Lexmark C925 User manual

Print quality guide
Many print quality problems can be solved by replacing a supply or maintenance item approaching the end of its intended
life. Check the printer control panel for a message about a printer supply.
Isolating print quality problems
Print the print quality test pages to help isolate print quality problems.
1Turn the printer off.
2Load letter- or A4-size paper in the tray or feeder.
3Hold down and 6MNO while turning the printer on.
4Release the buttons when the screen with the progress bar appears.
The printer performs a power-on sequence, and then the Configuration menu appears.
5Touch Print Quality Pages > Print Quality Pages.
The print quality test pages print.
6Touch Back > Exit Config Menu.
Printer is printing blank pages
Try one or more of the following:
MAKE SURE THERE IS NO PACKING MATERIAL LEFT ON THE TONER CARTRIDGE
Remove the toner cartridge and make sure the packing material is properly removed. Reinstall the toner cartridge.
MAKE SURE THE TONER CARTRIDGE IS NOT LOW ON TONER
When 88.xx [color] cartridge low appears, make sure the toner is distributed evenly within the toner cartridge:
1Remove the toner cartridge.
2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.
3Reinsert the toner cartridge.
Note: If print quality does not improve, replace the toner cartridge.
If the problem continues, the printer may need to be serviced. For more information, contact Customer Support.
Print quality guide
Page 1 of 13

Characters have jagged or uneven edges
If you are using downloaded fonts, verify that the fonts are supported by the printer, the host computer, and the software
program.
Colors not aligned properly
ABCDEABCDE
ABCDE
ABCDE
Color has shifted outside of the appropriate area or has been superimposed over another color area. Try one or more of the
following:
PERFORM COLOR ADJUST
From the printer control panel Quality menu, perform Color Adjust.
REINSTALL THE TONER CARTRIDGE
Remove and reinstall the toner cartridge.
ADJUST THE COLOR ALIGNMENT
1Turn the printer off.
2Load letter- or A4-size paper in the tray.
3Hold down and 6MNO while turning the printer on.
4Release the buttons when the screen with the progress bar appears.
The printer performs a power-on sequence, and then the Configuration menu appears.
5Touch Color Alignment > Color Alignment.
The color alignment pages print.
6Touch Color Alignment.
7On the printed alignment pages, find the straightest of the 20 lines beside the letter A.
Print quality guide
Page 2 of 13

8From the printer control panel, touch the left or right arrow to select that number.
9Repeat steps 9 and 10 to align sets B through L.
10 Touch Back > Exit Config Menu.
Note: If necessary, adjust the color alignment again.
Clipped images
Try one or more of the following:
CHECK THE GUIDES
Move the width and length guides in the tray to the correct positions for the paper size loaded.
CHECK THE PAPER SIZE SETTING
Make sure the paper size setting matches the paper loaded in the tray:
1From the printer control panel Paper menu, check the Paper Size setting.
2Before sending the job to print, specify the correct size setting:
•For Windows users, specify the size from Print Properties.
•For Macintosh users, specify the size from the Page Setup dialog.
Fine horizontal lines appear on color pages
You may notice fine, horizontal lines in photographs or pages with a high concentration of color. This can occur when the
printer is in Quiet Mode. To fix this, set Quiet Mode to Off (Image/Photo).
Shadow images appear on prints
ABCDE
ABCDE
ABCDE
ABCDE
ABCDE
ABCDE
CHECK THE PAPER TYPE AND WEIGHT SETTINGS
Make sure the paper type and weight settings match the paper loaded in the tray:
1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.
2Before sending the job to print, specify the correct type setting:
•For Windows users, specify the type from Print Properties.
•For Macintosh users, specify the type from the Print dialog.
Print quality guide
Page 3 of 13

