User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
First Release: 14-Jun-17
Last Update: 14-Jun-17
LEVIFLOW®INTEGRATED
FLOWMETER LFIF
USER MANUAL
LEVIFLOW®Integrated Flowmeter: LFIF-06 (10 l/min)
This manual contains information necessary for the safe and proper use of the LEVIFLOW®LFS flowmeter series.
Included are specifications for the standard configuration, components, and instructions regarding its use, installation,
operation, adjustment, inspection and maintenance. For special configuration of the LEVIFLOW®flowmeters refer to
accompanying information. If the flowmeters have to be configured for other parameter settings then the LEVIFLOW®
Configuration Software (see relevant manual Levitronix

Doc.# PL-4501-00) is necessary. Please familiarize yourself
with the contents of this manual to ensure the safe and effective use of this product. After reading, please store the
manual where the personnel responsible for operating can readily refer to it at any time.

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
2
Table of Contents
1SAFETY PRECAUTIONS ..........................................................................................................................................3
2SPECIFICATIONS .....................................................................................................................................................4
2.1 Component Overview........................................................................................................................................4
2.2 General Specifications.......................................................................................................................................4
2.3 Basic Dimensions of Main Components............................................................................................................5
2.3.1 Dimensions of Flowmeter.................................................................................................................................................5
2.3.2 Dimensions of Cables ......................................................................................................................................................5
2.4 Overview of Parameter Configuration................................................................................................................6
3INSTALLATION.........................................................................................................................................................7
3.1 Electrical Installation..........................................................................................................................................7
3.1.1 Overview and Preparation................................................................................................................................................7
3.1.2 Instructions for Electrical Installation.................................................................................................................................8
3.1.3 Configuration of Flowmeter Data......................................................................................................................................9
3.2 Mechanical and Hydraulic Installation................................................................................................................9
3.2.1 Instructions.......................................................................................................................................................................9
4OPERATION............................................................................................................................................................10
4.1 General Timing Specifications.........................................................................................................................10
4.1.1 Startup Time ..................................................................................................................................................................10
4.1.2 Thermal Stability Time....................................................................................................................................................10
4.1.3 Zero Adjustment Activation Time....................................................................................................................................10
4.1.4 Automatic Zero Adjustment Duration..............................................................................................................................10
4.2 Operation.........................................................................................................................................................10
4.2.1 System Operation with PLC Interface.............................................................................................................................10
4.2.2 Operation with RS485....................................................................................................................................................10
4.2.1 LED Messages...............................................................................................................................................................10
4.2.2 Operation with LEVIFLOW®Configuration Software.......................................................................................................11
5INSPECTION AND MAINTENANCE .......................................................................................................................11
6TROUBLESHOOTING.............................................................................................................................................12
6.1 Common Troubles...........................................................................................................................................12
6.2 Troubleshooting with LEVIFLOW®Configuration Software..............................................................................12
7TECHNICAL SUPPORT ..........................................................................................................................................12
8APPENDIX...............................................................................................................................................................13
8.1 Regulatory Status............................................................................................................................................13
8.1.1 CE Marking....................................................................................................................................................................13
8.2 Symbols and Signal Words..............................................................................................................................13

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
3
1 Safety Precautions
CAUTION
Do not under any circumstances open the flowmeter housing.
Levitronix does not assume responsibility for any damage, which
occurs under such circumstances.
!
WARNING
Hazardous voltage may be present.
In case of the usage of an inadequate AC/DC power supply, mains
voltages may be present (even if the system is designed for 24VDC).
Do not under any circumstances open the powered converter.
The usage of galvanic separated 3rd party tested (like CE and/or UL)
AC/DC supply is highly recommended.
!
WARNING
Toxic chemicals may be present.
When using the flowmeter to measure chemicals skin contact and toxic
gases may be hazardous to your health. Wear safety gloves and other
appropriate safety equipment.

