Lexmark Color Jetprinter Z13 User manual

www.lexmark.com
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33 LexmarkTM Z13 Color JetprinterTM
Lexmark Z23 Color Jetprinter
Lexmark Z33 Color Jetprinter
User’s Guide for Mac OS 8.6 to 9.1
Use this User’s Guide when you have questions about your using printer.
Navigating
•Click the categories in the left pane to navigate through the pages.
•Click the blue text to link to other parts of this User’s Guide.
•Click the arrows at the bottom of the screen to move forward and backward through
the pages.
Searching
1From the Acrobat Edit menu, choose Find.
2In the Find What: box, type the word or phrase you want to search.
3Click Find.
Printing
From the Acrobat File menu:
1Choose Page Setup, select the Landscape orientation button, and then click OK.
2Choose Print, specify the pages you want to print, and then click Print.

www.lexmark.com
2Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
This section contains information about the printer software and hardware and how they work
together.
•Understanding the printer software
•Understanding the printer parts

www.lexmark.com
3Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Understanding the printer software
Your printer software includes the:
•Page Setup dialog box
•Print dialog box
•Control Panel
When you installed the printer software, the Page Setup and Print dialog boxes were set to
the default settings. To print a typical document on plain paper, use these default settings:
•Print Quality: Normal
•Paper Type: Plain
•Paper Size: A4 or U.S. Letter
•Orientation: Portrait
To customize the settings for your document, use the Page Setup and Print dialog boxes. For
more information on which settings to select for your document, see Printing ideas.

www.lexmark.com
4Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Page Setup dialog box
While your document is open, use the Page Setup dialog box to select settings such as paper
size and orientation.
To customize the settings in the Page Setup dialog box:
1From the File menu of your software application, choose Page Setup.

www.lexmark.com
5Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
2Change the settings as needed.
•Click OK to apply the settings and close the Page Setup dialog box.
•If you want more information about the settings in the Page Setup dialog box, click
Help to view the printer software Help. When you are finished, click Done.
From the pop-up
menu in the upper
left, choose: Select: When you want to:
General Paper Size Choose a paper size.
Scaling Change the scaling value of the document. Valid values
are between 25% and 400%.
Orientation Choose between portrait and landscape.
Watermark Watermarks Choose a watermark design.

www.lexmark.com
6Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Print dialog box
While your document is open, you can use the Print dialog box to select settings that affect
the appearance of your document.
To customize the settings in the Print dialog box:
1From the File menu of your software application, choose Print.

www.lexmark.com
7Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
2Change the settings as needed.
From the pop-
up menu in the
upper left,
choose: Select: When you want to:
General Copies Specify the number of copies to print.
Pages Print all of the pages in a document or print a given range of
pages.
Print Last
Page First Print the pages in reverse order so the first page of your document is on top of the stack in the paper exit tray.
Wait for
pages to dry Add more time between pages as they exit the printer. Select this option when you want to keep documents from smearing.
Paper Type/
Quality Paper Type Specify the type of paper you’ve loaded into the printer. Select Plain, Coated, Transparency, Iron-On Transfer, or Glossy/Photo
Paper.
Print Quality Select Quick Print, Normal, Better, or Best.
Normal print quality is recommended for most documents.
Higher print quality settings result in better quality documents,
but take longer to print.

www.lexmark.com
8Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Color ColorSync
Color
Matching
Select a printer profile to match the color on the screen to the
color in the document.
Built-inColor
Matching Let the printer software match the color on the screen to the color in the document.
Background
Printing Print in: Foreground Print when there are not enough system resources available otherwise.
Note: You will not be able to use your computer while
printing in foreground.
Print in:
Background •Print most documents. Background printing is recommended for all jobs unless a problem occurs.
•Select an exact date and time for the document to print.
•Mark a print job Urgent.
•Put a print job on hold.
Note: You can use your computer while printing in
background.
From the pop-
up menu in the
upper left,
choose: Select: When you want to:

www.lexmark.com
9Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
If you want more information about the settings in the Print dialog box, click Help to
view the printer software Help. When you are finished, click Done.
3Click Print to apply your settings and print your document.

www.lexmark.com
10Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Control Panel
Use the Control Panel to:
•View ink levels.
•Install print cartridges.
•Align the print cartridges.
•Clean the print nozzles.
•Print a test page.
•Order supplies.
•View printer software version and copyright information.