MAKE SURE THE IMAGING UNIT IS NOT DEFECTIVE
Replace the imaging unit.
MAKE SURE THE TONER CARTRIDGE IS NOT LOW ON TONER
When 88.xx [color] cartridge low appears, make sure the toner is distributed evenly within the toner cartridge.
1Remove the toner cartridge.
Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality
of future print jobs.
2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.
3Reinsert the toner cartridge.
Note: If print quality does not improve, replace the toner cartridge.
If the problem continues, the printer may need to be serviced. For more information, contact Customer Support.
Gray background
ABCDE
ABCDE
ABCDE
CHECK THE TONER DARKNESS SETTING
Select a lighter Toner Darkness setting:
•From the printer control panel Quality menu, change the setting.
•For Windows users, change the setting from Print Properties.
•For Macintosh users, change the setting from the Print dialog.
THE TONER CARTRIDGE MAY BE WORN OR DEFECTIVE
Replace the toner cartridge.
Incorrect margins
ABC
DEF
ABC
DEF
Print quality guide
Page 4 of 13

These are possible solutions. Try one or more of the following:
CHECK THE PAPER GUIDES
Move the guides in the tray to the correct positions for the paper size loaded.
CHECK THE PAPER SIZE SETTING
Make sure the paper size setting matches the paper loaded in the tray:
1From the printer control panel Paper menu, check the Paper Size setting.
2Before sending the job to print, specify the correct size setting:
•For Windows users, specify the size from Print Properties.
•For Macintosh users, specify the size from the Page Setup dialog.
Light colored line, white line, or incorrectly colored line appears on prints
ABCDE
ABCDE
ABCDE
ABCDE
ABCDE
Try one or more of the following:
MAKE SURE THERE IS NO DEFECTIVE TONER CARTRIDGE
Replace the defective toner cartridge.
MAKE SURE THE IMAGING UNIT IS NOT DEFECTIVE
Replace the defective imaging unit.
MAKE SURE THE TRANSFER MODULE IS NOT DEFECTIVE
Replace the transfer module.
CLEAN THE PRINTHEAD LENSES
Remove and reinstall the imaging unit. The LED wipe at the end of the imaging unit will rub across the row of LEDs, thus
cleaning the printhead lenses.
Print quality guide
Page 5 of 13

Paper curl
Try one or more of the following:
CHECK THE PAPER TYPE AND WEIGHT SETTINGS
Make sure the paper type and weight settings match the paper loaded in the tray or feeder:
1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.
2Before sending the print job, specify the correct paper type setting:
•For Windows users, specify the paper type from Print Properties.
•For Macintosh users, specify the paper type from the Print dialog.
LOAD PAPER FROM AFRESH PACKAGE
Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it.
Print irregularities
) )
ABCDE
ABCDE
ABCDE
Try one or more of the following:
LOAD PAPER FROM AFRESH PACKAGE
The paper may have absorbed moisture due to high humidity. Store paper in its original wrapper until you use it.
CHECK THE PAPER TYPE AND WEIGHT SETTINGS
Make sure the paper type and weight settings match the paper loaded in the tray or feeder:
1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.
2Before sending the print job, specify the correct paper type setting:
•For Windows users, specify the paper type from Print Properties.
•For Macintosh users, specify the paper type from the Print dialog.
AVOID TEXTURED PAPER WITH ROUGH FINISHES
MAKE SURE THERE IS NO DEFECTIVE TONER CARTRIDGE
Replace the worn or defective toner cartridge.
Print quality guide
Page 6 of 13

MAKE SURE THE TRANSFER MODULE IS NOT DEFECTIVE
Replace the defective transfer module. For more information, see the instruction sheet that came with the replacement part.
MAKE SURE THE FUSER IS NOT DEFECTIVE
Replace the defective fuser. For more information, see the instruction sheet that came with the replacement part.
Repeating defects appear on a page
Cause Solution
) )
)
)
)
If marks occur repeatedly in only one color and multiple times on a page:
The transfer module is defective. Replace the transfer module if the defects occur every:
•38 mm (1.50 in.)
An imaging unit is defective. Replace the imaging unit if the defects occur every:
•41.0 mm (1.61 in.)
•75.0 mm (2.95 in.)
If marks occur down the page repeatedly in all colors:
The fuser is defective. Replace the fuser if the defects occur every:
•141 mm (5.55 in.)
Skewed print
These are possible solutions. Try one or more of the following:
CHECK THE PAPER GUIDES
Move the length and width guides in the tray to the correct positions for the paper size loaded.
•Make sure the guides are not too far from the paper stack.
•Make sure the guides are not pressing too lightly against the paper stack.
CHECK THE PAPER
Make sure you are using paper that meets the printer specifications.
Print quality guide
Page 7 of 13

