Levitronix LEVIFLOW LFSC-i06X User manual

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
First Release: 27-Sep-2019
Last Update: 16-Apr-2021
LEVIFLOW®
CLAMP-ON FLOWMETERS
USER MANUAL
LFSC-iX Clamp-On Flowmeters
LFSC-i06X:
1/8x1/4”, 1 l/min
LFSC-i10X:
1/4x3/8”, 4 l/min
LFSC-i16X:
3/8x5/8”, 20 l/min
LFSC-i19X:
1/2x3/4”, 50 l/min
LFSC-i25X:
3/4x1”, 80 l/min
LFSC-i35X:
1x13/8”, 160 l/min
This manual contains information necessary for the safe and proper use of the LEVIFLOW®LFSC-iX clamp-on
flowmeter series. Included are specifications for the standard configuration, components, and instructions regarding its
use, installation, operation, adjustment, inspection and maintenance. For special configuration of the LEVIFLOW®
flowmeters refer to accompanying information. If the flowmeters shall be configured for other parameter settings, then
the Levitronix®Service Software (with manual Levitronix

Doc.# PL-4048-00) with version V2.0.6.0 or higher is
necessary. Familiarize yourself with the contents of this manual to ensure the safe and effective use of this product.
After reading, please store the manual where the personnel responsible for operating can readily refer to it at any time.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
2
Table of Contents
1SAFETY PRECAUTIONS ..........................................................................................................................................3
2SPECIFICATIONS .....................................................................................................................................................4
2.1 Component Overview........................................................................................................................................4
2.2 Standard System Configurations.......................................................................................................................5
2.3 Specifications.....................................................................................................................................................6
2.4 Overview of Parameter Configuration................................................................................................................7
3INSTALLATION.........................................................................................................................................................8
3.1 Preparation........................................................................................................................................................8
3.2 Overview of Electrical Flowmeter Interface........................................................................................................9
3.3 Instructions for Electrical Installation................................................................................................................11
3.4 Mechanical and Hydraulic Installation..............................................................................................................12
3.5 Instructions for Tube Mounting ........................................................................................................................13
4OPERATION............................................................................................................................................................15
4.1 General Timing Specifications.........................................................................................................................15
4.1.1 Startup Time ..................................................................................................................................................................15
4.1.2 Thermal Stability Time....................................................................................................................................................15
4.1.3 Zero Adjustment.............................................................................................................................................................15
4.2 Standalone Operation with User Panel............................................................................................................15
4.2.1 Basic Operation..............................................................................................................................................................15
4.2.2 System Menu Functions.................................................................................................................................................15
4.3 Operation with PLC Interface...........................................................................................................................16
4.3.1 Operational Specifications..............................................................................................................................................16
4.3.2 Typical Setups Using the PLC Interface .........................................................................................................................16
4.4 Operation with Levitronix®Service Software....................................................................................................16
4.5 Operation with RS485......................................................................................................................................16
4.6 Measurement of Dynamic Flow Profiles ..........................................................................................................16
5INSPECTION AND MAINTENANCE .......................................................................................................................16
6TROUBLESHOOTING.............................................................................................................................................17
6.1 Common Troubles...........................................................................................................................................17
6.2 Troubleshooting with Messages on Flowmeter LED........................................................................................17
6.3 Troubleshooting with Levitronix®Service Software..........................................................................................17
7TECHNICAL SUPPORT ..........................................................................................................................................17
8APPENDIX...............................................................................................................................................................18
8.1 Regulatory Status............................................................................................................................................18
8.1.1 CE Marking....................................................................................................................................................................18
8.1.2 Disposal of Equipment –WEEE Directive 2012/19/EU...................................................................................................18
8.2 Symbols and Signal Words..............................................................................................................................19

