Lexicon Lambda User manual

Owner’s Manual
COMPLETE RECORDING SOLUTION

WARRANTY
1. Please register your product online at lexiconpro.com. Proof-of-purchase is considered to be
the responsibility of the consumer. A copy of the original purchase receipt must be provided
for any warranty service.
2. Lexicon Professional warrants this product, when purchased new from an authorized
U.S. Lexicon Professional dealer and used solely within the U.S., to be free from defects in
materials and workmanship under normal use and service. This warranty is valid to the
original purchaser only and is non-transferable.
3. Lexicon Professional's liability under this warranty is limited to repairing or, at our
discretion, replacing defective materials that show evidence of defect, provided the product
is returned to Lexicon Professional WITH RETURN AUTHORIZATION from the factory, where
all parts and labor will be covered up to a period of 1 year. A Return Authorization Number
must first be obtained from Lexicon Professional. The company shall not be liable for any
consequential damage as a result of the product’s use in any circuit or assembly.
4. Lexicon Professional reserves the right to make changes in design or make additions to
or improvements upon this product without incurring any obligation to install the same
additions or improvements on products previously manufactured.
5. The foregoing is in lieu of all other warranties, expressed or implied, and Lexicon
Professional neither assumes nor authorizes any person to assume on its behalf any
obligation or liability in connection with the sale of this product. In no event shall Lexicon
Professional or its dealers be liable for special or consequential damages or from any delay
in the performance of this warranty due to causes beyond their control.
TECHNICAL SUPPORT & SERVICE
If you require technical support, contact Lexicon Professional Technical Support. Be prepared
to accurately describe the problem. Know the serial number of your device – this is printed on a
sticker attached to the chassis.
Before you return a product to the factory for service, we recommend you refer to this manual.
Make sure you have correctly followed installation steps and operating procedures. For further
technical assistance or service, please contact our Technical Support Department at (801) 566-
8800 or visit lexiconpro.com. If you need to return a product to the factory for service, you MUST
first contact Technical Support to obtain a Return Authorization Number.
NO RETURNED PRODUCTS WILL BE ACCEPTED AT THE FACTORY WITHOUT A RETURN
AUTHORIZATION NUMBER.
Please refer to the Warranty information, which extends to the first end-user. After expiration of
the warranty, a reasonable charge will be made for parts, labor, and packing if you choose to
use the factory service facility. In all cases, you are responsible for transportation charges to the
factory. If the product is still under warranty, Lexicon Professional will pay the return shipping.
Use the original packing material if it is available. Mark the package with the name of the shipper
and with these words in red: DELICATE INSTRUMENT, FRAGILE! Insure the package properly.
Ship prepaid, not collect. Do not ship parcel post.
Warranty/Technical Support/Service

Table of Contents
INTRODUCTION ....................................1
FEATURES .............................................1
UNPACKING THE LAMBDA STUDIO .......2
COMPUTER MINIMUM REQUIREMENTS ..2
THE FRONT PANEL ................................3
Mic 1-2 Gain..................................................................3
Line 1-2 Gain.................................................................3
Peak LEDs ......................................................................3
Monitor Assign...............................................................3
Monitor Mix Control......................................................4
Output Level...................................................................4
Input Bargraph Meter....................................................4
USB LED.........................................................................4
+48V Phantom Power LED...........................................4
1⁄8" Headphone Output Jack...........................................4
¼" Instrument Input Jack.............................................4
THE REAR PANEL ..................................5
Line In 1-2 .....................................................................5
Insert 1-2 .......................................................................5
Mic 1-2 Inputs................................................................5
Left/Right Line Outputs.................................................5
MIDI In And Out ...........................................................5
+48V Phantom Power Switch.......................................6
USB Port ........................................................................6
CONNECTING TO THE LAMBDA STUDIO 7
Monitoring Connections..................................7
Connecting Headphones................................................7
Connecting To Monitor Speakers..................................7
Connecting To A Home Stereo.......................................7
Recording Connections ...................................8
Connecting A Microphone.............................................8
Connecting A Line-Level Source....................................8
Connecting An Instrument............................................8
Mixdown Connections ....................................9
Connecting To An External Recorder............................9
Mixing Within Cubase®LE...........................................9
Connection Diagram.......................................10
SOFTWARE SETUP .................................11
Windows®......................................................................11
Mac®.............................................................................11
USING THE LAMBDA STUDIO ................12
Recording With The Lambda Studio ................12
A. Recording Using The Mic or Line Inputs .................12
B. Recording A Guitar Using The Instrument Input....13
C. Recording Midi..........................................................14
D. Recording With Cubase LE.......................................15
E. Setting Monitor Levels...............................................23
F. Using Software Input Monitoring..............................24
Adjusting The Buffer Settings ..........................26
Adjusting The Buffers In Windows................................26
Adjusting The Buffers In Mac OS X ..............................27
SPECIFICATIONS ...................................28
SIGNAL ROUTING DIAGRAM.................29
TABLE OF CONTENTS