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
4
2 Specifications
2.1 Component Overview
Figure 1: Standard LEVIFLOW®LFIF components and accessories
Pos.
Article Name
Part #
Feature/Description
Note
1
LFIF-06
100-30393
Integrated Flowmeter
Calibration parameters are stored in flowmeter.
2a
LFE-E.1-50
190-10371
Extension Cable 5m PVC
Waterproof lock-release mounting connector type for flowmeter connection.
Open wires at cable end for connecting to other equipment.
2b
LFE-E.2-50
190-10372
Extension Cable 5m PVC
Waterproof lock-release mounting connector type for flowmeter connection. Integrated
pull-up resistor at digital output for flow switch applications.
2b
LFE-E.3-50
190-10383
Extension Cable 5m PVC
Waterproof lock-release mounting connector type for flowmeter connection. Open
wires at cable end, integrated conversion for analog output from current to voltage.
3
YN-485I-TR, USB to
RS485 Adaptor-TR
Isolated
100-30392
Structure/Design
USB connector (3a) with termination resistor and cable with connector pair (3b and 3c)
for external RS485 wire connection. Magnetically isolated. Cable length is 2m.
Purpose
Communication over fieldbus of converter with PC
Table 1: Order information for standard flow sensor models
2.2 General Specifications
Characteristics
Specification
Flow Range [l/min]
0 –10 l/min
Accuracy of Reading
@ 20 °C Water
For > 1.7 l/min: ± 2%
For < 1.7 l/min: ± 34 ml/min
Kinematic Viscosity
0.36 –1.3 mm2/s (0.36 –1.3 cSt)
Sound Speed
1450 –1550 m/s (water)
Fluid Temperature
10 –80 oC (50 –176 oF )
Ambient must be < 40 °C at 80 °C fluid temp.
Ambient Temperat.
0 –50 oC (32 - 122 oF)
Max. Fluid Pressure
0.5 MPa = 5 bar
Power Supply
Inrush current
24 VDC ±10%, 38 mA
Peak < 690 mA during < 1 ms
Pressure Drop
380 mbar at 10 l/min and 20 °C water
Wet Parts / Fittings
PFA / Tube 3/8” (OD=9.52, ID=6.38 mm)
Characteristics
Specification
Weight
~ 80 g for flowmeter and ~ 180 g for 5m extension cable
Housing
Materials
PPS for housing body, FKM for sealing gaskets
PEEK for screws, PET for label
IP Classification
IP-65 (indoor)
Electrical
Connector
Circular type, lock-release mounting
(housing material: PPS)
Cables
Separate extension cable with connector (see Figure 3)
Interfaces
(see also Table 5)
RS485 with Modbus protocol
Analog Output with 0-20 mA (4-20mA configurable)
Digital Output:
Measurement Error, Flow Alarm, Volume Counter Pulse,
Pulsed Flow Output (0-1000Hz)
Configuration
Parameters
(Lev. Config. SW)
Viscosity Linearization (up to 10 points)
Low Cutoff Alarm Outputs (low and high)
Damping Time (filter) Volume Counter
Table 2: Specifications of flowmeter LFIF-06
(All data based on water at 20 oC with zeroing and ambient at 25°C.)
1
2
3a
3b
3c

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
5
2.3 Basic Dimensions of Main Components
2.3.1 Dimensions of Flowmeter
Figure 2: Dimensions of LFIF-06 Flowmeter
2.3.2 Dimensions of Cables
Figure 3: Dimensions of extension cable LFE-E.1/2/3-50
Note: Maximum bending load is 15N.

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
6
2.4 Overview of Parameter Configuration
Table 3 shows the standard (“Default”) and possible parameter configurations of the flowmeter. This user
manual is dealing with the standard configuration. For setting up other configurations the LEVIFLOW®
Configuration Software is needed. Consult the “Configuration-SW User Manual” (Levitronix