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
3
1 Safety Precautions
CAUTION
Do not under any circumstances open the flowmeter housing.
Levitronix®does not assume responsibility for any damage, which
occurs under such circumstances.
!
WARNING
Hazardous voltage may be present.
In case of the usage of an inadequate AC/DC power supply, mains
voltages may be present (even if the system is designed for 12-24VDC).
Do not under any circumstances open the powered flowmeter.
The usage of galvanic separated and 3rd party certified AC/DC supply is
highly recommended.
!
WARNING
TOXIC CHEMICALS may be present.
When using the flowmeter to measure chemicals skin contact and toxic
gases may be hazardous to your health. Wear safety gloves and other
appropriate safety equipment.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
4
2 Specifications
2.1 Component Overview
Pos.
Part Name
Article #
Tube: ID x OD
Flow Range
Calibration Sets and Note
1a
LFSC-i06X-002
100-30485
ID = 1/8”= 3.2 mm, OD = 1/4”= 6.4 mm
1 lpm
Water @ 20°C and 37°C
Silicone Pharma compatible with AdvantaSil®APHP (High Pressure)1
C-Flex® 2 and AdvantaFlex®(TPE) 1
Default activated calibration set is Silicone Pharma at 37°C water
temperature.
Other calibrations sets can be chosen with Levitronix®Service
Software or with user panel LUI-B.1.
1b
LFSC-i10X-001
100-30477
ID = 1/4”= 6.4 mm, OD = 3/8”= 9.5 mm
4 lpm
1c
LFSC-i16X-001
100-30482
ID = 3/8”=9.5 mm, OD = 5/8”=15.9 mm
20 lpm
1d
LFSC-i19X-001
100-30479
ID = 1/2”=12.7 mm, OD = 3/4”=19.1 mm
50 lpm
1e
LFSC-i25X-001
100-30480
ID = 3/4”=19.1 mm, OD = 1”=25.4 mm
80 lpm
1f
LFSC-i35X-001
100-30481
ID = 1”= 25.4 mm, OD = 13/8”= 34.9 mm
160 lpm
Table 1: Standard flow sensor configurations
Note 1: AdvantaSil®and AdvantaFlex®are registeredtrademarks of NewAge Industries. All rights reserved.
Note 2: C-Flex®is a registered trademark of Saint Gobain Performance Plastics, 2015. All rights reserved.
Pos.
Component
Article Name
Article #
Features
Special Feature / Description
2
User Panel
LUI-B.1-02
100-30473
Description
Standard Firmware
Monitoring flow, zeroing and tubing set selection. IP65 rating. Basic dimens.:
A4.00
3
Desktop AC/DC
Power Supply
SMI36-24-V HR30
100-40023
Voltage Output / Input
Basic Dimensions
Safety Approvals
Note
24VDC, 36 W / 90 –264 VAC, 47-63 Hz
78.5 x 66 x 35 mm, cable length = 1.4 m
UL/cUL (60950-1, 62368-1), RCM, CCC, PSE
Included are interchangeable AC blades (adaptors) for global usage (B).
4
Y-Split Cable
ICY-1.1-02 (0.2 m)
190-10448
Materials / Length
Connection In / Out
Main Purpose
PVC jacket with TPE split block / 0.2m for one cable side, 0.2m for split cables.
Circular Hirose type / 2x Circular Hirose type
Split signals to connect flow sensor to power supply and user panel or PC.
5
IPS Cable Signal
6 Wires
ICS-1.1-01 (0.1 m)
ICS-1.1-10 (1 m)
ICS-1.1-30 (3 m)
190-10343
190-10344
190-10345
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 6x 0.08 mm2and shielding
Circular Hirose type / Circular Hirose type
Interconnect cable for LUI-B.1 user panel.
6
IPS Cable Signal
6 Wires
ICS-1.3-50 (5 m)
190-10389
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 6x 0.08 mm2and shielding
Connector with screw type plug for open wire connection / Circular type
Interconnection cable from Fieldbus of Split-Cable to USB/RS485 adaptor.
7
USB to RS485
Adaptor-TR Isolated
YN-485I-TR
100-30392
Structure/Design
USB connector (A) with termination resistor and cable with connector pair (B and C) for
external RS485 wire connection. Magnetically isolated. 2m cable length. Included is a USB
space saver cable (D).
Purpose
Communication over fieldbus of flowmeter with PC
8a
IPS Cable Signal
12 Wires
ICS-2.2-50 (5 m)
190-10446
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 12x 0.14 mm2and shielding
Connector with screw type plug for open wire connection / Circular Hirose type
Cable for OEM configurations.
8b
IPS Cable Signal
12 Wires
ICS-2.4-50 (5 m)
190-10475
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 12x 0.14 mm2and shielding
Connector with screw type plug for open wire connection / Circular Hirose type
Cable for OEM configurations with integrated supply source (A) for current output of analog out.
Table 2: Accessories
Figure 1: LEVIFLOW®flowmeter components
Figure 2: Accessories
1c
1d
1b
1e
1a
1f
2
8a
A
7
B
C
A
B
4
5
6
3
8b
A

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
5
2.2 Standard System Configurations
Figure 3: Stand-Alone system configuration
(See section “Order Information” for details to numbered components and other options)
Figure 4: Configuration for PC with Levitronix®Service Software (parameter configuration, Data logging and monitoring)
(See section “Order Information” for details to numbered components and other options)
Figure 5: OEM system configuration
(See section “Order Information” for details to numbered components and other options)
Flow In
Flow Out
LEVIFLOW®
Clamp-On
Flowmeter
LFSC-iX
Series
Splitting Cable
User Panel
LUI-B.1
AC/DC Supply
International
Mains Insert
Interconnect Cable
(Direct connection possible.)
Flow In
Flow Out
LEVIFLOW®
Clamp-On
Flowmeter
LFSC-iX
Series
Splitting Cable
AC/DC Supply
International
Mains Insert
Levitronix®
Service Software
Configuration
Service/Firmware Update
Data Logging/Monitoring
USB to RS485
Converter with Cable
Flow In
Flow Out
LEVIFLOW®
Clamp-On
Flowmeter
LFSC-iX
Series
OEM Cable
PLC:
2x Analogue Output
2x Digital Output
1x Digital Input
Screw type connector for
open-wires connection
included in cablepackage.
DC Supply
Fieldbus
(RS485 Modbus)
1
4
3
3
2
4
B
1
6
A
8
7
1
5