1
INTRODUCTION
Congratulations on your purchase of the Lexicon®Lambda Desktop Recording
Studio™.
The Lexicon Lambda Studio is a complete package of hardware and software that turns
your USB-equipped computer into a professional multitrack recording workstation.
Whether you use it for high-quality stereo location recording with a laptop computer,
or for multitrack overdubbing and mixing in a home studio desktop system with MIDI
synthesizers, the Lambda Studio hardware provides the professional-quality inputs
and outputs, metering, and level controls that computer sound cards or built-in audio
connections lack.
So you can make full use of the Lambda Studio right away, we’ve included the popular
Steinberg®Cubase®LE production suite software for PC and Mac®computers. Cubase
LE offers integrated multitrack audio and MIDI recording, editing, and mixing, VST®
Instrument support, VST plug-in effects support, and an array of additional features.
The included Lexicon reverb plug-in is also a major feature of the Lambda Studio
package, providing the lush Lexicon reverbs that have been used on professional
recordings for over thirty years. Alternatively, the Lexicon Lambda Studio may be used
as an interface with almost any other major audio recording software you may have,
such as Steinberg Cubase®, Ableton™Live, MOTU®Digital Performer®, GarageBand®,
Cakewalk®Sonar™, Logic®, Pro Tools®, and many others.
FEATURES
• 5 analog audio inputs
• 2 - XLR mic inputs with extremely low-noise dbx®preamps, 44 dB gain, and
+48V phantom power (switchable)
• ¼" TRS Insert jack on each mic input
• 2 - ¼" analog RF filtered TRS active-balanced line inputs
• 1 - ¼" ultra-high-impedence analog instrument input
• 2 - ¼" analog TRS active line outputs
• High powered headphone amplifier
• MIDI In and Out
• 24-bit A/D and D/A converters, supporting sample rates of 44.1 kHz and 48 kHz
• Zero-latency analog record monitoring with adjustable balance between Direct
and Playback
• Stereo and Mono input source monitoring
• 100% USB Powered
Introduction

2
UNPACKING THE LAMBDA STUDIO
Thoroughly inspect the Lambda Studio and packing materials for signs of damage.
Report any shipping damage to the carrier that delivered the product or dealer from
whom you purchased the product at once.
COMPUTER MINIMUM REQUIREMENTS
The Lexicon Lambda doesn't require an extremely powerful computer to use. However,
once you start playing multiple tracks, applying processing to these tracks with plug-
ins, and utilizing the other processing features available in your recording software,
more computing resources are required.
Powerful software for audio recording requires a powerful computer with the right
operating system software, processor, memory, and hard drive space. Most computers
currently sold already meet these requirements, or can be upgraded to meet these
requirements. As with all such systems, adding more RAM than the minimum will
allow you to do more processing and improve performance, and more disk space will
give you more storage for your audio files.
For the latest Lambda Studio and included Lexicon reverb plug-in system
requirements, visit http://lexiconpro.com/en-US/products/lambda.
For the latest Steinberg Cubase LE requirements, visit https://www.steinberg.net/en/
products/cubase/specs_downloads.html.
Introduction