www.lexmark.com
11Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
To open the Control Panel:
1From the Apple menu, choose Control Panels the Control Panel for your printer.
To learn more, click the ?to view the printer software Help. When you’re finished, click
Done.
2Click the Close box in the upper left corner to close the Control Panel.

www.lexmark.com
12Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Understanding the printer parts
The table beginning on the next page describes each part.
Paper guide
Paper exit tray
Paper support
Sheet feeder
USB connector
Power supply
Paper Feed
button and Paper
Feed light
Powerbutton
and Power
light
Front cover

www.lexmark.com
13Printer overview
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Use this: When you want to:
Front cover •Install or change print cartridges.
•Clear paper jams.
Paper exit tray Stack paper after printing.
Paper Feed button •Eject paper from the printer.
•Advance a sheet of paper into the sheet feeder.
Paper Feed light Check the printer status. For more information, see Understanding
error messages and flashing lights.
Paper guide Make sure paper feeds correctly into the printer.
Paper support Keep paper straight in the sheet feeder. Make sure you fully extend the
paper support.
Power button Turn the printer on or off.
Power light Check the printer status. For more information, see Understanding
error messages and flashing lights.
Power supply Supply power to the printer.
Sheet feeder Feed plain or specialty paper automatically. For more information, see
Printing ideas.
USB connector Connect the printer to the computer with a USB cable.

www.lexmark.com
14Basic printing
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Basic printing is as easy as:
Step 1: Load the paper
Step 2: Customize the printer settings
Step 3: Print your document
Note: For help printing on specialty paper (such as photo paper, banner paper,
transparencies, or iron-on transfers), see Printing ideas.

www.lexmark.com
15Basic printing
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Step 1: Load the paper
You can load up to 100 sheets of plain paper at a time, depending on the thickness of the
paper.
1Make sure the paper support is upright and fully extended.
2Place the paper against the right side of the paper support
with the print side facing you.
Note: If loading letter size paper, align the top of the
paper with the top of the paper support.
3Squeeze the release tab and the paper guide together.
Slide the paper guide to the left edge of the paper
For information about specialty paper, see Printing ideas.

www.lexmark.com
16Basic printing
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Step 2: Customize the printer settings
If you are using A4 or letter size paper and you want normal print quality and speed, you don’t
need to adjust the printer settings.
If you are using specialty paper, see Printing ideas to customize your printer settings.
For more information about the different printer settings, see Understanding the printer
software.

www.lexmark.com
17Basic printing
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Step 3: Print your document
After you load the paper and customize the printer settings (if necessary), you are ready to
print:
1From the software application File menu, choose Print.
2Click Print.

www.lexmark.com
18Printing ideas
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Your printer prints more than typical text documents. This section shows you how to get the
most from your printer, taking you step by step to print your customized documents.
•Printing photos
•Printing on premium paper
•Printing cards
•Printing envelopes
•Printing color images in
black and white
•Printing labels
•Printing on custom size
paper
•Printing an iron-on transfer
•Printing transparencies
•Printing your document in
reverse order
•Printing a banner

www.lexmark.com
19Printing ideas
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Printing photos
You can print up to 25 sheets of coated, photo, or glossy paper at a time, depending on the
thickness of the paper. You may want to print your photos on plain paper before loading photo
paper and changing your settings. To print on a photo card, see Printing cards.
Step 1: Load the photo paper
•If your paper came with instructions, read them carefully.
•Make sure the glossy or coated side is facing you.
•Load the photo paper against the right side of the paper
support.
Note: Make sure you do not push the photo paper too
far into the sheet feeder.
•Slide the paper guide to the left side of the photo paper.

www.lexmark.com
20Printing ideas
Printer overview
Basic printing
Printing ideas
Maintenance
Troubleshooting
Notices
Index
Lexmark Z13
Lexmark Z23
Lexmark Z33
Step 2: Customize the printer settings
For help, see Understanding the printer software.
1Choose a paper size and orientation:
aFrom the software application File menu, choose Page Setup.
bFrom the Paper Size pop-up menu, choose the paper size for your photo. To
choose a custom paper size, see Printing on custom size paper.
cChoose Portrait or Landscape orientation.
dClick OK.
2Choose a paper type and print quality:
aFrom the software application File menu, choose Print.
bFrom the pop-up menu in the upper left of the Print dialog box, choose Paper Type/
Quality.