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
6
2.3 Specifications
Characteristics
LFSC-i06X
LFSC-i10X
LFSC-i16X
LFSC-i19X
LFSC-i25X
LFSC-i35X
Flow Range [l/min]
0 –1 l/min
0 –4 l/min
0 –20 l/min
0 –50 l/min
0 –80 l/min
0 –160 l/min
Accuracy of Reading 3
(Tubing variation not incl.)
> 10% FS
< 10% FS
±2 %
±2 ml/min
±1.5 %
±6 ml/min
1.5 %
±30 ml/min
±1.5 %
±75 ml/min
1.5 %
±120 ml/min
1.5 %
±240 ml/min
Weight
390 g
390 g
480 g
480 g
1090 g
1090 g
Maximum Fluid Pressure
(max. pressure of tube might limit this value)
6.5 bar
6.5 bar
5 bar
5 bar
5 bar
5 bar
Pressure Drop Coefficient C 2
P = C x Q2 , (for water), Q = Flow [l/min]
P = Press. Drop [kPa = 10 mbar]
0.00985 at 20°C
0.00980 at 37°C
0.00185 at 20°C
0.00185 at 37°C
3.47x10-4 at 20°C
3.45x10-4 at 37°C
9.48x10-5 at 20°C
9.43x10-5 at 20°C
Usable
Flexible Tubing
Dimensions
ID
OD
Wall thickness
1/8” = 3.2 mm
1/4” = 6.4 mm
1/16” = 1.6 mm
1/4” = 6.4 mm
3/8” = 9.5 mm
1/16” = 1.6 mm
3/8” = 9.5 mm
5/8” = 15.9 mm
1/8” = 3.2 mm
1/2” = 12.7 mm
3/4” = 19.1 mm
1/8” = 3.2 mm
3/4” = 19.1 mm
1” = 25.4 mm
1/8” = 3.2 mm
1” = 25.4 mm
13/8” = 34.9 mm
3/16” = 4.8 mm
Standard Tube Material
a: Silicone Pharma 5, compatible with Silicone AdvantaSil®APHP (High Pressure) 4
b: Saint Gobain C-Flex®(374) 1c: AdvantaFlex®(TPE) 4
All calibration sets stored in flowmeter and calibrated at 20°C and 37°C water temperature. Default parametersetting is Silicone Pharma at 37°C.
Fluid / Ambient Temperature
Normal range: 10 –60 oC ( 50 –140 oF ) / 0 –40 oC (32 - 104 oF)
Measurable Kin. Viscosity / Sound Speed
0.5 –100 mm2/s (0.5 –100 cSt) / 1000 –2000 m/s (others on request)
Enclosure / Material / Cleaning
IP-65 / PPS/PTFE like coating/PP / Wiping with IPA or water
Ambient Temp / Humidity Range
0 –40 °C (32 –104 °F) / 15 –95% (non condensing)
Electrical Connector / Cables
Circular type (IP-67), lock-release mounting / Various extension/adaptor cables available.
Supply Volt. / Current / Inrush
12 - 24 VDC ± 10% /
Interfaces
RS485 -> MODBUS protocol 1x Analog Output 4 –20mA (0 –20mA configurable)
1x Digital Input: Volume Counter Reset or Zero Adjust Status LED
2x Digital Outputs: Flow Alarm, Error, Volume Counter Pulse, Counter Alarm, Flow as Frequency or Bubble Detection
Configuration Parameters
Low Cutoff, Dampening time (filter), Full scale, Linearization, Alarm Outputs (High/Low Alarm), Volume Counter Settings
Note: Available and configurable with RS485/USB converter and service software.
Table 3: Specifications of flowmeters (all data based on calibration with water at 20 or 37 °C with zeroing after clamping)
Note 1: C-Flex®is a registered trademark of Saint Gobain Performance Plastics, 2015. All rights reserved. Note 2: Pressure coefficient is calculated and accounts for the clamp length only.
Note 3: Accuracy is based on 1x standard deviation for calibration at 20 or 37°C ±3°C liquid temperature and 20°C±5°C ambient temperature with zeroing after clamping. Accuracy does not include tubing variation effects.
Note 4: AdvantaSil®and AdvantaFlex®are registered trademarks of NewAge Industries. All rights reserved. Note 5: All sensors calibrated with Pharma 65. LFSC-i25X/35X compatible to Pharma 80.
Sensor Type
Size
Type
Dimensions in [mm]
B
C
D
E
F
G
H
LFSC-i06X
1
54
66.3
82.2
51.3
M6 x 6
20
11.1
LFSC-i10X
1
LFSC-i16X
2
54
76.3
92.2
61.7
M6 x 6
25
12.1
LFSC-i19X
2
LFSC-i25X
3
80
104.6
120.4
87.1
M8 x 8
41
17.7
LFSC-i35X
3
Figure 6: Basic dimensions for clamp-on flowmeters
Note 1: Non-tolerated dimensions are for reference only.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
7
2.4 Overview of Parameter Configuration
Table 4 shows the standard (“Default”) and possible parameter configurations of the clamp-on flowmeters.
This user manual is dealing with the standard configuration. For setting up other configurations the Levitronix®
Service Software is needed. Consult the LevtronixService Software manual for more detailed description.
Block
Parameter
Option/Range
Default
Note
Basic
Sensor size
LFSC-ixxX
Automatically set.
xx = 06/10/16/19/25/35
Full scale
0.01 –160 L/min
Automatically set.
Default values are:
LFSC-i06X=1 lpm LFSC-i10X=20 l/min LFSC-i16X=20 lpm
LFSC-i19X=50 lpm LFSC-i25X=80 lpm LFSC-i35X=160 lpm
Damping time
0 –25 s
2.0 s
Low-pass filter with
T
fdB  =
 21
3
Low cutoff
0.0 –25.0 %
2 %
Flow cut to 0 below this percentage of full-scale
If cutoff 0% is chosen, negative flow becomes visible
Kinematic Viscosity
(= Dynamic Visc. / Density)
Not implemented
for LFSC-iX series
Not implemented
for LFSC-iX series
Not implemented for LFSC-iX series sensors.
Analog output
settings
Analog output setting
4 –20 mA or
0 –20 mA
4 –20 mA
--
Digital input
settings
Digital input
Volume counter reset
Zero adjust
Set Volume Counter to zero
Zero adjust
--
Digital output
settings
Digital output 1
Flow alarm High
Flow alarm Low
Vol. counter alarm H
Vol. counter alarm HH
Vol. counter Pulse
Measurement Error
Flow as Frequency
Bubble detect
Custom Output
Measurement
Error
- Upper flow limit detection
- Lower flow limit detection
- Flow volume detection first value (one-time)
- Flow volume detection second value
- Pulse per volume
- Error signal (empty sensor etc.)
- Flow as Frequency output (100% of full-scale = 1 kHz)
- Bubble detected signal
- Bits of equipment status can be OR-ed on the output
Digital output 2
Flow alarm High
Flow alarm
Hysteresis (Flow alarm)
0 –20 %
0 %
Can be used to get tolerance to noise.
Alarm high
0 –125 %
105 %
Alarm setting In percentage of full-scale.
Contact type
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
-
Alarm low
-10 –125 %
- 5 %
Alarm setting In percentage of full-scale.
Contact type
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
-
Volume counter
settings
Volume counter enable
(activation box)
activated, not activated
not activated
These are settings for volume detection (integration of
flow).
Has to be active for the options “ Vol. Counter Alarm H”,
“Vol. Counter Alarm HH” and “Vol. Counter Pulse”.
Volume counter base unit
1 mL, 1 L, 1 m3
1 mL
Multiplier factor
0.01, 0.1, 10, 100, 1000
0.1
Volume counter pulse length
0.5, 50, 100ms
0.5 ms
Volume counter alarm enable
(activation box)
activated, not activated
not active
-> Settings for one-time volume detection.
-> Volume = “Volume unit” x “Multiplier factor” x “Vol.
Counter Alarm H“ value”
-> Has to be active for the options “Vol. Counter Alarm
H”, “Vol. Counter Alarm HH”.
Value (Volume counter alarm H)
0 –999999
--
Contact type (H)
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
Value (Volume counter alarm HH)
0 –999999
--
Contact type (HH)
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
Measurement
Error Settings
Instant Measurement Error Ignore
Time
0-99 s
10s
During this time instant measurement errors are ignored.
If an instant measurement error stays active for longer
time than this time, measurement error arises.
Flow Level on Measurement Error
0%, -25, 125%
Hold
0 %
Signal level of analog output and flow, when
measurement error arises
Bubble
Detection
Settings
Bubble Detect Hold Time
Not implemented
for LFSC-iX series
Not implemented
for LFSC-iX series
Not implemented for LFSC-iX series sensors.
Table 4: Overview of parameters