3
THE FRONT PANEL
Mic 1 Mic 2
Line 1 Line 2
Monitor
Stereo Mono
Monitor
Peak Peak
Peak Peak
Stereo Mono
Monitor Mix Output Level
Direct Playback
Clip
-6
-20
-40
+48V USB
Instrument
Mic 1-2 Gain
Peak LEDs
Monitor Assign
Line 1 Gain
Monitor Assign
Monitor Mix Control
USB LED
1/4” Instrument Input Jack 1/8” Headphone Output Jack
+48V Phantom Power LED
Output Level
Line 2 Gain
Peak LEDs
Input Bargraph Meter
MIC 1-2 GAIN
These knobs adjust the input gain levels of the Mic 1 and Mic 2 inputs.
LINE 1-2 GAIN
These knobs adjust the input gain levels of the Line 1 and Line 2 inputs.
PEAK LEDS
These LEDs light when the input signal is within 5 dB of analog clipping. If the Peak
LEDs flicker occasionally, the signal is approaching clipping levels, but this does not
necessarily indicate distortion or actual clipping.
MONITOR ASSIGN
These buttons select whether a pair of analog audio sources will be heard in stereo
or mono in the Direct Monitor Mix. In Stereo mode, the left inputs (Mic 1, Line 1)
are routed to the left monitor and right (Mic 2, Line 2) inputs are routed to the right
monitor.
In Mono mode, you’ll hear the selected inputs in the center of the Direct Monitor Mix
through the Headphone or Line outputs.
When a Monitor switch is in Mono, it does not change the signals going to the
computer in any way — they will still be separate and stereo in the computer.
For the cleanest
recording,
adjust the Gain
so the level
reaches at least
-6 on the Input
Bargraph Meter,
but never lights
the Clip LED
on the loudest
sound you’ll be
recording. If you
see the Peak LED
light constantly,
turn the Gain
knob down until
it flashes only
occasionally, on
the loudest part of
the performance.
DO NOT TURN
DOWN A GAIN
CONTROL TO
GET THE RIGHT
MIX IN YOUR
HEADPHONES
OR MONITORS
WHILE
RECORDING. USE
THE Monitor Mix
CONTROL FOR
THIS PURPOSE.
The Front Panel

4
MONITOR MIX CONTROL
The Lambda Studio gives you the ability to hear your analog input signals directly
and immediately while recording, without having to adjust levels in software, and
before the delay caused by digital converters and computer recording latency. This
zero-latency analog monitoring is controlled by the Monitor Mix knob, which you
can use to adjust the blend between the Lambda Studio’s live analog inputs (called
“Direct”) and any sounds coming back from the computer via USB (“Playback”).
To adjust the playback mix coming back from the computer (previous tracks, effect
returns, etc.), use the faders on the Mixer screen of the recording software. To hear only
the live source input signals plugged into the Lambda Studio, turn the Monitor Mix
knob fully left to Direct. To hear only the mix from the computer, turn the Monitor
Mix knob fully right to Playback. The output from the Monitor Mix control is routed
directly to the Line and Headphone outputs. This ability to easily control the relative
levels of computer audio playback and latency-free live analog inputs is very useful
when overdubbing.
OUTPUT LEVEL
This knob controls the overall output level of the Lambda Studio’s Line and Headphone
outputs.
INPUT BARGRAPH METER
This LED Meter shows the signal level going into the A/D converters. When the Input
Bargraph Meter’s Clip LEDs illuminate, input signals are clipping the A/D converter.
Adjust the gain with the Mic and Line knobs so that the -6 dB LED flashes only
occasionally.
USB LED
When the blue USB LED is on, it shows the Lambda Studio is powered and
communicating with your computer via USB, and audio and MIDI signals can pass in
and out of the system.
+48V PHANTOM POWER LED
This LED indicates that 48 volt phantom power is active on the Mic 1 and Mic 2 inputs,
providing phantom power for condenser microphones that require it to operate. Turn
phantom power on or off as needed with the switch labeled +48V on the rear panel.
1⁄8" HEADPHONE OUTPUT JACK
The high-powered Headphone output accommodates stereo headphones with an 1⁄8"
stereo plug.
¼" INSTRUMENT INPUT JACK
This ¼" jack accepts unbalanced, low-level, high-impedance instrument sources such
as electric guitar, acoustic guitar with a pickup, or electric bass. The input gain is
adjusted using the Line 1 knob on the front panel. When an instrument is plugged into
this input, it disables the Line 1 audio input on the rear panel.
The Front Panel

