Photometric Performance
• 5kW Fresnel, Lamp No. 176-159 5000W ANSI Code DPY
• For field diameter at any distance, multiply that distance by .36 for spot and 1.25 for flood
Beam Candlepower
Spot 569,800
Flood 89,000
Features
• High intensity spot with a smooth, even flood field
• Pole-operated versions provide maximum flexibility
for studio lighting applications
• State-of-the-art ventilation system guarantees
cooler unit operation with extended lamp and
gel life
• All operating controls thermally insulated for cool
handling operations
• Torlon® insulators provide smooth focusing
operation
• Lightweight, rugged construction
• Split diamond socket design for extreme durability
5kW Studio Fresnel
5kW Studio Fresnel
Dimensional Data – in. [cm] lbs.[kg]
A19.00 [48.26]
B26.25 [66.70]
C17.00 [43.18]
Weight 37.00 [16.00]
Description Cat. No.
5kW Studio Fresnel Manual 1-0105
with wire lead only Pole-Op 1-1105
5kW Studio Fresnel with 50A,
2-pole, 3-wire grounding OPT-00002
pin connector same
5kW Studio Fresnel with
36” cable and OPT-00004
U-ground connector same
5kW Studio Fresnel 50A,
2-pole, 3-wire grounding OPT-00006
twistlock same
5kW Studio Fresnel with
variation on OPT-00007
standard (describe) same
Accessories Cat. No.
10" Eight Leaf Barndoor 118-023
10" Diffusion Frame 120-016
Safety Cable 138-059
Compact Stand (Castered) 152-053
1 1/8" stud adapter for
pole-operated yokes 1-9501
1 1/8" stud adapter for
manual yokes 532-012
Combo Stud (Stand mount) 138-012
Super Stand 152-054
C-clamp, 1/2” stud
(furnished w/instrument) 158-003
Operating Pole 1-9701
Lamps Cat. No.
5000W, 120V, 3200˚K,
500 Hrs., ANSI Code DPY 176-159
5000W, 240V, 3200˚K,
400 Hrs., Code C229, G38
5000W, 220V, 3200˚K,
400 Hrs., Code CP29, G38
Specifications subject to change without notice
Specifications
• Housing is constructed of extruded and die-cast
aluminum, sheet steel and sheet aluminum with
a high-temperature baked finish.
Mechanical
• Optical Train consists of a one mogul bipost
halogen lamp, one specular pure aluminum
coated Alzak®reflector, and one low expansion
fresnel lens mounted in a hinged door for rapid
lamp replacement.
• Socket shall be mogul bipost steatite insulated,
with floating diamond, four-point nickel-plated
forged brass contacts. UL recognized for 250volts,
10,000 Watts, 200˚C continuous operation. Rated
lamp seal temperatures shall not be exceeded.
• Voltage 120/240V AC/DC
• Performance with catalog number 176-159
(ANSI code DPY) lamp in a 20.4˚ field with
569,800 beam candlepower, in spot focus, and
in flood focus a 73˚ field with 89,000 beam
candlepower.
• Mounting heavy steel yoke, with reinforced cast
aluminum corners for easy carrying. Manual
version fits 5/8" combo stud or C-clamp to fit up
to 2" ID pipe. Pole-operated yoke equipped with
panning gear mechanism which accommodates
1 1/8" stud or C-clamp to fit up to 2" ID pipe.
• Electrical 36" cable, 3 wire leads.
5kW Studio Fresnel
C A
B
Beam Angle
(50% of max. int.)
Field Angle
(10% of max. int.)
Spot Focus (Beam angle 11.9˚, Field angle 20.4˚)
Illumination* 1425/15828 63/7035 356/3957 228/2532
(footcandles/lux)
Diameter Beam: Field 4.2/1.3:7.2/2.2 6.3/1.9:10.8/3.2 8.3/2.5:14.4/4.3 10.4/3.1:18/5.4
(feet/meters)
Distance 20/6 30/9 40/12 50/15
(feet/meters)
Flood Focus (Beam angle 59.9˚, Field angle 73˚)
Distance (feet/meters) 20/6 30/9 40/12 50/15
Diameter Beam: Field 19/5.7:25/7.5 28.6/8.6:37.5/11.3 38.1/11.4:50/15 47.6/14.3:62.5/18.8
(feet/meters)
Illumination* 223/2472 98.9/1099 55.6/618 35.6/396
(footcandles/lux)
*All illumination data is measured at beam center
