Leviton 47693-ESM Installation instructions

1x8 CATV Module 47693-ESM, 47693-GSM
47693-ESM
47693-GSM
Product
Specifications
1x8 CATV MODULES
APPLICATION
Leviton’s 1x8 CATV modules are designed to
distribute incoming RF signals (Cable TV,
Antenna, or other modulated sources) to eight
locations throughout the home or office on
coaxial cable. Variable attenuator enables precise
amplification for fine-tuning picture quality (-5 to
+15 dB) of incoming signal. The 1x8 CATV
modules incorporate state-of-the-art bi-directional
signaling to support advanced interactive
applications such as cable modem and cable box
communications. The module features one cable
input and eight isolated television outputs.
FEATURES AND BENEFITS
• Digital CATV compatible.
• High quality, professional-grade product.
• Distributes signals such as: CATV, antenna, VCR/DVD,
Camera/CCTV signals on coaxial cable throughout the home or
office.
• Built-in amplifier easily adjusts to compensate for variations in
incoming signal strength (-5 to +15dB).
• Provides bi-directional signal paths to support cable modem or
cable box communications.
• Installs easily into Leviton’s Structured Media™ enclosures.
• Small circuit board design set at a 90º angle for easy
installation.
• Includes termination caps
PHYSICAL SPECIFICATIONS
Dimensions: 3.50” H x 6.50” W x 3.20” D
Impedance: 75 Ohm
Connector Type: F-Type (1 input, eight outputs)
47693-ESM: Nickel Plated
47693-GSM: Gold Plated
Power Input: 12VDC 1A, adapter supplied
Frequency: 52-1000 MHz
TYPICAL SPECIFICATIONS
The 1 GHz 1x8 CATV Module shall distribute RF signals
over coaxial cable to eight locations and contain a variable
attenuator with -5 to +15dB amplification. It shall feature
one cable input and eight isolated television outputs. The
CATV module shall support bi-directional signal paths for
cable modem or cable box communications. It shall also
come in a small circuit board design with a 90° angle, an
impedance of 75 Ohm, F-Type connectors and come with
a 12VDC 1A power supply. The manufacturer shall provide
a two-year limited product warranty.
Leviton Mfg. Co., Inc.
59-25 Little Neck Pkwy • Little Neck, NY 11362-259
Customer Service: 1-800-323-8920 • Tech Line: 1-800-824-3005 • Fax: [phone]
Visit our Website at: www.leviton.com

ORDERING INFORMATION
Description Cat. No.
1x8 CATV Modue, 1 GHz 47693-ESM
Nickel Plated Connectors
1x8 CATV Module, 1 GHz 47693-GSM
Gold Plated Connectors
2
Product
Specifications
DIMENSIONAL DRAWINGS
3.00 (76.2)
0.25 (6.3)
6.00 (152.4)
0.25 (6.3)
6.50 (165.1)
3.50 (88.9)
3.20 (81.2)
Power to RF Input Isolation 5-1000 MHz 100dB (min)
RFI Isolation 5-1000 MHz -110dBc
Noise Figure 5-1000 MHz 3.5dB
CSO -65dBc
Distortions* CTB -74dBc
Xmod -75dBc
Parameter Bandwidth Forward Path Return Path
Band - - 52-1000Mhz 5-42Mhz
Gain (Loss) - - 4dB (-0.5dB)
Flatness - - ±0.75dB ±1.5dB
Return Loss – Input - - 22.0dB 21.0dB
Return Loss – Output - - 22.0dB 21.0dB
Port Isolation – Output - - 25.0dB 27.0dB
Group Delay (span 3.58Mhz) 54-60Mhz 15ns - -
61-1000Mhz 7ns - -
Group Delay (span 1Mhz) 5-42 MHz - - 17ns
10-40 MHz - - 10ns
B-1208/J6 nsk
Visit our Website at www.leviton.com
Leviton Manufacturing Co., Inc.
59-25 Little Neck Parkway, Little Neck NY 11362-2591
Customer Service: 1-800-323-8920 • FAX: [phone] Tech Line: 1-800-824-3005
Leviton Manufacturing of Canada, Ltd.
165 Hymus Boulevard, Pointe Claire, Quebec H9R 1E9 Customer Service: 1-800-469-7890 • FAX: [phone]
Leviton S. de R.L. de C.V.
Lago Tana 43 Mexico DF, Mexico CP 11290 Tel. [phone] www.leviton.com.mx
Note: Features and specifications subject to change
Patents Pending ©2006 Leviton Manufacturing Co., Inc.
AGENCY STANDARDS & COMPLIANCE
Meets all applicable standards.
WARRANTY INFORMATION
Two-year limited product warranty
100-47693-ESM/GSM
* Input level at +10dBmV flat 77 channels & 200Mhz noise for QAM test from 550 to 790Mhz
Operating Temperature: -40ºC to +60 ºC
1x8 CATV
MODULES
.............................