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
8
3 Installation
3.1 Preparation
Figure 7: Clamp-on flowmeter LFSC-iX
1. Every sensor comes delivered with a calibration sheet. Check if the S/N on the calibration sheet
corresponds to the S/N of the sensor (see Figure 8).
2. Please store the delivered calibration sheet or its data on a defined storage place in order to be
able to refer to it in case of problems.
3. Assure that the correct calibration set for the tubing and liquid temperature is chosen. The
flowmeters are calibrated for multiple tubing types and liquid temperatures. Please check the
default factory setting on the article label. To switch to another calibration set the Levitronix®
Service Software or the user panel LUI-B.1-02 can be used (see Section 4.2.2).
Figure 8: Labels of flowmeter LFSC-iX
Flexible Tube
Clamp Mechanism
Circular Connector
Transducer Area
Flow Direction
Type Label
(located below the clamp)
Status LED
Type Label
Default calibration setting.
Attention
label can be
removed
here.
Serial Number Label

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
9
3.2 Overview of Electrical Flowmeter Interface
Figure 9: Electrical schematics of interfacing to OEM with PLC cable ICS-2.1
Note 1: RS485/USB converter cable with termination resistors to be ordered according to Table 2.
Note 2: Do not use multiple master devices on the RS485 at the same time.
GND
GND
1
3 4
6
GND
GND
22 Ohm
GND
0 Ohm
36V
GND
22 Ohm
GND
0 Ohm
36V
GND
R1
RE 2
DE 3
D4 GND
5
A
6
B
7
VCC
8R
D
GND
24V
GND
VCC
33V
GND
375mA
Cable Shield
4700 Ohm
LFSC-iX Casing
SupplyGround
SupplyDC+
RS485+
RS485-
Current Output 1
Dig Output 2ital
Digital Output 1
Digital Input
max. 24V DC / 100mA
5 ... 24V DC
0 ... 20mA
0 ... 20mA
To be connected to protective earth
180 Ohm
max.
-
+
5 ... 24V DC
180 Ohm
max.
-
+
5 ... 24V DC
40 Ohm
GND
40 Ohm
GND
GND
+12V ... +24V DC
-
+
5 ... 24V DC
Pin 8
Pin 9
Pin 12
Pin 7
Pin 6
Pin 4
Pin 5
Pin 2
Pin 1
Pin 11
Pin 3
- +
5 ... 24V DC
33V
10 Ohm
10 Ohm
GND
GND
GND
Pin 10
GND_CL1
GND_CL2
Power Source 1
Power Source 2
33V
33V
Current Output 1
Return Line
Current Output 2
Return Line
Current Output 2
510 Ohm
510 Ohm
GND
+5V
120 Ohm
User Cabinet
User Interface LFSC-iX
Interface
max. 24V DC / 100mA
ICS-2. Cable2
Pin 8
Pin 9
Pin 12
Pin 7
Pin 6
Pin 4
Pin 5
Pin 2
Pin 1
Pin 11
Pin 3
Pin 10
Hirose
connector
Phoenix
connector