Doc.# PL-4501-
00) for more detailed description.
Note: The LFIF-06 flowmeter needs configuration software version V1.34 or higher.
Block
Parameter
Option/Range
Default
Note
Basic
Sensor size
LFIF-xx
xx = 06
xx = 06
(accord. Sensor size)
xx indicates the measurement ID of the tube.
Full scale
0.01 –100 L/min
(accord. Sensor size)
Default Values:
LFIF-06 = 10 L/min
Damping time
0 –25 s
2 s
Low-pass filter with
T
fdB  
 21
3
Low cutoff
0.0 –25.0 %
2 %
Flow cut to 0 below this percentage of full-scale
If cutoff 0% is chosen, negative flow becomes visible
Kinematic Viscosity
0.00 –99.99 cSt
1 cSt
Kinematic Visc. = Dynamic Visc. / Density
Not implemented for LFIF-06 flowmeter.
Analog output
settings
Analog output setting
4 –20 mA or
0 –20 mA
0 –20 mA
With the LFE-E.3 cable the current can be converted into
0 –10 V voltage.
Digital output
settings
Digital output
Flow alarm High
Flow alarm Low
Vol. counter Pulse
Measurement Error
Flow as Frequency
Digital Output Off
Measurement Error
- Upper flow limit detection
- Lower flow limit detection
- Pulse per volume
- Error signal (empty sensor etc.)
- Flow as Frequency output (100% of full-scale = 1 kHz)
- Set digital output off
Flow alarm
Hysteresis (Flow alarm)
0 –20 %
0 %
Can be used to get tolerance to noise.
Alarm high
0 –125 %
105 %
Alarm setting In percentage of full-scale.
Contact type
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
For digital output.
Alarm low
-10 –125 %
-5 %
Alarm setting In percentage of full-scale.
Contact type
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
For digital output.
Volume counter
settings
Volume counter enable
(activation box)
activated, not activated
not activated
These are settings for volume detection (integration of
flow).
Has to be active for the option “Vol. Counter Pulse” on
digital output.
Volume counter base unit
1 mL, 1 L, 1 m3
1 L
Multiplier factor
0.01, 0.1, 10, 100, 1000
1
Volume counter pulse length
0.5, 50, 100ms
0.5 ms
Measurement
Error Settings
Instant Measurement Error
Ignore Time
0-99 s
10s
During this time instant measurement errors are ignored.
If an instant measurement error stays active for longer
time than this time, measurement error arises.
Flow Level on Measurement
Error
0%, -25, 125%
Hold
0 %
Signal level of analog output and flow, when
measurement error arises
Table 3: Overview of parameters

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
7
3 Installation
3.1 Electrical Installation
3.1.1 Overview and Preparation
Figure 4: Integrated flowmeter LFIF-06
Interface Item
Description
1
Cable Connector
Supply and electrical interface (see Table 5 for specifications).
2
“Zero” Button
For offset elimination with zeroing. To be pressed for more than 3 seconds to start zeroing.
Zeroing process duration is about 20 seconds.
3
“Flow” LED
Indicates status of flow measurement is blinking with frequency proportional to flow (~20 Hz
at 100% of full scale). At zero flow it is constantly on.
4
“High” LED
Indicates high flow alarm (see Table 3).
5
“Low” LED
Indicates low flow alarm (see Table 3).
6
“Arrow” Label
Indicates flow direction.
7
Label with Serial Number
Unique serial number for traceability.
8
Type Label
Contains article number and part name.
Table 4: Standard specifications of interface items on flowmeter
Pin #
Cable
Wire Color
Wire Size
Description
Standard
Designation
Specification and Description.
6
Brown
AWG26
0.18 mm2
DC24V-
Power Supply
Supply Voltage: 24 VDC ±10%
DC24V- to be connected to earth.
5
Red
AWG26
0.18 mm2
DC24V+
4
Yellow
AWG28
0.11 mm2
RS485-
Field Bus
Modbus protocol for communication with PC.
3
Orange
AWG28
0.11 mm2
RS485+
2
Green
AWG28
0.11 mm2
Analog Out+
Flow Value
Current: 0 –20 mA (load resistance < 500 Ohm), Reference is DC24V-
Note: Cable LFE-E.3 contains integrated resistor for conversion 0 –10V output.
1
Blue
AWG28
0.11 mm2
Digital Out+
Error
Open collector with nominal load DC 30V/10mA, Reference is DC24V- 1
Note: Cable LFE-E.2 contains integrated pull-up resistor for electrical definition of
default signal.
Note: see Table 3 for origin of errors.
Table 5: Standard interface specification of flow sensor connector and cable LFE-E.1/2
Note 1: Cable LFE-E.2 contains integrated pull-up resistor for electrical definition of default signal.
2: „Zero“ Button
6: „Arrow“ Label for
Flow Direction
1: Cable Connector
3: „Flow“ LED
4: „High“ LED
5: „Low“ LED
7: Label with Serial Number
8: Type Label

