Leviton Mini Broad Operation manual

PRODUCT DATA
Leviton Mfg. Co., Inc. Lighting Management Systems
20497 SW Teton Avenue, Portland, OR 97062 1-800-736-6682 Tech Line: 1-800-959-6004 Fax: [phone] www.leviton.com/lms
© 2008 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
FEATURES
• Ultra light weight
• High light output for wide coverage
• Accepts a wide range of accessories
• All aluminum construction for maximum
portability
• Constant drag pan and tilt handle permits
quick adjustment
• Captive latch locks accessories in place
Mini Broad
Mini Broad
PHOTOMETRIC PERFORMANCE:
• Mini Broad No. 176-002 650W lamp ANSI FBX
• For field diameter at any distance, multiply that
distance by 2.47.
• For illumination at any distance, divide 7,840 by
the distance squared.
Beam (Beam angle 60˚x52˚)
Illumination* 78.4/490 34.8/217.8 19.6/122.5 12.5/78.4
(footcandles/lux)
Diameter Beam: Field 11.6/4 17.5/7 23.3/9.33 29.18/11.67
(feet/meters)
Distance 10/4 15/6 20/8 25/10
(feet/meters)
Field (Field angle 102˚)
Distance (feet/meters) 10/4 15/6 20/8 25/10
Diameter Beam: Field 24.7/9.88 37.1/14.82 49.4/19.76 61.75/24.7
(feet/meters)
Illumination* 78.4/490 34.8/217.8 19.6/122.5 12.5/78.4
(footcandles/lux)
*All Illumination data is measured at beam center
Beam Angle
(50% of max. int.)
Field Angle
(10% of max. int.)
Efficiency Flood Beam
Lumens Candlepower
Beam 5,550(34.4%) 7,840
Field 12,700(79.4%)

PRODUCT DATA
Leviton Manufacturing Co., Inc. Lighting Management Systems
20497 SW Teton Avenue, Portland, OR 97062
Telephone: [phone] • FAX: [phone] • Tech Line (6:00AM-4:00PM P.S.T. Monday-Friday): 1-800-959-6004
Leviton Manufacturing of Canada, Ltd.
165 Hymus Boulevard, Pointe Claire, Quebec H9R 1E9 • Telephone: [phone] • FAX: [phone]
Leviton S. de R.L. de C.V.
Lago Tana 43, Mexico DF, Mexico CP 11290 • Tel. [phone] • FAX: [phone] • www.leviton.com.mx
Visit our Website at: www.leviton.com/lms
© 2008 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
LEVITON SPECIFICATION SUBMITTAL
JOB NAME: CATALOG NUMBERS:
JOB NUMBER:
CAT. NO. DESCRIPTION
000MB-42B Mini-Broad w/9’ cable & Edison connector
ACCESSORIES
AMPBD-000 Four Leaf Barndoor, Mini-Pro
AMPDF-000 Dichroic Filter, Mini-Pro
AMPEC-000 Mini-Pro/Mini Broad Extension Cable, 25 ft. 3-way
AMPGG-000 Gaffer Grip w/ 1/2” and 5/8” Studs
AMPHA-000 Mini-Pro Handle
AMPMS-000 Mini-Stand 1/2” stud
AMPRC-000 Mini-Pro 120V Replacement Cable 9 ft.
AMPSS-SGL Scrim, Single (fits 5” diameter)
AMPSS-SET Set Single/Half Single Scrim - Mini-Pro, Mini-Broad (fits 5” diameter)
CT140-003 30V DC Cord - Mini-Pro
LAMPS
L0FBX-000 FBX 650W 120V 3200K 125HR Frosted
L0FCA-000 FCA 650W 120V 3400K 30HR
L0EHR-000 EHR 400W 120V,3000K 2000HR
L0DXX-000 DXX 800W 220V 3200K 80HR
SPECIFICATIONS
• Housing shall be constructed of ventilated
aluminum with high temperature gray finish.
MECHANICAL
• Performance with catalog number 176-002
(ANSI code FBX) lamp
• Mounting steel yoke, fits 1/2” or 5/8” stud
• Cable 12’ 3-wire with parallel blade U-ground cap
• Voltage: 120/240 AC/DC
• Amperage:
5.4 at 120V with 650W lamp
3.3 at 240V with 800W lamp
• Switch in line
A
B
C
G-7966/B8-ak
Mini Broad
DIMENSIONAL DATA – IN. [CM] LBS. [KG]
A 5.37 [13.70]
B 8.25 [21.00]
C 3.25 [8.30]
Weight 1.75 [0.82]