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
10
Figure 10: Electrical schematics of interfacing to OEM with PLC cable ICS-2.4
Note 1: The cable ICS-2.4 contains an integrated power source for analog Current Output 1.
Note 2: RS485/USB converter cable with termination resistors to be ordered according to Table 2.
Note 3: Do not use multiple master devices on the RS485 at the same time.
GND
GND
1
3 4
6
GNDGND
22 Ohm
GND
0 Ohm
36V
GND
22 Ohm
GND
0 Ohm
36V
GND
R1
RE 2
DE 3
D4
GND
5
A
6
B
7
VCC
8
R
D
GND
24V
GND
VCC
33V
GND
375mA
Cable Shield
4700 Ohm
LFSC-iX Casing
GND
+12V ... +24V DC
RS485+
RS485-
Current Output 1
Digital Output 2
Digital Output1
Digital Input
max. 24V DC / 100mA
max. 24V DC / 100mA
5 ... 24V DC
0 ... 20mA to sensor
0 ... 20mA to sensor
180 Ohm
max.
-
+
5 ... 24 VDC
180 Ohm
max.
- +
40 Ohm
GND
40 Ohm
GND
GND
+12V ... +24V DC
-
+
5 ... 24V DC
Pin 8
Pin 9
Pin 12
Pin 7
Pin 6
Pin 4
Pin 5
Pin 2
Pin 1
Pin 11
Pin 3
-
+
5 ... 24V DC
33V
10 Ohm
10 Ohm
GND
GND
GND
Pin 10
GND_CL1
GND_CL2
Power Source
33V
33V
Current Output 1
Current Output 2
510 Ohm
510 Ohm
GND
+5V
120 Ohm
User cabinet
12 VDC
Pin 8
Pin 9
Pin 12
Pin 7
Pin 6
Pin 5
Pin 2
Pin 1
Pin 11
Pin 3
Pin 10
Pin 4
ICS-2.4 Cable Hirose
connector
Phoenix
connector
User Interface LFSC-iX Interface
fromsensor
Current Output 2
fromsensor

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
11
CAUTION
The analog outputs of the PLC of the flowmeter need an insulated power source on
the user side, which is separated from the flowmeter supply. Non insulated power
sources may damage the sensor.
Sensor Connector
ICS-2.2 and ICS-2.4
OEM Cable
Specification
Standard Configuration / Description
PIN
Designation
PIN
Wire Color 3
11
Supply DC+
11
Red
Voltage: 12-24 VDC ±10%,
Current: max. 120 mA
Inrush current: max. 0.3 A for 2ms
Supply.
3
Supply Ground
3
Yellow
1
RS485 +
1
White
RS485 with MODBUS Protocol.
Communication to PC, user panel and other devices. Multi-
flow sensor arrays with fieldbus.
2
RS485 -
2
Brown
7
Current Output 1+
7
Violet
4-20 mA or 0-20mA configurable
Max. load resistance 180 .
Note: Needs insulated power source on user
side. 2
Flow reading with 4-20 mA (0-20mA configurable). 1
Standard full scale flow range of each sensor model.
Note: ICS-2.4 cable contains an integrated power source for
analog Current Output 1.
6
Current Output 1
Return Line
6
Blue
4
Current Output 2+
4
Grey
4-20 mA or 0-20mA configurable
Max. load resistance 180 .
Note: Needs insulated power source on user
side. 2
For future use
5
Current Output 2
Return Line
5
Pink
8
Digital Output 1
8
Grey-Pink
Max. 24 VDC/100 mA
Reference is Supply Ground.
Measurement error
Other designations can be configured. 1
9
Digital Output 2
9
Blue-Red
Max. 24 VDC/100 mA
Reference is Supply Ground.
Flow alarm high
Other designations can be configured. 1
12
Digital Input
12
Black
5-24 VDC, 4.7 kOhm input shunt.
Reference is Supply Ground.
Zeroing input.
Other designations can be configured. 1
10
Shielding
10
White-Green
and Shield
Connected to flowmeter housing.
To be connected to protective earth of user interface. 2
Table 5: Standard configuration of electrical interface connector
Note 1: Configuration with Levitronix®Service Software. Note 2: See schematics Figure 9 for example of interfacing. Note 3: Wire size is 12x 0.14 mm2.
3.3 Instructions for Electrical Installation
1. Remove the DC power and all cables from the flowmeter before any installation work is done.
2. For operation with the user panel LUI-B.1 or with a PC attach the cables as shown in Figure 3 and
Figure 4.
3. For operation with the OEM cable ICS-2.2 or ICS-2.4, attach the necessary wires (AWG 14-26)
according to the pin specifications in Table 5. Strip the sheath approximately 3 mm from the wires
end. Insert core into the cable terminal to the end and tighten the screw. Confirm that the wires are
securely fixed by pulling it gently by hand.
4. Alternatively, the terminal of the ICS-2.2 or ICS-2.4 cable can be removed to assemble another
connector like wall-mountable circular connectors for cabinet mounting.
5. If another AC/DC power supply than the one offered by Levitronix®is used, than the specifications
in Table 5 shall be considered (voltage range, consumption current and start-up current).
6. For usage of a fuse at the power input a 200 mA slow-blow type is recommended considering the
inrush (start-up) current of the flowmeter (see Table 5).
7. Before powering on check again all wiring connections. Confirm that the terminals are securely
fastened and that there is no possibility of short circuit.
8. When applying power, the controller needs about 10 seconds for a start-up procedure to be ready.
In order to get stable temperature and signals for converter and sensor 30 minutes must be waited
after power-on.
9. After start-up a Zeroing is recommended. Assure that the sensor is filled completely with the
according fluid, free of bubbles and that zero flow is realized. Section 4.1.3 explains the zeroing
possibilities.
10. The Levitronix®Service Software can be used to debug and configure the flowmeter over the RS485.
For communication with RS485 the MODBUS protocol can be requested at Levitronix