5
THE REAR PANEL
Line In 1-2
Insert 1-2
Mic 1-2 Inputs
Left/Right Line Outputs
MIDI In and Out
USB Port
+48V Phantom Power Switch
Line
In
Insert
+48 V
12
12
Line Out
LR
Mic 1
Mic 2
MIDI
In
Out
Lambda Studio is
a trademark of
Lexicon Pro, Inc.
LINE IN 1-2
These ¼" inputs can accept both balanced (3-conductor TRS) and unbalanced
(2-conductor TS or instrument) audio sources. Each input gain is adjusted
individually using the Line 1-2 gain knobs on the front panel.
INSERT 1-2
Each mic input is equipped with a TRS insert point. Inserts provide a send and
return of the input channel’s signal directly after the mic preamp and before the A/D
converter. You can insert any line-level signal processor (such as a compressor or
equalizer) to pre-process the mic signal before it is recorded, using a standard insert
cable (single TRS plug to two TS plugs). The tip is send and the ring is return.
MIC 1-2 INPUTS
These balanced XLR inputs feature high-quality mic preamps designed specifically for
low-impedance professional microphones. The input gain is adjusted using the Mic
1-2 gain knobs on the front panel respectively, with 44 dB of gain at the maximum
setting.
LEFT/RIGHT LINE OUTPUTS
These outputs support balanced TRS or unbalanced TS ¼" connections. These outputs
can be connected to a mixing board, power amplifier, powered studio monitors,
recorder, or another line-level input.
MIDI IN AND OUT
The MIDI jacks provide MIDI input and MIDI output to and from your computer.
Connect your MIDI keyboards, sound modules, and external controllers here.
The Rear Panel

6
+48V PHANTOM POWER SWITCH
This switch enables the phantom power to the Mic 1 and Mic 2 inputs. Dynamic
microphones do not require phantom power to operate, but are not harmed by it. Most
condenser microphones do require phantom power to operate. If you are unsure about
the phantom power requirements for your microphone, consult your microphone’s
documentation or contact the manufacturer. This switch should be OFF if you are
connecting any line-level source to the Mic In jacks.
USB PORT
The USB Port is used to connect the Lambda Studio to your computer and provides the
Lambda Studio hardware with power. A standard USB cable is included. The Lambda
Studio supports USB 2.0 full speed.
The Rear Panel
IMPORTANT:
To avoid damage,
do not plug a line
output into the Mic
In jacks unless the
+48V switch is
turned off.

7
CONNECTING TO THE LAMBDA STUDIO
The Lambda Studio is both a 4 x 2 x 2 mixer and a USB audio/MIDI interface that can
be used in a variety of audio applications. This section describes how to make basic
connections for the following functionality:
• Monitoring Audio
• Recording Audio
• Connecting a Recorder for Mixdown
MONITORING CONNECTIONS
The Lambda Studio allows you to monitor audio both from the hardware inputs
(Direct) and from the computer (Playback). Use the Monitor Mix control to balance
between the direct audio and playback audio from your computer (For a complete
description of the Monitor Mix control, see "Monitor Mix Control" on page 4).
You can monitor the audio through the 1⁄8" Headphone jack on the front panel,
through studio monitors using the ¼" L/R Line Out jacks on the rear panel, or both.
The output level of both the L/R Line Out jacks and the Headphone jack are controlled
with the Output Level knob above the Headphone jack on the front panel.
The Lambda Studio’s L/R Line Outputs have a nominal output of +4 dBu, and support
both balanced (¼" TRS) or unbalanced (¼" TS) connections.
CONNECTING HEADPHONES
1. Connect headphones to the Headphone jack located on the front panel of the
Lambda Studio. The Headphone jack accepts an 1⁄8" TRS connector.
2. Adjust headphone volume with the Output Level knob.
CONNECTING TO MONITOR SPEAKERS
1. Using ¼" cables (balanced TRS cables are recommended), connect the L/R Line
Out jacks on the rear panel of the Lambda Studio to the appropriate inputs on
your mixer, power amp, or powered speakers.
2. Adjust the Lambda Studio's output volume with the Output Level knob. If using
both headphones and monitor speakers, adjust the level of the external power
amp or speakers using their gain controls after you’ve set the desired level in your
headphones.
CONNECTING TO A HOME STEREO
Connect the Line Out 1-2 jacks on the rear panel of the Lambda Studio to the
appropriate inputs on your stereo, typically the Tape In or Aux In jacks, using a ¼" to
male phono (RCA) connector or adapter. Keep the Output Level knob on the Lambda
Studio low at first, raising it slowly to match the level of other units connected to the
stereo.
Connecting to the Lambda Studio – Monitoring Connections

