Printing Guide
Loading trays
CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all trays
closed until needed.
1Pull the tray completely out.
Note: Do not remove trays while a job prints or while Busy appears on the printer display. Doing so may cause a jam.
A4
LTR
EXEC
B5
A5
A6
2Squeeze, and then slide the width guide tab to the correct position for the size of the paper you are loading.
A4
LTR
EXEC
B5
A5
2
1
LTR
LGL
EXEC
A4B5A5
Printing Guide
Page 1 of 5

3Unlock the length guide. Squeeze, and then slide the length guide tab to the correct position for the size of the paper you
are loading.
A4
LTR
EXEC
B5
A5
LTR
LGLA4
EXEC
B5A5A6
2
1
Notes:
•For some paper sizes like letter, legal, and A4, squeeze and slide the length guide tab backward to accommodate their
length.
•When loading legal‑size paper, the length guide extends beyond the base leaving the paper exposed to dust. To
protect the paper from dust, you can purchase a dust cover separately. For more information, contact customer
support.
•If you are loading A6-size paper in the standard tray, then squeeze and then slide the length guide tab toward the
center of the tray to the A6‑size position.
•Make sure the width and length guides are aligned with the paper size indicators on the bottom of the tray.
Printing Guide
Page 2 of 5

A4
LTR
EXEC
B5
A5
LTR
LGLA4
EXEC
B5A5A6
4Flex the sheets back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface.
5Load the paper stack.
Notes:
•Load with the printable side facedown when using recycled or preprinted paper.
•Load prepunched paper with the holes on the top edge toward the front of the tray.
Printing Guide
Page 3 of 5

•Load letterhead facedown, with the top edge of the sheet toward the front of the tray. For two‑sided printing, load
letterhead faceup with the bottom edge of the sheet toward the front of the tray.
•Make sure the paper is below the maximum paper fill indicator located on the side of the width guide.
A4
LTR
EXEC
B5
A5
LTR
LGLA4
EXEC
B5A5A6
6Insert the tray.
7From the printer control panel, set the paper size and type in the Paper menu to match the paper loaded in the tray.
Note: Set the correct paper size and type to avoid paper jams and print quality problems.
Printing Guide
Page 4 of 5

Setting the paper size and type
1From the printer control panel, navigate to:
> Settings > > Paper Menu > > Paper Size/Type >
2Press the up or down arrow button to select the tray or feeder, and then press .
3Press the up or down arrow button to select the paper size, and then press .
4Press the up or down arrow button to select the paper type, and then press to change the settings.