.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
12
3.4 Mechanical and Hydraulic Installation
1. In order to mechanically fix the flowmeter body, 2 fixation threads on the backside of the housing can
be used (see Figure 6).
2. Assure that at the mounting location, the allowed ambient temperature and humidity ranges are not
exceeded (see Table 3).
3. Clamp the sensor to the tubing according to the procedure described in Section 3.5. Use only tubing
material for the specified calibration (see calibration sheet).
4. The flow circuit should be filled completely with fluid. The integrated converter contains special
algorithms, which increase the robustness of the measurement against bubbles. However, assure
that excessive bubbles are avoided in the circuit.
5. Ideal mounting position for the flow sensor is vertical direction (if not possible a slight angle) with
upward flow direction to avoid the stagnation of bubbles and particles in the measuring path of the
tubing.
6. An arrow mark on the flow sensor (see Figure 7) indicates the flow direction. Make sure that the
arrow corresponds to the direction of the flow in the hydraulic circuit.
7. Avoid excessive vibrations such as in the vicinity of displacement pumps. Insufficient contact of the
transducer (within the sensor) onto the pipe wall caused by vibration may result in inaccurate
measurement.
8. The flowmeter measures flow velocity. In order to obtain fully developed flow pattern for accurate
velocity measurement, straight run of 30x tubing ID upstream and of 12x tubing ID downstream is
recommended. If non-uniform turbulent flow or swirl flow is expected, install longer upstream straight
run and/or a flow-rectifier.
9. To install on a tubing that has open end, the sensor should be mounted in lower position of the
pipeline.
10. The sensor should be mounted where pressure in the pipe is above the atmospheric pressure in
order to avoid bubble generation by cavitation effects.
11. Devices like valves are recommended to be installed downstream of the sensor in order to prevent
formation of bubbles in the liquid. An upstream valve may form bubbles reducing the intensity of the
ultrasound signal and interfering with measurement.
12. A bypass pipe run (including bypass valve and shutoff valve) may be used for easy zero adjustment
and maintenance.
13. Please confirm that the maximum pressure is below the maximum pressure of the flexible tubing and
the maximum pressure of the sensor specified in Table 3.
11. After setup a“Zeroing”is recommended. Assure that the sensor is filled completely with the according
fluid and is free of bubbles. Stable liquid properties should be assured by flushing the circuit with the
final liquid until temperature and viscosity becomes stable. After this, zero flow shall be realized.
Section 4.1.3 explains the zeroing possibilities.
14. If Re-Zeroing is regularly necessary, automation is possible over the digital input of the flowmeter.
For the configuration of the digital input the Levitronix®Service Software is needed. Consult the
manual of the service software for more detailed description.
15. In the following cases a re-zero is recommended:
a. 30 minutes after power-on of a cool flowmeter.
b. Change of fluid properties (temperature, viscosity, density).
c. Change of chemistry.
d. Clamp-on of the sensor to a new tubing.
e. Change of the hydraulic circuit.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
13
3.5 Instructions for Tube Mounting
1. Attention:
The LFSC-iX flowmeters are calibrated for
multiple tubing types and liquid temperatures.
Please check the default factory setting on the
article label. To switch to another calibration set
the Levitronix® Service Software or the user
panel LUI-B.1-02 can be used (see user
manual).
2. For a proper and accurate flow measurement it
is very important that the ultrasonic beam is not
disturbed by particles, dust and air in the
measurement path, which would result in
reflections and lead to a wrong flow
measurement. Specifically, it must be assured
that in the clamp-area between tubing and
sensor no particle or dust is squeezed in during
the clamp-on process.
3. Therefore, check the cleanliness of the surface
area where the ultrasonic beam leaves the
sensor and if necessary clean it with alcohol.
CAUTION
Do not use aggressive cleaning agents, which could
attack the sensor surface and its parts. Alcohol has
been tested and approved as an adequate cleaning
agent.
4. Check the tubing surface area, which is clamped
into the sensor, for cleanliness and inertness.
Assure that no particle or dust is present. Clean
the tube with alcohol or an adequate cleaning
agent specified by the tubing manufacturer.
5. Properly align the tubing with the clamp area of
the sensor and avoid bending or squeezing the
clamp area.
Type Label
Default calibration setting.
Attention
label can be
removed
here.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
14
6. Fit the clamp hinge into the according sensor
body grove and close the clamp.
CAUTION
Take care to not squeeze the fingers during the clamp-
on process.
CAUTION
Assure that the tube is not squeezed and not axially
stretched during the clamp-on process.
7. For a stable and repeatable measurement, it is
very important that the tube is properly clamped
into the square shape of the transducer area of
the sensor. Therefore, check that the sensor is
properly fitted into the square area and that the
tubing is not squeezed somewhere.
1. After starting measurements with the system
with liquid temperature different from ambient,
or if the liquid temperature changes during
operation, full signal stability is reached after
about 30 min.
Do not squeeze the tube
during the clamp-on
procedure!
A squeezed tube affects
flow measurement!