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
8
Figure 5: Typical interface connection chart with LFE-E.1 (current output) and LFE-E.3 (voltage output)
Figure 6: Typical interface connection chart with LFE-E.2 (flow switch applications)
3.1.2 Instructions for Electrical Installation
!
WARNING
Hazardous voltage may be present.
Always isolate the electrical power supply before making or changing
connections to the unit.
!
WARNING
Flammable gases.
Do not place the integrated flowmeter next to flammable gases.
LFIF-06 Example of User
Interface Circuit
GND
Blue: Digital Output
Green: Analog Output
Orange: RS485+
Yellow: RS485-
GND
4-20mA /
0-20mA
RS485/USBCable
with Termination
Personal
Computer
(Service)
24V
R < 500 Ohm
Max. 30V / 10mA
Open
Collector R > 3 kOhm
Relais
Cable Wires
Colors/Designation
LFE-E.1
R = 510 Ohm
Tool
Control
R = 510 Ohm
AC/DC Supply
24 VDC
Red: 24 VDC
Brown: Ground
R = 120 Ohm
+5V
LFIF-06 Example of User
Interface Circuit
GND
Blue: Digital Output
Green: Analog Output
Orange: RS485+
Yellow: RS485-
GND
0-20mA
RS485/USBCable
with Termination
Personal
Computer
(Service)
24V
R > 100 kOhm
Max. 30V / 10mA
Open
Collector R > 3 kOhm
Relais
Cable Wires
Colors/Designation
LFE-E.3
R = 510 Ohm
Tool
Control
R = 510 Ohm
AC/DC Supply
24 VDC
Red: 24 VDC
Brown: Ground
R = 120 Ohm
+5V
Current-voltage resistor
20mA to 10V conversion
500Ohm/0.5W integrated
in cable LFE-E.3.
0-10V
LFIF-06 Example of User Interface Circuit
GND
Blue: Digital Output
Green: Analog Output
Orange: RS485+
Yellow: RS485-
GND
4-20mA /
0-20mA
RS485/USBCable
with Termination
Personal
Computer
(Service)
24V
Max. 30V / 10mA
Open
Collector R > 8.3 kOhm
Safety
Switch
Relais
Cable Wires
Colors/Designation
LFE-E.2
R = 510 Ohm
Tool
Control
R = 510 Ohm
AC/DC Supply
24 VDC
Red: 24 VDC
Brown: Ground
R = 120 Ohm
+5V
Pull-Up resistance
4.7 kOhm is integrated in
cable LFE-E.2.

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
9
1. Remove the DC power from the flowmeter.
2. Remove the cable from the flowmeter connector.
3. Attach the necessary cable wires according to the pin specifications in Table 5.
4. For usage of a fuse at the power input (24 VDC) a 200 mA slow-blow type is recommended. Consider inrush
current specification (see Table 2), when choosing the fuse type and the AC/DC power supply.
5. Attach the cable to the flowmeter connector.
6. Before powering on check again all wiring connections. Confirm that the terminals are securely fastened and
that there is no possibility of short circuit.
3.1.3 Configuration of Flowmeter Data
The flowmeter comes configured with the sensor specific data already stored in it. A calibration sheet
including the calibration data (the K-Factor and the 5 Calibration Values) is also part of the package. In case
this data should have to be changed to the users specific needs LEVIFLOW®Configuration Software can be
used. Consult the configuration “Configuration-SW User Manual” (Levitronix

Doc.# PL-4501-00) for
handling with the LEVIFLOW®configuration software.
Note: The LFIF-06 flowmeter needs configuration software version V1.34 or higher.
3.2 Mechanical and Hydraulic Installation
3.2.1 Instructions
1. In order to mechanically fix the sensor body 4 threads (see Figure 2) can be used.
2. Assure that at the mounting location the allowed ambient temperature is not exceeded (see Table 2)
3. The flow circuit should be completely filled with fluid. The converter DSP (Digital Signal Processor) contains
special algorithms, which increase the robustness of the measurement against bubbles. However, assure
that excessive bubbles are avoided in the circuit.
4. Ideal mounting position for the flow sensor is upward flow direction to avoid the stagnation of bubbles and
particles in the measuring tube.
5. Make sure that the arrow mark on the flowmeter shows into the direction of the flow in the hydraulic circuit.
6. Avoid excessive vibrations such as in the neighborhood of displacement pumps. Insufficient contact of the
transducer (within the sensor) onto the pipe wall caused by vibration may result in inaccurate measurement.
7. The flowmeter measures flow velocity. In order to obtain fully developed flow pattern for accurate velocity
measurement, straight run of 60 mm upstream and of 40 mm downstream is recommended. If non-uniform
turbulent flow or swirl flow is expected, install longer upstream straight run and/or a flow-rectifier.
8. To install on pipe that has open end, the sensor should be mounted in lower position of the pipe line.
9. The flowmeter should be mounted where pressure in the pipe is above the atmospheric pressure.
10.Devices like valves are recommended to be installed downstream of the sensor in order to prevent formation
of bubbles in the liquid. An upstream valve may form bubbles reducing the intensity of the ultrasound signal
and interfering with measurement.
11.A bypass pipe run (including bypass valve and shutoff valve) is recommended for easy zero adjustment and
maintenance.
12.Please confirm that the maximum pressure is below the in Table 2 specified pressure of the sensor.
13.After setup a “Zeroing” is recommended. Assure that the sensor is completely filled with the according fluid
and is free of bubbles. Stable liquid properties should be assured by flushing the circuit with the final liquid
until temperature and viscosity becomes stable. After this zero flow shall be realized. Then push the “ZERO”
button on the flowmeter for about 3 seconds. During adjustment the “High” and “LOW” LEDs are blinking.
14.In the following cases a re-zero is recommended:
a. 30 minutes after power-on of a cool converter and sensor
b. Change of fluid properties (temperature, viscosity, density)
c. Change of chemistry
d. Change of the hydraulic circuit