8
RECORDING CONNECTIONS
Analog audio signals are created by microphones, synthesizers, mixers, and
instruments with magnetic pickups. Of these sources, microphones and magnetic
instrument pickups have the lowest output level, and generally require the most
amplification. Keyboards, preamps, and mixers output “line-level” audio, which varies
with each device between the -10 dBV and +4 dBu standards.
CONNECTING A MICROPHONE
Plug an XLR cable directly from a microphone into the desired Mic input on the
Lambda Studio rear panel.
TO ACTIVATE PHANTOM POWER
If your microphone requires phantom power, first make sure the microphone
is connected, then press the Phantom Power switch (labeled +48V). The +48V
Phantom Power LED on the front panel indicates the phantom power is active. If
your mics don’t need phantom power, it is best to leave it off.
USING THE ANALOG INSERTS
The analog inserts require an insert cable (¼" TRS to 2 x ¼" TS). The signal from
the tip should be routed to the input of your outboard processor and the output of
your processor should be routed to the ring.
T
o Lambda Insert
T
T
T
ip
T
T
Ri
n
g
T
o External Processor Input
T
T
(
tip = send)
From External Processor Output
(
ring = return)
To External Processor Input
(tip = send)
From External Processor Output
(ring = return)
To Lambda Insert
Tip
Ring
External FX Processor
CONNECTING A LINE-LEVEL SOURCE
Plug a ¼" TS (unbalanced) or TRS (balanced) cable directly from the line-level
source into the desired Line In jack on the rear panel of the Lambda Studio. Line-level
sources include keyboards, drum machines, CD and cassette players, and external
microphone preamps and effects. If the line-level source has something other than ¼"
outputs, cable adapters can be used.
NOTE: When using the Line In 1 input, DO NOT plug a cable into the
Instrument input. Inserting a cable into the Instrument input disconnects the
Line In 1 input internally.
CONNECTING AN INSTRUMENT
Plug a standard ¼" TS (instrument) cable directly from the instrument into the
Instrument input jack on the front panel of Lambda Studio. Note that this will disable
the Line In 1 jack on the back panel.
IMPORTANT:
To avoid damage,
do not plug a line
output into the Mic
1-2 jacks unless the
+48V (phantom)
switch is turned OFF.
For the cleanest
recording, adjust
the Gain so the level
reaches at least
-6 on the input
bargraph meter,
but never lights the
“Clip” LED on the
loudest sound you’ll
be recording. If you
see the Peak LED
light constantly, turn
the Gain knob down
until it flashes only
occasionally, on the
loudest part of the
performance.
DO NOT TURN
DOWN A GAIN
CONTROL TO GET
THE RIGHT MIX IN
YOUR HEADPHONES
OR MONITORS
WHILE RECORDING.
USE THE MONITOR
MIX CONTROL FOR
THIS PURPOSE.
Connecting to the Lambda Studio – Recording Connections