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
15
4 Operation
4.1 General Timing Specifications
4.1.1 Startup Time
During start-up (after power-on) the flow measurement is not performed. Start-up time is about 8 seconds.
4.1.2 Thermal Stability Time
To guarantee specified accuracy thermal stability of sensor must be reached. Therefore, it is recommended to
wait 30 minutes after power-on to get stable flow measurements.
4.1.3 Zero Adjustment
The duration to perform a zero adjustment is < 30 seconds. Following options are available for zeroing:
1. Activating by Levitronix®Service Software.
2. Activating by the user panel in the system menu functions.
3. Activation by digital input (default configuration).
4.2 Standalone Operation with User Panel
Only the basic functions of the user panel are described here. For more detailed description consult the
standard firmware specification of the LUI-B.1-02.
4.2.1 Basic Operation
With the user panel LUI-B.1 the flowmeter can be operated and monitored manually according to Figure 11..
After power on the display shows the actual flow. By pressing the Up or Down button the actual calibration set
can be viewed. By pressing the Up or Down button again the user returns to the flow monitoring display.
Act. Flow [ml/min]
1000
Figure 11: User panel for manual operation
4.2.2 System Menu Functions
By pressing the On/Off button for more than 2 seconds the System Menu can be reached with the following
basic functions:
SETTINGS
ZERO ADJUSTMENT
INFO
1
a. Monitor the flow.
b. Selection of calibration set.
c. Volume counter.
2
a. Zero adjustment of flow meter.
3
a. Flow and full scale.
b. Serial number and sensor size.
c. Firmware and hardware revision.
d. Status.
Figure 12: System Menu and its basic functions
In the System Menu and its sub menus, the menu tabs are browsed using the Up and Down buttons. Items
are selected with the On/Off button, and values are modified using the Up and Down buttons. The Menu can
be left by pressing the On/Off button for more than 2 seconds.
SENSOR-TYPE
LFSC-i06X
CFlex, 37°C
Menu
Down
Display
Actual Calibration
Set
Up

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
16
4.3 Operation with PLC Interface
4.3.1 Operational Specifications
Table 5 specifies the electrical interface for OEM operation with a PLC. For other configurations the Levitronix®
Service Software shall be used.
4.3.2 Typical Setups Using the PLC Interface
Figure 9 and Figure 10 illustrate typical electrical setups how to connect signals to the flowmeter.
4.4 Operation with Levitronix®Service Software
For debugging, data collection and configuration of the flowmeter system the Levitronix®Service Software is
available at Levitronix®. Contact Levitronix®for a sample of the service software and the according manual.
The standard components for this type of operation are shown in Figure 4.
4.5 Operation with RS485
Operation from a mother system with communication over an RS485 bus is possible. The according MODBUS
protocol can be requested at Levitronix

.
4.6 Measurement of Dynamic Flow Profiles
Measuring dynamic flow profiles, which are for example typically generated by roller or other displacement
pumps, may influence the accuracy of the flow reading. Following converter settings (different from the default
parameters in Table 4) are recommended to improve the measurement accuracy under highly dynamic flow
conditions:
Parameter
Setting or Value
Note
Low Cutoff
0%
Avoid cutting-off low flow spikes (for example from
roller pumps).
Damping Time
0.2 –0.5 s (seconds)
Reduces the filter frequency and allows more
dynamic flow readings.
Table 6: Recommended parameter settings for measurements of highly dynamic flow profiles
The settings can be done with the LevitronixService Software (see relevant manual).
5 Inspection and Maintenance
The LEVIFLOW®ultrasonic flowmeters do not require special maintenance since there are no moving parts
that can be subjected to wear and tear. However, the following periodical checks are recommended to ensure
smooth and reliable operation:
1. Check for excessive mechanical stress onto the tubing clamped on the flowmeter body for example caused by
bended tubing.
2. Inspect for loosen connections caused by excessive vibrations.
3. Inspect the sensor visually for any deposits, excessive bubbles or foreign materials in the measuring tube.
4. When using the tubing multiple times it is recommended to change the clamp-area on the tubing in order to
account for creeping effects in the clamp-area.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
17
6 Troubleshooting
6.1 Common Troubles
#
Phenomenon
Possible Cause
Countermeasure
1
Incorrect flow measurement
after zeroing.
Non ideal situation during zeroing.
Check if the circuit is filled with liquid and the flow is really
zero, and conduct zero adjustment again
2
Incorrect flow measurement.
Incorrect signal received from
measurement in the sensor.
- Check if measuring tube is filled with liquid
- Check if there is something in the measuring path
disturbing the ultrasonic wave (bubbles, solid substances)
- Check if excessive noise is generated in the vicinity of the
sensor (devices like motors, high voltage cables etc)
- Check if cables are connected correctly and not damaged.
- Check if calibration set has been selected
3
Zero flow is indicated at flow
level below cut-off value.
Standard cut-off value as shown in
Table 4 is not adequate for application.
- Adapt lower cut-off value with Levitronix®Service Software
4
The flow indication does not
match the real flow
Wrong parameter settings, excessive
bubbles or solids in the measurement
path.
- Check if the parameters in the converter are set correctly
- Inspect the flow path for stagnating solids
- Inspect the measurement path for excessive bubbles
5
Above full scale flow is
indicated or the flow signal is
unstable
Wrong parameter settings, excessive
bubbles or solids in the measurement
path.
- Check if the parameters in the converter are set correctly
- Inspect the flow path for stagnating solids
- Inspect the measurement path for excessive bubbles
Table 7: Potential common troubles and the possible countermeasures
6.2 Troubleshooting with Messages on Flowmeter LED
#
LED Status
Possible Cause
Countermeasure
1
Yellow/Red blinking at 1 Hz
Non resolvable error detected e.g.
bootloader is active, primary image
defect, …
Power on/off or reset via Interface or try to download
correct firmware with Levitronix®Service Software, if
still occurs replace sensor.
2
Yellow blinking at 0.5 Hz
Error, measurement off
Power on/off or reset via Interface, if still occurs
replace sensor.
3
Red blinking at 0.5 Hz
Error, signal amplitude is out of range.
Measurement may be out of
specifications.
Assure better coupling of tube, check clamping
according 3.4
4
Yellow permanent
Signal amplitude is critical (at the limit)
but measurement are correct.
Assure better coupling of tube to avoid future wrong
measurements.
5
Green permanent
Correct flow measurement.
No countermeasures necessary.
Table 8: LED messages on flowmeter and the possible countermeasures
6.3 Troubleshooting with Levitronix®Service Software
For debugging, data collection and configuration of the flowmeter system the Levitronix®Service Software is
available at Levitronix®. Contact Levitronix®for a sample of the service software and the according manual.
The setup and components to work with a PC and Levitronix®Service Software is shown in Figure 4.
7 Technical Support
For troubleshooting, support and detailed technical information contact Levitronix