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
10
4 Operation
4.1 General Timing Specifications
4.1.1 Startup Time
After power-on a startup sequence proceeded. During this sequence flow measurement is not performed.
Start-up time is about 3 seconds.
4.1.2 Thermal Stability Time
To guarantee specified accuracy thermal stability of sensor has to be reached. Therefore it is recommended
to wait 30 minutes after power-on.
4.1.3 Zero Adjustment Activation Time
There are two possibilities to activate zero adjustment:
1. Activating by LEVIFLOW®configuration software: Zero adjustment starts immediately after pressing
corresponding button.
2. Activating by “Zero” button on the flowmeter (see Figure 4) has to be pressed during more than 3 seconds to
initiate zero adjustment.
4.1.4 Automatic Zero Adjustment Duration
The duration to perform an automatic zero adjustment is about 20 seconds.
4.2 Operation
4.2.1 System Operation with PLC Interface
Figure 5 shows the standard configuration of the digital and analogue output. For other configurations the
LEVIFLOW®configuration software has to be used (according manual is Levitronix

Doc.# PL-4501-00).
Note: The LFIF-06 flowmeter needs configuration software version V1.34 or higher.
4.2.2 Operation with RS485
Operation with communication over an RS485 bus is possible. The according MODBUS protocol can be
requested at Levitronix

.
4.2.1 LED Messages
#
Event/Situation
LED
Status Description
“Flow”
“High”
“Low”
1a
Power-on - successful
On
3 times blinking of all LEDs and then “Flow”constantly on.
1b
Power on - error
On
On
3 times blinking of all LEDs and then “Flow”and “High”constantly on.
Origin of error can be bubbles etc.
1c
After power-on –zero error
On
On
On
3 times blinking of all LEDs ant the all constantly on.
Zero adjustment failed when the power was turned on last time.
1d
After power-on –firmware
rewriting mode
Off
Off
Off
3 times blinking and then all LEDs off. Firmware rewriting mode.
Contact Levitronix for more information.
2a
Zero adjustment - successful
On
Successful zeroing start is indicated by “High” on and then “High” and
“Low” are on during the 20 seconds zeroing process.
2b
Zero adjustment - failed
On
On
On
Zeroing failed.
3a
Flow measurement - normal
Blinking
Is blinking with frequency proportional to percentage of full scale.
At zero flow constantly on.
3b
Flow measurement –high alarm
Blinking
On
High flow alarm error.
3b
Flow measurement –low alarm
Blinking
On
Low flow alarm error.
4
At parameter writing - error
On
On
On
Parameter writing failed (EEPROM write error etc.).
4
Firmware Download
On
Blinking
Firmware download on-going.
Table 6: LED messages/designation of flowmeter

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
11
4.2.2 Operation with LEVIFLOW®Configuration Software
For debugging, data collection and configuration of the flowmeter system the LEVIFLOW®Configuration
Software is available at Levitronix®. Contact Levitronix®for a sample of the configuration software and the
according manual (Levitronix

Doc.# PL-4501-00). An approved USB to RS485 adaptor with the according
connection cable can be ordered according to the information in Table 1.
Note: The LFIF-06 flowmeter needs configuration software version V1.34 or higher.
Figure 7: System operation with LEVIFLOW®configuration software
5 Inspection and Maintenance
The LEVIFLOW®ultrasonic flowmeters do not require special maintenance since there are no moving parts
that can be subjected to wear and tear. However, the following periodical checks are recommended to
ensure smooth and reliable operation:
1. Check for excessive mechanical stress onto the flow sensor body for example caused by
bended piping.
2. Inspect for loosen connections caused by excessive pipe vibrations.
3. Inspect the sensor visually for any deposits, excessive bubbles or foreign materials in the
measuring tube.
Power Supply
24 VDC
Analog and
Digital Outputs
- 1x Analog Output
- 1x Digital Output LEVIFLOW®
Configuration Software
System Configuration
Service, Firmware Update
Monitoring
Flow In
Flow Out
LEVIFLOW®
Integrated Flowsensor LFIF-06
Sensor Cable
(Opten Wire)
Screw type connector for
open-wires connection included in
converter cable package.
USB to RS485
Converter with Cable
Fieldbus
RS485