9
MIXDOWN CONNECTIONS
After you record and mix your sessions in either Cubase®LE or other recording
software, you may want to mix them down to a DAT, tape recorder, CD recorder, or
other stereo 2-track recording device.
Mixdown Deck
Headphones
CONNECTING TO AN EXTERNAL RECORDER
Connect the Line Out L-R jacks on the back of the Lambda Studio to the left and
right recorder inputs respectively. You may need adapter cables if your mixdown deck
has RCA input jacks. Refer to your recorder's operator's manual for more information
about setting recording levels.
If you are connecting to an analog mixdown deck (such as a tape machine), start with
the Output Level knob on the Lambda Studio at about the 12 o’clock position, and
the recorder’s input level also at or near 12 o’clock. Adjust the Output Level knob on
the Lambda Studio until the meters on your recording deck read consistently between 0
dB to +4 dB, raising the input level control on the recorder if necessary.
If you are connecting to a digital recorder, such as a DAT or CD recorder, set the
input level(s) on the recording device all the way open, to their maximum setting,
and then adjust the Output Level knob on the Lambda Studio until the meters
on your recording deck device consistently peak just below the 0 dBFS (Full Scale)
mark without causing clipping (going over the 0 dBFS mark). As a general rule of
thumb, the loudest peaks in the audio material should peak at around -6 dBFS on the
recorder's input meter(s).
To hear the mix through studio monitor speakers, connect the outputs of the
2-track recording deck to the inputs of the amplifier or powered speakers. Adjust the
monitoring level using the output level of the recording deck or the input level of the
amplifier or powered speakers.
MIXING WITHIN CUBASE®LE
You can mixdown directly within Cubase LE or other recording software, and burn
an audio CD from that mix (provided your computer has a CD-R drive). Consult
the Cubase LE manual or documentation for your recording software for a complete
description of mixing within the software.
Connecting to the Lambda Studio – Mixdown Connections

10
CONNECTION DIAGRAM
Connecting to the Lambda Studio – Connection Diagram

11
SOFTWARE SETUP
WINDOWS®
If you haven’t already installed the Windows USB driver, Cubase LE, and included
Lexicon®reverb plug-in software, please do so before continuing on to the next
section. Consult the Software Installation Guide available at http://lexiconpro.com/
en-US/products/Lambda#documentation to ensure successful installation of these
software programs.
NOTE: You must install the USB driver after you’ve made the connection between
your computer’s USB port and the USB port of the Lambda Studio.
MAC®
If you haven’t already installed the Cubase LE and included Lexicon®reverb plug-
in software, please do so before continuing on to the next section. Consult the
Software Installation Guide available at http://lexiconpro.com/en-US/products/
Lambda#documentation to ensure successful installation of these software programs.
NOTE: A USB device must initialize itself with the host computer to operate
correctly. The Lambda Studio comprises multiple devices (audio and MIDI) and
each of those must be initialized. Some Apple®Macintosh®computers will not
recognize all of these devices if the Lambda Studio is connected to the USB port
before the computer is turned on. The simplest way to avoid problems is to connect
the Lambda Studio to the USB port after the computer is booted.
Software Setup

12
USING THE LAMBDA STUDIO
RECORDING WITH THE LAMBDA STUDIO
A. RECORDING USING THE MIC OR LINE INPUTS
This section explains how to record using the Mic or Line inputs on the back of the
Lambda Studio. The diagram below shows how the Lambda Studio is connected for
this particular application.
Mic In 2Line In 1
Headphones
Microphone
Keyboard
Turn down all of the Lambda Studio's input and output level controls. Plug your
microphone cable into the Mic 2 XLR jack or line-level audio source to the Line 1 ¼"
jack on the back of the Lambda Studio. If the mic requires phantom power, engage the
+48V switch (on the back of the Lambda Studio).
NOTE: Remove phantom powered mics when not in use and turn off the phantom
power switch.
To set the input level for the Mic or Line inputs:
1. If you're recording a mic and the Lambda Studio is connected to studio monitors
in the same room, turn them off to avoid bleed and feedback and use headphones.
2. Set the Output Level knob to the 9 o'clock position.
3. Set the Monitor Mix knob to the 12 o'clock position. Press the corresponding
Monitor Assign button so it is in the Mono position. This will let you hear
output on both sides of your headphones when recording only one microphone or
line-level signal.
Monitor Button
Monitor Mix
Input Louder
Playback Softer
Playback Louder
Input Softer
4. While playing the line-level instrument or speaking/singing into the microphone,
gradually increase the corresponding gain by turning up the Line 1 or Mic
2knob until the Peak LED next to the knob just begins to light occasionally.
Re-adjust the Output Level knob for the desired monitoring level.
5. For instructions on recording in Cubase LE, go to "D. Recording With Cubase
LE" on page 15.
Using the Lambda Studio – Recording with the Lambda Studio

