RX-1200iTBR/W
Models have the additional capability of
displaying the True Ballistic Range to the target,
or shot placement information.

7
BATTERY POWER STATUS INDICATOR
To determine your battery’s power level, look for the following indicators:
FULL – A full battery bar indicates your battery is at or near peak capacity.
HALF – A half-full bar indicates your battery has reached half-capacity.
LOW – The battery is nearing the end of its life and should be replaced.
NO POWER – If the battery bar is empty, and there is no data displayed
above the bar, your battery is dead and you must replace it. The battery
status bar will flash and the unit will shut down when no power remains.
MEASURING DISTANCE WITH THE RX-1200 i
Measurement of distance with the RX -1200 i is a very simple operation:
1. View the object of interest through the monocular.
2. Depress the POWER button to power up the unit.
3. Align the reticle over the object being viewed.
4. Depress the POWER button again – this will cause the laser to activate.
5. Read the distance as shown in the image field.

8
CONTINUOUS MEASUREMENT OF A MOVING TARGET / SCAN MODE:
Follow the instructions for “Measuring distance…” as explained previously.
1. Once the target has been measured, continue to hold down the POWER
button and follow the object as it moves.
2. The distance will automatically update as long as the POWER button is
continuously depressed.
3. This procedure can also be used to obtain the range of multiple animals
or objects; simply move the reticle from one target to another while
holding down the POWER button.
CLEARING THE LAST DISTANCE OBTAINED:
The last range reading taken does not need to be cleared before reading
another object’s distance. For that reason, there is no reset button. Simply aim at
the new object using the reticle, depress the POWER button and hold until the
new range reading is displayed.
The ranging accuracy of all Leupold RX -1200 i Series rangefinders is ± 0.5 yards/
meters at distances less than 125 yards/meters, while the accuracy beyond 125
yards/meters is ± 2 yards. The maximum range of the unit depends on the
reflectivity of the target and atmospheric conditions.

9
Following is a reference table listing the ranges of all RX-1200imodels under
different conditions:
Surface texture, color, size, and shape of the target all affect reflectivity, which
in turn affects the maximum range of the instrument. As a rule of thumb,
brightly colored targets are much more reflective than darker targets. Tan
game coats are more reflective (and thus provide a more solid reading) than a
black roof. A shiny surface is more reflective than a dull surface. Smaller targets
are more difficult to range than larger targets. Light conditions, haze, fog, rain,
and other environmental conditions can all affect ranging performance. Any
factor which degrades air clarity will reduce the maximum effective range. The
sun generates infrared energy that can degrade ranging performance in bright
conditions or when ranging towards the sun.
TYPICAL MAXIMUM RANGE (All RX-1200iModels)
CONDITION Yards Meters
Reflective Target
1200 1097
Trees
900 822
Deer
800 731

10
The RX -1200iSeries of digital laser rangefinders provides a variety of useful
modes to tailor performance to the conditions you experience in the field. Model
features are identified on the following pages.
Specifications
RX-1200iRX-1200iTBR/W
Magnification
6× 6×
Inclinometer
No Yes
TBR/W (True Ballistic Range/Wind)
No Yes
Bright OLED Display
Yes Yes
Last Target Mode
No Yes
Line of Sight Distance (LOS)
Yes Yes
Yards / Meters Mode
Yes Yes
Scan Mode
Yes Yes
Battery Life >5,000 Actuations >5,000 Actuations
Weight
7.8 oz 7.8 oz
Dimension (Inches) 3.8 x 2.9 x 1.3 3.8 x 2.9 x 1.3
Battery Status Indicator
Yes Yes
Warranty
2 Years 2 Years
Weatherproof
Yes Yes
Wavelength
895-915nm
Beam Divergence
1.31mrad
Pulse Duration
20ns
Power
<5.14 mW

11
QUICK SET MENU™
Operation
*Display shown with all possible segments visible

12
To initiate rangefinder setup mode, press the POWER button to activate the
unit, then press and hold the MODE button for 2 seconds to enter the Quick Set
MenuTM.
To manipulate a function, press and release the MODE button until that
function is flashing, then use the POWER button to change the setting. If this
is the last function to be changed, you can allow the rangefinder to sit idle
for 20 seconds which will cause an automatic power-off, saving all selections.
If additional functions require manipulation, simply press MODE to continue
through the Quick Set Menu. Pressing and holding MODE for 1 second at
any time will save all changes, exit the Quick Set Menu, and prepare the
rangefinder for immediate use.
To reset your RX-1200ito factory settings, Press POWER to activate the
rangefinder, press and hold MODE, then press and hold POWER. A 10-second
countdown timer will appear; factory reset will occur after 0 has been reached.
Note: Activating certain modes automatically disables other modes. For example
activating the yards mode will automatically deactivate the meters mode.