Solid color pages
Try one or more of the following:
MAKE SURE THE IMAGING UNIT IS INSTALLED CORRECTLY AND IS NOT DEFECTIVE
Remove and then reinstall the imaging unit. If the problem continues, the imaging unit may need to be replaced.
MAKE SURE THE TONER CARTRIDGES ARE INSTALLED CORRECTLY, ARE NOT DEFECTIVE AND
NOT LOW ON TONER
•Remove and reinstall the toner cartridges.
•Make sure toner is distributed evenly within the toner cartridge:
1Remove the toner cartridge.
Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print
quality of future print jobs.
2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.
3Reinsert the toner cartridge.
Note: If print quality does not improve, replace the toner cartridge.
•If the problem continues, the printer may need to be serviced. For more information, contact customer support.
Streaked horizontal lines appear on prints
ABCDE
ABCDE
ABCDE
Try one or more of the following:
SELECT ANOTHER TRAY OR FEEDER
•From the printer control panel Paper Menu, select Default Source.
•For Windows users, select the paper source from Print Properties.
•For Macintosh users, select the paper source from the Print dialog and pop-up menus.
Print quality guide
Page 8 of 13

MAKE SURE THERE IS NO WORN, DEFECTIVE, OR EMPTY TONER CARTRIDGE
Replace the worn, defective, or empty toner cartridge.
CLEAR THE PAPER PATH AROUND THE TONER CARTRIDGE
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching.
Clear any paper you see or clean any visible toner from the paper path. If the problem persists, then contact Customer Support.
Streaked vertical lines appear on prints
ABCDE
ABCDE
ABCDE
Try one or more of the following:
SELECT ANOTHER TRAY OR FEEDER
•From the printer control panel Paper menu, select Default Source
•For Windows users, select the paper source from Print Properties.
•For Macintosh users, select the paper source from the Print dialog and pop-up menus.
MAKE SURE THERE IS NO WORN, DEFECTIVE, OR EMPTY TONER CARTRIDGE
Replace the worn, defective, or empty toner cartridge.
CLEAR THE PAPER PATH AROUND THE TONER CARTRIDGE
Check the paper path around the toner cartridge.
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component,
allow the surface to cool before touching.
Clear any paper you see.
MAKE SURE THERE IS NO TONER IN THE PAPER PATH
Print quality guide
Page 9 of 13

Uneven print density
ABCDE
ABCDE
ABCDE
Try one or more of the following:
MAKE SURE THERE IS NO DEFECTIVE OR WORN TONER CARTRIDGE
Replace the worn or defective toner cartridge.
MAKE SURE THE IMAGING UNIT IS NOT DEFECTIVE
Replace the defective imaging unit.
Print is too dark
Try one or more of the following:
CHECK THE DARKNESS, BRIGHTNESS, AND CONTRAST SETTINGS
The Toner Darkness setting may be too dark, the Brightness setting may be too dark, or the Contrast setting may be too high.
•Change these settings from the printer control panel Quality menu.
•For Windows users, change these settings from Print Properties.
•For Macintosh users:
1Choose File > Print.
2From the Orientation pictures drop-down menu, choose Printer Features.
3Choose a lower value for the Toner Darkness, Brightness, and Contrast settings.
LOAD PAPER FROM AFRESH PACKAGE
The paper may have absorbed moisture due to high humidity. Store paper in its original wrapper until you use it.
Print quality guide
Page 10 of 13
