LevelOne KVM-0217 User manual

2
17-inch
Modularized KVM Console KVM-0217
H/W Version: 1
Product Overview
The LevelOne KVM-0217 is a compact and modular
KVM console drawer designed to be used in a
standard 19-inch server rack. It oers connectivity to 8
or 16 computers by depending on the LevelOne KVM
module that is installed (KCM-0831 or 1631). It features
a 17-inch retractable LCD monitor and keyboard with
built-in touchpad. Users can daisy chain up to seven
KVM-0217 together, providing control of up to 128
computers in total. The LevelOne KVM-0217 provides
a double layer password access control ensuring only
authorized users have access to connected computers.
It supports an administrator and 8 user accounts, each
one with a separate and customizable prole.
Advanced Remote Management via optional
modules
LevelOne also oers a unique module for remote
server control. Just slide in the IP Console Module
(ACC-2000) to KCM-0831/1631 to access and manage
the server farm over the Internet using a standard
web browser. It supports a 1600x1200 pixel screen
resolution for high-quality viewing.
Key Features
- Control servers and computers either locally via
control port or remotely via optional modules
through the module expansion slot
- Combo architecture with PC support for PS/2 and
USB interface
- Flexible auto-scan mode for exible PC monitoring
- Locate Cat5 console up to 300 meters away from the
KVM switch.
- Built-in daisy chain port for cascading with
KVM-0831 or KVM-1631 up to 8 units
- Provide ACL (Access Control List) security function -
store up to 8 independent ACLs for controllable PCs
- Support Windows, NetWare, Unix, Linux, Mac OS and
Sun Microsystems
- 19”rackmount 1U size design KVM (Keyboard, video
and mouse) access over IP
KCM-0831
8-port Combo KVM Module
for KVM-0217
Works Well With
1. KCM Moudule Connector
KCM-1631
8-port Combo KVM KVM
Module for KVM-0217
1
* Features are based on KVM-0217 combined a LevelOne KVM mobule.

www.level1.com
I
one world_one brand_one level_
3
KVM Switches/Consoles/Extenders
Switch Ports
PC Port
8-port HDDB15 for PS2/USB
Local Console Port
1 Console port for USB
1 Expansion Slot for optional modules
*ACC-1000 KVM Cat.5 Console Module
*ACC-2000 IP KVM Console Module
Keyboard and Mouse Emulation
PS/2 or USB
VGA Resolution
1920X1440
Daisy Chaining
Daisy Chaining
Support Daisy Chaining up to 8 units
Connector: HDDB 15 pin (Female Type)
Daisy Chain Max. Level
8 units
Max. PC Connection
120 PCs/Servers (cascading 1 KVM-0831 + 7 KVM-1631)
Scan Intervals
5 ~ 99 Sec.
Bandwidth
200 MHz
Switch Management
PC selection
On Screen Display (OSD) Menu, Hot Key, Push Button
Security
Provide ACL (Access Control List) security function, store up to
8 independent controllable PC lists
Hotkey
Provide various Hotkey (Scroll-Lock/ Cap-Lock/ Num-Lock/ Alt/
Ctrl/ Win)
Multilingual OSD (On Screen Display) control
8 languages (English, France, Germen, Spanish, Italian, Russian,
Japanese, Simplied Chinese)
Physical Specications
PC LEDs
8
Housing
Metal
Power Adapter
DC 12V, 4.16A
Operation Temperature
0 ~ 50°C
Storage Temperature
-20 ~ 60°C
Humidity
0~95%, Non-Condensing
Dimension (mm)
445 (L) x 160(W) x 45 (H)
2.0 kg
Technical Specication
Prodouct Diagram
PCs
PC
Moniter
Mouse
Keyboard
KVM-9007
KVM Console Receiver
ACC-1000
KCM-0831/KCM-1631
KVM-0217
19" Network and Server Cabinet
** Specicutions are based on KVM-0217 + KVM-0831/1631 modules.

4
Order Information KVM-0217: 17-inch Modularized KVM Console
Package Contents KVM-0217 x 1
Rail with front and rear bracket x 2
Brackets A. (Needed for rack depth 828 ~ 1000 mm) x 2
Brackets B. (Needed for rack depth 504 ~ 614 mm) x 2
Brackets C. (Needed for rack depth 504 ~ 614 mm) x 2
Power Adapter x 1
CD Manual x 1
QIG x 1
Keys x 2
Screws
Option Accessories
All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.
© Copyright Digital Data Communications GmbH. All Rights Reserved.
V1.0
ACC-2109
Daisy Chain Cable 90cm
ACC-2101
PS/2 and USB Cable KVM
1.8m
ACC-2102
PS/2 and USB Cable KVM
3.0m
ACC-2103
PS/2 and USB Cable KVM
5.0m