13
FUNCTION 1: TBR, BOW OR LOS
To activate TBR, BOW, or LOS, activate the RX-1200iby pressing the POWER
button, then press and release the MODE button to enter the menu. While
“Out Put” is shown in the display, press and release the POWER button
to rotate through TBR, BOW, and LOS modes. Once the desired mode is
displayed, press the MODE button for >1 and release.
The inclinometer output is shown beside the battery status indicator.
NOTE: LOS is always active on non-TBR models.
TBR FOR RIFLE USERS (TBR/W MODELS ONLY)
TBR calculates the equivalent horizontal range (level fire range) from which
you can determine the correct aim for the conditions. For example, if you
are shooting a .270 caliber, 130 grain bullet at 3,050 feet per second up a 30°
incline at 400 yards, direct line of sight, the TBR output will be 367 yards. The

14
first step in correctly using TBR is to Practice, Practice, Practice. Anytime
you handle a firearm or bow, you are ultimately responsible for your
projectile.
For rifle users, scope adjustment or holdover information can also be
displayed. The available settings are as follows: BAS outputs the equivalent
horizontal range, HOLD displays the inches or centimeters (depending
on unit of measure selected) to holdover the intended point of impact,
MIL displays the number of milliradians to holdover the intended point of
impact and MOA displays the minute of angle correction.
TBR for rifle settings is effective to 800 yards for most
cartridges. For rifle users, TBR mode is comprised of five
functions: BAS, HOLD, MIL, MOA and TRIG. One of these
modes must be selected. To select the desired function,
rotate through the output until TBR is reached (activate if
necessary). While the TBR icon is highlighted and the word “SEt” is shown
in the upper display, pressing POWER repeatedly will scroll through BAS,
HOLD, MIL, MOA and TRIG respectively; press MODE when the desired
function is displayed. For information regarding BOW settings, please see
page 17.

15
BAS displays the equivalent horizontal range, which is
based upon the ballistics group and sight-in distance
you will choose in a later mode. This is the range you will
want to use when shooting, rather than the line of sight
distance, which may contain gross errors depending upon
the shot angle. Readings will be displayed with equivalent
horizontal range in the lower portion of the display.
HOLD will display the appropriate amount of holdover to use,
which is based upon the ballistics group and sight-in distance
you will choose in a later mode. The upper display shows the
line of sight distance to the target. The lower display will
briefly show whether you should hold high or low, then the
appropriate number of inches or centimeters to hold over or
under. In the example to the right, the line of sight distance
is 484 yards, and the lower display indicates that you should
hold 51.4 inches above your intended point of impact. If the
RX-1200iTBR/W is set to range in meters, the appropriate holdover would be
shown in centimeters.

16
MIL will display the appropriate amount of holdover in
milliradians to use, which is based upon the ballistics group
and sight-in distance you will choose in a later mode. The
upper display shows the line of sight distance to the target.
The lower display will briefly show whether you should hold
high or low, then the appropriate number of mils to hold
over or under. In the example to the right, the line of sight
distance is 484 yards, and the lower display indicates that you
should hold 2.9 mils above your intended point of impact.
Holdover values will be displayed in mils for both yards and
meters modes.
MOA Mode will show the minute-of-angle adjustment for
your target which is based upon the ballistics group and sight-
in distance you will choose in a later mode. The upper display
shows the line of sight distance to the target. The lower
display will briefly show whether you should dial the scope
in the up or down direction, then the appropriate number
of MOA adjust. In the example to the right, the line of sight
distance is 484 yards, and the lower display indicates that you
should dial the scope up 10.1 MOA to account for bullet drop.

17
Scope corrections will be displayed in MOA for both yards and meters
modes.
TRIG, a function that is included to support engineers and
sportsmen, displays the true horizontal range and true
vertical range, which is based upon trigonometry using
angle and line of sight distance. Line of sight distance
(LOS) readings will be displayed in the lower portion of
the display. The upper display will briefly show the true
horizontal distance (cosine) then the absolute value of the
true vertical distance (sine). Have you ever wondered if
that leaning tree would hit your home or tent if it fell?
Measure the height by obtaining the true vertical distance
and then measure the distance from your house or tent to the tree.
BOW (TBR/W MODELS ONLY)
This mode, when activated, works with TBR to provide the
equivalent horizontal range (level fire range) for arrows.
The displayed range represents the ballistically equivalent
horizontal distance to the target if the target is 125 yards
or less. If the target is farther than 125 yards (114 meters),
the LOS icon will flash while BOW remains displayed, and