Technical Service
Department:
Levitronix

Technical Service Department
Technoparkstr. 1
CH-8005 Zurich, Switzerland
Phone for US: 888-569 07 18
Phone for outside US: [phone]
E-Mail: [email protected]

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
18
8 Appendix
8.1 Regulatory Status
8.1.1 CE Marking
The LEVIFLOW®clamp-on flowmeters of the LFSC-iX series, in its various configurations, is in conformity with
the below mentioned European Directives. The flowmeter system is thought to be used in hydraulic circuits of
production equipment of Bioprocessing and Pharmaceutical industry.
Part Name
Description
LFSC-ixxX
xx = Size
Flowmeters: LFSC-i06X (0 - 1 lpm, rated for 6.5 bar without tubing limitation)
LFSC-i10X (0 - 4 lpm, rated for 6.5 bar without tubing limitation)
LFSC-i16X (0 - 20 lpm, rated for 6.5 bar without tubing limitation)
LFSC-i19X (0 - 50 lpm, rated for 5 bar without tubing limitation)
LFSC-i25X (0 - 80 lpm, rated for 5 bar without tubing limitation)
LFSC-i35X (0 - 160 lpm, rated for 5 bar without tubing limitation)
Note: All flowmeters with 24V DC supply input.
EMC Directive 2014/30/EC:
The following standards of the EMC directive are tested and confirmed at a certified laboratory:
EN61000-6-2
Generic standards, Immunity for industrial environments
EN61000-6-4
Generic standards, Emission standard for industrial environments
Machinery Directive 2006/42/EC:
The machinery directive essentially has been followed by a risk analysis, according mitigation actions and a
user manual for safe operation. For the design and testing the following standards are used as a guideline:
EN ISO 15494
Plastic piping system for industrial applications
ISO12100
Safety for machinery –principles for risk assessments: used for system risk analysis.
Pressure Equipment Directive 97/23/EC:
The pressure equipment directive is used as guideline according to Category I Modul A (internal quality
control). For maximum pressure validation the following standard is followed:
EN ISO 15494
Plastic piping system for industrial applications
It must be noted that the maximum pressure for the clamp-on sensor has been tested without tubing limitations.
For the pressure rating of the clamp-on sensor with the mounted tubing, the specification of the used flexible
tubing material must be consulted in order to avoid bursting effects not covered by the clamp-on sensor
specifications.
8.1.2 Disposal of Equipment –WEEE Directive 2012/19/EU
Follow local legislation for disposal of equipment. In the European Union (EU) marked ( ) devices are governed by the
European WEEE Directive 2012/19/EU. Do not dispose with normal waste.

User Manual for LEVIFLOW®LFSC-iX Flowmeters
www.levitronix.com
PL-5001-00, Rev00, DCO# 21-084
19
8.2 Symbols and Signal Words
Symbol /
Signal Word
Description
Type
Source
DANGER
Indication of an imminently hazardous situation that, if
not avoided, will result in death or severe injury.
Limited to the most extreme situation
Signal word
SEMI S1-0701
WARNING
Indication of a potentially hazardous situation which, if
not avoided, could result in death or severe injury.
Signal word
SEMI S1-0701
CAUTION
Indication of potentially hazardous situations which, if
not avoided, could result in moderate or minor injury.
Also alert against unsafe practice.
Without safety alert indication of hazardous situation
which, if not avoided, could result in property damage.
Signal word
SEMI S1-0701
!
Safety alert for “Warning” and “Caution”
Safety alert
SEMI S1-0701
!
Safety alert for “Danger”
Safety alert
SEMI S1-0701
Caution (refer to accompanying documents)
(is used on article labels for reference to manual)
Refer to manual
ISO 3864
Toxic material, poison
Hazard identification
IEC 61310
Corrosive material, corrosion
Hazard identification
IEC 61310
Cut/sever hand, sharp object
Hazard identification
ANSI Z535.3
Strong magnetic field
Hazard identification
SEMI S1-0701
Danger: electricity, electrical hazard
Hazard identification
IEC 61310,
ISO 3864
Wear safety gloves
Hazard avoidance
Mandatory action
IEC 61310
Wear face shield
Hazard avoidance
Mandatory action
SEMI S1-0701
No pacemakers
Hazard avoidance
Prohibition
SEMI S1-0701
Table 9: Safety symbols and signal words