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
12
6 Troubleshooting
6.1 Common Troubles
#
Phenomenon
Possible Cause
Countermeasure
1
Zero flow is indicated even if there is
flow in the hydraulic circuit
Wrong parameter and
mechanical setup of sensor or
zero adjustment performed
under flow conditions.
- Check if the parameters have been set to the optimal
values
- Check if the flow direction is correct
- Redo zeroing at 0 lpm
2
Zero flow is indicated at flow level
below cut-off value.
Standard cut-off value as
shown in Table 3 is not
adequate for application.
- Adapt lower cut-off value with LEVIFLOW®Configuration
Software
3
The flow indication does not match
the real flow
Wrong parameter settings,
excessive bubbles or solids in
the measurement path.
- Check if the parameters in the converter are set correctly
- Inspect the flow path for stagnating solids
- Inspect the measurement path for excessive bubbles
4
Above full scale flow is indicated or
the flow signal is unstable
Wrong parameter settings,
excessive bubbles or solids in
the measurement path.
- Check if the parameters in the converter are set correctly
- Inspect the flow path for stagnating solids
- Inspect the measurement path for excessive bubbles
Table 7: Potential troubles and the possible countermeasures
6.2 Troubleshooting with LEVIFLOW®Configuration Software
More detailed error analysis can be done with the LEVIFLOW®Configuration Software. Contact Levitronix®
for a sample of the configuration software and the according manual (Levitronix

Doc.# PL-4501-00).
Note: The LFIF-06 flowmeter needs configuration software version V1.34 or higher.
7 Technical Support
For troubleshooting, support and detailed technical information contact Levitronix

Technical Service
Department:
Levitronix

Technical Service Department
Technoparkstr. 1
CH-8005 Zurich
Switzerland
Phone for US: 888-569 07 18
Phone for outside US: [phone]
E-Mail: [e-mail]

User Manual for LEVIFLOW®LFIF-06 Flowmeters
www.levitronix.com
PL-4511-00, RevA, DCO# RD
13
8 Appendix
8.1 Regulatory Status
8.1.1 CE Marking
The LEVIFLOW®LFIF-06 flowmeter, in its various configurations is in conformity with the below mentioned
European Directives. The flowmeter is thought to be used in hydraulic circuits of the production equipment of
Semiconductor and Chemical industry.
EMC Directive 2014/30/EC:
The following particular harmonized standards of the EMC Directive are tested and confirmed.
EN 61000-6-4
Generic Emission standard for industrial environments
EN 61000-6-2
Generic Immunity standard for industrial environments
Pressure Equipment Directive 97/23/EC:
The pressure equipment directive is used as guide line according to Category I Modul A (internal quality
control). For maximum pressure validation the following standard is followed:
EN ISO 15494
Plastic piping system for industrial applications
ISO12100
Safety for machinery –principles for risk assessments: used for system risk analysis.
8.2 Symbols and Signal Words
Symbol /
Signal Word
Description
Type
Source
DANGER
Indication of an imminently hazardous situation that, if not
avoided, will result in death or severe injury. Limited to the
most extreme situation
Signal word
SEMI S1-0701
WARNING
Indication of a potentially hazardous situation which, if not
avoided, could result in death or severe injury.
Signal word
SEMI S1-0701
CAUTION
Indication of potentially hazardous situations which, if not
avoided, could result in moderate or minor injury. Also alert
against unsafe practice.
Without safety alert indication of hazardous situation which,
if not avoided, could result in property damage.
Signal word
SEMI S1-0701
!
Safety alert for “Warning” and “Caution”
Safety alert
SEMI S1-0701
!
Safety alert for “Danger”
Safety alert
SEMI S1-0701
Caution (refer to accompanying documents)
(is used on article labels for reference to manual)
Refer to manual
ISO 3864
Toxic material, poison
Hazard identification
IEC 61310
Danger: electricity, electrical hazard
Hazard identification
IEC 61310,
ISO 3864
General warning
Hazard identification
ISO 3864
Wear safety gloves
Hazard avoidance
Mandatory action
IEC 61310
Table 8: Safety symbols and signal words