13
B. RECORDING A GUITAR USING THE INSTRUMENT INPUT
This section explains how to record using the ¼" Instrument input jack on the
front panel. The diagram below shows how the Lambda Studio is connected for this
particular application.
Instrument In
L/R Line Outputs
Guitar Powered Speakers
Turn down all of the Lambda Studio's input and output level controls. Plug your
electric, acoustic, or bass guitar into the Instrument input jack on the front of the
Lambda Studio hardware.
The Instrument input uses the same recording channel as the Line 1 input; anything
plugged into the ¼" Line 1 input jack on the back of the Lambda Studio will not be
recorded when a cable is connected to the ¼" Instrument input jack on the front
panel.
NOTE: This jack is intended for electric guitar and bass, or acoustic instrument
pickups, not line-level signals such as the output of keyboards or a direct out from a
guitar amplifier. For those, use the Line 1-2 input jacks on the back of the Lambda
Studio hardware.
To set the input level for the Instrument input:
1. Set the Output Level knob to the 9 o'clock position.
2. Set the Monitor Mix knob to the 12 o'clock position. Press the Monitor Assign
button between the Line 1 and Line 2 knobs so that it is in the Mono position.
This will let you hear the mono guitar signal out of both speakers.
Monitor Mix
Input Louder
Playback Softer
Playback Louder
Input Softer
Monitor Button
3. While playing the guitar, gradually increase the gain by turning up the Line
1 knob until the Peak LED next to the knob just begins to light occasionally.
Re-adjust the Output Level knob for the desired monitoring level.
4. For instructions on recording in Cubase LE, go to "D. Recording With Cubase
LE" on page 15.
Using the Lambda Studio – Recording with the Lambda Studio

14
C. RECORDING MIDI
The Lambda Studio also functions as a MIDI interface. This allows you to record MIDI
data into a MIDI track of Cubase®LE or other MIDI compatible recording software, and
then play that MIDI data back from the computer into a keyboard, sound module, or
virtual instrument. The diagram below shows how the Lambda Studio is connected for
this particular application. In this application, the keyboard will be used for generating
the sounds.
Line
In
Insert
+48 V
1 2
1 2
Line Out
L R
Mic 1
Mic 2
MIDI
In
Out
Lambda Studio is
a trademark of
Lexicon Pro, Inc.
Left Line Out RIght Line Out MIDI Out MIDI In
Connect the MIDI out from the keyboard to the MIDI In on the Lambda Studio. Connect
the MIDI Out from the Lambda Studio hardware to the MIDI in on the keyboard.
To hear your keyboard, you either need to run the line output of the keyboard to one
(mono) or two (stereo) Line inputs on the back of the Lambda Studio.
For instructions on recording in Cubase LE, go to "D. Recording With Cubase LE" on
page 15.
Using the Lambda Studio – Recording with the Lambda Studio

15
D. RECORDING WITH CUBASE LE
To create a new session and prepare Cubase LE to record:
1. Open Cubase LE.
2. To create a new empty recording session, select the Prompt for project location
option. Select More>Empty, then click the Create button.
3. Select the location on the hard drive where you would like to create the new
project; create a new folder if necessary. When done, click the Open button (or
OK button if using Windows).
Using the Lambda Studio – Recording with the Lambda Studio

16
4. Go to the Devices menu and select the Device Setup option.
5. Click on VST Audio System and, if not already selected, select Lambda ASIO
(for Windows) or Lexicon Lambda In/Out (for Mac). Click the Switch button
to select the driver, then click OK. You are now ready to begin recording using
your Lambda Studio and Cubase LE.
Using the Lambda Studio – Recording with the Lambda Studio

17
To create an audio track and assign an audio input:
1. Click the Project menu and select Add Track>Audio.
2. When the Add Audio Track dialog appears, select the Mono configuration,
name the track, then click the Add Track button.
3. Make sure the Inspector window is enabled, located in the upper-left corner of
the screen. The Inspector window is displayed on the left side of the screen.
Using the Lambda Studio – Recording with the Lambda Studio
